Ericsson T66 Manuel utilisateur

NotforCommercialUse

EricssonMobileCommunicationsAB

Important

battery

information

It takes up to 30 minutes

for a new battery

to start charging.

Insert the SIM card and attach the

battery to the phone before you start

charging.

Connect the charger to the mains,

then to the phone.

It takes up to 30 minutes for a new

battery to start charging.

It takes about 4 hours to fully

charge a battery the first time.

Disconnect the charger by tilting

the plug up.

NotforCommercialUse

EricssonMobileCommunicationsAB

If you have a WAP account for your phone, you can go to Ericsson Mobile

Internet and get the WAP settings sent to your phone via SMS.

Go to mobileinternet.ericsson.com and select the brick for WAP and e-mail

configuration. Choose to have the WAP settings sent to your phone, and follow

the instructions.

To install the new WAP settings

1.When you receive the text message, press YES.

2.Select the WAP profile in which you want to save the WAP settings,

and press YES.

You can now start using your WAP browser.

Easy access to

WAP

NotforCommercialUse

EricssonMobileCommunicationsAB

Contents

Getting Started .............................. 5

Making and Receiving Calls ......... 8

Key Functions ............................. 12

Using the Menus ......................... 13

Entering Letters ........................... 17

Chinese Input .............................. 20

Your Personal Phone Book ......... 26

Using the Call List ...................... 31

Your Voice Mail Service ............ 32

Personalizing Your Phone ........... 33

Text and Chat Messages ............. 41

Profiles ........................................ 47

Diverting Incoming Calls ............ 48

Security for Your Phone and

Subscription ................................ 49

More Than One Call ................... 53

Setting Network Preferences .......56

Call Time and Call Cost ..............57

Using the WAP Browser .............59

Calendar ......................................62

Code Memo ................................. 64

Calling Card Calls .......................66

Extras ..........................................67

Online Services ...........................70

Ericsson Mobile Internet .............71

Troubleshooting ..........................71

Display Icons ...............................73

Quick Keys .................................. 75

Technical Data ............................76

Safe and Efficient Use .................77

Limited Warranty ........................84

Regulatory Information ...............86

NotforCommercialUse

EricssonMobileCommunicationsAB

Ericsson T66

First edition (May 2001)

This manual is published by Ericsson Mobile

Communications AB, without any warranty. Improvements

and changes to this manual necessitated by typographical

errors, inaccuracies of current information, or

improvements to programs and/or equipment, may be

made by Ericsson Mobile Communications AB at any time

and without notice. Such changes will, however, be

incorporated into new editions of this manual.

©Ericsson Mobile Communications AB, 2001

Publication number: EN/LZT 108 4574 R1A

INNOVATRON PATENTS

Note: Some of the services in this manual are not

supported by all networks. This also applies to the GSM

International Emergency Number 112.

Note: You should read the Guidelines for Safe and

Efficient Use and the Warranty chapters before using

your mobile phone.

Please contact your network operator or service provider

if you are in doubt whether you can use a particular

service or not.

T9™ Text Input is a registered trademark of Tegic

Communications.

T9™ Text Input is licensed under one or more of the

following: U.S. Pat. Nos. 5,818,437, 5,953,541,

5,187,480, 5,945,928, and 6,011,554; Canadian Pat. No.

1,331,057, United Kingdom Pat. No. 2238414B; Hong

Kong Standard Pat. No. HK0940329; Republic of

Singapore Pat. No. 51383; Euro.Pat. No. 0 842

463(96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE,

GB; and additional patents are pending worldwide.

NotforCommercialUse

EricssonMobileCommunicationsAB

Getting Started 5

Getting Started

Front

Back

Volume

key

Display

Option key

Arrow keys

Microphone

Indicator

light

Earpiece

On/off key

Keypad

Battery cover lid

Charging

connector Handsfree

connector

Internal antenna

NotforCommercialUse

EricssonMobileCommunicationsAB

6 Getting Started

About this User’s Guide

Some services and functions described in this User’s

Guide are service provider - and subscription-

dependent. Because of this, all menus may not be

available in your phone and the shortcut numbers to

menus and functions may vary between phones.

This symbol indicates that a service or

function is network- or service provider

dependent.

Please refer to the information provided

by your service provider for more information about

your subscription.

We recommend that you read the chapter “Using

the Menus” on page 13 for information about how to

move through the menus.

The SIM Card

When you register as a subscriber with a network

operator, you get a SIM (Subscriber Identity Module)

card. The SIM card contains a computer chip that

keeps track of your phone number, the services

included in your subscription, and your Phone book

information, among other things.

SIM cards come in two sizes. One is the size of a

credit card and the other is smaller. Your phone uses

the smaller card. Many credit card-sized SIM cards

have a perforated smaller card that you can take

out easily.

Assembly

Before you can use your phone you need to:

•insert the SIM card.

Note: Always insert the SIM card into the phone

before attaching the battery.

•attach and charge the battery.

Note: Always turn off the phone and detach the

charger before you insert or remove a SIM card.

NotforCommercialUse

EricssonMobileCommunicationsAB

Getting Started 7

Inserting and Removing the SIM Card Attaching the Battery to your Phone

SIM

•Slide the SIM

card into the

slot, under the

silvery holder,

with the golden

connectors

facing down

and the cut

corner to

the left.

•To remove the

SIM card, slide

it out.

2. Slide the battery

cover upwards

from the bottom

of the phone

into place as

shown in the

picture.

1. Place the

battery into the

back of the

phone, with

the golden

connectors

facing down,

and push down

until it clicks

into place.

Note: To remove the battery cover, press the

top centre of the cover and slide downwards.

NotforCommercialUse

EricssonMobileCommunicationsAB

8 Making and Receiving Calls

Charging Connections

Note: The mains plug may look different depending

on the mains socket in your country. Do not connect

it to any other item than your Ericsson Travel

Charger CTR-10. It must not be separated from the

charger when plugged into the wall socket.

You can use the phone while the battery is being

charged. However, this lengthens the charging time.

When the battery is fully charged, the battery meter

in the display is full.

Making and Receiving Calls

Turning Your Phone On

1. Press and hold NO until you hear a tone.

2. Enter your PIN (Personal Identity Number), if you

have one for your SIM card. Your PIN is provided by

your network operator.

If you make a mistake while entering your PIN,

delete the wrong number by pressing .

3. Press YES.

If you enter your PIN incorrectly 3 times in a row

then the SIM card is blocked. See “The SIM Card

Lock” on page 49.

Network Search

After you have turned on the phone (and entered

your PIN), the phone searches for a network. When a

network is found, the phone beeps three times. The

indicator light on top of the phone flashes green. This

is called “standby mode”. You can now make and

receive calls.

NotforCommercialUse

EricssonMobileCommunicationsAB

Making and Receiving Calls 9

Turning Your Phone Off

•In standby mode, press and hold NO until you hear

atone.

Making a Call

1. Enter the area code and phone number.

If you make a mistake while entering the number,

delete the wrong number by pressing .

2. Press YES.

Press NO to end the call.

Note: The Ongoing call menu is displayed when

is pressed during a call.

Changing the Earpiece Volume

During a call you can change the earpiece volume by

sliding the volume key on the side of the phone.

•Slide the key upwards to increase the volume.

•Slide the key downwards to decrease the volume.

Turning Off the Microphone

During a call you can turn off the microphone.

•Press and hold .

•Press to resume the conversation.

Re-dialling a Previously Called Number

The Call list contains numbers that you have dialled,

answered or missed.

To re-dial a previously called number

1. Press YES from standby mode to enter the Call list.

2. Press or to scroll through the list.

3. When the number you want to call is highlighted,

press YES to make the call.

Automatic Re-Dialling

If a connection failed, and the display shows Retry?,

you can re-dial the number by pressing YES. Your

phone automatically re-dials (up to 10 times):

•until the call is answered.

•until you press a key or receive a call.

Note: Automatic re-dialling is not available for

data calls.

NotforCommercialUse

EricssonMobileCommunicationsAB

10 Making and Receiving Calls

Making International Calls

1. Press and hold the key until a +sign appears.

The +replaces the international prefix number of the

country from which you are calling.

2. Enter the country code, area code (without the

leading zero) and phone number. Press YES.

Making Emergency Calls

1. Enter 112 (the international emergency number).

2. Press YES.

Your Ericsson phone supports the international

emergency numbers, 112, 911 and 08. This means

that it can normally be used to initiate an emergency

call in any country, with or without a SIM card

inserted, if a GSM network is within range.

Note: Some service providers may require that a SIM

card is inserted, and in some cases that the PIN has

been entered as well.

Emergency Numbers

Some countries may not promote the

international emergency number, 112. Your

operator may therefore have stored additional local

emergency numbers on the SIM card.

To use another emergency number

1. Press to go to the Phone book menu.

2. Press YES to select the menu.

3. Press until Special numbers is highlighted,

then press YES.

4. Press until SOS numbers is highlighted,

then press YES.

5. Press or to go to the number you want,

then press YES to make the call.

Receiving Calls

When you receive a call, the phone rings and the

display shows Answer?.

Tip: Press when the phone rings to mute

signal.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Ericsson Téléphone portable

Ericsson

Ericsson GH688 - OTHER Manuel utilisateur

Ericsson

Ericsson ACeS OG698 Manuel utilisateur

Ericsson

Ericsson PF 768 Mode d’emploi

Ericsson

Ericsson DT292 Manuel utilisateur

Ericsson

Ericsson W20 Manuel utilisateur

Ericsson

Ericsson T65 Manuel utilisateur

Ericsson

Ericsson T39 Guide de référence rapide

Ericsson

Ericsson A1018 Manuel utilisateur

Ericsson

Ericsson T28 Manuel utilisateur

Ericsson

Ericsson T28s Manuel utilisateur

Ericsson

Ericsson T65 Manuel utilisateur

Ericsson

Ericsson R250d PRO Manuel utilisateur

Ericsson

Ericsson R250d PRO Manuel utilisateur

Ericsson

Ericsson T60d Manuel utilisateur

Ericsson

Ericsson KF 788 Manuel utilisateur

Ericsson

Ericsson S868 Manuel utilisateur

Ericsson

Ericsson GF788E Manuel utilisateur

Ericsson

Ericsson EF738 Manuel utilisateur

Ericsson

Ericsson GH688 - OTHER Manuel utilisateur

Ericsson

Ericsson GF768 Manuel utilisateur

Ericsson

Ericsson T28s Manuel utilisateur

Ericsson

Ericsson T68m Manuel utilisateur

Ericsson

Ericsson T68 Guide de configuration

Ericsson

Ericsson GH198 Manuel utilisateur

Manuels Téléphone portable populaires d'autres marques

Zte

Zte BLADE A520 Manuel utilisateur

Nokia

Nokia Lumia 620 Manuel utilisateur

Blackbe;rry

Blackbe;rry KEYone Manuel utilisateur

Bea-fon

Bea-fon X5 Premium Manuel utilisateur

Blackbe;rry

Blackbe;rry 8707 Series Manuel utilisateur

Blackbe;rry

Blackbe;rry Storm Mode d'emploi

LG LM-X420QN Manuel utilisateur

LifeWatch

LifeWatch V Manuel utilisateur

Bea-fon

Bea-fon SILVER LINE SL860 Manuel utilisateur

IKI Mobile

IKI Mobile KF4.5i Manuel utilisateur

Hitech

Hitech HT-850 Manuel utilisateur

Yezz

Yezz Fashion F10 Manuel utilisateur

Point Mobile

Point Mobile PM60 Manuel utilisateur

Blackbe;rry

Blackbe;rry Q10 Manuel utilisateur

Blackbe;rry

Blackbe;rry Bold 9900 Manuel utilisateur

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuel utilisateur

LG LM-K420EMW Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuel utilisateur
