ETNA VW549M Manuel utilisateur

VW549M

INSTRUCTIONS FOR USE

ANLEITUNG

DISHWASHER

GESCHIRRSPÜLER

EN User instruction EN 3 - EN 27

DE Anleitung DE 3 - DE 27

Pictograms used - Benutzte Piktogramme

Important information - Wissenswertes

Tip - Tipp

Contact a registered installer to fit your appliance

(see “Installation instructions”). Do not connect the

appliance to the electrical mains until the installation is

complete.

This appliance is intended to be used in household and

similar applications such as:

▷staff kitchen areas in shops, offices and other working

environments;

▷farmhouses;

▷by clients in hotels, motels and other residential type

environments;

▷bed and breakfast type environments.

For EN60335-1:

• This appliance can be used by children aged from

8 years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved. Children

shall not play with the appliance. Cleaning and user

maintenance shall not be done by children without

supervision.

SAFETY INSTRUCTIONS

For IEC60335-1:

• This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person

responsible for their safety.

• Packaging material could be dangerous for children!

• This appliance is for indoor household use only.

• To protect against the risk of electrical shock, do not

immerse the unit, cord or plug in water or other liquid.

• Please unplug before cleaning and performing

maintenance on the appliance.

• Use a soft cloth moistened with mild soap, and then

use a dry cloth to wipe it again.

Earthing Instructions

• This appliance must be earthed. In the event of a

malfunction or breakdown, earthing will reduce the

risk of an electric shock by providing a path of least

resistance of electric current. This appliance is equipped

with an earthing conductor plug.

• The plug must be plugged into an appropriate outlet

that is installed and earthed in a ccordance with all local

codes and ordinances.

• Improper connection of the equipment-earthing

conductor can result in the risk of an electric shock.

SAFETY INSTRUCTIONS

• Check with a qualified electrician or service

representative if you are in doubt whether the appliance

is properly grounded.

• Do not modify the plug provided with the appliance, if it

does not fit the outlet.

• Have a proper outlet installed by a qualified electrician.

• Do not abuse, sit on, or stand on the door or dish rack

of the dishwasher.

• Do not operate your dishwasher unless all enclosure

panels are properly in place.

• Open the door very carefully if the dishwasher is

operating, there is a risk of water squirting out.

• Do not place any heavy objects on or stand on the door

when it is open. The appliance could tip forward.

When loading items to be washed:

▷Locate sharp items so that they are not likely to

damage the door seal;

▷Warning: Knives and other utensils with sharp points

must be loaded in the basket with their points facing

down or placed in a horizontal position.

• Some dishwasher detergents are strongly alkaline.

They can be extremely dangerous if swallowed.

Avoid contact with the skin and eyes and keep children

away from the dishwasher when the door is open.

SAFETY INSTRUCTIONS

• Check that the detergent powder is empty after

completion of the wash cycle.

• Do not wash plastic items unless they are marked

“dishwasher safe” or the equivalent.

• For unmarked plastic items not so marked, check the

manufacturer's recommendations.

• Use only detergent and rinse agents recommended for

use in an automatic dishwasher.

• Never use soap, laundry detergent, or hand washing

detergent in your dishwasher.

• The door should not be left open, since this could

increase the risk of tripping.

• If the supply cord is damaged, it must be replaced

by the manufacturer or its service agent or a similarly

qualified person in order to avoid a hazard.

• During installation, the power supply must not be

excessively or dangerously bent or flattened.

• Do not tamper with controls.

• The appliance needs to be connected to the main water

valve using new hose sets. Old sets should not be

reused.

• To save energy, the appliance will go to standby mode

automatically when there is no operation during some

time.

SAFETY INSTRUCTIONS

EN 3

CONTENTS

Your dishwasher

Introduction 4

Using your dishwasher

Description 5

Quick start 5

Control panel 6

Water softener 7

Adding salt 8

Preparing and loading dishes 9

Function of the rinse aid and dishwasher detergent 13

Filling the rinse aid reservoir 14

Filling the detergent dispenser 15

Programming the dishwasher

Wash cycle table 16

Starting a cycle wash 17

Changing the program mid-cycle 17

Forget to add a dish? 18

Maintenance

Filtering system 19

Cleaning the spray arms 20

Caring for the dishwasher 21

Cleaning the door 22

Errors

What should I do, if... 23

Error table 23

Technical data sheet 26

Your dishwasher and the environment

Disposal 27

EN 4

Introduction

You have chosen to purchase a Etna dishwasher.

Optimum user comfort and easy operation were paramount during the development of this

product.

This manual describes how you can get the most out of your dishwasher. It provides you with

information on how to operate the appliance, as well as background information about how it

works. You will furthermore also find maintenance tips.

The safety instructions that are relevant during the installation are included in the installation

guide. This is intended for the installation technician.

Read this manual before using the appliance. Keep this manual somewhere safe so that

subsequent users can also benefit from the information contained within.

YOUR DISHWASHER

EN 5

USING YOUR DISHWASHER

Description

Features and appearance of baskets and cutlery baskets may vary, depending on your

model.

1. Salt container

2. Detergent dispenser

3. Rainse aid reservoir

4. Lower spray arm

5. Filtering system

6. Cutlery basket

7. Cup rack

8. Upper spray arm

9. Upper basket

10. Lower basket

Quick start

Please read the corresponding content in this manual for more details about the operation.

Inside Outside

1. Setting the water softener/loading the salt.

2. Removing larges residues on the cutlery/dishes.

3. Loading the baskets.

4. Filling the dispenser and the rinse aid reservoir.

5. Selecting a program and running the dishwasher.

EN 6

USING YOUR DISHWASHER

Control panel

4321 67

65° 55° 45° 60° 50°

Operation (push buttons)

1 On/Off Press this button to turn on your dishwasher, the screen lights up.

2 Half-load If you do not have too much load, you might consider using the half-load

program. This function saves water and energy. It can be used with the

programs Intensive, Universal, ECO and 90 min.

3 Delayed

start

Press this button to set a delayed start.

4 Program Select the appropriate washing program. The corresponding indicator will

be lit.

Indicators

5 Program

indicator

65° 45° 60°

55° 50°

Intensive

Heavily soiled items include pots and pans. With dried on food.

65° 45° 60°

55° 50°

Universal

For normally soiled loads, such as pots, plates, glasses and lightly

soiled pans.

65° 45° 60°

55° 50°

ECO

This is the standard program, it is suitable to clean normally

soiled tableware and it is the most efficient program in terms of its

combined energy and water consumption for that type of tableware.

65° 45° 60°

55° 50°

90 Min

For normally soiled loads that need quick wash.

65° 45° 60°

55° 50°

Rapid

A shorter wash for lightly soiled loads that do not need drying.

6 Warning

indicator

65° 45° 60°

55° 50°

Rinse aid

If this indicator is lit, it means the dishwasher is low on dishwasher

rinse aid and requires a refill.

65° 45° 60°

55° 50°

Salt

If this indicator is lit, it means the dishwasher is low on dishwasher

salt and needs to be refilled.

7 Delayed

start time

To show the delayed start time (3h/6h/9h).
