ESAB Origo M13 Feed 304 Manuel utilisateur

Valid for serial no. 620-xxx-xxxx, 917-xxx-xxxx0459 162 101 GB 20120621

Origo™ M13

Feed 304

Feed 484

Instruction manual

-2-

- 3 -

TOCe

Rights reserved to alter specifications without notice.

1 SAFETY 4...........................................................

2 INTRODUCTION 5...................................................

2.1 Equipment 6................................................................

3 TECHNICAL DATA 6.................................................

4 INSTALLATION 7....................................................

4.1 Lifting instructions 7.........................................................

5 OPERATION 8.......................................................

5.1 Connections and control devices 9............................................

5.2 Water connection 9..........................................................

5.3 Starting procedure 9.........................................................

5.4 Function explanations 10......................................................

5.5 Wire feed pressure 11........................................................

5.6 Changing / loading wire Feed 304 12............................................

5.7 Changing / loading wire Feed 484 12............................................

5.8 Changing feed rollers on Feed 304 12...........................................

5.9 Changing feed rollers on Feed 484 13...........................................

6 MAINTENANCE 13....................................................

6.1 Inspection and cleaning 13....................................................

7 ORDERING SPARE PARTS 14.........................................

DIAGRAM 16............................................................

ORDER NUMBER 21.....................................................

WEAR PARTS 22........................................................

ACCESSORIES 26.......................................................

- 4 -

bm34d1ea

1 SAFETY

Users of ESAB equipment have the ultimate responsibility for ensuring that anyone who works on or

near the equipment observes all the relevant safety precautions. Safety precautions must meet the

requirements that apply to this type of equipment. The following recommendations should be ob

served in addition to the standard regulations that apply to the workplace.

All work must be carried out by trained personnel well-acquainted with the operation of the equip

ment. Incorrect operation of the equipment may lead to hazardous situations which can result in in

jury to the operator and damage to the equipment.

1. Anyone who uses the equipment must be familiar with:

Sits operation

Slocation of emergency stops

Sits function

Srelevant safety precautions

Swelding and cutting

2. The operator must ensure that:

Sno unauthorised person is stationed within the working area of the equipment when it is

started up.

Sno-one is unprotected when the arc is struck

3. The workplace must:

Sbe suitable for the purpose

Sbe free from drafts

4. Personal safety equipment

SAlways wear recommended personal safety equipment, such as safety glasses, flame-proof

clothing, safety gloves.

SDo not wear loose-fitting items, such as scarves, bracelets, rings, etc., which could become

trapped or cause burns.

5. General precautions

SMake sure the return cable is connected securely.

SWork on high voltage equipment may only be carried out by a qualified electrician.

SAppropriate fire extinquishing equipment must be clearly marked and close at hand.

SLubrication and maintenance must not be carried out on the equipment during operation.

CAUTION

Read and understand the instruction manual before

installing or operating.

CAUTION

Class A equipment is not intended for use in residential locations where

the electrical power is provided by the public low-voltage supply system.

There may be potential difficulties in ensuring electromagnetic

compatibility of class A equipment in those locations, due to conducted

as well as radiated disturbances.

CAUTION

This product is solely intended for arc welding.

- 5 -

bm34d1ea

WARNING

Read and understand the instruction manual before installing or operating.

Arc welding and cutting can be injurious to yourself and others. Take precautions when welding and

cutting. Ask for your employer's safety practices which should be based on manufacturers' hazard

data.

ELECTRIC SHOCK - Can kill

SInstall and earth the unit in accordance with applicable standards.

SDo not touch live electrical parts or electrodes with bare skin, wet gloves or wet clothing.

SInsulate yourself from earth and the workpiece.

SEnsure your working stance is safe.

FUMES AND GASES - Can be dangerous to health

SKeep your head out of the fumes.

SUse ventilation, extraction at the arc, or both, to take fumes and gases away from your breathing zone

and the general area.

ARC RAYS - Can injure eyes and burn skin.

SProtect your eyes and body. Use the correct welding screen and filter lens and wear protective

clothing.

SProtect bystanders with suitable screens or curtains.

FIRE HAZARD

SSparks (spatter) can cause fire. Make sure therefore that there are no inflammable materials nearby.

NOISE - Excessive noise can damage hearing

SProtect your ears. Use earmuffs or other hearing protection.

SWarn bystanders of the risk.

MALFUNCTION - Call for expert assistance in the event of malfunction.

PROTECT YOURSELF AND OTHERS!

Dispose of electronic equipment at the recycling facility!

In observance of European Directive 2002/96/EC on Waste Electrical and Electronic

Equipment and its implementation in accordance with national law, electrical and/or

electronic equipment that has reached the end of its life must be disposed of at a

recycling facility.

As the person responsible for the equipment, it is your responsibility to obtain

information on approved collection stations.

For further information contact the nearest ESAB dealer.

ESAB can provide you with all necessary welding protection and accessories.

2 INTRODUCTION

The Feed 304and Feed 484 wire feed units with control

panel M13 are intended for MIG/MAG-welding together

with infinitely adjustable welding power sources.

They come in different variants, see on page 21.

The wire feed units are sealed and contain four-wheel

drive wire feed mechanisms as well as control electronics.

They can be used together with wire on ESAB's

MarathonPact, or on wire bobbin (standard Ø 300 mm,

accessory Ø 440 mm).

The wire feed unit can be installed either at the power source, suspended above the

workplace, on a support arm or on the floor with or without wheel set.

- 6 -

bm34d1ea

ESAB's accessories for the product can be found on page 26.

2.1 Equipment

The Feed 304 wire feed unit is supplied with:

SInstruction manual

SStickers with recommended wear parts.

The Feed 484 wire feed unit is supplied with:

SSpacer (4)

SHex key wrench (4 mm)

SInstruction manual

SStickers with recommended wear parts.

3 TECHNICAL DATA

Feed 304 Feed 484

Power supply 42 V 50 - 60 Hz 42 V 50 - 60 Hz

Power requirement 336 VA 378 VA

Motor current Imax 8 A 9 A

Settings data

Wire feed speed

Burnback time

Crater filling time

Creep start

2/4 stroke

1.9-25.0 m/min

0-0.5 s

0-5.1 s

OFF or ON

2 stroke or 4 stroke

1.9-25.0 m/min

0-0.5 s

0-5.1 s

OFF or ON

2 stroke or 4 stroke

Gun connection EURO EURO

Max. diameter wire bobbin 300 mm (*440mm) 300 mm (*440mm)

Wire dimension 0.6-1.6 mm 0.6-2.4 mm

Weight

basic version

with sealed bobbin holder

11.5 kg

15 kg

14.5 kg

19 kg

Dimensions (l x w x h)

basic version

with sealed bobbin holder

380 x 275 x 400 mm

690 x 275 x 420 mm

380 x 275 x 400 mm

690 x 275 x 420 mm

Operating temperature -10 to +40°C-10 to +40°C

Shielding gas

max pressure

All types intended for

MIG/MAG welding

5 bar

All types intended for

MIG/MAG welding

5 bar

Coolant

max pressure

50% water / 50% glycol

5 bar

50% water / 50% glycol

5 bar

Permissible load at

60% duty cycle 630 A 630 A

Enclosure class IP23 IP23

* Accessories, see page 26.

- 7 -

bm34d1ea

Duty cycle

The duty cycle refers to the time as a percentage of a ten-minute period that you can weld or cut at

a certain load without overloading. The duty cycle is valid for 40°C.

Enclosure class

The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid

objects or water. Equipment marked IP23 is designed for indoor and outdoor use.

4 INSTALLATION

The installation must be carried out by a professional.

WARNING

When welding in an environment with increased electrical danger, only power

sources intended for this environment may be used. These power sources are

marked with the symbol

4.1 Lifting instructions

Ordering number for the lifting eye can be found on page 26.

Note! If another mounting device is used, this should be insulated from the wire feed

unit.

- 8 -

bm34d1ea

5 OPERATION

General safety regulations for handling the equipment can be found on

page 4. Read through before you start using the equipment!

WARNING

Assure that the side panels are closed during operation.

WARNING

To prevent the reel from sliding off the hub: Lock the

reel in place by turning the red knob as shown on the

warning label attached next to the hub.

WARNING

Rotating parts can cause injury, take great care.

WARNING

Risk of crushing when replacing the wire bobbin!

Do not use safety gloves when inserting the welding wire between the feed rollers.

WARNING

There is a risk of tipping if the wire feed unit is fitted with a counterbalance arm.

Secure the equipment, especially if used on an uneven or sloping surface.

NOTE: When moving the equipment use intended handle. Never pull on the gun.

- 9 -

bm34d1ea

5.1 Connections and control devices

1Display 9Connection for welding gun

2Knob for setting the voltage 10 Switch for 2-stroke / 4-stroke

3Knob for setting crater filling time 11 Knob for setting burnback time

4Switch for creep start OFF / ON 12 Connection for welding current from power

source, (OKC)

5Knob for setting wire feed speed. 13 Connection for control cable from power

source

6Connection for remote control unit,

Miggytrac, Railtrac

14 Connection RED for cooling water to

power source (cooling unit)

7Connection BLUE, with ELP* for cooling

water to the welding gun

15 Connection BLUE for cooling water from

power source (cooling unit)

8Connection RED for cooling water from

welding gun

16 Connection for shielding gas

NOTE! Display (digital instrument) and cooling water connections only available on certain models.

* ELP = ESAB Logic Pump, see point 5.2.

5.2 Water connection

When connecting a water-cooled welding gun, the power source's main power

supply switch must be in the Off position and the cooling unit switch must be in

position “ELP/0”.

The wire feed unit with water connection is equipped with a detection system ELP

(ESAB Logic Pump) which checks that the water hoses are connected. When

connecting a water-cooled welding gun, the water pump starts.

Detection only works with power sources that are equipped with ELP.

5.3 Starting procedure

When the wire feed starts, the power source generates welding voltage.

If there is no welding current flow within three seconds, the power source switches

the welding voltage off. The wire feed continues until the welding gun's switch is

switched off.

- 10 -

bm34d1ea

5.4 Function explanations

Burnback time

Burnback time is a delay between the time when the wire starts to brake until the

time when the power source switches off the welding voltage. Too short burnback

time results in a long wire stickout after completion of welding, with a risk of the wire

being caught in the solidifying weld pool. Too long a burnback time results in a

shorter stickout, with increased risk of the arc striking back to the contact tip.

Crater filling

Crater filling helps to avoid pores, thermal cracking and crater formation in the weld

when welding stops.

Figure 1 shows an interruption in the

welding, and a crack or crater opens up

readily in the solidified central part due

to shrinkage during the solidifying pro

cess.

Fig. 1.After welding without crater filling

Figure 2 shows that the arc continues to

give off a certain amount of heat while

the weld pool is solidifying. This chang

es the solidification process so that the

last solidified part of the weld pool ends

up at the top, and in this way it is possib

le to avoid the occurrence of a crater.

Fig. 2.After welding with crater filling

2 stroke

With 2 stroke, wire feed starts when the trigger switch is pressed in and ends when

it is released.

4 stroke

With 4 stroke, the gas flow starts when the trigger switch is pressed in and the wire

feed starts when it is released. The welding process continues until the switch is

pressed in again, the wire feed stops and when the switch is released the gas stops

flowing.

Creep start

Creep start means that the wire is fed at low speed until it comes into electrical

contact with the workpiece and then the speed increases to the set speed.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ESAB Système de soudage

ESAB

ESAB ET 186i AC/DC Manuel utilisateur

ESAB

ESAB Powercut 650 Manuel utilisateur

ESAB

ESAB Aristo U6 Manuel utilisateur

ESAB

ESAB Origo Tig 3001i Manuel utilisateur

ESAB

ESAB Aristo Mig 5000i 460 V Manuel utilisateur

ESAB

ESAB Aristo Mig 3001i Manuel utilisateur

ESAB

ESAB CoolMidi 1800 Manuel utilisateur

ESAB

ESAB THERMAL DINAMICS CUTMASTER 60i Manuel utilisateur

ESAB

ESAB PCM-750i Manuel utilisateur

ESAB

ESAB LAF Series Manuel utilisateur

ESAB

ESAB Rogue Series Manuel utilisateur

ESAB

ESAB Aristotig 255 LTN 255 Manuel utilisateur

ESAB

ESAB Buddy Tig 160 Manuel utilisateur

ESAB

ESAB KHM 190 HS Manuel utilisateur

ESAB

ESAB Origo Mig L3000i Manuel utilisateur

ESAB

ESAB Warrior 400i CC/CV Manuel utilisateur

ESAB

ESAB Mig 325 Manuel utilisateur

ESAB

ESAB MECHTIG 160 Manuel utilisateur

ESAB

ESAB Buddy Arc 200 Manuel utilisateur

ESAB

ESAB Origo Mig 3001i Manuel utilisateur

ESAB

ESAB Tig 4000i Aristo Manuel utilisateur

ESAB

ESAB LHJ 750 Mode d’emploi

ESAB

ESAB CIGWELD CutSkill 60 Manuel utilisateur

ESAB

ESAB Aristo Mig 5000iw WeldCloud Manuel utilisateur

Manuels Système de soudage populaires d'autres marques

Berner

Berner PLASMACUT 54 Manuel utilisateur

Pro Spot

Pro Spot PR-155 Manuel utilisateur

Forney

Forney 210 Manuel utilisateur

Thermal Arc

Thermal Arc 400S Manuel utilisateur

Lincoln Electric

Lincoln Electric HANDYMIG 170I Manuel utilisateur

GYS

GYS PROTIG 201 AC/DC Manuel utilisateur

TAFA

TAFA 30*8B35 Manuel utilisateur

Lincoln Electric

Lincoln Electric INVERTEC V350-PRO CE Manuel utilisateur

CIGWELD

CIGWELD 636804 Guide rapide

Red-D-Arc

Red-D-Arc DC-400 Manuel utilisateur

Hobart Welding Products

Hobart Welding Products Spool Gun DP 3035-10 Manuel utilisateur

Elettro

Elettro HI-MIG 3000 SYNERGIC Manuel utilisateur

WIA

WIA Weldmatic 270 CP132-2 Manuel utilisateur

Sonics

Sonics H520T Manuel utilisateur

Miller

Miller Big Blue 400D Manuel utilisateur

NewArc

NewArc RT2000 Guide de démarrage rapide

Hypertherm

Hypertherm powermax1000 Manuel utilisateur

Lincoln Electric

Lincoln Electric POWER WAVE I400 Manuel utilisateur
