Euromaid EWD8045 Manuel utilisateur

User Manual

8/4.5kg Front Load

Washer/Dryer

EWD8045

Product / Installer details

For future reference we suggest that you staple a copy of your purchase receipt here and complete the below so the

information is always at hand.

Product Details

Model number: ________________________________________________________________________________________

Description: ___________________________________________________________________________________________

Serial number: _________________________________________________________________________________________

(Located on the product rating label)

Purchase Details

Date of purchase: ______________________________________________________________________________________

Place of purchase: _____________________________________________________________________________________

Store name: ___________________________________________________________________________________________

Address: ______________________________________________________________________________________________

Telephone: ____________________________________________________________________________________________

Invoice / receipt number: ________________________________________________________________________________

Installation Details

Electrical date of installation: ___________________________________________________________________________

Electrician Installers Details: Company / Installers Name: _____________________________________________

Licence Number: ______________________________________________________

Telephone Number: ____________________________________________________

Gas date of installation: _________________________________________________________________________________

Gas installers details: Company / Installers Name: _____________________________________________

Licence Number: ______________________________________________________

Telephone Number: ____________________________________________________

Plumbing date of installation: ___________________________________________________________________________

Plumbers installers details: Company / Installers Name: _____________________________________________

Licence Number: ______________________________________________________

Telephone Number: ____________________________________________________

Dear Customer,

Congratulations on the purchase of your new product from

Home Appliances Pty Ltd.

We recommend you please take some time to read the instruction manual

thoroughly to familiarise yourself with the functionality and operations to ensure

optimum performance of your new appliance.

After reading the manual, please store it in a safe and accessible location for

future reference.

Installation

The installation of your new appliance must be carried out by a qualied

installer / technician in accordance to local regulations.

The packaging of your appliance has been selected from environmentally

friendly materials and can usually be recycled. Please ensure these are disposed

of correctly.

Customer Care

Our Customer Care centre is available should you wish to learn more about your

appliance in relation to how to use it to its best potential, or tips on cleaning as

well as available accessories.

For further details please contact our Customer Care team on

1800 444 357 or email: customercar[email protected]

Thank you

Regards,

Home Appliances

Icon Type Meaning

WARNING Risk of serious injury or death

RISK OF ELECTRIC SHOCK Dangerous voltage risk

FIRE Fire risk

CAUTION Injury or property damage risk

IMPORTANT / NOTE Information on operating the system correctly

Thank you for choosing this product.

This User Manual contains important safety information and instructions on the operation

and maintenance of your appliance.

Please take the time to read this User Manual before using your appliance and keep this

book for future reference.

CONTENTS

1.SAFETY INSTRUCTIONS ................................................................................ ................1

1.1. General Safety Warnings ..............................................................................................2

1.2. During Use ....................................................................................................................7

1.3. Packaging and Environment..........................................................................................8

1.4. Savings Information.......................................................................................................8

2.TECHNICAL SPECIFICATIONS..................................................................... ................10

3.OVERVIEW OF YOUR MACHINE ...................................................................................11

3.1. General Appearance................................................................................... ................11

4.SETTING UP YOUR MACHINE.......................................................................................11

4.1. Remove the Transit Screws......................................................................... ................11

4.2. Placing the Machine and Adjusting the Feet ...............................................................12

4.3. Electrical Connection...................................................................................................12

4.4. Water Inlet Connection ................................................................................................13

4.5. Water Draining Connection .........................................................................................13

5.CONTROL PANEL OVERVIEW...................................................................... ................14

5.1. Detergent Drawer General View .................................................................................14

5.2. Sections ...................................................................................................................15

5.3. Programme Dial...........................................................................................................15

6.WASHING OPERATION ................................................................................. ................15

6.1. Sorting Laundry ...........................................................................................................15

6.2. Explanation of Washing Symbols ................................................................................16

6.3. Placing Laundry Into the Machine ...............................................................................16

6.4. Choice of Detergent and Placing Into the Machine .....................................................16

6.5. Programme Selection..................................................................................................17

7.Additional Functions..................................................................................... ................17

7.1. Half-Load Detection System.......................................................................................18

7.2. Cancelling Programme................................................................................................21

7.3. Finishing Programme ..................................................................................................22

8.PROGRAMME TABLE.................................................................................... ................23

9.MAINTENANCE AND CLEANING OF YOUR MACHINE ............................. ................24

9.1. Warning ...................................................................................................................24

9.2. Water Inlet Filters ........................................................................................................24

9.3. Detergent Drawer ........................................................................................................24

9.4. Pump Filter ..................................................................................................................25

10.FLUSH STOPPER / BODY / DRUM ............................................................. ................26

11.TROUBLESHOOTING .................................................................................. ................27

12.AUTOMATIC FAULT WARNINGS AND WHAT NEEDS TO BE DONE ...... ................28

EN - 1

1.SAFETY INSTRUCTIONS

Operating voltage / frequency (V/Hz) (220-240)

V~/50Hz

Total current (A) 10

Water pressure (Mpa) Maximum 1 Mpa /

Minimum 0.1Mpa

Total power (W) 2200

Maximum washing capacity

(dry laundry) (kg) 8

Maximum drying capacity (kg) 4,5

• Do not install your machine on a carpet or such

grounds that would prevent the ventilation of its

base.

• The appliance is not intended for use by people

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge unless they have been given supervision

or instruction concerning use of the appliance by a

person responsible for their safety.

• Children of less than 3 years should be kept away

unless continuously supervised.

• Call the nearest authorized service centre for a

replacement if the power cord malfunctions.

• Use only the new water inlet hose coming with your

machine when making water inlet connections to

your machine.Never use old, used or damaged

water inlet hoses.

• Children should not play with the appliance.

Cleaning and user maintenance should not be made

by children without supervision.

EN - 2

NOTE: For softcopy of this user manual, please

contact following address: “washingmachine@

standardtest.info”. In your e-mail, please provide the

model name and serial number (20 digits) which you

can find on the appliance door.

To ensure your safety and the safety of others,

please read the following safety precautions

before using or installing your Washer Dryer.

Your machine is for domestic use only.

Using it for commercial purposes will void

your warranty.

1.1. General Safety Warnings

Before setting up your Washer Dryer, remove the

four transit bolts and the rubber washers from the

rear of the machine.

• Your warranty does not cover damage caused by

external factors such as fire, flooding and other

sources of damage.

• Retain this user manual for future use and pass it

on to the next user.

• The necessary ambient temperature for operation of

your Washer Dryer is 15-25 °C.

• Where the temperature is below 0 °C, hoses may

split or the electronic card may not operate correctly.

• Please ensure that garments loaded into your

Washer Dryer are free from foreign objects such as

nails, needles, lighters and coins.

• Lints must not to be allowed to accumulate around

the washer dryer.

• Residue may build up on detergent and softeners

exposed to air for a long period of time. Only put

EN - 3

softener or detergent in the drawer at the beginning

of each wash.

• Unplug your Washer Dryer and switch off the water

supply if the Washer Dryer is left unused for a long

time. We also recommend that you leave the door

open to prevent build up of humidity inside the

Washer Dryer.

• Some water may be left in your Washer Dryer as a

result of quality checks during production. This will

not affect the operation of your Washer Dryer.

• Keep the document bag that was supplied inside

your Washer Dryer and contained this user manual

out of the reach of children and babies to prevent

the risk of suffocation.

• The packaging of the machine could be hazardous

to children. Do not allow children to play with the

packaging or small parts from the Washer Dryer.

• Only use pre-wash programmes for very soiled

laundry.

• Do not exceed the maximum load for the washing or

drying programme you have chosen.

• In the event of a fault, unplug your Washer Dryer

and switch off the water supply. Do not attempt to

repair your Washer Dryer yourself. Repairs should

only be undertaken by an approved service agent.

• Never open the detergent drawer while your Washer

Dryer is running.

• Never force the door open when your Washer Dryer

is running.

• Please follow the manufacturers’ instructions on the

use of fabric conditioner or any similar products that

you intend to use in your Washer Dryer.

• Do not stop your Washer Dryer before the drying

phase of a programme has been completed. If you

EN - 4

have to do so, quickly remove all of your laundry

and immediately spread the items on an appropriate

surface to allow them to cool.

• The appliance must not be supplied through an

external switching device, such as a timer, or

connected to a circuit that is regularly switched on

and off by a utility.

• This appliance must not be installed behind a

lockable door, a sliding door or a door with a hinge

on the opposite side to that of the washer dryer, in

such a way that a full opening of the washer dryer

door is restricted.

• Install your Washer Dryer in a location that can be

ventilated and has constant air circulation.

• Oil-affected items can ignite spontaneously,

especially when exposed to heat sources such as in

a tumble dryer. The items become warm, causing an

oxidation reaction in the oil. Oxidation creates heat.

If the heat cannot escape, the items can become hot

enough to catch fire. Piling, stacking or storing oil-

affected items can prevent heat from escaping and

so create a fire hazard.

• If it is unavoidable that fabrics that contain vegetable

or cooking oil or have been contaminated by hair

care products be placed in a tumble dryer they

should first be washed in hot water with extra

detergent - this will reduce, but not eliminate, the

hazar.

SAFETY WARNINGS

• You must read these warnings. Ignoring these

warnings may put you or others at risk of fatal

injuries.

RISK OF BURNS

• Do not touch the door, drain hose or any discharged

EN - 5

water while your Washer Dryer in running. The high

temperatures involved pose a burn risk.

• Open the door fully after the drying process. Do not

touch the door glass. It will reach high temperatures

and pose a burn risk.

ELECTROCUTION RISK

Do not connect your Washer Dryer to the mains

electricity supply using an extension lead.

• A damaged power cord/plug can cause fire or give

you an electric shock. When damaged it must be

replaced, this should only be done by qualified

personnel.

• Never remove the plug from the socket by pulling

the cord. Always hold the plug.

• Never touch the power cord/plug with wet hands as

this could cause a short circuit or electric shock.

• Do not touch your Washer Dryer if your hands or

feet are wet.

• Call the nearest authorised service company for

assistance if the power cord malfunctions.

Explosion Risk

• Thoroughly rinse off any chemicals, such as stain

remover, from your garments before beginning a

washing and drying programme. Failure to do so

may cause a risk of explosion when the drying

function is used.

Fire Risk

• Do not keep flammable or explosive liquids near

your machine.

• Items that have been soiled with substances such

as cooking oil, acetone, alcohol, petrol, kerosene,

spot removers, turpentine, waxes and wax removers

Table des matières

Autres manuels Euromaid Laveuse-sécheuse

Euromaid

Euromaid WMD107 Manuel utilisateur

Manuels Laveuse-sécheuse populaires d'autres marques

Whirlpool

Whirlpool WFC8090GX Manuel utilisateur

Whirlpool

Whirlpool LTE5243DQ6 Manuel utilisateur

Bosch

Bosch XQG100-WDU285H00W Manuel utilisateur

montpellier

montpellier MWD7512S Manuel utilisateur

LG FHD0905 T Series Manuel utilisateur

Midea

Midea MF200D85B Manuel utilisateur

Maytag

Maytag MGT3800XW Manuel utilisateur

Siemens

Siemens WD15G440TR Fiche technique

Equator

Equator Clothes Processor EZ1500 Manuel utilisateur

Splendide

Splendide WDC7100XCP Manuel utilisateur

John Lewis

John Lewis JLWD 1408 Manuel utilisateur

Ariston

Ariston A1200WD Manuel utilisateur

Whirlpool

Whirlpool YLTE5243DQ5 Manuel utilisateur

Whirlpool

Whirlpool WFCR 75230 Guide d'installation

ATT

ATT Hammer Jet v1 Manuel utilisateur

AEG

AEG LAVAMAT 63742 VI Manuel utilisateur

Electrolux

Electrolux EWW8024P5WB Manuel utilisateur

GE GTD42EASJWH Manuel utilisateur
