Eventide RIPTIDE Manuel utilisateur

QUICK REFERENCE GUIDE

Vibe Speed

Modulation rate

Vibe Intensity

Modulation depth

Swap LED Button

O = Vibe → Drive

On = Drive →Vibe

Drive Level

Drive Tone

Left is dark, Right is bright

50% is neutral

Vibe Mix

For classic Uni-Vibe:

50% for chorus

100% for vibrato

Drive Amount

0% is cleanest

100% is dirtiest

Preset LED Ladder

Drive LED Button

Green/Red = Drive On

O = Drive O

Press to toggle Voicing

Preset Mode: Toggle

Latching/Momentary for

Active/Bypass

Drive Footswitch

On/O for Drive eect

Preset Mode: Load Preset

and Active/Bypass

Vibe Footswitch

On/O for Vibe eect

Press and hold to toggle

Perform and Preset Modes

Vibe LED Button

Green/Red = Vibe On

O = Vibe O

Press to toggle Voicing

Press and hold to save Preset

Alternate Voicings

EXP

Connect Expression Pedal,

Aux Switches or TRS MIDI

(See System Setup)

Outputs 1 & 2

In Mono, both outputs

have the same dry signal

Input

Standard TS (Mono)

or TRS (Stereo)

Power

9VDC center-negative

Mini USB

Software updates and

MIDI over USB

Mono/Stereo Switch

Left = Mono (TS plug)

Right = Stereo (TRS plug)

In Stereo: Tip is OUT1, Ring is OUT2

I/O Level Switch

Left = Guitar (instrument)

Right = Line/Eects Loop

The perfect pairing of tones to surf the slow vibey

waves or drive to pulsing depths.

Drive: a balanced distortion with superb dynamics and

touch sensitivity.

Vibe: a faithful emulation of the classic Uni-Vibe™

by Shin-ei — in stereo!

Press Swap LED Button to change the eect order.

Both Drive and Vibe have an alternate voicing that can

be toggled by pressing the LED Buttons above their

corresponding footswitch. The color of the LED Button

indicates the chosen voicing.

Green Drive is a dynamic, mid range crunch.

Red Drive is a smooth and boosted overdrive.

Green Vibe is the traditional Uni-Vibe.

Red Vibe is a deeper, phasey Vibe.

Two Eects in One

Presets 5 On Board, 127 Via MIDI

The current Preset is indicated on the Preset LED Ladder. When a Preset is modied the Preset LED blinks once.

Perform and Preset Modes

Press and hold Vibe Footswitch to toggle between

Perform and Preset Modes. Preset LEDs will blink twice.

Perform Mode: Footswitches turn Drive and Vibe

eects on and o, and the corresponding LED Buttons

toggle between 2 available voicings (Green or Red).

Preset Mode: Vibe Footswitch selects Preset 1–5, and

Drive Footswitch controls Pedal Active/Bypass.

Catch Up Knob Function

When loading a new Preset, knob positions will not

align with their current parameter values. As a result,

turning a knob will likely cause an audibly abrupt

change. With Catch Up enabled, the sound does not

change until the Knob is moved to the position of the

current value.

See “System Setup” on how to enable Catch Up.

Load Presets

In Presets Mode, to select and load a Preset:

1. Press Vibe Footswitch to select Preset 1–5.

Preset 1 (top LED) to Preset 5 (bottom LED) blinks.

2. Press Drive Footswitch to load the Preset.

LED stops blinking.

Save Preset

To save one of the ve onboard Presets:

1. Press and hold Vibe LED Button. Blinking Ladder LEDs

and LED Buttons indicate you have entered Save Mode.

2. Press Vibe LED Button to select Preset 1–5.

3. Press Drive LED Button to save Preset.

LEDs stop blinking to let you know the Preset is saved.

NOTE: Save Mode times out after a few seconds.

Pressing either Footswitch exits Save Mode.

CC PARAMETER

4 Expression Pedal

9 Tap Rate

Pedal Active/Bypass

Drive On/O

CC PARAMETER

53 Vibe On/O

54 Drive Voicing

Vibe Voicing

Swap Eect Order

CC DRIVE PARAMETER

23 Drive

24 Tone

25 Level

CC VIBE PARAMETER

20 Vibe

21 Speed

22 Intensity

Expression Pedal MIDI Messages

Save Preset

Press and hold the Vibe LED Button to enter Save Mode,

then a MIDI program change message will save a Preset

to the Preset slot of the given value 1–127.

Load Preset

MIDI program change message loads the Preset from

the Preset slot of the given value 1–127. The bottom

two Ladder LEDs will be lit when Presets 6–127 are

selected externally via MIDI.

Morphing from Heel to Toe

Use an Expression Pedal to change any grouping

of Knob Parameters in one smooth gesture. Easily

Program an Expression Pedal by setting end points for

Heel and Toe. Here’s how:

1. Press Exp Pedal fully Heel down.

2. Adjust any combination of Knob Parameters to set

the Heel values.

3. Press Exp Pedal fully Toe down.

4. Adjust any combination of Knob Parameters to set

the Toe values.

5. Save it or lose it. See“Presets.”

Clear Expression Pedal Mappings

To clear the Expression Pedal mappings for all Knob

Parameters, press and hold the Drive Footswitch and,

while holding, press and hold the Drive LED Button

until the Preset Ladder LEDs ash twice.

Knob Parameters

NOTE: To use an Expression Pedal, the EXP Jack must be

set to either [EXP] or [EXP + AUX] in System Setup.

1 2 3 4 165 ...

PRESS

VIBE

BUTTON

PRESS

DRIVE

BUTTON

BUFFER

RELAY

DSP+FX

KILL DRY

PRESS

DRIVE

SWITCH

PRESS

VIBE

SWITCH

PRESS

BUTTON

EXP (Default)

EXP + AUX

TRIPLE AUX

MIDI BOX

MIDI TRS

System Setup

Only applies to Pedal Bypass

Factory Default = BUFFER

EXP+AUX

TIP = Expression Pedal

RING = Tap RATE

TRIPLE AUX

TIP = Increment Preset

RING = Decrement Preset

TIP + RING = Load Preset

Note: Times out after a few seconds

MIDI BOX

Receive and Send MIDI via a MIDI

Converter Box (Tip Active)

MIDI TRS

Receive MIDI directly with a DIN

to TRS or TRS cable

Enter System Setup

To access these Global Settings, apply power while holding Drive Footswitch and Swap LED Button. Top two

Preset LEDs are on when in System Setup. Changes are stored as they are made. Cycle power to exit System Setup.

Set MIDI Channel

Set MIDI Clock

Set Bypass Mode

Catch Up ON/OFF

Set EXP Pedal Jack

Set MIDI Channel: Press Vibe LED Button

Factory Default = OMNI

MIDI Clock disables Aux Tap switch and CC 9

Factory Default = O

Riptide Quick Reference Guide for Firmware v1.0+ Eventide Part#141348 Rev A

Eventide is a registered trademark of Eventide Inc.

Restore Factory Settings: Power on while pressing Drive Footswitch and Drive LED Button

Software Update: Power on while pressing Vibe Footswitch and Vibe LED Button

Downloads for Mac and PC available at eventideaudio.com/riptide
