Ericsson MINI-LINK AMM 1U-1 Manuel utilisateur

MINI-LINK High Capacity

Indoor Installation Manual

MINI-LINK

AMM 1U-1, AMM 2U-4

reproduced, stored in a retrieval system, or transmitted in any form or by any

means, electronic, mechanical, photocopying, recording or otherwise, without

prior permission of the publisher.

Disclaimer

The contents of this document are subject to revision without notice due to

continued progress in methodology, design, and manufacturing. Ericsson shall

have no liability for any error or damage of any kind resulting from the use

of this document.

EN/LZT 712 0156 R1A 2002-10-01

MINI-LINK High Capacity Indoor Installation Manual

Contents

1 Introduction 1

1.1 How to use this Manual 2

1.2 Target Group 2

1.3 Revision Information 3

1.4 Related Documents 3

1.5 Installation Workflow 4

2 Safety Instructions 5

2.1 Introduction 5

2.2 Safety Standards 5

2.3 Safety Requirements 6

2.4 Safety Symbols and Definitions 7

2.5 Hazards 8

3 System Overview 11

3.1 Introduction 11

3.2 Indoor Units 12

3.3 Management System 14

4 Preparations 15

4.1 Tools and Equipment 15

4.2 Units and Accessories 18

5 Indoor Installation 23

5.1 Fitting the Radio Cable Panel (optional) 24

5.2 Fitting the DDU (optional) 25

5.3 Installing the Fan Unit 26

5.4 Installing the AMM 29

5.5 Fitting the Dummy Front (optional) 32

5.6 Inserting and Removing the Plug-in Units 33

6 Indoor Cabling 37

6.1 Assembling and Connecting the Cables 38

6.2 Marking and Labelling 77

6.3 Connector and Pin Connection Overview 77

EN/LZT 712 0156 R1A 2002-10-01

MINI-LINK High Capacity Indoor Installation Manual

7 Initial Settings 83

7.1 Setting Frequency and Output Power 84

8 Indoor Radio Cabling 87

8.1 Preparing the Radio Cable 88

8.2 Connecting the Radio Cable to the Indoor Unit 89

9 Software Setup 97

10 Functional Test 99

10.1 Preparations 99

10.2 General Tests 100

10.3 Hop Test 102

10.4 Optional Tests 103

10.5 Starting the System 104

11 Local Supervision and Repair Handling 107

11.1 Local Supervision Interface 107

11.2 Repair Handling 108

Glossary 111

Index 113

EN/LZT 712 0156 R1A 2002-10-01

MINI-LINK High Capacity Indoor Installation Manual

1 Introduction

This installation manual contains information on how to install the indoor part

of a MINI-LINK High Capacity system. The outdoor part is described in the

MINI-LINK Point-to-point Outdoor installation Manual.

The MINI-LINK High Capacity system is a digital microwave radio link for voice

and data transmission and represents a new generation of synchronous radio

for short haul point-to-point implementations.

The radio system provides traffic capacity at 155 Mbit/s and supports the

SDH STM-1 electrical and optical standards as well as the SONET OC-3

standard.

The terminal consists of an outdoor radio unit with antenna, and indoor units

which hold traffic, modem, service and switching functions. Two types of

terminal configuration are possible: unprotected terminals (1+0) and protected

terminals (1+1).

5392

15GHz

RADIO

ALARM POWER

15GHz

RADIO

ALARM POWER

Figure 1 A terminal in a 1+1 configuration

EN/LZT 712 0156 R1A 2002-10-01

MINI-LINK High Capacity Indoor Installation Manual

1.1 How to use this Manual

The manual includes the following sections.

1. Introduction gives a brief description of MINI-LINK High

Capacity and information on how to use this

manual.

2. Safety Instructions describes safety regulations and

requirements as well as safety information

used throughout the manual.

3. System Overview describes the function and design of the

indoor part of MINI-LINK High Capacity.

4. Preparation contains information on required tools, units

and accessories for the outdoor installation.

5. Indoor Installation contains job instructions for installation of the

AMM and of indoor accessories.

6. Indoor Cabling contains job instructions for indoor cabling.

7. Initial Settings contains the necessary initial settings for the

terminal.

8. Indoor Radio Cabling contains job instructions for the cabling

procedure between the radio unit and the

AMM.

9. Software Setup contains a description of the software setup

when the installation is completed.

10. Functional Test contains a functional test to verify the

installation.

11. Local Supervision

and Repair Handling

contains a description of the local supervision

interface and instructions on how to handle

faulty equipment.

Glossary contains important terms used in this

manual.

1.2 Target Group

This manual has been written for field technicians and supervisors who work

with the installation of MINI-LINK equipment on site.

The personnel must be authorized and have the appropriate technical training

and experience.

The field technician is expected to be experienced in radio and mobile

communications, and have a good understanding of technical English or any

other language in which this manual is available.

2EN/LZT 712 0156 R1A 2002-10-01

MINI-LINK High Capacity Indoor Installation Manual

1.3 Revision Information

This is the first release of the MINI-LINK High Capacity Indoor Installation

Manual.

1.4 Related Documents

References to the following documents are made throughout the manual using

the document name only.

EN/LZT 712 0015 MINI-LINK Point-to-point Outdoor Installation

Manual

The manual describes how to install the outdoor part of

a MINI-LINK hop.

EN/LZT 712 0058 MINI-LINK High Capacity Operation Manual

The manual describes how to set up, operate and

maintain the terminal.

EN/LZT 110 2049 DC Distribution Unit (DDU), Installation Instruction

The instruction describes how to install a DC Distribution

Unit with associated cabling.

1/22 102-

FGB 101 004/1

MINI-LINK Product Portfolio Description

The description gives technical and functional

description of the main products in the MINI-LINK

product portfolio.

EN/LZT 712 0156 R1A 2002-10-01

MINI-LINK High Capacity Indoor Installation Manual

1.5 Installation Workflow

The flowchart below shows the recommended installation workflow. The

outdoor installation is described in the MINI-LINK Point-to-point Outdoor

Installation Manual.

Read the Safety

Instructions

Indoor Installation

Indoor Cabling

Initial Settings

Outdoor Installation

Outdoor Radio Cabling

Antenna Alignment

SW Setup

Functional Test

Start the System

Read the Safety

Instructions

5790

Indoor Radio Cabling

Indoor Installation Outdoor Installation

Figure 2 Installation workflow

4EN/LZT 712 0156 R1A 2002-10-01
