esky HN-28 Manuel utilisateur
- 1 -
Model: HN-28
Manufacturer Model: HN-028
Solar Hand Crank Radio
EN
- 2 -
Please read this user manual carefully to ensure safe use and
keep it on hand for future reference.
Description
This Esky solar hand crank radio is a compact
multifunctional device that gives access to FM/AM radio,
weather information, and an illumination whenever and
wherever you need it. Recharged by Type-c cable, solar,
and manual handcranking, the radio provides informative
listening enjoyment as well as emergency lighting in your
daily life.
Radio Operation
1.Flashlight Button: turn on/o the ashlight
2.Band Selector: switch among FM,AM
3.Tuning Dial: rotate it to select channels
4.0N/OFF/Vol+ or - Dial: turn on/o the radio increase/
decrease the volume
5.SOS Button:Audible alarm and ashlight ashing
Crank handle
Flashlight button
Tuning indicator
Flashlight
SOS
Antenna
Solar panel
Charging indicator
Speaker
ON/OFF Vol+/-
Band selector
Tuning Dial
- 3 -
Charging Instruction
A.Recharged by Type-c Cable
1. It’s the most eective, recommended way to charge the
radio.Please inse one end of the provided charging cable
into its Type-c po and the other end to the USB outlet of
your computer or a 5V power adapter.
2.The red indicator will ash in charging process, and will
change to sturdily on after being fully charged within 3 to
4 hours.
3.After being fully charged, the radio can broadcast for
continuous 28 hours with the maximum volume or
illuminate for continuous 15-20 hours with only ashlight
functioning.
4.Please fully charge the radio after receiving the parcel
Charging: Flashing red
Fully charged: Solid red
Turning indicator Charging indicator
Charging indicator status Charging indicator
Speaker
- 4 -
B. Recharged by Hand Cranking
1.Wind the hand crank either in the direction of clockwise or
counterclockwise for 3-5 minutes to activate the internal
batte for the rst time.
2.To fully charge the radio, you can lift and wind the hand
crank clockwise or counterclockwise for continuous 2 to 2.5
hours at a speed of 130rmp/min. The red indicator glows in
the whole charging process.
3.Eve one minute of continuous hand crankina can iuminate
no less than 20 minutes or broadcast for 5 to 10 minutes.
4.Due to thelaborious, long-time operation, hand cranking
often works as an emergent way to charge the radio in
outdoor conditions without power outlets.
- 5 -
C. Recharged by Solar Power
1.To charge the radio, please expose it to direct sunlight. The
red indicator glows in the whole charging process.
2.Because the output current of solar panel is relatively small,
it is dicult to fully charge the radio. Hence it is mainly
used to maintain the radio batte or rell a small amount of
energy for the device.
Notes:
1.There are 3 ways to charge the radio. No matter which
way you choose from, do not let the radio work during the
charging process because this way will shoen the device’s
batte life.Please charge the radio in the o state.
2.The device may excessively discharge or even cause failed
batte when the batte is low. Therefore, please charge
the radio with provided Type-c cable if the device works for
over 3 hours to avoid over discharge and ensure enough
batte for the next use.
3. If the radio won’t be used for a long time, please spend 2
hours per month to fully charge the radio.
4.Wind the hand crank for 3-5 minutes before each use to
activate and keep the internal batte healthy
- 6 -
Operation Instruction
1.Turn the ON/OFF/Vol+ or - Dial clockwise to power on the
radio and set a proper volume level.
2.Switch to FM or AM with the band selector. Extend the
antenna for a better signal reception
3.Turn tuning dial to select your desired station, and a yellow
tune indicator will turn on when the selected station is fully
engaged
4.When turning the tuning dial, it is normal to nd the
dialis slightly tight. This design can reduce the frequency
deviation generated during a single rotation. preventing
the inability to catch radio stations within small frequency
sections.
5.lf the radio can receive a few stations or noisy stations. this
is usually caused by the inteerence of radio wave signals.
Please operate it in an open, at place or a high position.
6.Long press the sos button to sta the sos mode, at this
time there is an alarm sound accompanied by the ashlight
ashing
Tuning indicator
Turning dial ON/OFF Vol+/-
Band selector andle
- 7 -
Charge External Devices
1.Inse one end of charging cable to the USB po of radio
and the other end to your device, then the radio will
automatically sta to charge your device.
2.The output voltage is 5V. Please make sure your device
suppos5V charging voltage before operation.
3.The maximum output current of radio is 1A. Hence, it will be
ve slow to charge an external device(e.g.a mobile phone).
The batte capacity of radio is 2000mAh (less than the
batte of your phone), so it’s dicult to fully charge your
phone or it will stop charging because of exhausted batte.
You can only expect the radio to work as an emergency
power bank to guarantee a smooth emergent conversation.
4.The provided charging cable is only for charging Type-c
devices. As for other devices. please use their original
charging cables to charge them.
5.lf the radio can not charge your phone, check whether the
cable is damaged or the radio batte is low. Please t
again with another charging cable or after fully charging
the radio.
ON/OFF Vol+/-
Band selector andle
- 8 -
Care and Maintenance
1.Wipe clean the suace of radio with a soft and damp cloth.
2. Do not clean it with any harsh abrasive solvent.
3.Although it is water-resistant, do not submerge it in water
or use it in the rain.
4.Do not charge the radio in your car in high temperature
days as it may shoen its lifespan.
Specications
Frequency range AM 520-1710kHz
FM 87-108MHz
Dimensions 128x60vx45mm/5x2.4x1.8in
Weight 230g/0.5lb
Product material ABS
Power consumption 3W(max)
Working voltage 2.7V-4.2V
Output voltage/current 5V/1A
Water-resistand level IPX3
LED ashlight 1W/60LM
Power source 3.7v 2000mAh
FCC statement
This device complies with Pa 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmfu inteerence,and (2) this
device must accept any inteerence received. including
inteerence that may cause undesired operation.
- 9 -
Modell: HN-28
Hersteller Modell: HN-028
Solar-Handkurbelradio
DE
- 10 -
Bitte lesen Sie diese Bedienungsanleitung sorgfältig durch,
um einen sicheren Gebrauch zu gewährleisten, und bewahren
Sie sie zum späteren Nachschlagen auf.
Beschreibung
Dieses Esky Solar-Handkurbelradio ist ein kompaktes
Multifunktionsgerät, das Zugang zu FM/AM-Radio,
Wetterinformationen und Beleuchtung bietet, wann und wo
immer Sie es brauchen. Aufgeladen über ein Kabel Typ-C,
Solarenergie oder über manuelles Kurbeln, bietet das Radio
informativen Hörgenuss sowie eine Notbeleuchtung in
Ihrem täglichen Leben.
Bedienung des Radios
1.Taste für Taschenlampe: schaltet die Taschenlampe ein/aus
2.Bandwahlschalter: Umschalten zwischen FM und AM
3.Drehregler: Drehen Sie ihn, um Kanäle auszuwählen
4.0N/OFF/Vol+ oder - Dial: Schalten Sie das Radio ein/aus und
erhöhen/verringern Sie die Lautstärke
5.SOS-Taste: Akustischer Alarm und Blinken der
Handkurbel
Taste für Taschenlampe
Drehregler
Taschenlampe
SOS
Antenne
Solarpanel
Ladekontrollleuchte
Lautsprecher
EIN/AUS Lautstärke+/-
Bandwahlschalter
Abstimmknopf
