Everest EBB23 Manuel utilisateur

Owner’s Manual for models:

Back Bar Coolers

24" Deep Back Bar Coolers

24" Deep Galss Door Back Bar Coolers

Glass Door Back Bar Coolers

24" Deep Galss Sliding Door Back Bar Coolers

EBB23, EBB48, EBB59, EBB69, EBB90

EBB48-24, EBB59-24, EBB69-24, EBB90-24

EBB23G, EBB48G, EBB59G, EBB69G, EBB90G

EBB48G-24, EBB59G-24, EBB69G-24, EBB90G-24

EBB48G-SD, EBB59G-SD, EBB69G-SD, EBB90G-SD

www.EVEREST .ref

com

Thank you for choosing EVEREST

A Step Above the Standard

ISO-9001

When installing the unit, be careful that the

electrical cord is not under the unit or

pressed against the wall.

This could cause a

damage to the cord.

time, make sure the unit

is free from all packaging.

Packaging left

on the unit

during

operation may

To prevent electrical shock, please do

not plug or unplug the cord

with wet hands.

WARNING - When using your appliance, always follow basic precautions, including

the following :

Install the unit on a hard

and level surface.

Before cleaning or maintaining the unit,

please unplug it. Do not use any

around the unit.

Please do not store temperature

sensitive items in the unit,

such as medical or

science research

related materials.

If you suspect a refrigerant leak,

unplug the unit and

immediately contact an

authorized service

technician.

Please do not hang or climb

on the unit as this may

cause the unit to fall.

Safety Notices

REFRIGERATION

Safety Notices

not to overload the outlet into which the

unit is plugged into. A dedicated circuit of

To prevent electrical shock and

malfunction, do not spray the

unit with water.

Clean the pronges of the electrical plug

with a soft cloth or brush before plugging

it into an electrical receptacle to prevent a

WARNING - Read and follow all safety notices in this installation guide.

information. Failure to do so may lead to serious injury and /

or damage to the unit.

When it is time to salvage the unit, make

sure to remove the rubber gaskets from

the doors to prevent the risk of children

or animals getting trapped inside the

unit.

REFRIGERATION

To prevent damage to the electrical

components, have the unit plugged indirectly

to its own circuit. EVEREST isnot responsible

forany damage causedby improperelectrical

connections resulting from electrical power

failure, use of extension cords &

surge protectors, and any

voltage drops to the unit.

Caution!

To prevent electrical shock and damage to

the electrical cord, please hold

the plug head

when plugging

and unplugging

the unit.

Do not use the

electrical cord

or plug if they

are damaged

in any way.

To avoid personal injuries

from broken glass,

please do not

place glass items

in the freezer.

After unplugging the unit, please wait at

least 6 minutes

before re-plugging

it in. Failure to do

so could cause

extensive damage

to the compressor.

Avoid installing the

unit where it could

be exposed to

water or

moisture.

If the unit will

not be used for an

extended period of

time, please unplug

it from the outlet.

Please do not attempt to

remove or

repair any

components

unless you are

an authorized

service technician.

The refrigerator compartment temperature

should be set at 33°F~54°F (See page 9).

Setting the

temperature

out of the

recommended

ranges will void

the unit’s warranty.

Do not put your hands under the unit when

moving it. You could be injured by sharp

edges, protruding parts,

crushing, etc.

REFRIGERATION

Installation Guide

Install the unit on a hard and level surface

or the unit could produce undesired noises.

The unit should be atleast 2” away from the

wall.

Indoor Use Only

Outdoor use may cause a decrease in

unit.

Dusty and High Humidity Areas

Dusty environments will cause the

condenser coil to prematurely clog which

will require it to be cleaned more often.

High humidy environments could cause the

unit to rust.

Do not build an enclosure or cabinet

around the unit.

condenser area will cause the compressor to

work harder, which can result in compressor

failure and the unit not being able to

maintain the desired temperature.

Select a location away from other heat

and moisture generating equipment

such as stoves, ovens, dish washers, etc.

High ambient temperatures cause the

compressor to work harder, which can result

in compressor failure and the unit not being

able to maintain the desired temperature.

REFRIGERATION

Maintenance Guide

Shelf Cleaning

Periodically remove the shelves from the unit

and clean them

with mild soap

and warm water.

Door Gasket Cleaning

To preserve the life span of the door gasket,

clean the gasket

with mild soap

and water on

a regular basis.

Do not use the following products when cleaning

Clean the exterior of the product with mild soap and warm water.

Never use steel wool, strong acids, abrasive cleaners or degreasers.

Acidic products and products containing vinegar must

be stored in sealed containers to prevent acid damage

to the interior of the unit and the evaporator coil. (Rust

resulting from the lack of or improper maintenance will

not be covered under warranty.)

Interior Cleaning

Clean the interior surface of the unit with mild soap and warm

water. Do not let water accumulate inside the unit. To prevent

water damage, wipe the interior of the unit with a dry cloth as

needed. Do not use abrasive cleaners, concentrated detergents,

bleaches, cleaning waxes, solvents or polishes to clean the interior

of the unit.

Condenser Coil Cleaning

Poor condensing unit performance is caused by heavy dust

build-up on the condenser coil. The condenser coil should be

condenser with a soft brush or a vacuum with a brush

attachment. The condenser coil should be cleaned in the

REFRIGERATION

Condenser Coil Maintenance

REFRIGERATION

Diagram

EBB-L-001-D1

Diagram

EBB-L-001-D2 Diagram EBB-L-001-D3

Diagram

EBB-L-001-D4

Diagram EBB-L-001-D6

Diagram

EBB-L-001-D5

EBB/EBD Series

Applicable Model Preﬁx: EBB23/EBD1

IMPORTANT: Failure to clean the condenser coil will result in a void of warranty.

Follow these simple steps at least once a month to ensure the proper operation of your Everest product.

1. Always unplug the unit before performing maintenance.

2. Locate the condenser coil at the back of the unit. See diagrams EBB-L-001-D1, EBB-L-001-D2 and EBB-L-

001-D3.

3. Unscrew the back grill completely. See diagrams EBB-L-001-D4 and EBB-L-001-D5.

4. Use any hard bristled brush in a vertical sweeping motion to remove lint, dust and debris from in between

the aluminum ﬁns of the condenser coil. Do not apply heavy pressure so as not to bend the ﬁns*.

5. For grease-coated ﬁns, use any commercial condenser coil cleaner*. Please follow the speciﬁc instructions

on the bottle.

6. Repeat steps 4 to 5 until ﬁns are clear of any blockage from lint, dust or grease.

* Do not use vacuum brush attachments and abrasive, acid-based cleaners or degreasers to avoid damage to the

aluminum ﬁns.

Model Shown: EBB23

Front Right Side

Condenser Coil Maintenance

REFRIGERATION

Diagram EBB-L-001A-D1

Diagram EBB-L-001A-D2

Diagram

EBB-L-001A-D3

EBB/EBD Series

Applicable Model Preﬁx: EBB/EBD

IMPORTANT: Failure to clean the condenser coil will result in a void of warranty.

Follow these simple steps at least once a month to ensure the proper operation of your Everest product.

1. Always unplug the unit before performing maintenance.

2. Locate the condenser coil at the front, left side of the unit. See diagrams EBB-L-001A-D1 and EBB-L-001A-D2.

3. Unscrew the front grill completely. See diagrams EBB-L-001A-D1 and EBB-L-001A-D3.

4. Use any hard bristled brush in a vertical sweeping motion to remove lint, dust and debris from in between

the aluminum ﬁns of the condenser coil. Do not apply heavy pressure so as not to bend the ﬁns*.

5. For grease-coated ﬁns, use any commercial condenser coil cleaner*. Please follow the speciﬁc instructions

on the bottle.

6. Repeat steps 4 to 5 until ﬁns are clear of any blockage from lint, dust or grease.

* Do not use vacuum brush attachments and abrasive, acid-based cleaners or degreasers to avoid damage to the

aluminum ﬁns.

Model Shown: EBB69G

Symptom Possible Solutions

Condensing unit

fails to start

Refrigerated

compartment is too

cold

Sound of water

dripping

Exterior walls are

warm

Condensation on the

interior

Condensation on the

exterior surface

Noisy operation

Cabinet does not

maintain proper

temperature

heat

Trouble Shooting

REFRIGERATION

Please check the following before requesting service.

a. Ensure the electrical cord has been connected.

b. Ensure the unit is turned on.

a. Adjust the temperature control to a warmer

setting.

a. This is the sound of the refrigerant circulating

during the compressor rest period and it is

normal.

a. Heaters have been placed around the door

openingsto prevent condensation buildup.

This is normal.

a. Condensation can occur during hot and

humid

weather with frequent or prolonged door

opening.

This is normal.

b. The doors might not be closed properly. Check door

alignment and gaskets for proper seal.

a. Checkfor loose parts.

b. Checkfor tubing rattle.

c. Checkfora bent fan blade.

d. Checkfor damaged fan motorbearings.

e. Ensure the unit is stable.

f. Ensure the cabinet islevel.

a. Checkthe doorgasketsfor properseal.

b. Checkto see if the temp. control setting is too

high, then adjust asnecessary.

c. Avoid installing the unit next to heat generating

equipment and direct sunlight.

d. Avoid storing hot contents.

e. Ensure the doors are fully closed.

a. Condensation on the exterior surface of the

unit isperfectly normal during periodsof high

humidity.

b. Checkdooralignment and gasketsforproper

seal.

Warning - Never attempt to adjust a shelf when loaded!

Shelves

The unit’s shelves are adjustable so that

the refrigerated compartment can be

The shelf clip pilasters are spaced and

labeled in 1” increments for your

convenience.

To install a shelf, hook the shelf clips into the pilasters by inserting the top part of the clips

To remove a shelf, start by unloading the shelf. Second, remove the shelf itself. Finally,

remove the shelf clips by tilting them up and allowing the bottom of the clip to come out

Shelf Clip

Pilaster

1”

Shelves

REFRIGERATION

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Everest Réfrigérateur

Everest

Everest ETR1 Manuel utilisateur

Everest

Everest EMGR24 Manuel utilisateur

Everest

Everest ESR1 Manuel utilisateur

Everest

Everest EBR1 Manuel utilisateur

Everest

Everest ESPT-1G-1S Manuel utilisateur

Everest

Everest ebd1 Manuel utilisateur

Everest

Everest ESR1 Manuel utilisateur

Everest

Everest ECB36D2 Manuel utilisateur

Everest

Everest EGC37 Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
