Eureka NER E10s Manuel utilisateur

ROBOT VACUUM CLEANER

INSTRUCTION

MANUAL

Please read the manual before use

NER E10s

CONTENTS

Safety instructions

Technical data

What comes in the box

How to identify parts of

your robot

Assembling and charging

robot

How to use your robot

11-12

How to set up app, connect

the device and use app

How to maintain your robot

How to maintain brushroll 16

Other routine maintenance 17-18

Troubleshooting 19

TRADEMARKS, COPYRIGHTS

AND LEGAL STATEMENT 21

SAFETY INSTRUCTIONS

Warning for the machine

This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the

appliance.

Plug must be removed from the socket-outlet before cleaning or maintaining

If the supply cord is damaged, it must be replaced by the manufacturer, its

service agent or similarly qualiﬁed persons in order to avoid a hazard.

WARNING: For the purposes of recharging the battery, only use the detach-

able supply unit provided with this Appliance.

Use only with BS2302 supply unit.

This Appliance contains batteries that are only replaceable by skilled

persons.

Do not bring the smart robot close to heat source, radiation or burning

cigarette butts. It is strictly forbidden to vacuum the following objects:

1) All liquids such as water and solvents;

2) Lime, cement dust and other construction dust and garbage;

3) Heat generating objects, such as unextinguished carbon butts, cigarette

butts;

4) Sharp fragments, such as glass, etc.;

5) Flammable and explosive items, such as gasoline and alcohol products.

Before using, please remove all fragile items from the ground (such as

glasses, lamps, etc.), and items that may be tangled with the side brush,

Roller brush and drive wheels(such as wires, curtains and other easily-entan-

gled materials).

Please pay attention to your hair and avoid entanglement on wheels or roller

brushes when using, cleaning and maintaining the robot.

Do not use this product at an altitude of more than 2000m.

10.

11.

12.

13.

Correct Disposal of this product.

This marking indicates that this product should not be

disposed of with other household wastes throughout the EU.

To prevent possible harm to the environment or human health

from uncontrolled waste disposal, recycle it responsibly to

promote the sustainable reuse of material resources. To return

your used device, please use the return and collection systems

or contact the retailer where the product was purchased. They

can take this product for environmentally safe recycling.

Warranty Information

The manufacturer provides warranty in accordance with the legislation of the

customer's own country of residence, with a minimum of 1 year (Germany: 2

years), starting from the date on which the Appliance is sold to the end user.

The warranty only covers defects in material or workmanship.

The repairs under warranty may only be carried out by an authorized service

centre. When making a claim under warranty, the original bill of purchase (with

purchase date) must be submitted.The warranty will not Apply in cases of:

- Normal wear and tear

- Incorrect use, e.g. overloading of the Appliance, use of non-Approved

accessories

- Use of force, damage caused by external inﬂuences

- Damage caused by non-observance of the user

manual, e.g. connection to an unsuitable mains supply or non-compliance with

the installation instructions

- Partially or completely dismantled Appliances

Wireless network: 2400-2483.5MHz, MAX POWER:20dBm.

BLUETOOTH MAX POWER:10dBm

To satisfy RF exposure requirements, a separation distance of 20 cm or more

should be maintained between the antenna of this device and persons during

device operation. To ensure compliance, operations at closer than this

distance is not recommended.

CLASS 1 LASER PRODUCT

INVISIBLE LASER RADIATION

SAFETY INSTRUCTIONS

“IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS" and

"DANGER – TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CARE-

FULLY FOLLOW THESE INSTRUCTIONS".

This appliance can be used by children aged from 8 years and above and

persons with reduced physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given supervision or instruction

concerning use of the appliance in a safe way and understand the hazards

involved.

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children without

supervision.

Plug must be removed from the socket-outlet before cleaning or maintaining

the Appliance.

If the supply cord is damaged, it must be replaced by the manufacturer, its

service agent or similarly qualiﬁed persons in order to avoid a hazard.

Docking base is only Applicable to the product NER E10s. (Battery pack

type : Li-ion, DC 14.4 V, 5200 mAh)

The Docking base will automatically start charging after Robot Vacuum

Cleaner returned to the base.

Warning: The battery charger (Docking station) is not intended to charge

non-rechargeable batteries.

CAUTION: In order to avoid a hazard due to inadvertent resetting of the

thermal cut-out, this Appliance must not be supplied through an external

switching device, such as a timer, or connected to a circuit that is regularly

Warning for docking station

SAFETY INSTRUCTIONS

before removing the battery.

Please note that do not disassemble the battery by yourself.

If you need to replace it, please contact the after-sales service center.

Please dispose of used battery according to local laws and regulations

Do not dismantle, open or shred the battery.

Do not expose batteries to heat or ﬁre. Avoid storage in direct sunlight.

Do not short-circuit a battery.

Do not store batteries haphazardly in a box or drawer where they may

short-circuit each other or be short-circuited by other metal objects.

Do not subject batteries to mechanical shock.

In the event of a leaking, do not allow the liquid to come in contact with

copious amounts of water and seek medical advice.

Do not use any charger other than that speciﬁcally provided for use with

the equipment.

Do not use any battery which is not designed for use with the equipment.

Keep batteries out of the reach of children.

Seek medical advice immediately if the battery has been swallowed.

Keep batteries clean and dry.

Do not leave a battery on prolonged charge when not in use.

After extended periods of storage, it may be necessary to charge and

discharge the batteries several times to obtain maximum performance.

The batteries give their best performance when they are operated at

normal room temperature (20 °C ± 5 °C).

Retain the original product literature for future reference.

The battery may be irreversibly damaged if the battery is in low power for

before storage.

10.

11.

12.

13.

14.

15.

16.

17.

18.

19.

20.

21.

Warning for battery

SAFETY INSTRUCTIONS

[symbol IEC 60417-5957

( 2004-12 )]

[symbol ISO 7000-0790

( 2004-01 )]

[symbol IEC 60417-5031

( 2002-10 )]

[symbol IEC 60417-5032

( 2002-10 )]

[symbol IEC 60417-5172

( 2003-02 )]

time-lag miniature fuse-link where X is the symbol for the

time/current characteristic as given in IEC 60127

for indoor use only

read operator's manual

direct current

alternating current

class II equipment

SAFETY INSTRUCTIONS

TECHNICAL DATA

Product Model: NER E10s

Host Charging Voltage: 16.7V

Host Rated Voltage: 14.4V

Host Rated Power: 55W

Docking Station Model: BS2302

Docking Station Input: 220-240V~, 50-60Hz, 850W

Docking Station Output: 16.7V , 1A

Battery Model: BP14452C

Battery Rated Voltage: 14.4V

Battery Capacity: 5200mAh 74.88Wh

Charging Limit Voltage: 16.8V

10.

11.

Note: You can also view the instructions on the App.

Parts and Components

What comes in the box

350mm

97mm

Robot Vacuum

Side Brush x2 Instruction Manual

244mm

178mm

445mm

Self-Emptying Base

Cleaning Brush

Instruction

Manual

How to identify parts of your robot

Power Cable

Slot

Dust Cup

Indicator Light

Release Button

Self-empty

Inlet

Charging

Contacts

Carpet Detection

Sensor

Auto-lifting Mop

Assembly

Omni-directional

Wheel

Side Brush

Main Wheel

Cover Plate of

Main Brush

Charging Contacts

Main Brush

Edge Sensor

Power Button

Network / Spot

Cleaning Button

Bumper

LiDAR Sensor

Recharging Button

Dustbin /

Water Tank

Dustbin Release

Button

Release Button of

Auto-lifting Mop

Reset Button
