7700 Multi-Frame Manual

7707RGBR/DVIR DVI and RGB Video/Audio Fiber Receiver

Revision 1.4

TABLE OF CONTENTS

1. OVERVIEW.......................................................................................................................................... 1

2. INSTALLATION................................................................................................................................... 4

2.1. OPTICAL CONNECTIONS......................................................................................................... 4

2.2. SIGNAL CONNECTIONS........................................................................................................... 5

2.3. BNC CONNECTIONS................................................................................................................. 6

2.4. CARE AND HANDLING OF OPTICAL FIBER............................................................................ 6

2.4.1. Safety.............................................................................................................................. 6

2.4.2. Assembly......................................................................................................................... 6

2.4.3. Labeling........................................................................................................................... 6

2.4.4. Handling and Connecting Fibers..................................................................................... 7

3. SPECIFICATIONS............................................................................................................................... 8

3.1. ANALOG VIDEO OUTPUTS....................................................................................................... 8

3.2. DIGITAL VIDEO OUTPUTS........................................................................................................ 8

3.3. DIGITAL VIDEO CONTROL....................................................................................................... 8

3.4. ANALOG AUDIO OUTPUTS (A2 &A2KM VERSIONS)................................................................ 8

3.5. KEYBOARD/MOUSE INPUT/OUTPUT (A2KM VERSIONS)......................................................... 9

3.6. SERIAL PORT (A2KM VERSIONS)............................................................................................... 9

3.7. USB PORT (USB VERSIONS)....................................................................................................... 9

3.8. OPTICAL INPUT......................................................................................................................... 9

3.9. COAXIAL INPUT (- C2, -C2 VERSIONS)....................................................................................... 9

3.10. OPTICAL OUTPUT..................................................................................................................... 9

3.11. COAXIAL OUTPUT (-C2 VERSIONS) ........................................................................................... 9

3.12. ELECTRICAL ........................................................................................................................... 10

3.13. PHYSICAL................................................................................................................................ 10

4. CARD-EDGE MONITORING AND CONTROL ................................................................................. 11

4.1. STATUS INDICATOR LEDS..................................................................................................... 12

7700 Multi-Frame Manual

7707RGBR/DVIR DVI and RGB Video/Audio Fiber Receiver

Revision 1.4

4.2. CARD-EDGE DISPLAY AND CONTROLS .............................................................................. 12

4.2.1. Card-Edge Display Warning Indications........................................................................ 14

4.2.2. Selecting the Output Sync Type (7707RGBR Models Only)......................................... 14

4.2.3. Adjusting the Headphone Jack Volume (A2 & A2KM Versions Only)........................... 14

4.2.4. Adjusting the Output Brightness (7707RGBR Models Only)......................................... 15

4.2.5. Selecting the Output Laser Enable Mode (A2KM Versions Only)................................. 15

4.2.6. Setting the Orientation of the Text on the Card Edge Display....................................... 16

4.2.7. Displaying the Video Resolution and Refresh............................................................... 16

4.2.8. Displaying the Connected Display Type (7707RGBR Models Only)............................. 16

4.2.9. Displaying the Input Video Sync Type (7707RGBR Models Only)................................ 17

4.2.10. Displaying the Input Optical Power ............................................................................... 17

4.2.11. Displaying the Firmware Version................................................................................... 17

5. JUMPER CONTROLS....................................................................................................................... 18

5.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED

BY THE GLOBAL FRAME STATUS ........................................................................................ 18

5.2. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES.............................................. 18

6. VISTALINK

REMOTE MONITORING/CONTROL........................................................................... 19

6.1. WHAT IS VISTALINK

? ........................................................................................................... 19

6.2. VISTALINK

MONITORED PARAMETERS .............................................................................. 19

6.3. VISTALINK

CONTROLLED PARAMETERS ........................................................................... 20

Figures

Figure 1-1: 7707RGBR Block Diagram.................................................................................................................2

Figure 1-2: 7707DVIR Block Diagram...................................................................................................................3

Figure 2-1: 7707RGBR/DVIR Rear Panels...........................................................................................................4

Figure 2-2: Reproduction of Laser Certification and Identification Label..............................................................7

Figure 4-1: Location of Status Indicators and Jumpers ......................................................................................11

Figure 4-2: 7707RGBR/DVIR Card Edge Menu Flow Cart.................................................................................13

Tables

Table 1-1: Typical Application Configurations.......................................................................................................2

Table 4-1: LED Functionality...............................................................................................................................11

Table 6-1: VistaLINK

Monitored Parameters.....................................................................................................19

Table 6-2: VistaLINK

Controlled Parameters....................................................................................................20

7700 Multi-Frame Manual

7707RGBR/DVIR DVI and RGB Video/Audio Fiber Receiver

Revision 1.4

REVISION HISTORY

REVISION DESCRIPTION DATE

1.0 First Release Nov 04

1.1 Updated safety section and added assembly and labeling sections Aug 05

1.2 Change of 7707RGBR-A2KM-F2 part number to 7707RGBR-A2KM-USB-F2 Sept 05

1.3 Added DVIR; coaxial & G-Link options; other updates & corrections July 06

1.3.1 Added LED functionality table Mar 07

1.3.2 Fixed referencing and typos-1q April 07

1.4 Added 7707RGBR-A2-GC rear plate to Figure 2-1. Added

tables to section 4. Jan 09

Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for

the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of

Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered

by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.

Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty is

granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order confirmation.

Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you encounter an error,

please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in equipment design or

specifications.

7700 Multi-Frame Manual

7707RGBR/DVIR DVI and RGB Video/Audio Fiber Receiver

Revision 1.4

WARNING

Never look directly into an optical fiber. Non-reversible damage to the eye can

occur in a matter of milliseconds.

Do not hook up the 7707RGBR/DVIR DWDM cards directly with a short fiber

optic cable. The 7707RGBR/DVIR DWDM cards produce +7dBm of power

which will damage the receiver if connected directly.

7700 Multi-Frame Manual

7707RGBR/DVIR DVI and RGB Video/Audio Fiber Receiver

Revision 1.4 7707RGBR/DVIR-1

1. OVERVIEW

The 7707RGBR RGB Fiber Receiver extends one digital (DVI) or analog (RGB) video display connection

over a single fiber optic link with display resolutions up to WUXGA (1920 x 1200). The DVI-I connector

combines analog and digital display technologies, promoting optimal compatibility with different display

types. Two optional analog audio outputs are also available, as well as optional serial data, USB,

keyboard, and mouse. These options facilitate complete remote computer control and display, including

the ability to connect USB peripherals. The 7707RGBR is designed to operate with a companion

7707RGBT transmitter.

The 7707DVIR provides the same features listed above, but only accepts a digital (DVI) input.

Instead of fiber optic cable connections, the -C and –C2 versions of the card provide an economical 3.125

Gb/s electrical coaxial link.

The –GF version provides a fiber optic link and the –GC version provides a coaxial link to receive an RGB

or DVI signal from Evertz MVP

or VIP

multi-display products using the G-Link protocol.

Monitoring and control of card status and card parameters are provided locally, at the card-edge, or

remotely via VistaLINK

capability. The 7707RGBR/DIVIR has a wide-band optical input and can accept

any wavelength between 1270nm and1610nm.

Features:

•Digital (DVI) and analog (RGB) display technologies are supported through one interface on the

7707RGBR.

•Available in a variety of fiber optic and coaxial versions

•VESA video resolutions supported up to WUXGA (1920x1200).

•Two optional analog audio channels

•Optional keyboard, mouse and serial

•Optional USB interface

•Optional G-Link support for use with Evertz VIP

and

MVP

multi-display products

•Full 24 bits per pixel color resolution

•Convenient audio monitoring headphone jack with adjustable volume

•Full-bandwidth 3 Gb/s signal transport over fiber – no compression or sub-sampling

•Ideal for use with high resolution LCD, plasma or projection screens

•All configuration settings are controllable through the card-edge user interface, or VistaLINK

•Comprehensive signal and card status monitoring via four-digit card-edge display, or VistaLINK

•Wide-band optical input is compatible with standard, CWDM, or DWDM transmission schemes.

•Compatible with multi-mode and single-mode fiber.

•SC/PC, ST/PC, or FC/PC fiber connector options.

•Fully hot swappable from front of frame.

•VistaLINK

enabled for remote monitoring and control when installed in 7700FR-C frame with

7700FC Frame Controller.

7700 Multi-Frame Manual

7707RGBR/DVIR DVI and RGB Video/Audio Fiber Receiver

7707RGBR/DVIR-2 Revision 1.4

Transmit Side Receive Side

Fiber

Type Optical/Link

Budget Ordering Product Info TX

Power Ordering Product Info RX

Sensitivity Description

Multi-Mode < 500m 7707RGBT13-A2KM-USB-

F2 -7dBm 7707RGBR13-A2KM -

USB-F2 -21dBm 1310nm on Tx and Rx fibers

Single-

Mode 14dB/40km 7707RGBT13-A2KM -

USB-F2 -7dBm 7707RGBR13-A2KM -

USB-F2 -21dBm 1310nm on Tx and Rx fibers

Single-

Mode 17dB/48km* 7707RGBT15-A2KM -W -2dBm 7707RGBR13L-A2KM -W -19dBm 1310nm/1550nm WDM bi-

directional, one fiber

Single-

Mode 17.5dB/70km** 7707RGBTxx-A2KM -

USB-F2 0dBm 7707RGBRyy-A2KM -

USB-F2 -21dBm Different CWDM Wavelengths

for Tx & Rx, with 8Ch CWDM

Mux/Demux**

Single-

Mode 23dB/92km*** 7707RGBTDxxx-A2KM -

USB-F2 +7dBm 7707RGBRDyyy-A2KM -

USB-F2 -21dBm Different DWDM Wavelengths

for Tx & Rx, with 8Ch DWDM

Mux/Demux***

* With >20dB return loss on fiber interfaces Tx Power/Rx Sensitivity are nominal values of ±1dBm

** Assumes 8Ch CWDM Mux/Demux loss of 3.5dB Fiber loss =0.35/0.25dB per km @ 1310nm/1550nm

*** Assumes 8Ch DWDM Mux/Demux loss of 5dB

Table 1-1: Typical Application Configurations

DVI/RGB out

+A2KM-USB version

Optical I/O

(Single fiber

version) TX/RX

Interface

Control / Indication

DEMUX MUX

VistaLINK

2 Stereo Pair

Analog Audio

+A2 version

Keyboard

Mouse

OPTICAL

RECEIVER

OPTICAL

TRANSMITTER

OPTICAL

COMBINER

Optical

Output

Optical

Input

USB

DB-9

+A2KM version

Serial

BNC Coax

Input

(-C, -C2 & -GC

versions)

BNC Coax

Output

(-C2 versions)

Figure 1-1: 7707RGBR Block Diagram

7700 Multi-Frame Manual

7707RGBR/DVIR DVI and RGB Video/Audio Fiber Receiver

Revision 1.4 7707RGBR/DVIR-3

DVI out

+A2KM-USB version

Optical I/O

(Single fiber

version)

TX/RX

Interface

Control / Indication

DEMUX MUX

VistaLINK

2 Stereo Pair

Analog Audio

+A2 version

Keyboard

Mouse

OPTICAL

RECEIVER

OPTICAL

TRANSMITTER

OPTICAL

COMBINER

Optical

Output

Optical

Input

USB

DB-9

+A2KM version

Serial

BNC Coax

Input

(-C, -C2 & -GC

versions)

BNC Coax

Output

(-C2 versions)

Figure 1-2: 7707DVIR Block Diagram

7700 Multi-Frame Manual

7707RGBR/DVIR DVI and RGB Video/Audio Fiber Receiver

7707RGBR/DVIR-4 Revision 1.4

2. INSTALLATION

Each 7707RGBR/DVIR module comes with a companion rear plate that has one DVI-I video connector

and (depending on the options ordered) may also have analog audio terminals, PS2 keyboard and mouse

connectors, a DB9 serial connector, and three type-A USB connectors. In addition, there will be SC/PC

(shown), ST/PC, or FC/PC optical connector(s) and/or a BNC connector for link connections. On

7707RGBR models only, the DVI-I connector supports combined analog and digital video through a single

interface. An industry-standard DB-15 connector adapter may be used for RGB. For information on

mounting the rear plate and inserting the module into the frame, see section 3 of the 7700FR chapter. The

following diagrams show some sample rear plate options for the 7707RGBR and 7707DVIR.

7707DVIR-C

DVI OUT

INPUT

7707DVIR

-A2-C

DVI OUT ANALOG AUDIO OUT

INPUT

7707DVIR-A2KM-USB-F2

DVI OUT 21

Figure 2-1: 7707RGBR/DVIR Rear Panels

2.1. OPTICAL CONNECTIONS

FIBER INPUT: There is one SC/PC (shown), ST/PC or FC/PC female connector for the optical input to

the 7707RGBR/DVIR. This wide band optical input accepts optical wavelengths of

1270nm to 1610nm, accommodating standard or CWDM transmission schemes. This

input is compatible with multimode fiber when connected directly to a companion

7707RGBT/DVIT transmitter. On the 7707RGBR/DVIR-GF versions, this connector will

accept an input signal in the G-Link format for connection to Evertz MVP

multi-display

products.

7700 Multi-Frame Manual

7707RGBR/DVIR DVI and RGB Video/Audio Fiber Receiver

Revision 1.4 7707RGBR/DVIR-5

FIBER OUTPUT (F2 Versions): There is one SC/PC (shown), ST/PC, or FC/PC female connector

when the 7707RGBT/DVIT is equipped with an optical output. The optical output is

available in 1310nm, 1550nm, CWDM (ITU-T G.694.2 compliant) and DWDM (ITU G.694.1

compliant) wavelengths. This connector is compatible with multimode fiber when connected

directly to a companion 7707RGBT/DVIT transmitter.

FIBER I/O (A2KM-W Version Only): There is one SC/PC (shown), ST/PC or FC/PC female

connector with the optical input/output for the 7707RGBT/DVIT15-W version. This

connector should be mated to a companion 7707RGBR13L-W version card using single-

mode fiber optic cable.

All single fiber versions of the 7707RGBR13L-W are designed to work only with single-

mode fiber optic cable.

2.2. SIGNAL CONNECTIONS

VIDEO OUTPUT: The 7707DVIR accommodates display devices with digital DVI connections only.

The 7707RGBR DVI-I connector accommodates analog and digital display technologies,

promoting optimal compatibility with different display types. Display devices with DVI

connectors may be connected directly to this port. A DB-15 RGB connection may also be

accommodated using an industry standard DB-15 to DVI-I adapter such as the Belkin

F2E4162, or appropriately terminated cable assembly such as the Amp 16539332-1.

Note: When making digital DVI connections, Evertz recommends using only high quality

DVI cables, no longer than 6 feet (1.8m).

AUDIO OUTPUTS (A2 & A2KM Versions): The 7707RGBR/DVIR-A2 and 7707RGBR/DVIR-

A2KM modules provide a terminal block for output connections compatible with either

balanced or unbalanced analog audio. Balanced audio signals should be connected to the

positive (+) and negative (-) output terminals. Unbalanced audio signals should be

connected to the positive (+) input terminal, and a jumper connection should be installed

between the negative (-) input terminal and the ground terminal ( ).

KEYBOARD (A2KM Versions): The 7707RGBR/DVIR-A2KM provides a PS2 port for a keyboard

connection. Connect this port to a standard PS2 keyboard.

MOUSE (A2KM Versions): The 7707RGBR/DVIR-A2KM provides a PS2 port for a mouse connection.

Connect this port to a standard PS2 mouse.

SERIAL (A2KM Versions): Female DB9 RS232 serial port with standard PC style layout. This port may

be connected to serial peripherals. This port may also operate in RS422 mode by changing

a user-selectable menu item (see section 4.2.7).

USB PORTS (USB Versions): When equipped with the USB option, the 7707RGBR/DVIR provides

three type-A USB ports. These ports may be used to connect USB peripherals.

7700 Multi-Frame Manual

7707RGBR/DVIR DVI and RGB Video/Audio Fiber Receiver

7707RGBR/DVIR-6 Revision 1.4

2.3. BNC CONNECTIONS

INPUT (-C, -C2, -GC versions): BNC connector for the electrical link input of the 7707RGBR/DVIR.

This signal should be connected to the Tx port of a companion 7707RGBT/DVIT. –GC

versions will accept a G-Link formatted signal for connection to Evertz MVP

multi-display

products.

OUTPUT (-A2KM-C2 versions): BNC connector for the electrical link output of the 7707RGBR/DVIR.

This signal should be connected to the Rx port of a companion 7707RGBT/DVIT. This

connection may be extended using Belden 1694 or equivalent cable.

2.4. CARE AND HANDLING OF OPTICAL FIBER

2.4.1. Safety

CLASS 1 LASER PRODUCT

Background colour: yellow

Triangular band: black

Symbol: black

2.4.2. Assembly

Assembly or repair of the laser sub-module is done only at the Evertz facility and performed only by

qualified Evertz technical personnel.

2.4.3. Labeling

Certification and Identification labels are combined into one label. As there is not enough room on the

product to place the label it is reproduced here in the manuals.

•There is no date of manufacture on this label as it can be traced by bar code label placed on the

Printed circuit board of each Evertz plug-in module

•The Model number is one of: 7707RGBR, 7707RGBR-A2, 7707RGBR13-A2KM- F2,

7707RGBR13-A2KM-USB-F2, 7707RGBR13M-A2KM-W

7707 RGBR xx, (xx = 27, 29, 31, 33, 35, 37, 43, 45, 47, 49, 51, 53, 55, 57, 59, 61)

7707 RGBR Dyyy (Dyyy represents ITU Grid Channel: D200, D210, D220, D230, D240, D250,

D260, D270, D280, D290, D300, D310, D320, D330, D340, D350, D360, D370, D380, D390,

D400, D410, D420, D430, D440, D450, D460, D470, D480, D490, D500, D510, D520, D530,

D540, D550, D570, D580, D590, D600). 7707DVIR part numbers are similar, replacing “RGBR”

with “DVIR”.

Autres manuels pour 7700 Series

127

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels evertz Récepteur

evertz

evertz 7707VR-8-OC48 Manuel utilisateur

evertz

evertz 7706LR Series Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 2407RGBR/DVIR Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7700 MultiFrame Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7707CVR-8 Series Manuel utilisateur

evertz

evertz 7700 MultiFrame Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 2306LR Manuel utilisateur

evertz

evertz 7707AR-A Series Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz MultiFrame 7807LR-2 Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 2408RGBR/DVIR Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7700 MultiFrame Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 2406LR Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

Manuels Récepteur populaires d'autres marques

Garmin

Garmin GA 23 Manuel utilisateur

Aiphone

Aiphone PS-12F Manuel utilisateur

IMES

IMES TCS-01CA-PMI Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE SR Manuel

AMIMON

AMIMON AMN12310 WHDI Manuel utilisateur

Dual

Dual DMCPA79BT Mode d'emploi

Sound Associates

Sound Associates SA652P Manuel utilisateur

Sherwood

Sherwood NewCastle R-772 Manuel utilisateur

Audio

Audio A10-RX Series Manuel utilisateur

AllSee

AllSee PushShare PSRV1.1 Manuel utilisateur

DEMAG

DEMAG DRC-DR D2 Manuel utilisateur

Teleco

Teleco TVRCL868A02 Manuel utilisateur

Bosch

Bosch RF3222E Manuel utilisateur

Kramer

Kramer 631R Manuel utilisateur

Xpress

Xpress xmc10 Manuel utilisateur

JVC

JVC KD-MR1BTS Manuel utilisateur

Omega Engineering

Omega Engineering UWTC-REC3 Manuel utilisateur

e-survey

e-survey E300 Pro Manuel utilisateur
