3. Insert the remaining charger units into the enclosure and insert their

respective AC power cord plugs into the receptacles of the AC Outlet

Strip (see Figure 2, view A).

Perform the following steps (Steps 4 thru 6) to ensure

that the charger units function prior to installing the top

retaining cover on the enclosure.

NOTE

4. Place the enclosure into position where it will be used and connect the

AC power cord plug from the AC Outlet Strip to a 110 VAC power

source.

5. Press the power switch on the AC Outlet Strip to the ON position.

6. Insert a

Monogram

Series MPG 300 radio unit into each of the

charger slots and verify that the corresponding indicators light.

7. Install the top retaining cover and secure with two screws (see Figure

2, view B). Ensure that no cabling is pinched or damaged when the

cover is secured.

8. Install the four self-adhesive rubber feet to the bottom of the enclosure.

VIEW A VIEW B

Figure 2 - Assembly Instructions

ericssonz

LBI-39009

Installation Manual

Monogram

Series

DUAL RATE

MULTI-CHARGER

(6-UNIT) KIT

MHCH3W

2

TABLE OF CONTENTS

UNPACKING ................................................................................. 3

ASSEMBLY .................................................................................... 3

This manual is published by Ericsson Inc., without any warranty.

Improvements and changes to this manual necessitated by typographical

errors, inaccuracies of current information, or improvements to programs

and/or equipment, may be made by Ericsson Inc., at any time and without

notice. Such changes will be incorporated into new editions of this manual.

No part of this manual may be reproduced or transmitted in any form or by

any means, electronic or mechanical, including photocopying and

recording, for any purpose, without the express written permission of

Ericsson Inc.

Copyright© October 1993, Ericsson GE Mobile Communications Inc.

3

UNPACKING

When unpacking, be sure all parts are included. The following material

should be part of the kit.

•

Six (6) Dual Rate Charger Units - MHCH3V

•

One (1) Enclosure with retaining cover

•

Two (2) Machine screws with washers and nuts: No. 10-16 x 2.5"

•

Two (2) Thread forming screws: No. 10-16 x 3/4" or (machine screws)

•

One (1) AC Outlet Strip

•

Four (4) self-adhesive rubber feet

ASSEMBLY

REQUIRED TOOLS

•

Phillips screwdriver

•

Pliers or 1/4' nutdriver

ASSEMBLY

1. Install the AC Outlet Strip to the bottom of the enclosure using the two

machine screws. Insert the machine screws from the bottom of the

enclosure through the two holes and through the mounting holes of the

AC Outlet Strip. Use a washer and a nut on each screw and tighten

securely (see Figure 1, view A).

2. Insert one of the Dual Rate Charger Units into the enclosure and insert

its AC power cord plug into one of the receptacles of the AC Outlet

Strip (see Figure 1, view B).

VIEW A VIEW B

Figure 1 - Assembly of 6-Unit Charger

2

TABLE OF CONTENTS

UNPACKING ................................................................................. 3

ASSEMBLY .................................................................................... 3

This manual is published by Ericsson Inc., without any warranty.

Improvements and changes to this manual necessitated by typographical

errors, inaccuracies of current information, or improvements to programs

and/or equipment, may be made by Ericsson Inc., at any time and without

notice. Such changes will be incorporated into new editions of this manual.

No part of this manual may be reproduced or transmitted in any form or by

any means, electronic or mechanical, including photocopying and

recording, for any purpose, without the express written permission of

Ericsson Inc.

Copyright© October 1993, Ericsson GE Mobile Communications Inc.

3

UNPACKING

When unpacking, be sure all parts are included. The following material

should be part of the kit.

•

Six (6) Dual Rate Charger Units - MHCH3V

•

One (1) Enclosure with retaining cover

•

Two (2) Machine screws with washers and nuts: No. 10-16 x 2.5"

•

Two (2) Thread forming screws: No. 10-16 x 3/4" or (machine screws)

•

One (1) AC Outlet Strip

•

Four (4) self-adhesive rubber feet

ASSEMBLY

REQUIRED TOOLS

•

Phillips screwdriver

•

Pliers or 1/4' nutdriver

ASSEMBLY

1. Install the AC Outlet Strip to the bottom of the enclosure using the two

machine screws. Insert the machine screws from the bottom of the

enclosure through the two holes and through the mounting holes of the

AC Outlet Strip. Use a washer and a nut on each screw and tighten

securely (see Figure 1, view A).

2. Insert one of the Dual Rate Charger Units into the enclosure and insert

its AC power cord plug into one of the receptacles of the AC Outlet

Strip (see Figure 1, view B).

VIEW A VIEW B

Figure 1 - Assembly of 6-Unit Charger

Ericsson Inc.

Private Radio Systems

Mountain View Road

Lynchburg, Virginia 24502

1-800-528-7711 (Outside USA, 804-528-7711) Printed in U.S.A.

3. Insert the remaining charger units into the enclosure and insert their

respective AC power cord plugs into the receptacles of the AC Outlet

Strip (see Figure 2, view A).

Perform the following steps (Steps 4 thru 6) to ensure

that the charger units function prior to installing the top

retaining cover on the enclosure.

NOTE

4. Place the enclosure into position where it will be used and connect the

AC power cord plug from the AC Outlet Strip to a 110 VAC power

source.

5. Press the power switch on the AC Outlet Strip to the ON position.

6. Insert a

Monogram

Series MPG 300 radio unit into each of the

charger slots and verify that the corresponding indicators light.

7. Install the top retaining cover and secure with two screws (see Figure

2, view B). Ensure that no cabling is pinched or damaged when the

cover is secured.

8. Install the four self-adhesive rubber feet to the bottom of the enclosure.

VIEW A VIEW B

Figure 2 - Assembly Instructions

ericssonz

LBI-39009

Installation Manual

Monogram

Series

DUAL RATE

MULTI-CHARGER

(6-UNIT) KIT

MHCH3W
