Estella 348WBMP1A Manuel utilisateur

USER MANUAL

www.EstellaEquipment.com 05/2023

#348WBMP1A

PRESS-STYLE

WAFFLE MAKER 5025815 5025815

CONFORMS TO UL STD. 197

CONFORMS TO NSF/ANSI STD. 4

www.EstellaEquipment.com2

USER MANUAL

INDEX

Serial Plate ..................................................... 2

Unboxing ........................................................ 2

Safety Precautions ................................... 3-4

Notes for First Time Use............................. 5

Changing Grids............................................. 5

Operation Instructions ................................ 6

Care & Cleaning.............................................7

Tips & Maintenance ......................................7

Troubleshooting............................................ 8

INTRODUCTION

Congratulations on your purchase of Estella Equipment. Estella Equipment takes pride in the design and quality

of our products. When used as intended and with proper care and maintenance, you will experience years

of reliable operation from this equipment. To ensure best results, it is important that you read and follow the

instructions in this manual carefully.

SERIAL PLATE

UNBOXING

Serial plate containing important electrical data,

certiﬁcations, and warnings is located on the

back of the unit.

All equipment should be examined for damage before and during unloading. The freight carrier has assumed

responsibility for its safe transit and delivery. If equipment is received damaged, either apparent or concealed,

a claim must be made with the delivering carrier.

A) Apparent damage or loss must be noted on the freight bill at the time of delivery. It must then be signed by

the carrier representative (Driver). If this is not done, the carrier may refuse the claim. The carrier can supply the

necessary forms.

B) If concealed damage is not apparent until after equipment is uncrated, a request for inspection must be

made to the carrier within 5 days. The carrier should arrange an inspection. Be certain to hold all contents and

packaging material.

Installation and service should be performed by a qualiﬁed installer who thoroughly reads, understands, and

follows these instructions.

If you have questions concerning the installation, operation, maintenance, or service of this product, visit Estella

Equipment www.estellaequipment.com.

IMMEDIATELY INSPECT FOR SHIPPING DAMAGE

ITEM:

348WBMP1A

PRODUCT DESCRIPTION:

BELGIAN, PRESS, SINGLE WAFFLE MAKER,

NON-STICK, DIGITAL

VOLTAGE:

120V | WATTAGE: 1340W

PHASE:

1 Phase | HERTZ: 60 Hertz

AMPERAGE:

11.2A | PLUG TYPE: 5-15P

SERIAL NUMBER:

CONFORMS TO UL STD. 197,

CONFORMS TO NSF/ANSI STD. 4

WARNING! Improper installation, adjustment, alteration, service or maintenance can

cause property damage, injury, or death. Read the installation, operating, and

maintenance instructions thoroughly before installing or servicing this equipment.

Commercial use only. WARNING! Disconnect from electric supply before adjustment,

alteration, servicing, or maintenance. Do not immerse in water. MADE IN CHINA

5025815 5025815

www.EstellaEquipment.com 3

USER MANUAL

SAFETY PRECAUTIONS

Potential hazard or unsafe practice, which could result in

serious injury or death.

Potential hazard or unsafe practice, which could result in

minor or moderate injury or product/property damage.

Information that needs special attention or must be fully understood,

even though not dangerous.

WARNING

CAUTION

NOTICE

• SHOCK HAZARD - Turn OFF all power to equipment before cleaning the equipment.

• FIRE HAZARD - For your safety, do not store or use gasoline or other ﬂammable vapors or liquids

in the vicinity of this or any appliances. Keep the area free and clear of combustible materials.

(See ANSI Z83. 14B, 1991).

• Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury,

or death. Read the installation, operating, and maintenance instructions thoroughly before installing

or servicing this equipment.

• A factory authorized agent should handle all maintenance and repair. Before doing any maintenance

or repair, contact your authorized service representative.

• An earthing cable must connect the appliance to all other units in the complete installation and from

there to an independent earth connection.

• These models are designed, built, and sold for commercial use only. If these models are positioned so

the general public can use the equipment, make sure that cautions, warnings, and operating instructions

are clearly posted near each unit so that anyone using the equipment will use it correctly and not injure

themselves or harm the equipment.

• This product is intended for commercial use only. Not for household use.

• Local codes regarding installation vary greatly from one area to another. The National Fire Protection

Association, Inc., states in its NFPA96 latest edition that local codes are “Authority Having Jurisdiction”

when it comes to requirements for installation of equipment. Therefore, installation should comply with

all local codes.

• The unit when installed, must be electrically grounded and comply with local codes, or in the absence of

local codes, with the national electrical code ANSI/NFPA70- latest edition. Canadian installation must comply

with CSA-STANDARD C.22.2 Number 0 M1 982 General Requirements-Canadian Electrical Code Part ll,

109-M1981-Commercial Cooking Appliances. Do not use unit if the appliance malfunctions or if the appliance,

cord, or plug has been damaged in any manner.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT REMOVE UNIT'S COVER. NO USER-

SERVICEABLE PARTS INSIDE. REPAIR SHOULD BE DONE BY AUTHORIZED SERVICE PERSONNEL ONLY

www.EstellaEquipment.com4

USER MANUAL

SAFETY PRECAUTIONS

The following safety precautions must be observed when using this product:

1. Read the relevant instructions carefully before using this product.

2. DO NOT share the same power source with other high-power appliances to avoid excessive power load

and other dangers.

3. The surface temperature of this product is very hot during operation. Burns may be caused by contact

with hot parts.

4. Keep machine away from children and non-authorized personnel. DO NOT permit them to go near the

machine or its working area.

5. DO NOT allow this product to be used unattended.

6. DO NOT touch the power cord with sharp objects or high-temperature surfaces to avoid damage to

the power cord.

7. ALWAYS check that the machine is not damaged prior to each use. Frequently check whether the power

cord and plug aren't damaged. Carefully check that all safety devices are working, that the removable parts

are not blocked, there are no parts damaged, that all the parts have been set up correctly, and that all

conditions that could inﬂuence the regular function of the machine are in working order. If the machine is

damaged or there are issues during its use, turn o the machine immediately and contact the manufacturer

for assistance or repair. Repairs should only be made by qualiﬁed technicians, using the correct

manufacturer parts. Non-compliance with these rules may void the warranty.

8. After use, press the power button to close and pull out the plug from the socket to avoid leakage or shock

due to aging insulation.

9. DO NOT submerge or saturate with water. Unit is not waterproof. DO NOT steam clean or use excessive

water on unit. DO NOT use a pressure washer. DO NOT operate if unit has been submerged or saturated

with water. ALWAYS unplug the power cord and remove, check, or clean the product after it has cooled

completely.

10. DO NOT plug or unplug the power cord with wet hands to avoid electric shock.

11. DO NOT use this unit for other than its intended use.

12. DO NOT use outdoors.

13. ALWAYS cook on a ﬁrm, dry, and level surface.

14. High temperatures will cause scalding. DO NOT touch the outer grid or grid while in operation.

15. DO NOT modify unit. This may void the warranty.

www.EstellaEquipment.com 5

USER MANUAL

NOTES FOR FIRST TIME USE

1. Read the manual carefully.

2. Check that all switches are in the OFF position.

3. Check all the accessories are complete.

4. Remove the protective ﬁlm on the surface of the product, then wipe clean the rust-preventing oil on the

surface of the product with a dry cloth.

5. The supply voltage must match the voltage speciﬁed on this machine.

6. Smoke is normal during ﬁrst use, as it’s caused from the oil inside the machine which helps to protect it from

rusting during transit.

7. These units are suitable for installation on non-combustible surfaces only. Do not install near any

combustible surfaces or any other equipment. Do not store or use gasoline or other ﬂammable vapors and

liquids in the vicinity of this or any other equipment.

Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury,

or death. Read the installation, operating, and maintenance instructions thoroughly before installing or

servicing this equipment.

CHANGING GRIDS

Additional grid styles are available. See product page for more details.

1. Use the wrench included to remove the (4) bolts for the upper grid

and the (4) bolts for the lower grid.

2. Carefully remove grid without damaging the heating element or

other components.

3. To install the new grid, align the bolt holes, and then tighten the

bolts gently. Do not over tighten and thread the holes.

www.EstellaEquipment.com6

USER MANUAL

7. When the unit beeps and

the timer display shows END,

the wae is ready.

8. Open the grid and remove

the wae with tongs.

9. Keep the grid closed between

baking periods for best

performance. Allow the unit to

return to it's target temperature

before cooking the next wae.

Power

emperature

Timer

Star t

Stop

Power

emperature

Timer

Star t

Stop

OPERATION INSTRUCTIONS

1. Press the POWER button to turn

ON the unit. The unit is preset

to the recommended settings

for waes:

Preset cook time is 3 minutes.

Preset temperature is 365°F.

2. To change the temperature set

point and/or cook time, press

the UP (▲) or DOWN (▼) arrows

next to the respective display.

3. With grids open, allow 30-45

minutes for unit to preheat.

4. While the unit is preheating,

prepare the wae mix

according to the instructions

on the product. For best

performance, always use

fresh batter and do not allow

it to warm too much.

Cook times vary based on

the mix that is used.

5. Once the unit has come to

temperature, it will beep once.

Pour the desired amount of

batter evenly into the center of

the lower grid.

Note: Be careful not to overﬁll

the grid with batter.

6. Close the top grid and press

the START/STOP button.

DO NOT remove the wae

before the timer ends.

Power

emperature

Timer

Star t

Stop

Note: The temperature display will show both the set point and the current temperature reading. When cold

batter is added to a plate, there will be a drop in temperature dierence between the set point and current

temperature reading. This is normal and will not aect baking. Under normal conditions, please allow 15-25

seconds for current temperature to recover to set point.

Note: DO NOT use metallic utensils as they will damage the non-stick coating. It is recommended to use a

soft-bristled, high-heat brush to remove any residue and crumbs from the grids to prevent burning.

www.EstellaEquipment.com 7

USER MANUAL

TIPS & MAINTENANCE

CARE & CLEANING

1. Unplug the power cable and ensure that the product is cooled completely before cleaning.

2. Clean the grids with a soft cloth or sponge dampened in a mild detergent and warm water.

ONLY use "safe for aluminum" cleaners or permanent damage may result.

3. Rinse and wipe dry to ensure no detergent residue is left on the grids.

4. For end of day or deep cleaning, remove the grids using instructions above. Then, soak grids in hot soapy

water or mild detergent. Wash with soft plastic brush. Rinse thoroughly and wipe dry. Plates MUST be

completely dry before reinstalling on unit.

5. For daily exterior cleaning, wipe the frame of the unit with a non-abrasive cloth dampened in warm water

and mild soap. Stubborn stains may be removed with a good stainless steel cleaner. Hard-to-reach areas

should be cleaned with a small soft bristle brush. We recommend using Noble Chemical Excel Stainless

Steel Cleaner for exterior cleaning.

6. Remove the drip tray and clean with a soft cloth or sponge and mild detergent.

Note: The drip tray is dishwasher safe.

• Grids MUST be open when pre-heating. If closed, the temperature inside the grid is much higher than

when open. Long periods of high temperature is not good for non-stick coating. Please allow 30-45

minutes for pre-heating from a cold start. 356-400°F is optimal operational temperature.

• If maker is not being used for periods of 20-30 minutes between use, we recommend either turning

OFF the unit OR reducing the set temperature to 175°F.

• The unit is equipped with a temperature limiter, which will shut o the unit automatically if the temperature

reaches above 554°F.

• DO NOT use any metal tool to remove wae, use wooden or plastic utensils. It's recommended to use a

high-temp soft bristle brush to remove crumbs in between uses to avoid burning.

• If black ﬂakes appear on waes or the surface, it’s recommended to stop using the unit and not serve

customers. This indicates the non-stick coating is damaged. Please replace the grids before continuing use.

• With non-stick grids, it’s not necessary to use oil or non-stick spray directly on the grid. However, if sticking

begins to occur, use a soft bristle or silicone brush to evenly coat grids with cooking oil.

• For high volume application, it may be necessary to replace wae grids every 3-4 months. Wae grids are

not dishwasher safe.

• DO NOT use a wire brush, sti brush, or other corrosive liquids to clean the grids to avoid damage

to the surface coating.

• DO NOT use an abrasive cleanser or harsh pad.

• DO NOT clean the product with a pressure washer or immerse the unit in water.

• DO NOT place damp or wet grids back into the unit.

www.EstellaEquipment.com8

USER MANUAL

TROUBLESHOOTING

ERROR CODE CAUSE SOLUTION

E-1 Thermocouple open circuit Check whether the thermocouple is in good contact

E-2 Thermocouple overheated Check whether the heater temperature is normal

E-3 After heating 4 minutes, the

temperature is below 158°F Check whether the heating line is properly connected

E-4 NTC open circuit Check whether NTC is damaged

E-5 NTC short circuit Check whether NTC is damaged

E-6 EEPROM error Replace IC

PROBLEM CAUSE SOLUTION

Unit stops heating

High limit tripped Unplug and let the unit cool

for 10 minutes

Circuit breaker tripped Check circuit breaker

One side of grid assembly stops

working

Heating element is broken

Contact customer service

Loose/broken wire connection

Black ﬂakes in batter/wae

Too much heat or abrasive

utensil use has caused damaged

to non-stick coating

Immediately stop cooking waes

and serving to customers.

Replace grids before continuing.

Controls stop working Buttons damaged or PCB damage Contact customer service

Digital Board Errors

General Problems

Table des matières

Manuels Gaufrier populaires d'autres marques

Kenwood

Kenwood PG-2000 Manuel utilisateur

BRAYER

BRAYER BR2300 Manuel utilisateur

Ricardo

Ricardo Mini Waffle Maker Guide d'installation

KYOWA

KYOWA KW-2616 Manuel utilisateur

Herenthal

Herenthal EWM-1200 Manuel utilisateur

MPM

MPM MGO-30M Manuel utilisateur

Nostalgia

Nostalgia MyMini MWF5AQ Guide rapide

SEVERIN

SEVERIN WA 2101 - Guide de l'utilisateur

Trebs

Trebs Comfortbakery 99255 Manuel utilisateur

Black & Decker

Black & Decker WMB505C Manuel utilisateur

Wilfa

Wilfa WM-623BELL Manuel utilisateur

Cuisinart

Cuisinart WAF-350C Series Manuel d'exploitation

SEVERIN

SEVERIN WA 2110 Guide de l'utilisateur

Villaware

Villaware UNO 2000 Manuel

Unold

Unold 48266 Manuel utilisateur

Royal Catering

Royal Catering RCWM-1400-B Manuel utilisateur

Curtis Stone

Curtis Stone CSWB100 Manuel utilisateur

Trebs

Trebs Comfortbakery 99257 Manuel utilisateur
