ETEKCITY MSR-A2000 Manuel utilisateur

Questions or Concerns? support@etekcity.com • (855) 686-3835

Digital Multimeter

Model: MSR-A2000

User Manual

Table of Contents

Package Contents

Specications

Features

Safety Information

Safety Terms and Symbols

Multimeter Features & Diagram

Rotary Switch

Keypad

Display Screen

Measurement Units

Input Terminals

Operation

Taking Measurements

Multimeter Features

Care & Maintenance

Technical Specications

Warranty Information

Customer Support

For full details on using your Digital Multimeter, scan the

QR code to see the extended digital manual.

You can also type the following link into a web browser:

www.etekcity.com/support/manual/model/msr-a2000

Specications

Package Contents Features

Max Voltage 1000V

Max Display Value 5999

Battery 1 ×9V 6F22 Battery

1 ×Digital Multimeter

1 ×User Manual

1 ×9V 6F22 Battery (Pre-Installed)

2 ×Test Leads

1 ×K-Type Thermocouple

• Auto-Off

• Backlit LCD Display

• Overload Protection

• True RMS

• Auto & Manual Range Options

• Overcurrent & Overvoltage Protection

• Test Lead Insertion Detection Function

Safety Information

Before using, read all instructions. Only use the

multimeter as directed, or the multimeter may

be damaged, and you may be seriously injured.

• Limit operation to the specied measurement

category, voltage, or amperage ratings.

• Do not use the multimeter if it is damaged.

Before you use the multimeter, inspect the

case. Look for cracks or missing plastic.

Pay particular attention to the insulation

surrounding the connectors.

• Do not use the test leads provided for other

products. Use only the certied test leads

specied for this multimeter.

• Inspect the test leads for damaged

insulation or exposed metal.

• Before use, verify the multimeter’s operation

by measuring a known voltage.

• Only qualied technicians can perform

maintenance on this multimeter.

• Always use the specied battery type.

This multimeter is supplied with a battery

for power. Observe the correct polarity

markings before you insert the batteries to

ensure proper insertion of the batteries in

the multimeter.

• Check all Terminal Ratings. To avoid re or

shock hazard, check all ratings and markers

for this multimeter. Refer to this manual

for more information about ratings before

connecting anything to the multimeter.

READ AND SAVE THESE INSTRUCTIONS

Safety Information (cont.)

• Do not operate the multimeter with the

cover, or portions of the cover, removed or

loosened.

• Use Proper Fuses. Use only the specied

type and rating fuse for the multimeter.

• Do not operate if in any doubt about whether

the multimeter is safe to use. If you suspect

damage has occurred to the multimeter,

have it inspected by qualied service

personnel before further operation.

• To avoid electric shock, do not operate this

multimeter in wet or damp conditions.

• Do not operate in an area with explosive

substances or gasses.

• Always keep the multimeter’s surfaces clean

and dry.

• Do not apply more than the rated voltage (as

marked on the multimeter) between terminals,

or between terminal and earth ground.

• When measuring current, turn off the circuit

power before connecting the multimeter

in the circuit. Remember to place the

multimeter in series with the circuit.

• When servicing the multimeter, use only the

specied replacement parts.

• Use caution when working above 60V DC,

30V AC RMS, or 42.4V peak. Such voltages

pose a shock hazard.

• When using the test leads, keep your ngers

behind the nger guards on the test leads.

Never touch any exposed metal while

measuring.

• Remove the test leads from the multimeter

before you open the battery cover.

• To avoid false readings, which may lead to

possible electric shock or personal injury, replace

the battery as soon as the low battery indicator

appears and flashes.

Safety Information (cont.)

• Disconnect circuit power and discharge all high-

voltage capacitors before testing resistance,

continuity, diodes, or capacitance.

• Always use the proper terminals, function, and

range for your measurements. When the range

of the value to be measured is unknown, set

the rotary switch position as the highest range,

or choose the auto-ranging mode. To avoid

damages to the multimeter, do not exceed the

maximum limits of the input values shown in the

technical specication tables (see pages 31–34).

• Connect the common test lead before you

connect the live test lead. When you disconnect

the leads, disconnect the live test lead rst.

• Before changing functions, disconnect the test

leads from the circuit undergoing testing.

• Do not alter the internal circuitry of the

multimeter. This may result in serious injury.

• Do not use or store the multimeter in wet or

humid environments, in very high temperatures,

around explosive or flammable substances, or in

areas with strong magnetic elds. The multimeter

will not perform correctly, which may create a

safety hazard.

• Do not allow children to operate or play with

this multimeter.

Safety Information (cont.)

Measurement Category Safety Rating

Measurement Category (CAT)

Denitions:

The multimeter has a safety rating of 1000V,

CAT III and 600V, CAT IV.

Measurement CAT I applies to measurements

performed on circuits not directly connected

to the AC mains. Examples are measurements

on circuits not derived from the AC mains and

specially protected (internal) mains-derived

circuits, such as signal levels, electronics, and

limited-energy parts of equipment, which usually

have little chance of danger or overloading.

Measurement CAT II applies to measurements

performed on circuits directly connected

to the low-voltage installation. Examples

are measurements on energy-consuming

equipment such as TVs, PCs, portable tools,

and other household circuits.

Measurement CAT III applies to

measurements performed on equipment in

xed equipment installations, such as wiring,

distribution panels, feeders and short branch

circuits, and lighting systems in large buildings.

Measurement CAT IV applies to

measurements performed at the source of

the low-voltage installation. Examples are

electricity meters and measurements on

primary overcurrent protection devices and

ripple control units.

Safety Terms and Symbols

Safety Terms Safety Symbols

Terms in this Manual. The following terms may

appear in this manual:

Symbols on the Product. The following symbol

may appear on the product:

Terms on the Product. The following terms

may appear on this product:

Warning: Warning indicates the conditions or

practices that could result in personal injury or

death.

Caution: Caution indicates the conditions

or practices that could result in damage to this

product or other property.

Danger: Indicates an injury or hazard may

immediately occur.

Warning: Indicates an injury or hazard may

potentially occur.

Caution: Indicates a potential damage to the

instrument or other property might occur.

Direct current

(DC) Fuse

Alternating

current (AC) CAT II

Category II

overvoltage

protection

Both direct

and alternating

current

CAT III

Category III

overvoltage

protection

Ground terminal CAT IV

Category IV

overvoltage

protection

Equipment

protected

throughout by

double insulation

or reinforced

insulation

Caution, risk of

danger (refer to this

manual for specic

Warning or Caution

information)

Multimeter Features

A. Display Screen (see page 12)

B. Keypad (see page 11)

C. Rotary Switch (see page 10)

D. Input Terminals (see page 15)

E. LED Indicator

F. Non-Contact Voltage Detector (NCV)

(see page 24)

G. Flashlight (see page 19)

Accessories

F G

H. 9V 6F22 Battery (Pre-Installed)

I. Test Leads

J. K-Type Thermocouple

Position Description Details

Power off Page 18

DC or AC voltage measurement Page 20

Resistance measurement Page 21

Continuity test Page 21

Diode test Page 22

Capacitance measurement Page 22

Frequency / duty cycle

measurement Page 23

Temperature measurement Page 23

Rotary Switch

Position Description Details

Single test lead living wire

detection Page 24

Non-contact voltage detection Page 24

DC or AC current measurement,

Up to 6000 microamperes Page 26

DC or AC current measurement,

Up to 600 milliamperes Page 26

DC or AC current measurement Page 26
