eSync DVR Manual

Appendix A

FCC Compliance Statement

Model Name: eSync Series (SSA-1648e, SSA-0824e, SSA-0424e).

This device complies with Part 15 of the FCC Rules. Operation is Subject to the following two conductions: (1) this

device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operations.

WARNING

•Unauthorized reproduction of all or part of this manual is strictly prohibited.

•The figures in this manual are for illustration purposes only (may differ from the actual product).

The specifications and design of the product are subject to change without notice.

eSync DVR Manual

Appendix A

CAUTIONS

To get the best use out of the eSync DVR, be sure to read the cautions before using the eSync unit.

For safety, please take note of the following:

•Before turning on the DVR

1. To prevent electric shock when installing, moving, or opening the DVR and peripheral devices,

disconnect the power cable.

2. Keep the packing materials used for the DVR or other peripheral devices out of reach of children.

•Installation Environment of the DVR

1. Maintain the following conditions: operating temperature of 32˚F ~ 96˚F; operating humidity of 10% ~

80%

2. Install the DVR in a safe place that is free from external vibration.

3. Install the DVR in a well-ventilated place.

4. To protect the hard disk from data loss and breakdown, install the DVR away from magnetic materials.

5. When using a rack other than the standard one, use a separate table with sufficient spacing, i.e., 20

inch from the floor, 18 inch from the ceiling, and 8 inch from the side and back walls and other objects.

•Safety Notes on the DVR

1. When installing Application HDD, turn OFF the DVR and remove the power cable completely.

2. Keep the product away from heat-generating devices such as heaters.

3. Do not use a damaged power cord.

4. To prevent problems due to magnetic interference and electric surge, use only grounded power cables

and power outlets.

5. If the power cord is connected, do not touch the power supply unit inside of the DVR (if the power cord

is connected, electric current is still flowing internally even after the switch is turned OFF).

6. Do not place a heavy object on top of the product.

7. Do not drop a conductive object in the ventilation holes.

8. Allow sufficient space for system cabling, such as (i.e. HDD SATA Cable, SATA Power cable, etc.)

9. Use only the parts indicated in the manual. Do not disassemble, repair, or modify the product without

permission.

10. Incorrect system setup may cause malfunction.

11. Shut down the system normally as instructed in the manual.

•Safety Notes on the Lithium Battery

1. Replace lithium batteries as instructed to avoid danger.

2. Dispose of used lithium batteries properly.

Warnings and Cautions are indicated as follows:

Possible injury or product damage

Risk of minor injury or product damage

eSync DVR Manual

Table of Contents

Appendix A ..................................................................................................................................................1

FCC Compliance Statement .........................................................................................................................1

WARNING.....................................................................................................................................................1

CAUTIONS....................................................................................................................................................2

Chapter 1. Introduction...............................................................................................................................5

1-1 About the Product...............................................................................................................................5

1-2 Major Features ...................................................................................................................................5

1-3 Components .......................................................................................................................................6

Chapter 2. Installation and Connection....................................................................................................7

2-1 Name and Features of Each Panels ..................................................................................................7

2-1-1 Front Panel....................................................................................................................................7

2-1-2 Back Panel....................................................................................................................................8

2-2 Installation and Connection................................................................................................................9

2-2-1 Connection of Devices..................................................................................................................9

Chapter 3. Operation and Setup Tools ...................................................................................................10

3-1 Remote Controller ............................................................................................................................10

3-2 Mouse...............................................................................................................................................11

Chapter 4. System Operation...................................................................................................................12

4-1 Starting and Exiting the DVR............................................................................................................12

4-1-1 Starting the System.....................................................................................................................12

4-1-2 Exiting the System ......................................................................................................................12

4-2 Monitoring.........................................................................................................................................12

4-2-1 Screen Division and Automatic Screen Conversion ...................................................................12

4-2-2 Menus in Live mode....................................................................................................................13

4-2-3 Relocating the recording status window .....................................................................................13

4-3 System Login....................................................................................................................................14

4-3-1 User Accounts.............................................................................................................................14

4-3-2 Login............................................................................................................................................14

4-3-3 Logout .........................................................................................................................................14

4-4 Audio Recording and Playback ........................................................................................................15

4-4-1 Setting up the Audio Recording ..................................................................................................15

4-4-2 Live Audio....................................................................................................................................15

4-5 Viewing System Information and Changing the Display Setup........................................................16

4-5-1 System Information.....................................................................................................................16

4-5-2 Channel Grouping.......................................................................................................................16

4-5-3 Adjusting the Screen Brightness.................................................................................................16

4-5-4 Adjusting the Screen Contrast ....................................................................................................17

4-5-5 Camera Position Adjustment.......................................................................................................17

4-5-6 Display Control............................................................................................................................17

4-5-7 Display/Hide Camera Name........................................................................................................17

4-5-8 Adjusting the Screen Border.......................................................................................................17

4-6 Spot Control......................................................................................................................................17

4-7 Relay Out..........................................................................................................................................17

4-8 Playback...........................................................................................................................................18

4-8-1 Shifting to Playback Mode...........................................................................................................18

4-8-2 Playback Menu............................................................................................................................18

4-8-3 Multi-Channel Search..................................................................................................................19

4-8-4 Multi-Time Search.......................................................................................................................20

4-8-5 Multi-Day Search.........................................................................................................................21

4-8-6 Playback Speed Control..............................................................................................................22

eSync DVR Manual

Table of Contents

4-8-7 Playback on a divided screen .....................................................................................................22

4-8-8 Playback on Audio ......................................................................................................................22

4-8-9 Playback on Event ......................................................................................................................22

4-8-10 Go To The Date & Time Search ...............................................................................................23

4-8-11 Go To The First Search.............................................................................................................23

4-8-12 Go To The Last Search.............................................................................................................23

4-9 Log List.............................................................................................................................................24

4-9-1 Log Types....................................................................................................................................24

4-9-2 Viewing the System Log..............................................................................................................24

4-10 Recording .......................................................................................................................................25

4-10-1 Recording Types.......................................................................................................................25

4-10-2 Recording Setup .......................................................................................................................25

4-10-3 Viewing the Recording Status...................................................................................................25

4-10-4 Starting and Stopping Force Record.........................................................................................26

4-11 Search ............................................................................................................................................27

4-11-1 Selecting the Search Mode.......................................................................................................27

4-11-2 Selecting the Search Method....................................................................................................27

4-11-3 Search using the file list............................................................................................................27

4-11-4 Multi-Channel Search................................................................................................................28

4-11-5 Multi-Time Search.....................................................................................................................28

4-11-6 Multi-Day Search.......................................................................................................................28

4-12 Backup............................................................................................................................................29

4-12-1 Backup Method.........................................................................................................................29

4-13 Snapshot.........................................................................................................................................30

4-14 Direct Printing.................................................................................................................................30

4-15 PTZ Camera Control ......................................................................................................................31

4-15-1 Configuring PTZ Features.........................................................................................................31

4-15-2 Shifting to PTZ Mode ................................................................................................................31

4-15-3 PTZ Control...............................................................................................................................31

Chapter 5. System Setup..........................................................................................................................33

5-1 Main Setup........................................................................................................................................33

5-1-1 Starting the Main Setup...............................................................................................................33

5-1-2 Data Selection (Data 1 ~ Data 4)................................................................................................33

5-1-3 Shifting to Recording Setup Mode..............................................................................................33

5-1-4 Saving the Recording Settings....................................................................................................34

5-1-5 Recording Setup .........................................................................................................................34

5-1-6 Recording Schedule....................................................................................................................40

5-1-7 System ........................................................................................................................................42

5-1-8 Storage........................................................................................................................................47

5-1-9 NTP.............................................................................................................................................51

5-2 Application Setup..............................................................................................................................53

5-2-1 Selecting the Application Setup Menu........................................................................................53

5-2-2 PTZ setup....................................................................................................................................53

5-2-3 Network setup .............................................................................................................................55

eSync DVR Manual

Introduction

Chapter 1. Introduction

1-1 About the Product

The eSync Series is a digital video recorder that can monitor, record, play, archive, network, and transmit video singal

from 4, 8, and 16 cameras depending on model. Using the front buttons, remote controller, mouse, and keyboard

controller the user can control the DVR. The eSync Series offers strong networking capabilities such as remote

monitoring and remote configuration up to 128 cameras.

Powerful network functions including remote monitoring and remote system configuration are also supported.

1-2 Major Features

•Stable Standalone DVR (Embedded Linux)

•Simutanous Video output

Monitor Output: 1 BNC, 1 VGA

Loop Output: 4/8/16 BNC

Spot Output: 1 BNC

•Real Time Live/Record/Playback FPS per channel

480/480/480fps: SSA-1648e @ CIF

240/240/240fps: SSA-0824e @ Half D1 & CIF

120/120/120fps: SSA-0424e @ Full D1 & Half D1 & CIF

•Compression type : MPEG4 (video) / G.723.1 (audio)

•Backup/Copy – Ethernet, IEEE1394, USB2.0

•System operation – Front Button / Remote controller / Network / USB2.0 mouse / Keyboard controller

•Audio Input

16 channel: SSA-1648e

8 channel: SSA-0824e

4 channel: SSA-0424e

•Various network interfaces

Cable modem, Ethernet, ADSL/DHCP client

•System automation (all features are remote-controllable)

•Watchdog Feature

•HDD in Line Fault Tolerance

•Network Time Protocol support

•Various recording modes

Auto, Continuous, Motion, Audio, Sensor recording

•Multiple Scheduled recording feature

•Multi-language support

•Automatic email notification for event

•PTZ control through RS485 communication

•Remote monitoring software/Remote monitoring through the web browser/Smartphone/PDA

•Storage device

Internal storage device: Max. of 4HDD / 4TB

External storage device: Ethernet, USB2.0 IEEE1394 RAID external storage device

eSync DVR Manual

Introduction

1-3 Components

After unpacking the product, check whether the following accessories are included:

eSync CMS CD (e-Manual, CMS, PDA Viewer)

eSync User Manual

Remote Controller

Two AAA 1.5V batteries

Power Cord

Rack Mounting Handle

eSync DVR Manual

Installation and Connection

Chapter 2. Installation and Connection

2-1 Name and Features of Each Panels

The front panel of eSync Series features easy-to-use buttons for various DVR features.

The back panel consists of all the connections of devices such as (i.e. camera, audio, RS485, sensor, relay, display

output, Ethernet, IEEE1394 Firewire, etc.)

2-1-1 Front Panel

No. Name Features

1 LABEL Model Number

2 RECORD Force Record

3 USB Connection ports to USB mouse and/or memory stick

4 Number Key buttons for System Logon and Channel Number

5 ODD DVD-RW

6 Reverse Play / Fast Reverse

RELAY Backward Playback/Rewind (in Playback mode)

Relay Control (in Live mode)

7 Reverse Frame by Frame or

STATUS Backward Playback Frame by Frame (in Playback mode)

View Configuration Statistics (in Live mode)

8 PAUSE

LOCK Pause (in Playback mode)

Lock (in Live mode)

9 Forward Frame by Frame or LOG Playback Frame by Frame (in Playback mode)

View Event Log (in Live mode)

10 Forward Play / Fast Forward

PLAY Playback/Fast Forward (in Playback mode)

Starts Playback Mode (in Live mode)

11 COPY Option to Backup, Snapshot or Print from Recorded Files

12 PTZ Control Assigned PTZ

13 SEARCH Open up search window

14/15 UP/DOWN Speed Control for Playback Mode and Volume Up/Down

16 ESC Button Exits the current menu or selects the upper menu

17 MENU Access Menu options for Live / Playback mode

18 RECORD LED Green LED turned on upon HDD operation

19 NETWORK LED Green LED turned ON during remote access

20 ALARM LED Red LED turned on upon the occurrence of event or motion

21 ERROR LED Red LED turned on upon fan defect or recording interruption

22 POWER LED Power On/Off

23 SELECT Selects the current menu or selection or enable automatic screen rotation

23 Directional Buttons Navigate selection through DVR menus and change the screen display mode

24 IR Sensor IR receiver for remote control

25 USB Port Connection port to the USB2.0 devices (i.e. mouse and memory stick)

26 POWER Button Turn the system power ON or OFF

eSync DVR Manual

Installation and Connection

2-1-2 Back Panel

•16ch Back Panel (SSA-1648e/1624)

No. Name Features Type

1 AC POWER Power cable connection to the body

2 AC Selector Not Available for Americas eSync Model

3 RS485

DIO Connection for the PTZ - See chart on the lower right back panel for detail

Sensor/Relay extension board connect ion Terminal

Block

4 CAMERA IN

LOOP OUT Connection from the video camera

Connection for the video signal loop output BNC

BNC

5 AUDIO IN Audio input connection (1 Audio Per Channel) RCA

6 NTSC/PAL

VGA/TV Used to select the video input format

Used to select the video output format DA-2

7 FIREWIRE Port for external backup device via Firewire IEEE1394

8 Ethernet ADSL, cable modem, and Ethernet 10/100 Base-T connection RJ-45

9 RS-232C Serial cable connection for keyboard controller, system upgrades & checking D-SUB 9P

10 VGA Connection for VGA Monitor D-SUB 15P

11 TV Connection for TV or CCTV display monitor BNC

12 SPOT

Connection for TV or CCTV monitor connection to output image from the channel

generating an event signal (full screen) BNC

13 AUDIO OUT Audio output connection RCA

•8ch Back Panel (SSA-0824e)

•4ch Back Panel (SSA-0424e)

eSync DVR Manual

Installation and Connection

2-2 Installation and Connection

2-2-1 Connection of Devices

Connect the PTZ controller cable, audio input/output, network, and sensors as shown below.

1) PTZ Camera

Connect the PTZ data control cable to RS485 port on the terminal block on the rear side of the DVR.

Be sure to connect the PTZ data control cable to the proper terminals listed TRX+ and TRX- on the DVR.

2) SPOT Monitor

The Spot monitor can be connected to a CCTV monitor that displays events when triggered.

SPOT: The Spot monitoring function displays video from the channel detecting an event (motion, sensor, or

sound) in full screen. Events are checked every second. If events are detected from multiple channels, the latest

event is displayed.

3) Audio Input/output

Audio ports can be connected; 4/8/16 input lines and 1 output line.

4) Sensor/Relay

Connect to the rear side of the product using the cable.

Sensor Input Relay Output

4ch DVR 4 1

8ch DVR 8 2

16ch DVR 16 4

A. Sensor Connection

Connect to the DIO input port of the terminal block.

Each input terminal can be connected regardless of the channel number.

Sensor types include Normal Close (NC) and Normal Open (NO).

For more information on setup by sensor type, refer to {Data Setup} {Event Setup} {Sensor}.

Normal Close (NC): Normally closed; opens when a signal is received

Normal Open (NO): Normally open; closes when a signal is received

B. Relay Connection

Relay signals to external devices such as LED, light, or siren.

Connect the external alarm device to the COM or Out port of the sensor/relay terminal block.

Relay types include Normal Close (NC) and Normal Open (NO).

For more information on setup by sensor type, refer to {Data Setup} {Event Setup} {Sensor}.

Normal Close (NC): Normally closed; opens when a signal is received

Normal Open (NO): Normally open; closes when a signal is received

Ce manuel convient aux modèles suivants

Table des matières

Manuels DVR populaires d'autres marques

FLIR

FLIR M3100E Series Manuel utilisateur

VTRACKPRO

VTRACKPRO FPRO300 Manuel utilisateur

Swann

Swann NVR-7085 models Manuel utilisateur

XtendLan

XtendLan DVR-1670C Manuel utilisateur

urmet domus

urmet domus 1093/004AHD Manuel utilisateur

Holux

Holux M1 Manuel utilisateur

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manuel utilisateur

Whistler

Whistler D16VRS Manuel utilisateur

Defender Security

Defender Security 82-20235 Manuel utilisateur

MISUMI

MISUMI MP-WF100M Manuel utilisateur

Speco

Speco D8HU Manuel utilisateur

UST

UST DDR-E04AA Instructions d'utilisation

Consolidated

Consolidated Digital Video Recorder Manuel utilisateur

Mace

Mace DVR0404RW Guide de démarrage rapide

RCA

RCA RTD315W Manuel utilisateur

FSM

FSM Colibri Grande PRO Manuel utilisateur

Hauppauge

Hauppauge HD PVR 2 Manuel utilisateur

Identivision

Identivision ICR-PH161i PIONEER Manuel utilisateur

eSync SSA-0424e Manuel utilisateur

Manuels DVR populaires d'autres marques
