. . . . MODEL TSC-1005C, CA & CM INTERCOMS
INSTALLATION AND OPERATION P/N 0219-0019B
Intwire.sht
═══════════════════════════════════════════════════════════════════════════
DESCRIPTION
The Model TSC-1005C is a 5 channel 2-way intercom with a CALL-IN and external input capability. The TSC-1005CA
has all the features as the TSC-1005C including a siren type alarm. The TSC-1005CM has a 13” Top mounted flex
microphone. They were designed to suit such applications as service stations, C stores, truck stops, or fast food
restaurants. We recommend the use of ESCO speakers and interconnect cable for the best voice quality reproduction.
Please read these instructions carefully before installing your intercom system.
FEATURES:
A) VOLUME CONTROL / ON-OFF SWITCH: Located at the left of the intercom cabinet. Click "on" by rotating the
knob clockwise (POWER ON lamp will illuminate red). Continue rotating clockwise to increase volume.
B) TALK / LISTEN SWITCH: Located at the right of the intercom cabinet, depress to "talk" (or operate alarm on
Model TSC-1005CA only), release to "listen".
C) STATION SELECTOR SWITCHES: Located to the left of the TALK/LISTEN switch. To select station, depress
switch with corresponding station number. More than one station can be selected at the same time by
depressing corresponding station switches simultaneously. To deselect stations, depress any unselected
station switch halfway.
D) CALL-IN FEATURE: Connections located on bottom of intercom. The CALL-IN feature enables the customer
to alert the operator with a beeping tone by depressing a remote mounted CALL-IN button.
E) STANDBY: When all 5 stations are deselected, the intercom is in a silent "standby" mode.
F) EXTERNAL INPUT: Connections located on bottom of intercom. The external input feature enables the
intercom owner to route a message repeater or music to any deselected speaker stations. When a speaker
station is selected the external signal is disconnected from that speaker station.
G) VOLUME CONTROL: (Talk out): Located inside of the intercom, adjustment is made from the bottom of the
unit. This adjustment will increase (counterclockwise), or decrease (clockwise) the outside speaker volume.
H) ALARM SWITCH: Located on the rear of the intercom. Only the Model TSC-1005CA has a built-in siren type
alarm. Operation of the alarm can be obtained by pressing the TALK/LISTEN and the ALARM buttons at the
same time. The alarm will be broadcast over the remote speakers that have been selected. A rising and falling
police type alarm can be simulated by holding the TALK/LISTEN button down and pressing and releasing the
ALARM button.
FOR FURTHER INFORMATION CONTACT THE ESCO OFFICE IN YOUR AREA
ESCO Services, Inc. ESCO Manufacturing, Inc. ESCO Services, Inc.
Denver, Colorado Tampa, Florida Sterling Heights, Michigan
TOLL FREE (800) 824-5579 TOLL FREE (800) 237-9710 TOLL FREE (800) 521-1808
In Colorado (720) 382-2000 In Florida (813) 855-9466 In Michigan (586) 254-3367
TELEFAX (720) 382-2001 TELEFAX (813) 855-1649 TELEFAX (586) 254-2767
1
RECOMMENDED SPEAKER CABLE
All speaker cables must be twisted-pair (unshielded or shielded) containing 18 or 22 gauge wire. If using a shielded cable
(ESCO# 408-0035), ground the shield at the inside end only. Use of twisted pair cable (ESCO# 408-0036) provides
easiest connection to each Sub-station speaker. All speaker cables must route through a conduit that is SEPARATE from
those containing 120VAC power wiring.
DO NOT UNDER ANY CIRCUMSTANCES ROUTE AUDIO CABLES IN THE SAME CONDUIT WITH 120VAC WIRING.
THIS VIOLATES THE NATIONAL ELECTRICAL CODE AND PRESENTS A HAZARD.
INSTALLATION OF THE TSC-1005C, TSC-1005CA OR TSC1005CM
A. Key points for greater sound quality.
1) Use recommended 18-22 gauge twisted pair wire.
2) Run cable separately away from high voltage power wiring.
3) Sub-station speakers mounted in close proximity of Master-station may result in a howl (acoustical feedback) when
either one calls the other. This condition can be corrected by lowering volume or repositioning Sub-station
speaker.
B. Speaker and Call switch mounting.
1) We recommend that you use ESCO Speakers and Call switches for optimum performance.
2) Mount Speakers and Call switches per the installation and application guide included.
C. Wiring
1) Run an appropriate length of ESCO# 408-0035 or 408-0036 speaker cable from each remote speaker and call
switch to the area where the intercom is to be located (tagging wire ends is recommended to avoid confusion when
final connection is made to intercom).
2) Strip 3/16" of insulation from the end of each wire and twist the strands together.
3) Connection of the remote speakers and call switches to the intercom should be as follows:
Speaker #1 connects to terminals marked Station #1.
Speaker #2 connects to terminals marked Station #2.
Speaker #3 connects to terminals marked Station #3.
Speaker #4 connects to terminals marked Station #4.
Speaker #5 connects to terminals marked Station #5.
All call switches connect to terminals marked Call.
4) After completing installation, tie wires to bundle platform attached to intercom with a tie-wrap to insure no
movement of interconnect wiring.
5) Power unit up and check operation of all connected speakers. If volume is to low or an acoustical feedback is
present, adjust outside speaker volume (located under intercom) accordingly.
6) To insure proper warranty protection, be sure to fill out warranty registration information and return immediately.
2
Available options for the ESCO TSC-1005 intercom
___________________________________________________________________________________
Deluxe horn speaker
Model #SPK-1001 ESCO #0216-0003
7.0"H x 10.7"W x 9.1"D
8 Ohm, 15 Watt. Wide angle paging projector. Molded ABS horn and zinc die cast universal swivel mount. Indoor or
outdoor applications
Economy horn speaker
Model #SPK-1002 ESCO #0216-0002
5.75"H x 5.25"W x 6.50"D
8 Ohm, 10 Watt. Molded plastic horn, steel tilt mounting bracket. Indoor or outdoor use.
3.25" pump speaker
Model #SPK-1012 ESCO #0216-0008
3.44"W x 1.35"H
8 Ohm, 3 Watt, 7 Watt MAX. Solder terminals. Dust, smoke & moisture resistant.
Speaker/call box
Model #SPK-1003 ESCO #0941-0006
5.25"H x 7.5"W x 2.0"D
Polished stainless steel enclosure with rain lip. Momentary push-button for call. 8 Ohm, 3 Watt, 7 Watt MAX, dust &
moisture resistant speaker. 1 rear & 1 bottom dual size conduit knockout. Internal terminal strip for wiring.
Call switch box
Model #SPK-1005 ESCO #0941-0007
4.5"H x 2.75"W x 2.25"D
Standard industrial single gang box enclosure. Suitable for wet locations. Red momentary push button for call.
Speaker box
Model #SPK-1009 ESCO #0941-0009
Polished stainless steel enclosure with rain lip. 8 Ohm, 3 Watt, 7 Watt MAX, dust & moisture resistant speaker. 1 rear &
1 bottom dual size conduit knockout.
8” Pre-assembled ceiling speaker assembly with volume control
Model #SPK-1019 ESCO #0216-0040
8” 10 ounce dual cone speaker, 8 ohm impedance with a premounted dual voltage 10 watt line matching transformer.
High impact ABS white grill. Adjustable volume control.
Heavy duty outdoor handset
Model #SPK-1013 ESCO #0941-0002
4.5"H x 4.5"W x 2.25"D (Enclosure only)
Standard industrial dual gang box enclosure. Suitable for wet locations. Standard black handset w/polished armored
cable. Hearing aid compatible receiver per EIA Standard RS-504. Response-200 to 3200 Hz/Sensitivity-minimum 72db
@ 1KHz/Impedance-150 ohms nominal. Internal prewired terminal strip w/location for second external speaker. Handset
on when removed from cradle, second speaker on when handset on cradle. "Call" when handset lifted off cradle.
Impedance matching transformer
Model SPK-1010 ESCO #0204-0080
Four flying leads for installation. Two mounting ears. Necessary when using external music input. Matches five--8 ohm
parallel loads.
Individual speaker volume control:
Model #SPK-1011 ESCO #0205-0008
Single shaft, triple solder lug terminals. 8 Ohm, 25 Watt. Panel or baffle mount.
Shielded speaker wire
Model #SPK-1006 ESCO #0408-0035
20AWG, one pair w/shield, jacketed
Twisted pair speaker wire
Model #SPK-1004 ESCO #0408-0036
20AWG, 2 conductor, jacketed
3
4
ESCO INTERCOM SYSTEMS & OPTION LIST:
MODEL # PART # DESCRIPTION
TSC-1008MV................. 0941-0012 ....................E-Model 8 station intercom w/ 1 mounted flex-mic & VOX
TSC-1008 ...................... 0941-0010 ....................E-Model 8 station intercom w/ 1 internal mic, no VOX
TSC-1008V-R1.............. 0941-0019....................E-Model 8 station intercom w/ 1 remote flex mic & VOX
TSC-1008V-R2.............. 0941-0013....................E-Model 8 station intercom w/ 2 remote flex mics & VOX
TSC-1008MV-R1........... 0941-0015....................E-Model 8 station intercom w/ 1 mounted flex-mic & 1 remote flex mic & VOX
TSC-1012MV................. 0941-0016 ....................E-Model 12 station intercom w/ 1 mounted flex-mic & VOX
TSC-1012 ...................... 0941-0014 ....................E-Model 12 station intercom w/ 1 internal mic, no VOX
TSC-1012V-R1.............. 0941-0020....................E-Model 12 station intercom w/ 1 remote flex mic & VOX
TSC-1012V-R2.............. 0941-0017....................E-Model 12 station intercom w/ 2 remote flex mics & VOX
TSC-1012MV-R1........... 0941-0018....................E-Model 12 station intercom w/ 1 mounted flex-mic & 1 remote flex mic & VOX
TSC-1012MV-R2........... 0941-0026....................E-Model 12 station intercom w/ 1 mounted flex-mic & 2 remote flex mics & VOX
TSC-1005C ................... 0941-0004 ....................5 Station w/call & 1 internal mic (no VOX available)
TSC-1005CA ................. 0941-0005 ....................5 Station w/call, 1 internal mic & alarm (no VOX available)
TSC-1005C-R1.............. 0941-0021 ....................5 Station w/call & 1 Remote Flex-mic (no VOX available)
TSC-1005C-R2.............. 0941-0022 ....................5 Station w/call & 2 Remote Flex- mics (no VOX available)
TSC-1005CM ................ 0941-0027 ....................5 Station w/call & 13” Top Mounted Flex mic (no VOX available)
TSC-1005CM-R1........... 0941-0029 ....................5 Station w/call & 13” Top Mounted Flex mic & 1 Remote Flex- mic (no VOX available)
TSC-1005CAM .............. 0941-0028 ....................5 Station w/call / alarm & 13” Top Mounted Flex mic (no VOX available)
0502-0129 ..................... 0502-0129 ....................6' quick disconnect interconnection cable
0502-0135 ..................... 0502-0135 ....................10' quick disconnect interconnection cable
0502-0136 ..................... 0502-0136 ....................15’ quick disconnect interconnection cable
0204-0074 ..................... 0204-0074 ....................Wallmount E-model intercom transformer
0502-0148 ..................... 0502-0148 ....................13" (16" true w/flange & mic) External flex mic
0502-0149 ..................... 0502-0149 ....................19"(21" true w/flange & mic) External flex mic
SPK-1001 ...................... 0216-0003 ....................Deluxe horn speaker
SPK-1002 ...................... 0216-0002 ....................Economy horn speaker
SPK-1019 ...................... 0216-0040 ....................8” Ceiling speaker, 12” white grill w/ mounted volume control
SPK-1012 ...................... 0216-0008 ....................3.25" pump speaker
SPK-1003 ...................... 0941-0006 ....................Stainless steel speaker/call box
SPK-1005 ...................... 0941-0007 ....................Call switch box
SPK-1009 ...................... 0941-0009 ....................Stainless steel speaker box
SPK-1013 ...................... 0941-0002 ....................Heavy duty handset
SPK-1018 ...................... 0941-0031 ....................Management Security Speaker
SPK-1010 ...................... 0204-0080 ....................Impedance matching transformer
SPK-1011 ...................... 0205-0008 ....................Individual speaker volume control
SPK-1006 ...................... 0408-0035 ....................Shielded speaker wire
SPK-1004 ...................... 0408-0036 ....................Twisted pair speaker wire
+
-
+
-
+
-
+
-
+
-
STATION #1
STATION #2
STATION #3
STATION #4
STATION #5
EXTERNAL INPUT
CALL-IN
TRANSFORMER
ESCO #941-0006
SPEAKER/CALL SWITCH
HORN SPEAKER
HORN SPEAKER
ESCO #941-0006
SPEAKER/CALL SWITCH
ESCO #941-0006
SPEAKER/CALL SWITCH
ESCO #941-0007
ESCO #941-0007
CALL SWITCH
CALL SWITCH
SEE NOTE #2
NOTES
INTWIRE.SHT
#204-0070
WALL MOUNT
TRANSFORMER
ESCO #216-0003
ESCO #216-0003
#1 All speaker cable must be shielded or twisted pair containing 18 or 22 gauge wire.
SEE NOTE #1
SEE NOTE #1
SEE NOTE #1
SEE NOTE #1
SEE NOTE #1
#2 Use an impedance matching transformer (P/N 0204-0080) with any message repeater or music input.
Music/message crosstalk may occur on intercom internal listen speaker when external input signal strength is too large.
TSC-1005C & TSC-1005CA
1
INTERCOM INTERCONNECT WIRING DIAGRAM
ESCO SERVICES INC.
A
11Monday, May 06, 2002
MICHIGAN FLORIDA COLORADO
Title
Size Document Number Rev
Date: Sheet of
PRESS TO
CALL
PRESS TO
CALL
PRESS TO
CALL
PRESS TO
CALL
PRESS TO
CALL
+
-
8 ohm
OUTPUT
ESCO P/N 0204-0080
TO EXTERNAL INPUT
RED
RED
BLACK
BLACK
JUMPER
(CUSTOMER SUPPLIED)
AMPLIFIER MODEL# SPK-1010
SIGNAL IN
HOOK-UP/EXTERNAL IN
RED
RED
+
-
AMP
+
-
BLACK
BLACK
+
-
OF INTERCOM
TO EXTERNAL IN OF INTERCOM
NOTES: 1. FOR USE WITH E-MODEL INTERCOM, POINTS A AND B
ARE JB3-1 AND JB3-2 RESPECTIVELY, OF J-BOX.
ON TERMINAL STRIP UNDERNEATH UNIT.
2. FOR USE WITH TSC-1005 SERIES, POINTS A AND B ARE LOCATED
A
B
A
B
IMPEDANCE MATCHING TRANSFORMER
12 Watt
IMPXFMR.SHT
A
IMPEDANCE MATCHING TRANSFORMER CONNECTION
ESCO SERVICES, INC.
A
11Monday, May 06, 2002
Title
Size Document Number Rev
Date: Sheet of
