OrigoMag C140

Instruction manual

ENGLISH

−2 −

TOCe

1 DIRECTIVE 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 SAFETY 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 INTRODUCTION 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 Equipment 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4 TECHNICAL DATA 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5 INSTALLATION 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.1 Placing 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.2 Assembly of components 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.3 Electrical installation 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.4 Mains power supply 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6 OPERATION 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.1 Connection and control devices 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.2 Functions explanation 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7 MAINTENANCE 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.1 Inspection and cleaning 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8 FAULT TRACING 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9 ORDERING OF SPARE PARTS 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DIAGRAM 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

WEAR COMPONENTS 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ACCESSORIES 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

−3 −

OC140e

1 DIRECTIVE

DECLARATION OF CONFORMITY

ESAB Welding Equipment AB, S−695 81 Laxå, Sweden, gives its unreserved guarantee that welding

power source OrigoMag C140 from serial number 507 complies with standard IEC/EN 60974−1, in

accordance with the requirements of directive (73/23/EEC) and addendum (93/68/EEC) and with

standard EN 60974−10 in accordance with the requirements of directive (89/336/EEC) and addendum

(93/68/EEC).

−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−

Henry Selenius

Vice President

ESAB Welding Equipment AB

695 81 LAXÅ

SWEDEN Tel: + 46 584 81000 Fax: + 46 584 411924

Laxå 2005−08−31

2 SAFETY

Users of ESAB welding equipment have the ultimate responsibility for ensuring that anyone who

works on or near the equipment observes all the relevant safety precautions. Safety precautions

must meet the requirements that apply to this type of welding equipment. The following recommen-

dations should be observed in addition to the standard regulations that apply to the workplace.

All work must be carried out by trained personnel well−acquainted with the operation of the welding

equipment. Incorrect operation of the equipment may lead to hazardous situations which can result

in injury to the operator and damage to the equipment.

1. Anyone who uses the welding equipment must be familiar with:

Sits operation

Slocation of emergency stops

Sits function

Srelevant safety precautions

Swelding

2. The operator must ensure that:

Sno unauthorised person is stationed within the working area of the equipment when it is

started up.

Sno−one is unprotected when the arc is struck

3. The workplace must:

Sbe suitable for the purpose

Sbe free from draughts

4. Personal safety equipment

SAlways wear recommended personal safety equipment, such as safety glasses, flame−proof

clothing, safety gloves.

SDo not wear loose−fitting items, such as scarves, bracelets, rings, etc., which could become

trapped or cause burns.

5. General precautions

SMake sure the return cable is connected securely.

SWork on high voltage equipment may only be carried out by a qualified electrician.

SAppropriate fire extinquishing equipment must be clearly marked and close at hand.

SLubrication and maintenance must not be carried out on the equipment during operation.

−4 −

OC140e

WARNING

READ AND UNDERSTAND THE INSTRUCTION MANUAL BEFORE INSTALLING OR OPERATING.

ARC WELDING AND CUTTING CAN BE INJURIOUS TO YOURSELF AND OTHERS. TAKE PRECAU-

TIONS WHEN WELDING. ASK FOR YOUR EMPLOYER’S SAFETY PRACTICES WHICH SHOULD BE

BASED ON MANUFACTURERS’ HAZARD DATA.

ELECTRIC SHOCK −Can kill

SInstall and earth the welding unit in accordance with applicable standards.

SDo not touch live electrical parts or electrodes with bare skin, wet gloves or wet clothing.

SInsulate yourself from earth and the workpiece.

SEnsure your working stance is safe.

FUMES AND GASES −Can be dangerous to health

SKeep your head out of the fumes.

SUse ventilation, extraction at the arc, or both, to take fumes and gases away from your breathing zone

and the general area.

ARC RAYS −Can injure eyes and burn skin.

SProtect your eyes and body. Use the correct welding screen and filter lens and wear protective

clothing.

SProtect bystanders with suitable screens or curtains.

FIRE HAZARD

SSparks (spatter) can cause fire. Make sure therefore that there are no inflammable materials nearby.

NOISE −Excessive noise can damage hearing

SProtect your ears. Use earmuffs or other hearing protection.

SWarn bystanders of the risk.

MALFUNCTION −Call for expert assistance in the event of malfunction.

PROTECT YOURSELF AND OTHERS!

WARNING!

Read and understand the instruction manual

before installing or operating.

Do not use the power source for thawing frozen pipes.

WARNING!

This product is solely intended for arc welding.

−5 −

OC140e

3 INTRODUCTION

OrigoMag C140 are step controlled power sources in a compact design, intended for welding with

solid steel, stainless steel or tubular wire with or without shielding gas.The possibility of welding with

homogeneous wire/shielding gas and welding with gasless tubular wire is obtained by switching the +

and −connections on the switching terminal by the wire feed unit.

ESAB’s accessories for the product can be found on page 14.

3.1 Equipment

The power source is supplied with:

SWelding gun

SReturn cable with return clamp

SInstruction manual

4 TECHNICAL DATA

OrigoMag C140

Voltage 230V, 1∼50/60Hz

Permissible load at

100% duty cycle 42A

60 % duty cycle 54A

20 % duty cycle 100A

Setting range (DC) 35A−130A

Open circuit voltage 20−28V

Open circuit power 90W

Power factor at max load 0,92

Control voltage 230V, 50/60Hz

Wire feed speed 2,0−14m/min

Welding gun connection fixed

Wire dimension range 0,6−0,8(Fe)

0,8(cored)

0,8(CuSi)

Max diameter/weight

of wire bobin 200mm/5kg

Dimensions lxwxh 650x300x550

Weight 25kg

Operating temperature −10 ÷+40oC

Enclosure class IP 23

Application classification

Duty cycle

The duty cycle refers to the time as a percentage of a ten−minute period that you can weld at a cer-

tain load without overloading.

Enclosure class

The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid

objects or water. Equipment marked IP23 is designed for indoor and outdoor use.

−6 −

OC140e

Application class

The symbol indicates that the power source is designed for use in areas with increased

electrical hazard.

5 INSTALLATION

The installation must be executed by a professional.

5.1 Placing

Position the welding power source such way that its cooling air inlets and outlets are

not obstructed.

5.2 Assembly of components

−7 −

OC140e

5.3 Electrical installation

−8 −

OC140e

5.4 Mains power supply

Check that the unit is connected to the correct mains power supply voltage, and that it is protected by

the correct fuse size. A protective earth connection must be made, in accordance with regulations.

Rating plate with supply connection data

OrigoMag C140

Voltage V 230V, 1∼50/60Hz

Current A

at 100% duty cycle 5,4

at 60% duty cycle 7,6

at 20% duty cycle 13,8

Cable area mm23 x 1.5

Fuse slow A 10

NB: The mains cable areas and fuse sizes as shown above are in accordance with Swedish

regulations. They may not be applicable in other countries: make sure that the cable area and fuse

sizes comply with the relevant national regulations.

6 OPERATION

General safety regulations for the handling of the equipment can be found on

page 3. Read through before you start using the equipment!

WARNING!

Rotating parts can cause injury, take great care.

WARNING −TIPPING RISK!

There is a risk of tipping while transportation and operation, if the welding machine leans

more than 10o. In that case appropriate securing has to be provided !

−9 −

OC140e

6.1 Connection and control devices

1Welding voltage switch

OFF + 4 steps (mains ON/OFF) 4Return cable with clamp, fixed

2Orange indicating lamp, overheating 5Knob for wire speed setting

3Welding gun, fixed

6.2 Functions explanation

6.2.1 Overheating protection

If the internal temperature becomes too high, the welding is interrupted and disabled.

This state is indicated by lighting of the orange indicating lamp [2] on the front of the ma-

chine. It resets automatically when the temperature has fallen.

7 MAINTENANCE

Regular maintenance is important for safe, reliable operation.

Note!

All guarantee undertakings from the supplier cease to apply if the customer himself

attempts any work in the product during the guarantee period in order to rectify any

faults.

7.1 Inspection and cleaning

Check regularly that the power source is free from dirt.

The power source should be regularly blown clean using dry compressed air at reduced

pressure. More frequently in dirty environments. Otherwise the air inlet/outlet may be-

come blocked and cause overheating.

−10 −

OC140e

Welding gun

SCleaning and replacement of the welding gun’s wear parts should take place at

regular intervals in order to achieve trouble−free wire feed. Blow the wire guide

clean regularly and clean the contact tip.

8 FAULT TRACING

Try these recommended checks and inspections before sending for an authorised service technican.

Type of fault Actions

No arc SCheck that the mains power supply switch is turned on.

SCheck that the welding current supply and return cables are

correctly connected.

SCheck that correct current value is set.

Welding current is interrupted

during welding

SCheck whether the thermal overload trip has operated

(indicated by the orange lamp on the front).

SCheck the main power supply fuses.

Thermal overload trips

operate frequently

SCheck to see whether the air inlets/outlets are clogged.

SMake sure that you are not exceeding the rated data for the

power source (i.e. that the unit is not being overloaded).

Poor welding performance SCheck that the welding current supply and return cables are

correctly connected.

SCheck that the correct current value is set.

SCheck that the correct welding wires are being used.

SCheck the main power supply fuses.

SCheck the wire feed unit −if proper rolls are applied and

properly set the pressure of the wire feeder’s pressure rollers

9 ORDERING OF SPARE PARTS

OrigoMag C140 is designed and tested in accordance with the international and Euro-

pean standards IEC/EN 60974−1 and EN 60974−10. It is the obligation of the service

unit which has carried out the service or repair work to make sure that the product still

conforms to the said standard.

Spare parts may be ordered through your nearest ESAB dealer, see the last page of

this publication.

Table des matières

Autres manuels ESAB Système de soudage

ESAB

ESAB Warrior 750i CC/CV Manuel utilisateur

ESAB

ESAB CIGWELD WeldSkill 100 MIG Manuel utilisateur

ESAB

ESAB CUTMASTER A60 Manuel utilisateur

ESAB

ESAB ES 300i Manuel utilisateur

ESAB

ESAB EPP-200 Manuel utilisateur

ESAB

ESAB Rogue ES 150i Manuel utilisateur

ESAB

ESAB HandyPlasma 50 Manuel utilisateur

ESAB

ESAB POWERCUT-1500 Manuel utilisateur

ESAB

ESAB Aristo 500ix Manuel utilisateur

ESAB

ESAB Origo Arc 650c Manuel utilisateur

ESAB

ESAB Aristo RoboFeed 3004w Manuel utilisateur

ESAB

ESAB Renegade ET 180iP Manuel utilisateur

ESAB

ESAB EM235ic Manuel utilisateur

ESAB

ESAB BOMBARDIER SVI-450i Manuel utilisateur

ESAB

ESAB ESP-150 Manuel utilisateur

ESAB

ESAB Precision Plasmarc EPP-600 Manuel utilisateur

ESAB

ESAB MEF 44N Manuel utilisateur

ESAB

ESAB ESABMig C240 Manuel utilisateur

ESAB

ESAB ARC 601i Manuel utilisateur

ESAB

ESAB CaddyTig HF Manuel utilisateur

ESAB

ESAB ESABMig 400t Manuel utilisateur

ESAB

ESAB Aristo Arc 4000i Manuel utilisateur

ESAB

ESAB EPP-360 Manuel utilisateur

ESAB

ESAB ARC300i Manuel utilisateur

Manuels Système de soudage populaires d'autres marques

Berner

Berner PLASMACUT 54 Manuel utilisateur

Pro Spot

Pro Spot PR-155 Manuel utilisateur

Forney

Forney 210 Manuel utilisateur

Thermal Arc

Thermal Arc 400S Manuel utilisateur

Lincoln Electric

Lincoln Electric HANDYMIG 170I Manuel utilisateur

GYS

GYS PROTIG 201 AC/DC Manuel utilisateur

TAFA

TAFA 30*8B35 Manuel utilisateur

Lincoln Electric

Lincoln Electric INVERTEC V350-PRO CE Manuel utilisateur

CIGWELD

CIGWELD 636804 Guide rapide

Red-D-Arc

Red-D-Arc DC-400 Manuel utilisateur

Hobart Welding Products

Hobart Welding Products Spool Gun DP 3035-10 Manuel utilisateur

Elettro

Elettro HI-MIG 3000 SYNERGIC Manuel utilisateur

WIA

WIA Weldmatic 270 CP132-2 Manuel utilisateur

Sonics

Sonics H520T Manuel utilisateur

Miller

Miller Big Blue 400D Manuel utilisateur

NewArc

NewArc RT2000 Guide de démarrage rapide

Hypertherm

Hypertherm powermax1000 Manuel utilisateur

Lincoln Electric

Lincoln Electric POWER WAVE I400 Manuel utilisateur
