Eskon EPA300 Manuel utilisateur

EPA300

USER

MANUAL

PROCESS CONTROL DEVICE

1. INDEX

1. INDEX ------------------------------------------------------------------------------------ 2

2. CONNECTIONS ------------------------------------------------------------------------- 3

3. FRONT PANEL DEFINITIONS------------------------------------------------------- 5

4. SETUP------------------------------------------------------------------------------------ 6

4.1 CONNECTION TO SENSOR DEVICE------------------------------------------------------------------ 6

4.2 DEVICE CALIBRATION---------------------------------------------------------------------------------- 7

4.3 ENTER RELAY SET VALUE ----------------------------------------------------------------------------- 8

5. OPERATING MODE: FUNCTIONS -------------------------------------------------10

5.1 Tare Function------------------------------------------------------------------------------------------ 10

5.2 Viewing the Maximum and Minimum Reading Values-------------------------------------- 10

5.3 Changing Quick Set Values------------------------------------------------------------------------- 10

5.4 Transition to Programming Mode---------------------------------------------------------------- 10

6. PROGRAMMING MODE: PROGRAMMING DIVICE ----------------------------12

6.1 Output Menu [OUT] --------------------------------------------------------------------------------- 12

6.1.1 1. Relay Output Setting (OUT-1)--------------------------------------------------------------- 12

6.1.2 2., 3., 4. Relay Output Settings (OUT-2-3-4)------------------------------------------------ 14

6.1.3 Current and Voltage Analog Output Settings (ANLOG)---------------------------------- 14

Wave Form (VAVE.F.)--------------------------------------------------------------------------------------- 14

Analog Output Scale Setting (Scale)-------------------------------------------------------------------- 14

6.1.4 UART and CANopen Digital Output Settings (DGTAL)------------------------------------ 15

6.1.5 Keypad Setting (SOUND) ------------------------------------------------------------------------ 15

6.2 Calibration Menu [CALIB] -------------------------------------------------------------------------- 15

6.2.1 Specifying Scale Values (SCALE) --------------------------------------------------------------- 15

6.2.2 Manual Calibration Method Determination (CALOP) ------------------------------------ 16

6.2.3 Number of Calibration (CL.CNT)--------------------------------------------------------------- 16

6.2.4 Automatic Calibration (START) ---------------------------------------------------------------- 16

6.3 Display Menu [DISP] --------------------------------------------------------------------------------- 16

6.3.1 Choice of decimal point location (POINT) --------------------------------------------------- 16

6.3.2 Tare Functain Settings (TARE) ----------------------------------------------------------------- 16

6.3.3 Screen Refresh Rate (REFRS) ------------------------------------------------------------------- 17

6.3.4 Blocking the on Screen Volatility (FILTR) ---------------------------------------------------- 18

6.4 Secure Menu [SECUR]------------------------------------------------------------------------------- 18

6.4.1 Hide Menu (HIDE)--------------------------------------------------------------------------------- 18

6.4.2 Menu Lock (LOCK)-------------------------------------------------------------------------------- 19

6.4.3 Set Password (PASS)------------------------------------------------------------------------------ 19

6.4.4 Return to Factory Setting (FTRY) -------------------------------------------------------------- 19

6.4.5 Restart the Device (RESET)---------------------------------------------------------------------- 19

7. WARRANTY DOCUMENT-----------------------------------------------------------21

Supply Voltage

24 VAC / DC or 85 /

265 VAC

1. Relay Output

OUT-1

2. Relay Output

OUT-2

Shown in tables

below with pin

numbers assigned.

3. Relay Output

OUT-3

4. Relay Output

OUT-4

2. CONNECTIONS

Digital Comn.

RS485

GND

RS232

GND

USB HID

USB CONNECTOR

USB VIRTUAL

USB CONNECTOR

CANopen

CAN HIGH

CAN LOW

GND

Analog

Outputs

4-20 mA

Output

4-20 mA

Output

GND

4-20 mA

Output

GND

4-20 mA

Output

GND

0-10 V

Output

0-10 V

Output

GND

0-10 V

Output

GND

0-10 V

Output

GND

Tare

Output

Tare

Input

GND

COM

SENSOR

Potentiometer

1. tip

2. tip

3. tip

4-20 mA Input

Supply

Sensor Signal

GND

0-10 V Input

Supply

Sensor Signal

GND

3,33 mV/V Input

Supply

GND

Signal(+)

Signal(-)

SAFETY WARNINGS

1. Follow the instructions and warnings in the user guide.

2. Please check the power supply type before connects energy to the device.

3. Please the device mounted on panel against dangers of fall, snap, shake

during working.

4. Make Sensor connections without energy on the device; do not connect in

any way during operation.

5. Make sure that is shielded cables between device and sensor.

6. Do not leave the device exposed to a heat source (solar, heater etc.)

7. EPA300 industrial control device is not suitable for use in the external

environment, Use only room conditions.

8. Wipe with a damp cloth to clean the device, do not use water, thinner etc.

9. Comply with the limit values specified in the technical specifications for

relay outputs.

10. The device cannot be changed by the user in the event of a fault, Please

contact our technical service in case of failure.

3. FRONT PANEL DEFINITIONS

1) PRG ( ): Programming and Enter key. It is used to enter the menus or

confirm the entered values.

2) ESC ( ): Escape, exit and backspace key. It is used to return to the upper

menu or to exit the menus.

3) UP ( ): Up key. Navigating between menus; Is used to increment the

value or move to a higher digit when entering a value.

4) DOWN ( ): Down key. Navigating between menus; Used to decrease the

value when entering a value or to switch to a lower step.

5)Set1 Status LED: 1. Display when the relay output is active.

6)Set2 Status LED: 2. Display when the relay output is active.

7)Set3 Status LED: 3. Display when the relay output is active.

8)Set4 Status LED: 4. Display when the relay output is active.

9)Min Status LED: Lights up when the lowest (minimum) value read from the

moment the device starts to operate.

10)Max Status LED: Lights up when the maximum read value is displayed

when the device starts operating.

11)Tare Status Led: Indicator that is lit when the key function is active.

12) Display Screen: Display screen consisting of 5 lines from a single line.

13) LED bar: The entered scale values increase and decrease in range.

4. SETUP

4.1 CONNECTION TO SENSOR DEVICE

Potentiometer connections:

Connections of 4-20mA or 0-10 V sensors:

Linear potentiometer

Pressure sensor with 4-20 mA

or 0-10 V output

3.33 mV / V Ratiometric Sensor connections:

4.2 DEVICE CALIBRATION

Your device is calibrated automatically according to factory settings and operates in

the 0-100 value range. That is, the smallest reading on the sensor shows 0 on the

screen and 100 on the screen. You can change this scale from the calibration menu.

Use S-LO for the minimum value that will be shown on the screen, S-HI for the

maximum value.

(Keep it pressed)













The decimal point

starts flashing. Use

the UP and DOWN

keys to select the

decimal point.

Press and hold the UP and DOWN

keys to move to the next step. To

enter a negative (-) value, press

the DOWN key to come to one of

the non-digitized steps.

When PRG key is

pressed and entered,

the value input screen

opens. Enter the

desired value using

the UP and DOWN

keys.







The new S-LO value you confirmed with the PRG key has been

set. Press UP to move to S-HI.

After specifying the S-LO value, you can do the same for the S-HI value.

4.3 ENTER RELAY SET VALUE

Set the SET values for the relay outputs of your device to be activated. For SET-1

value:

2. Set the SET-2 value for Relay output:

(Keep it pressed)













The decimal point

starts flashing. Use the

UP and DOWN keys to

select the decimal

point.

Press and hold the UP and DOWN

keys to move to the next step. To

enter a negative (-) value, press

the DOWN key to come to one of

the non-digitized steps.

When PRG key is

pressed and entered,

the value input screen

opens. Enter the

desired value using

the UP and DOWN

keys.







The new S-LO value you confirmed with the PRG key has

been set. Press UP to move to S-HI.

(Keep it pressed)













When PRG key is

pressed and entered,

the value input screen

opens. Enter the

desired value using

the UP and DOWN

keys.







The new S-LO value you confirmed with the PRG key has

been set. Press UP to move to S-HI.

The decimal point

starts flashing. Use the

UP and DOWN keys to

select the decimal

point.

Press and hold the UP and DOWN

keys to move to the next step. To

enter a negative (-) value, press

the DOWN key to come to one of

the non-digitized steps.

3. Set the SET-3 value for Relay output:

4. Set the SET-4 value for Relay output:

(Keep it pressed)













The decimal point

starts flashing. Use the

UP and DOWN keys to

select the decimal

point.

Press and hold the UP and DOWN

keys to move to the next step. To

enter a negative (-) value, press

the DOWN key to come to one of

the non-digitized steps.

When PRG key is

pressed and entered,

the value input screen

opens. Enter the

desired value using

the UP and DOWN

keys.







The new S-LO value you confirmed with the PRG key has

been set. Press UP to move to S-HI.

(Keep it pressed)















The decimal point

starts flashing. Use the

UP and DOWN keys to

select the decimal

point.

Press and hold the UP and DOWN

keys to move to the next step. To

enter a negative (-) value, press

the DOWN key to come to one of

the non-digitized steps.

When PRG key is

pressed and entered,

the value input screen

opens. Enter the

desired value using

the UP and DOWN

keys.







The new S-LO value you confirmed with the PRG key has

been set. Press UP to move to S-HI.

5. OPERATING MODE: FUNCTIONS

Your EPA300 process controller operates in two different modes. Your device is in

'operating mode' while the initial value of the sensor readout is displayed; In the

'programming mode' on the screen where the settings are changed and the parameters are

changed. In this section, the functions in operating mode are explained.

5.1 Tare Function

***Only works when the Tare function is active. For activating or explaining the types of functions,

6.3.2 Setting the Tare Function

Each time the UP key is pressed while the unit is in the operating mode, the Tare function is

activated according to the type of the selected function and the Tare status lights up.

5.2 Viewing the Maximum and Minimum Reading Values

If you press the DOWN key while the unit is in operating mode, you can see the lowest

(minimum) value read from the moment the unit starts to operate. At the same time, Min

status will flash on the screen.

When you press the DOWN key again, you can see the highest (maximum) value read from

the moment the device starts to operate. At the same time Max will be on the screen.

5.3 Changing Quick Set Values

Press and hold the ESC key to quickly change all adjustable setpoints while the unit is

in run mode. You can then change the desired SET value by pressing the PRG key. When

entering a value, press and hold the UP and DOWN keys to move to the next step. To enter a

negative (-) value, press the DOWN key to come to one of the non-digitized steps.

5.4 Transition to Programming Mode

To switch your device from working mode to programming mode













(Keep it pressed)















Autres manuels pour EPA300

Table des matières

Autres manuels Eskon Contrôleurs

Eskon

Eskon EPA 200 Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
