HARDWARE REFERENCE MANUAL

Helios™Platform

Programmable Edge Controller

Disclaimer

The information in this document is subject to change without notice and should not be construed as a commitment

by any Eurotech company. While reasonable precautions have been taken, Eurotech assumes no responsibility for

any error that may appear in this document.

Trademarks

Helios™and Everyware™ are trademarks of Eurotech Inc.

All other product or service names are the property of their respective owners.

Revision History

Issue no.

PWB

Date

Comments

1 Jul-09 Preliminary release

2 Oct-09 Second preliminary release

A Nov-10 Updates for Rev B carrier boards

For contact details, see page 24.

Contents

110124-3000A 3

Contents

Introduction............................................................................................................................ 4

Block Diagram ........................................................................................................... 4

Features .................................................................................................................... 5

Further Reading......................................................................................................... 6

Handling Your System Safely..................................................................................... 6

Conventions............................................................................................................... 6

Software Support ................................................................................................................... 8

Operating System ...................................................................................................... 8

BIOS.......................................................................................................................... 8

Boot Options .............................................................................................................. 8

Everyware™Software Framework .............................................................................. 8

Hardware Reference.............................................................................................................. 9

Rear Panel................................................................................................................. 9

USB Bay ...................................................................................................................11

Indicators ................................................................................................................. 12

Enclosure................................................................................................................. 13

Configurations ..................................................................................................................... 14

Processor ................................................................................................................ 14

Memory.................................................................................................................... 14

CompactFlash®Card or Secure Digital Card ................................................ 14

On-Board Flash............................................................................................ 14

SATA Drive................................................................................................... 14

USB Disk Drive ............................................................................................ 15

Communications ...................................................................................................... 15

Universal Serial Bus..................................................................................... 15

Serial Port .................................................................................................... 15

Ethernet ....................................................................................................... 15

GPS ............................................................................................................. 15

Multimedia Cards..................................................................................................... 16

Power Supply........................................................................................................... 16

Peripherals .......................................................................................................................... 17

USB Device Support ................................................................................................ 17

System Specification............................................................................................................ 18

Processor ................................................................................................................ 18

Power ...................................................................................................................... 18

Electrical .................................................................................................................. 19

EMI/EMC ................................................................................................................. 20

Environmental.......................................................................................................... 21

Appendix A – Reference Information.................................................................................... 22

Appendix B – System Revision ............................................................................................ 23

Eurotech Worldwide Presence............................................................................................. 24

Helios Platform - Hardware Reference Manual

110124-3000A

Introduction

Helios™is a programmable edge controller that provides a flexible application-ready

hardware platform with enhanced wireless capabilities. It is based on the Catalyst XL

which integrates with a carrier board and supporting peripheral devices. All electronics

are housed in an enclosure. Three USB host ports for wireless devices and additional

storage are accessible in the USB Bay located under the removable cover.

With the Helios platform, you can quickly and easily create an edge controller device,

loaded with your application software that precisely meets your requirements. Several

options are available allowing you to choose the hardware based on your specifications.

Using pre-certified wireless modules in the USB Bay, the Helios platform can be easily

customized for any network. Software support includes Eurotech’s Everyware™Software

Framework offering an easy-to-use, Java-based development environment that

minimizes time to market and allows for easy portability for future expansion.

Block Diagram

The following diagram illustrates the system organization of the Helios platform. Notice

that the data connector on the Catalyst XL has been divided into two sections for this

illustration. Dotted lines indicate configuration options.For information about these

options, see Configurations, page 14.

Catalyst XL

1 x SD/MMC

Intel

Atom

™

Processor

(Z5xx)

IDE/PATA

SDVO

1 x PCIe

HD Audio

Pwr Supply

FSB

LPC Bus

TPM

VBAT (RTC)

Gigabit Ethernet Port

1 x USB2.0

CF Card

SD Card (optional)

V Reg

DDR-2

DRAM

BAT

Embedded

Ctrl

BIOS

I2C Bus

Sys Mgmt I/O

GPIOs

1 x PCIe

GigE

Controller

SMBus

LM75

Temp Monitor

I2C GPIO

Momentary Switch

8 x LED

On-board

PATA flash

LVDS Video

1 x USB2.0

Regulated Power Input

(optional Vehicle Pwr)

Sys Ctrls

Pwr LED

3 x USB2.0

2 x USB2.0

3 x USB2.0 Host Ports

(USB Bay )

2 x USB2.0 Host Ports

Sys Ctrls

Pwr LED

SMBus GPIO

Intel®

SCH US15W

SMBus

Helios

™

Platform

Audio

Codec

SDVO

to VGA

Stereo Line In

Stereo Line Out

Microphone In

VGA Display Out

Expansion Board Support

(VGA expansion board shown)

SATA

Drive

SATA

Controller

EIA 232/485

Serial Port

USB to

Serial

USB Hub

GPS

Rcvr

GPS Antenna

Connector

Introduction

110124-3000A 5

Features

Processor

•Intel®Atom™Z5xx processor at 1.1 GHz (options for 1.33 GHz or 1.6 GHz)

•Intel®System Controller Hub US15W

Integrated System Functions

•Embedded Controller

•Trusted Platform Management (option)

Memory

•1 GB DDR-2 DRAM (options for 512 MB or 2 GB)

•Integrated system BIOS

•Battery-backed real-time clock

•On-board PATA flash (option)

•CompactFlash® card or SD card (option)

•Internal SATA drive (option)

•External USB disk drive support

Communications

•Five USB 2.0 host ports operating low, full, and high speeds

- Two general-purpose ports

- Three USB Bay ports for wireless devices and storage

(option for up to three external antenna connections)

•EIA-232/EIA-485 serial port (software-selectable)

•Gigabit Ethernet port

•GPS receiver with external antenna connection (option)

User Interface and Display

•Multimedia card support for various display and audio options

(For details about expansion boards, see Multimedia Cards, page 16.)

•Power indicator

•Seven software-controlled LED status indicators

•Software-readable push-button

Power Supply

•12 V DC power input (up to 36 V vehicle power input option)

Mechanical

•ABS plastic and aluminum enclosure

Helios Platform - Hardware Reference Manual

110124-3000A

Further Reading

This document describes the Helios platform and is intended for system integrators. A

system-level overview is provided in the following sections. Check the Eurotech support

site (http://support.eurotech-inc.com/) for errata reports and for the latest releases of

these documents.

Handling Your System Safely

Anti-Static Handling

The Helios platform is designed to meet the Electrostatic Discharge (ESD) criteria

contained in IEC 61000-4-2 (EMC – Part 4-2: Testing and Measurement Techniques –

Electrostatic Discharge Immunity Test). The electronics included in the enclosure contain

CMOS devices that could be damaged by electrostatic discharge (ESD). Observe

industry-standard electronic handling procedures when handling these electronics.

Where possible, work on a grounded anti-static mat. At a minimum, touch an electrically

grounded object before handling any electronics.

Packaging

Please ensure that, should a system need to be returned to Eurotech, it is adequately

packed, preferably in the original packing material.

Electromagnetic Compatibility

The Helios platform is defined as an unintentional radiator of electromagnetic energy.

For additional information about the EMI/EMC specification, see EMI/EMC, page 20.

Conventions

The following table lists the symbols used in this document.

Symbol

Explanation

Note – information that requires your attention

Warning – proceeding with a course of action may

damage your equipment or result in loss of data

The following table describes the conventions for signal names used in this document.

Convention Explanation

GND digital ground plane

+ positive signal in differential pair

- negative signal in differential pair

Introduction

110124-3000A 7

The following table describes the abbreviations for direction and electrical characteristics

of a signal used in this document.

Type Explanation

I signal is an input to the system

O signal is an output from the system

IO signal may be input or output

P power and ground

nc no connection

reserved use is reserved to Eurotech

Helios Platform - Hardware Reference Manual

110124-3000A

Software Support

Eurotech provides an application-ready platform including BIOS, operating system, and

development environment.This section gives a brief description of the software support

available for the Helios platform. For additional details, contact your local Eurotech

technical support.

Operating System

The Helios platform is available with the following operating systems:

•Wind River Linux 3.0

•Windows®Embedded Standard

•Windows®CE 6.0

BIOS

The Helios platform incorporates a custom system BIOS developed by Eurotech.

Boot Options

The Helios platform has the capability to boot and install the operating system from five

sources. The following are the boot options:

•CF card

•USB disk drive

•SD card (future option)

•SATA drive

•On-board PATA flash

Everyware™Software Framework

Everyware Software Framework (ESF) is an inclusive software framework that puts a

middleware layer between the operating system and the OEM application. It provides

industry-standard interfaces that shorten development time, simplify coding, and allow

software to be ported from one Eurotech hardware platform to another. ESF is available

on the Helios platform.

Information about ESF is available at http://esf.eurotech.com.

Hardware Reference

110124-3000A 9

Hardware Reference

This section gives an overview of the hardware features of the Helios platform. The

overview includes location and function of connectors, indicators, and switches and

details about the enclosure.

Rear Panel

The following diagram illustrates the location of connectors and switches on the rear

panel. Notice that the system shown uses the VGA Expansion Board and includes

additional connectors not found on the standard system. For other multimedia card

options, see Multimedia Cards, page 16.

Standard system

The following table describes the connectors on the rear panel of a standard system.

Connector

Enclosure Connector

Description

Power 1 x 2 header, 3.5 mm Main power input

USB 1-2 USB Type A receptacle USB 2.0 host ports

Serial DB-9 plug EIA-232 (default) or EIA-485

Ethernet RJ-45 socket Gigabit Ethernet network

GPS SMA socket GPS external antenna connection

Antenna 1-3 Device dependent USB device external antenna connections

(optional)

USB

Serial

Ethernet

GPS

Power

Display Output

Line Out

Line In

Microphone

Antenna Connections

Switch

Helios Platform - Hardware Reference Manual

110124-3000A

Expansion Board Options

The following table describes the additional connectors on the rear panel of a system that

includes an expansion board.For additional details about the expansion boards offered

by Eurotech, see Multimedia Cards, page 16.

Connector

Enclosure Connector

Description

Microphone RCA jack Mono microphone input

Line In RCA jack Stereo line in

Line Out RCA jack Stereo line out

Display Output Display dependent VGA, LVDS, or DVI output

Connectors

The following tables describe connectors that do not follow an industry-standard pinout.

Power Input

Connector: 2-pin header, 3.5 mm, Phoenix Contact 1937318

Mating connector: 2-pin plug, Phoenix Contact 1847055

The Helios platform accepts input power from a regulated external supply. For details

about input power options, see Power Supply, page 16.

Name

Type

Description

1 GND P ground

2 VIN PI 12 V (nominal) power input

Serial Port

Connector: DB9 plug

Mating connector: DB9 socket

By default the Helios platform provides an EIA-232 serial port. As an alternate

configuration, the serial port can operate in EIA-485 mode. This configuration requires

software support for EIA-485 mode.

Pin EIA-232 (default) EIA-485

Name Type Description Name Type Description

1 DCD I Data Carrier Detect RX+ I Receive Data +

2 RXD I Receive Data RX- I Receive Data -

3 TXD O Transmit Data TX- O Transmit Data -

4 nc nc

5 GND P ground GND P ground

6 nc nc

7 RTS O Request To Send TX+ O Transmit Data +

8 CTS I Clear To Send nc

9 nc nc

Table des matières

Autres manuels Eurotech Contrôleurs

Eurotech

Eurotech Helios Guide rapide de l'utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
