EF5000
OUTDOOR GAS FIREPLACE
USER GUIDE
North America
630299_0
www.escea.net
SERIAL NUMBER 71000 AND ABOVE
17 Carnforth st, Green Island
Dunedin, New Zealand
E-mail: [email protected]
Web: www.escea.com
Phone: 1 866 615 3096
The area surrounding the appliance must be clear and free from combustible
materials, gasoline and other flammable vapors and liquids.
This appliance must not be installed or used indoors.
Children and adults should be alerted to the hazards of high surface
temperatures and should stay away to avoid burns or clothing ignition.
Young children should be carefully supervised when they are in the area of
the appliance.
Clothing or other flammable materials should not be hung from the
appliance, or placed on or near the appliance.
Any guard or other protective device removed for servicing the appliance
must be replaced prior to operating the appliance.
Installation and repair should be done by a qualified service person. The
appliance should be inspected before use and at least annually by a
qualified service person. More frequent cleaning may be required as
necessary. It is imperative that control compartment, burners and circulating
air passageways of the appliance be kept clean.
Do not use this appliance if any part has been under water. immediately call
a qualified service technician to inspect the appliance and to replace any
part of the control system and any gas control which has been under water.
Under no circumstances should you touch the coals or metalwork during
operation.
Any service work carried out on this appliance must only be done by a
recognised escea technician or authorized personnel.
The data plate for this appliance, containing technical information and
specifications, can be found to the right of the control tray, near the
base of the fire. To access this, the fascia must be removed.
Contents
Basic Operation 1
Removing the Fascia 4
Replacing Batteries 5
Cleaning and Maintenance 6
Warranty Information 7
Basic Operation
On / Off
Flame Up
Flame Down
The EF5000 is operated by the touch control located on the Right hand
side outer edge of the fascia. The basic operations possible from the
touch control are ON/OFF and manual adjustment of the flame height.
To turn on the fire push the ON-OFF button on the touch control.
The pilot will start sparking and gas will start flowing to the pilot
which should light and be visible in a few seconds.
The ignition process takes a duration of 30 seconds. No other button
should be pressed during those 30 seconds.
Ignition:
UP
DOWN
ON-OFF
Basic Operation
While the fire is on, push the FLAME UP button or the FLAME
DOWN button to increase or decrease the flame height.
If the FLAME UP button is pushed while the fire is on HIGH burner
flame position, nothing will happen. Similarly if the FLAME DOWN
button is pushed while fire is in the PILOT flame position, nothing will
happen.
Adjusting the flame height:
To turn the fire off, you must push the ON/OFF button. This will shut
down the gas flow to the pilot flame and both burners.
Turning off the fire:
Basic Operation
Wait 15 seconds...
High
Low
Pilot
Flame Up Flame Up
Flame Down Flame Down
-Check batteries are charged
and inserted correctly.
-Check that the cable connecting
the fascia to the fireplace is
connected.
Removing the Fascia
The EF5000 Stainless Steel fascia is attached to the fire by four
'hooks' on the corners of the fascia. If you need to remove the fascia,
first give the fascia a brief lift upwards as shown.
Now pull the fascia towards you, and rest the Fascia on the brackets
half way down the firebox, or on the ground while you unplug the cord
connecting the fascia to the fire.
Reverse these steps to re-fit the Fascia, ensuring the cord is correctly
plugged in by testing the fire.
Brackets to rest the
top fascia hooks on
while disconnecting
the control cords.
Replacing Batteries
The EF5000 uses 4x AA sized batteries, To access the battery pack
you will need to remove the fascia (as described on previous page).
When the fascia has been removed, you will find the battery pack
located in the lower right of the fire, velcroed to the chassis wall.
Pull the battery pack away from the outer wall.
Slide the battery pack lid off to access the batteries for
installation/replacement of the batteries.
Battery Pack
Cleaning your EF5000
Note: Always ensure the fireplace is cold before starting any cleaning
or maintenance.
To clean the glass and stones in the front stone tray, first remove the
stones from inside the tray and the glass will then be free to slide
upwards.
The glass can be cleaned using standard window cleaner. The quartz
stones can be washed using soapy water
To clean the weather cover warm soapy water should be used.
Cleaning of the ceramic stones and burners can be carried out using a
brush and a dry cloth
Fascia:
The Fascia is the visible surround of your Escea Gas Fireplace and
must be treated carefully to prevent unsightly marks from tarnishing
the visual quality of the product. Some marking over time is inevitable
however, so the following directions will assist you in getting the
maximum enjoyment from your Escea Gas Fireplace.
Never ever rub the fascia.
The outside of an Escea Fascia must only be cleaned with a soft microfibre
cloth. If heavier cleaning is required for the likes of grease or stubborn
fingerprint removal we recommend the use of: Steel Kleen brand Ezi Wipes
for stainless steel fascias only, and warm soapy water for powder coated
fascia’s. These recommendations have been tested by Escea technicians
and produce satisfying results when used correctly. Instructions for their use
follows:
Cleaning your EF5000
For Stainless Steel Fascias (Outdoor and Direct Vent products):
1. Ensure that the Gas Fireplace is off, and that the fascia is cold.
2. Using the gloves provided with your fascia, remove the towelette from the sachet
and wipe the fascia with even, straight strokes.
3. Make sure your strokes follow the direction of the grain or brush finish. Wiping
across the grain can leave small scratches.
4. The wipe will leave a very fine film over the fascia, ensure this film is distributed
evenly.
5. If the film is applied too heavily and is quite visible, you can remove the excess by
gently wiping dry with a microfibre cloth. Ensure your strokes still follow the direction
of the grain or brush finish.
6. Ensure that no film is applied to the glass of your Escea Gas Fireplace. If applied
accidentally, wipe off with an absorbent microfibre cloth.
For Powder Coated Fascias (Inbuilt, Outdoor and Direct Vent products):
1. Ensure that the Gas Fireplace is off, and that the fascia is cold to the touch.
2. Using the gloves provided with your fascia, gently clean the fascia with a cloth
and warm soapy water.
3. Wipe off with an absorbent microfibre cloth.
