EtroVISION EV8180A Manuel utilisateur
Users Manual
EV8x8x Models
Firmware Version 1.0.7
Document Version 1.2
About This Guide
The User’s Manual provides functionality and instructions for the 1080p/5M series
which includes:
•EV8180
•EV8180F
•EV8180U
•EV8180U-YN
•EV8580F
•EV8580U-B
•EV8580U-C
•EV8580
•EV8780U
•EV8781
•EV8781U-C
•EV8781F
Before Using the IP Camera/Video Server
Check the PC requirements
Review the OS platform requirements
Read an special and import precautionary information
Having basic knowledge of network setup and configuration will be helpful
Disclaimer
© 2010 Etrovision Technology. ll rights reserved.
EtroLink™ & nyUSB™ are trademarks of Etrovision Technology; other product or
service names mentioned herein are the trademarks of their respective owners.
Information contained in this document may be superseded by updates. No
representation or warranty is given and no liability is assumed by Etrovision
Technology with respect to the accuracy or use of the information, or infringement of
patents or other intellectual property rights. No licenses are conveyed, implicitly or
otherwise, under any intellectual property rights.
1
INTRODUCTION..............................................................................1
2
THE LIVE VIEW................................................................................2
2.1 Setup...........................................................................................................3
Set the Snapshot/Recording Path...............................................................3
2.2 Controls and Status.....................................................................................3
2.3 Digital Zoom................................................................................................4
2.4 Information..................................................................................................4
2.5 Streaming....................................................................................................4
2.6 Audio...........................................................................................................5
2.7 Control (PTZ Control)..................................................................................5
3
SETUP .............................................................................................6
3.1 System – Information ..................................................................................7
3.2 System – Generic Setting............................................................................7
Camera Name.............................................................................................7
System Time...............................................................................................8
Digital Input.................................................................................................8
LED.............................................................................................................8
HTTP Port...................................................................................................8
Language....................................................................................................9
3.3 System – User Account Management.........................................................9
3.4 System – Maintenance..............................................................................10
Firmware Update.......................................................................................10
Export/Import Camera Configuration.........................................................13
Restore Factory Default ............................................................................13
Reboot Device...........................................................................................13
3.5 System – Local Storage ............................................................................13
3.6 System – Record Setting...........................................................................14
3.7 Network – IP Setting..................................................................................14
3.8 Network – Streaming.................................................................................15
3.9 Network – DDNS.......................................................................................15
3.10 Video/Audio – Video Setting......................................................................16
TV Out Mode.............................................................................................16
Resolution Mode (EV8x80F Models Only) ................................................17
Profile Setting............................................................................................17
3.11 Video/Audio – Audio Setting......................................................................18
3.12 Video/Audio – Color Setting......................................................................19
3.13 Event Handle – Event Rule.......................................................................19
3.14 Event Handle – Event Server....................................................................20
Email Setting.............................................................................................21
Network Storage .......................................................................................21
3.15 Event Handle – Motion Detection..............................................................21
3.16 PTZ Control – Serial Setting......................................................................22
3.17 System Log – View Log.............................................................................22
3.18 System Log – Remote Log Setting............................................................23
4
STREAMING VIDEO......................................................................24
Authentication ...........................................................................................24
5
ADDING A CAMERA TO AN NVR..................................................26
5.1 RTSP URL.................................................................................................26
5.2 Administrator User & Password ................................................................27
6
FIREFOX & CHROME....................................................................28
1
1 INTRODUCTION
This guide is for the use with the 1080p/5MP series using firmware version 1.0.7.
Please pay close attention to areas that are highlighted in YELLOW. These areas
highlight special instructions for this firmware release.
2
2 THE LIVE VIEW
The IP camera web interface is made up of two main pages: the Live View page and
the Setup page. The Live View provides the current display from the IP camera
along with selected settings, configuration and functionality.
login is required to access the web UI. The administrator username is “root”, and
the password by default is “pass”.
fter logging into the IP camera via the browser, the user is first presented with the
Live View interface.
Below is an example of the Live View page. Following the screenshot is a discussion
of the different areas within the Live View page.
The right hand panel (Information, Streaming, udio, Control) can be hidden by
clicking the small arrow bordering the video and Streaming pane.
3
Click the arrow (highlighted in green) to hide/display the right side panel.
2.1 Setup
In the top right corner of the screen are three links.
•Live View: the main viewing screen with various controls.
•Setup: provides the interface for most of the camera configuration.
•Path Setup: sets the default Snapshot/Recording path on the PC
Set the Snapshot/Recording Path
Select Path Setu and then select the directory where Live View will write
snapshots/recordings.
2.2 Controls and Status
The View Size controls adjust the viewable screen size in Live View. The Zoom
feature can be used, and
Record and Snapshot will capture video/snapshots to the local hard drive.
Digital Out will trigger a digital output signal (e.g. to an alarm).
4
Full Screen will display video in full screen mode. Click the Esc key to exit Full
Screen mode.
SD Card shows the status of the SD card.
Digital In lert will display when a digital in alert has been triggered.
Motion Detection lert will display when motion detection has been triggered.
2.3 Digital Zoom
The Digital Zoom feature allows zooming in on a specific area. When using the
View Size controls, a magnifying glass icon will replace the mouse pointer icon.
To magnify a specific area, place the magnifying glass icon over the desired area
and left click the mouse. dditional left mouse clicks will continue to magnify
wherever the mouse is placed.
To zoom out, right click the mouse.
If the mouse is moved to the edge of the image window, the mouse icon will
change to a white, triangular icon.
This icon allows moving the view using ePTZ (Electronic Pan/Tilt/Zoom) if the
functionality is available and enabled.
2.4 Information
Resolution and frame rate will be displayed in the Information pane.
2.5 Streaming
To toggle between different video streams, use the Stream drop down list.
5
The number of ROI which are enabled in the Video Setting – Profile Setting will
determine the number of streams available for viewing. See the “Video Control –
Video Setting” section for more information.
2.6 Audio
udio volume controls for speaker and microphone. Clicking on the icon will
mute or enable.
2.7 Control (PTZ Control)
The PTZ control panel will not be present in those models where PTZ will not be
used (e.g. EV8580). Use the Set button to mark a preset, and the Go button to use
a preset.
6
3 SETUP
The web interface is made up of two main pages: the Live View page and the Setup
page. The Live View page interface was introduced in the previous section.
The Setup interface is primarily used for viewing and configuring the IP camera’s
settings.
From the Live View page, click the Setup link at the top right side:
Below is a screenshot of the Setup page. The initial page displayed is the “System
Information” page.
The left hand panel lists the configuration nodes which can be viewed and modified.
Clicking on an item will reveal sub menus which are available.
To return to the Live View page, click the Live View link in the right hand corner.
