Eureka NEN110 Series Manuel utilisateur
Owner’s Guide
Thank you for purchasing your new Eureka vacuum!
Important instructions
For easy assembly, please
take a few moments to read
this owner’s guide.
NEN110 series
Canister vacuum cleaner, household type
2
Where to nd important vacuum information
Please Retain
We suggest you record the model, type and serial
numbers below. They are located on the bottom of your
cleaner. For prompt and complete service information,
always refer to these numbers when inquiring about
service.
Model & Type _________________________________
Serial No. ____________________________________
It is also important to keep your receipt as proof of
date of purchase.
This Owner’s Guide provides important instructions to
prolong the life of your Eureka vacuum cleaner.
Inspection: Carefully unpack and inspect your new Eureka vacuum cleaner for shipping damage.
Each unit is tested and thoroughly inspected before shipping.
Contents
Important safeguards. ..................................................... 3
How to identify parts of your vacuum cleaner................. 5
How to assemble your vacuum cleaner. ......................... 6
How to use your vacuum cleaner. ................................... 7
How to maintain your vacuum cleaner. ........................... 8
Problem solving............................................................. 10
The Eureka 2 years limited warranty. ............................ 11
ââââââ
Follow caution information wherever you see this symbol.
3
IMPORTANT SAFEGUARDS
When using an electrical appliance, basic precautions should always be followed, including the following:
READALL INSTRUCTIONS BEFORE USING THIS VACUUMCLEANER
WARNING
To reduce the risk of
re, electric shock, or
injury:
• Do not use outdoors or on wet
surfaces.
• Do not leave vacuum cleaner
Turn off the
switch and unplug the electrical
cord when not in use and
before servicing.
• Do not allow to be used as a
toy. Close attention isnecessary
when used by or near children.
• Use only as described
in this manual. Use only
manufacturer's recommended
attachments.
• Do not use with damaged cord
or plug.
• Do not pull or carry by the
cord, use cord as a handle,
close door on cord, or pull cord
around sharp edges or corners.
Do not run vacuum cleaner over
cord. Keep cord away from
heated surfaces.
• Do not use extension cords or
outlets with inadequate current
carrying capacity.
• Turn off all controls before
unplugging.
• Do not unplug by pulling on
cord. To unplug, grasp the plug,
not the cord.
• Do not handle the vacuum
cleaner with wet hands or
operate without shoes.
• Do not put any objects into
openings. Do not use with any
opening blocked; keep free of
dust, lint, hair and anything that
may reduce airow.
• This vacuum cleaner creates
suction. Keep hair, loose
clothing, ngers, and all parts of
body away from openings and
moving parts.
• Do not pick up anything that
is burning or smoking, such
as cigarettes, matches, or hot
ashes.
• Do not use without dust cup or
lter(s) in place.
• Use extra care when cleaning
on stairs.
• Do not use to pick up ammable
or combustible liquids such as
gasoline, or use on areas where
they may be present.
!
4
• Store your cleaner indoors in a
cool, dry area.
• Keep your work area well lit.
• Unplug electrical appliances
before vacuuming them.
• Belt pulleys can become hot
•
during normal use. To prevent
burns, avoid touching the belt
pulley when servicing the drive
belt.
• Turn off the power switch and
•
unplug cleaner before rotating
the nozzle.
SAVE THESE INSTRUCTIONS
To reduce the risk of electric shock,this appliance has a polarized plug (one blade is widerthen the other). This
plug will t in a polarized outlet only one way. If the plug does not fullyt into the outlet, reverse the plug.
If it still does not t,contact a qualied electrician to install the proper outlet. Do NOT change the plug in any way.
Thermal Cut Off
This vacuum cleaner has a special thermostat that protects the cleaner in case of motor overheating. If the
cleaner suddenly shuts off, push the on/off switch off (0) and unplug the cleaner. Check the cleaner for a
possible source of overheating such as a full dust cup, a blocked hose or clogged lter. If these conditions are
plug the cleaner back in and push the on/off switch on (I).
Do Not Oil the motor or the brushroll at any time. The bearings are permanently
lubricated and sealed.
This appliance can be used
by children aged from 8
years and above and per-
sons with reduced physical,
sensory or mental capabili-
ties or lack of experience
and knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved. Children
shall not play with the appli-
ance. Cleaning and user
maintenance shall not be
made by children without
supervision.
If the supply cord is damaged,
it must be replaced by the
manufacturer, its service
agent or similarly qualied
persons in order to avoid a
hazard.
5
How to identify parts of your vacuum cleaner
1Handle
2Dust cup release button
3Power button
4Cord rewind button
5Filter
6Dust cup
Accessories
This vacuum cleaner includes the following accessories:
1Telescoping metal wand
2Hose
3Floor brush
6
How to assemble your vacuum cleaner
ASSEMBLY
Always disconnect the vacuum cleaner from the electrical socket before attaching or
removing accessories.
1. Attach the hose to the front of the vacuum cleaner by inserting it into the air inlet and
twisting to the right. To remove the hose twist to the left and pull to detach.
2. Attach the telescoping wand to the hose at the bend by pushing the two components
together.
3. Attach the oor nozzle to the wand by connecting the two parts. And then twist them into
position.
7
How to use your vacuum cleaner
CAUTION: Always switch off the vacuum cleaner before connecting or disconnecting the
hose/attachments or removing and emptying the dust cup.
IMPORTANT: The vacuum cleaner is equipped with a thermal cut-off. If for any reason the
vacuum cleaner does overheat, the thermostat will automatically turn the vacuum cleaner
off. If this happens, switch the vacuum cleaner off and unplug it from the electrical socket.
Remove and empty the dust cup and check the vacuum deaner for blockages. Allow the
vacuum cleaner to cool for approximately 1 hour (if you have cleaned the incorrect space,
please wait 24 hours for the lters to fully dry before putting them back into the machine).
Operation
Pull the power cord out of the vacuum cleaner and stop when you
see the yellow mark. Make sure the red mark is not visible or you
have pulled too far. When done cleaning, turn off the power, pull
the plug out of the electrical socket, and then push the rewind
button until the cord is completely retracted.
To turn on the vacuum cleaner, push the plug into an electrical
socket and press the power button.
Switching between carpet & hard oor
There is a switch located on the oor nozzle that can be pressed
with your foot to switch betweenoor modes. The symbols shown
below correspond to the type of oor the setting is for.
Position 1: Bristles extended for hard oor
Position 2: Bristles retracted for carpet
Position 1
Hard oor
Position 2
Carpet
8
How to maintain your vacuum cleaner
Emptying the dust cup
Always switch off the vacuum and unplug it from the electrical socket before conducting any
maintenance or cleaning.
Empty the dust cup after each use. Also be sure to empty the dust cup anytime dust reaches
the max ll line.
A full dust cup will reduce the efciency of the vacuum cleaner so be sure to empty the dust
cup regularly.
1. Press the dust cup release button and take the dust cup out of the vacuum.
2. Bring the dust cup over a trash receptacle and then press the release button to open the
lower lid. The dust will fall out the bottom and into the trash.
3. Close the dust cup lid after dust has been fully emptied. Return the dust cup to the
vacuum cleaner.
9
How to maintain your vacuum cleaner
Cleaning the Filter
The lter is an effective system for removing dust.
Sponge lters require cleaning on a monthly basis (or more depending on use frequency).
1. To remove the lter, pull on the dust cup lid clip and lift the cover upwards.
2. The lter is located inside the top cover of the dust
cup.
Pull on the handle of the lter housing then remove it.
3. Tap the lter over a bin to remove the dust.
4. Take the sponge lter out of the lter
housing.
5.
DO NOT USE DETERGENTS to clean any part.
Leave it out to dry for 24 hours or until fully dry before placing it back in the vacuum cleaner.
6. Put the lter back into the housing. Put the housing and lter back into the dust cup lid.
Finally, close the dust cup lid.
7. Place the dust cup back into the vacuum cleaner until a click is heard.
Filter frame handle
Cyclone separation
system
Filter
10
Problem solving
!
Make sure vacuum is turned off and power cord is unplugged.
NOTICE: Thermal cut-off
This vacuum cleaner has a special thermostat that protects the vacuum in case of motor
overheating. If the vacuum suddenly shuts off, proceed as follows: 1) Push the power
switch to off and unplug the vacuum. 2) Check the vacuum for a possible source of
overheating such as a full dust cup, blocked hose or clogged lter. If these conditions
are found, x them and wait at least 30 minutes before attempting to use the vacuum. 3)
After the 30 minute period, plug the vacuum back in and turn on the switch.
Problem Possible cause Solution
The vacuum
cleaner does not
turn on
• Too much dust in the cup
• Filter is blocked
• Hose is blocked
• Empty the dust cup
• Rinse the lter
• Clear the blockage
The vacuum
cleaner does not
work
• Electrical outlet is not
connected or not working
• Power switch was not
turned on
• Ensure the plug is properly
connected in the socket and
the socket is active
• Press the power button
The vacuum
cleaner suddenly
stops
• The dust cup is lled
• The lter is blocked
• Suction inlet of brush or
accessories is blocked
• Empty the dust cup
• Clean the lter
• Clear the blockage
Connecting to an electrical socket
Please check that the voltage indicated on the product corresponds with your supply voltage.
