1500W 190mm Circular Saw ERB566CSW
ERB566CSW
Original Instructions
(Version 1.0)
1500W 190mm Circular Saw ERB566CSW
GUARANTEE
This product carries a 2 year guarantee. If your product develops a fault within this
period, you should in the rst instance contact the retailer where the item was purchased.
This guarantee specically excludes losses caused due to:
- Fair wear and tear
- Misuse or abuse
- Lack of routine maintenance
- Failure of consumable items (such as batteries)
- Accidental damage
- Cosmetic damage
- Failure to follow manufacturer’s guidelines
- Loss of use of the goods
This guarantee does not affect your statutory rights. This guarantee is only valid in the UK.
For further technical advice, spare parts or repair service (outside of guarantee) please con-
tact the customer helpline number on 0345 607 6380.
Congratulations on your purchase of a quality power tool from Erbauer (UK) Ltd. This
product should give you reliable service but for your peace of mind this
power tool does carry a 2 year guarantee, the terms of which are detailed below.
If this product develops a fault within the guarantee period contact your retailer.
Please retain this handbook in case you need to refer to safety, care or guarantee
information in the future.
GENERAL POWER TOOL SAFETY WARNINGS
Warning: Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your electric (corded)
power tool or battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas
invite accidents.
b. Do not operate power tools in explosive atmospheres,
such as in the presence of ammable liquids, gases or dust.
Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the
plug in any way. Do not use any adapter plugs with earthed
(grounded) power tools. Unmodied plugs and matching outlets
will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators. There
is an increased risk of electric shock if your body is earthed or
grounded.
c. Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away from
heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for outdoor
use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable,
use a residual current device (RCD) protected supply. Use of
an RCD reduces the risk of electric shock.
1500W 190mm Circular Saw ERB566CSW
3. Personal safety
a. Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power tool
while you are tired or under the inuence of drugs, alcohol
or medication. A moment of inattention while operating power
tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source and/or
battery pack, picking up or carrying the tool. Carrying power
tools with your nger on the switch or energising power tools that
have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the
power tool on.
A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
e. Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool in
unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery.
Keep your hair, clothing and gloves away from moving parts.
Loose clothes, jewellery or long hair can be caught in moving
parts.
g. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for
your application. The correct power tool will do the job better
and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on
and off. Any power tool that cannot be controlled with the switch
is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or
the battery pack from the power tool before making any
adjustments, changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of starting the
power tool accidentally.
d. Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding
of moving parts, breakage of parts and any other condition
that may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many accidents are
caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind and
are easier to control.
g. Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account the
working conditions and the work to be performed. Use of
the power tool for operations different from those intended could
result in a hazardous situation.
5. Service
a. Have your power tool serviced by a qualied repair person
using only identical replacement parts. This will ensure that
the safety of the power tool is maintained.
ADDITIONAL SAFETY RULES FOR YOUR CIRCULAR SAW
Remove the plug from the socket before carrying out any
adjustment, servicing or maintenance.
1. Always wear a dust mask, hearing protection and eye
protection.
2. Only use saw blades recommended in the specication.
3. Always wear gloves when handling saw blades and rough
material. Saw blades shall be carried in a holder whenever
1500W 190mm Circular Saw ERB566CSW
practicable.
4. Fully unwind cable drum extension to avoid potential overheating.
5. When an extension cable is required you must ensure it has
the correct ampere rating for your power tool and is in a safe
electrical condition.
6. Ensure your mains supply voltage is the same as indicated on
the rating plate.
7. Your circular saw is a hand held tool, do not clamp your circular
saw.
8. Before cutting, check the cutting line is free of nails, screws, etc.
9. Do not cut small workpieces with a circular saw. If possible, use a
jigsaw.
10. Only make cuts with the blade direction downwards, never
upwards or at the side.
11. Do not use a blade unless the rated blade speed exceeds the
saw no load speed.
12. Never remove the guard system. Never use the saw if the guard
system does not function correctly. Never lock the moving guard
open. The guard must move freely.
13. Never use saw blades made from high speed steel(HSS).
14. Always check walls, oors and ceilings to avoid hidden power
cable and pipes.
15. After long working periods external metal parts and accessories
could be hot.
16. Do not cut material containing asbestos.
17. Do not use metal or stone saw blades. Only use wood saw blades.
18. Do not use circular saw to cut tree limbs or logs.
19. Do not use any abrasive wheels.
20. Use only blade diameter(s) in accordance with the markings.
SAFETY WARNINGS FOR ALL SAWS
a)
Danger: Keep hands away from cutting area and the
blade. Keep your second hand on auxiliary handle, or
motor housing. If both hands are holding the saw, they cannot
be cut by the blade.
b) Do not reach underneath the workpiece. The guard cannot
protect you from the blade below the workpiece.
c) Adjust the cutting depth to the thickness of the workpiece.
Less than a full tooth of the blade teeth should be visible below
the workpiece.
d) Never hold piece being cut in your hands or across your
leg. Secure the workpiece to a stable platform. It is important
to support the work properly to minimise body exposure, blade
binding, or loss of control.
e) Hold power tool by insulated gripping surfaces when
performing an operation where the cutting tool may contact
hidden wiring or its own cord. Contact with a “live” wire will
also make exposed metal parts of the power tool “live” and shock
the operator.
f) When ripping always use a rip fence or straight edge guide.
This improves the accuracy of cut and reduces the chance of
blade binding.
g) Always use blades with correct size and shape (diamond
versus round) of arbour holes. Blades that do not match the
mounting hardware of the saw will run eccentrically, causing loss
of control.
h) Never use damaged or incorrect blade washers or bolt.
The blade Warning of explosive to dust washers and bolt were
specially designed for your saw, for optimum performance and
safety of operation.
FURTHER SAFETY INSTRUCTIONS FOR ALL SAWS
KICKBACK CAUSES AND RELATED WARNINGS
- Kickback is a sudden reaction to a pinched, bound or misaligned
saw blade, causing an uncontrolled saw to lift up and out of the
workpiece toward the operator;
- When the blade is pinched or bound tightly by the kerf closing
down, the blade stalls and the motor reaction drives the unit
rapidly back toward the operator;
- If the blade becomes twisted or misaligned in the cut, the teeth
at the back edge of the blade can dig into the top surface of the
wood causing the blade to climb out of the kerf and jump back
toward the operator.
Kickback is the result of saw misuse and/or incorrect operating
procedures or conditions and can be avoided by taking proper
1500W 190mm Circular Saw ERB566CSW
precautions as given below.
a) Maintain a rm grip with both hands on the saw and position
your arms to resist kickback forces. Position your body to either
side of the blade, but not in line with the blade. Kickback could
cause the saw to jump backwards, but kickback forces can be
controlled by the operator, if proper precautions are taken.
b) When blade is binding, or when interrupting a cut for any reason,
release the trigger and hold the saw motionless in the material
until the blade comes to a complete stop. Never attempt to
remove the saw from the work or pull the saw backward while
the blade is in motion or kickback may occur. Investigate and
take corrective actions to eliminate the cause of blade binding.
c) When restarting a saw in the workpiece, centre the saw blade
in the kerf and check that saw teeth are not engaged into the
material. If saw blade is binding, it may walk up or kickback from
the workpiece as the saw is restarted.
d) Support large panels to minimise the risk of blade pinching and
kickback. Large panels tend to sag under their own weight.
Supports must be placed under the panel on both sides, near the
line of cut and near the edge of the panel.
e) Do not use dull or damaged blades. Unsharpened or improperly
set blades produce narrow kerf causing excessive friction, blade
binding and kickback.
f) Blade depth and bevel adjusting locking levers must be tight
and secure before making cut. If blade adjustment shifts while
cutting, it may cause binding and kickback.
g) Use extra caution when making a “plunge cut” into existing walls
or other blind areas. The protruding blade may cut objects that
can cause kickback.
SAFETY INSTRUCTION FOR CIRCULAR SAW WITH INNER
PENDULUM GUARD
a) Check lower guard for proper closing before each use. Do
not operate the saw if lower guard does not move freely and
close instantly. Never clamp or tie the lower guard into the
open position. If saw is accidentally dropped, lower guard may
be bent. Raise the lower guard with the retracting handle and
make sure it moves freely and does not touch the blade or any
other part, in all angles and depths of cut.
b) Check the operation of the lower guard spring. If the guard
and the spring are not operating properly, they must be
serviced before use. Lower guard may operate sluggishly due
to damaged parts, gummy deposits, or a build-up of debris.
c) Lower guard may be retracted manually only for special cuts
such as “plunge cuts” and “compound cuts.” Raise lower
guard by retracting handle and as soon as blade enters
the material, the lower guard must be released. For all other
sawing, the lower guard should operate automatically.
d) Always observe that the lower guard is covering the blade
before placing saw down on bench or oor. An unprotected,
coasting blade will cause the saw to walk backwards, cutting
whatever is in its path. Be aware of the time it takes for the blade
to stop after switch is released.
ADDITIONAL SAFETY WARNING FOR CONSTRUCTION DUST
The updated Control of Substances Hazardous to Health Regulations 1st October 2012 now
also targets to reduce the risks associated with silica, wood and gypsum dusts.
Construction workers are one of the at-risk groups within this because of the dust that they
breathe: silica dust is not just a nuisance; it is a real risk to your lungs!
Silica is a natural mineral present in large amounts in things like sand, sandstone and
granite. It is also commonly found in many construction materials such as concrete and
mortar. The silica is broken into very ne dust (also known as Respirable Crystalline Silica or
RCS) during many common tasks such as cutting, drilling and grinding
Breathing in very ne particles of crystalline silica can lead to the development of:
Lung cancer
Silicosis
Chronic Obstructive Pulmonary Disorder (Chronic obstructive pulmonary disease (COPD))
And breathing in ne particles of wood dust can lead to the development of Asthma
The risk of lung disease is linked to people who regularly breathe construction dust over a
period of time, not on the odd occasion.
To protect the lung, the COSHH Regulations sets a limit on the amount of these dusts that
you can breathe (called a Workplace Exposure Limit or WEL) when averaged over a normal
working day. These limits are not a large amount of dust: when compared to a penny it is
tiny – like a small pinch of salt:
This limit is the legal maximum; the most you can breathe after the right controls have been
used.
Autres manuels pour ERB566CSW
1
Table des matières
Autres manuels Erbauer Scie
Erbauer
Erbauer 3663602796244 Manuel utilisateur
Erbauer
Erbauer ERA568RSP Manuel utilisateur
Erbauer
Erbauer ERF298MSW Manuel utilisateur
Erbauer
Erbauer ERB238MSW Manuel utilisateur
Erbauer
Erbauer ERI490CSW Manuel utilisateur
Erbauer
Erbauer ERB1721A Manuel utilisateur
Erbauer
Erbauer ERB2502SE Manuel utilisateur
Erbauer
Erbauer EDD18-Li-2 Manuel utilisateur
Erbauer
Erbauer ERB690CSW Manuel utilisateur
Erbauer
Erbauer ECS18-Li Manuel utilisateur
Erbauer
Erbauer ERB566CSW Manuel utilisateur
Erbauer
Erbauer ERB596CSW Manuel utilisateur
Erbauer
Erbauer ERB610MSW Manuel utilisateur
Erbauer
Erbauer ERB2504SE Manuel utilisateur
Erbauer
Erbauer EMIS216S Manuel utilisateur
Erbauer
Erbauer ERB239MSW Manuel utilisateur
Erbauer
Erbauer ERB110SSW Manuel utilisateur
Erbauer
Erbauer ERS1100-1 Manuel utilisateur
Erbauer
Erbauer EMCS650 Manuel utilisateur
Erbauer
Erbauer ERB800RL Manuel utilisateur
