Equflow 6010BCPM Pulse Input Batch Controller

Instruction Manual

Equflow BV - P.O. Box 35- NL-5370 AA Ravenstein - The Netherlands

T +31 (0)24 3792666 –E [email protected]

www.equflow.com

Batch Controller

•Pulse, Open Collector, NPN, PNP, TTL, Switch Contact,

Sine Wave (Coil), Square Wave Inputs

•5, 10, or 24 V Flowmeter Power Supply

•K-Factor, Internal Scaling, or External Calibration

•Start, Batch, Pause, & Stop with Front Panel Buttons

•Display Batch Total + Rate, Grand Total, Batch Count or Preset

•Single or Multi-Stage Batching

•Automatic Overflow Protection

•Manual Control or Automatic Batching

•Dual-Line Display

•NEMA 4X and IP65 Rated Front Panel

•CE Marked

•Display Features 0.6" & 0.46" Digits

•Six Full Digits on Each Line

•Free USB Programming Software & Cable

•Isolated 24 VDC @ 200 mA Transmitter Power Supply

•Modbus®RTU Communication Protocol Standard

Equflow 6010BCPM Pulse Input Batch Controller Instruction Manual

Disclaimer

The information contained in this document is subject to change without notice. Equflow

makes no representations or warranties with respect to the contents hereof; and specifically

disclaims any implied warranties of merchantability or fitness for a particular purpose.

CAUTION: Read complete

instructions prior to installation

and operation of the controller.

WARNING: Risk of

electric shock or

personal injury.

Warning

This product is not recommended for life support

applications or applications where malfunctioning

could result in personal injury or property loss.

Anyone using this product for such applications

does so at his/her own risk. Equflow shall not be

held liable for damages resulting from such

improper use.

Limited Warranty

Equflow warrants this product against defects in material or workmanship for the specified

period under “Specifications” from the date of shipment from the factory. Equflow’s liability

under this limited warranty shall not exceed the purchase value, repair, or replacement of the

defective unit.

Registered Trademarks

Modbus®is a Registered Trademark of Schneider Automation Inc. All other trademarks

mentioned in this document are the property of their respective owners.

www.equflow.com

Equflow 6010BCPM Pulse Input Batch Controller Instruction Manual



3

Table of Contents

Table of Contents-----------------------------------------3
Table of Figures-------------------------------------------4
Introduction-------------------------------------------------4
Ordering Information ------------------------------------4
Specifications----------------------------------------------5
General------------------------------------------------------------5
Pulse Input-------------------------------------------------------5
Batch Controller Rate/Totalizer Display ---------------6
Relays -------------------------------------------------------------6
Modbus®RTU Serial Communications-----------------7
60101044 Digital Input & Output Expansion Module
-----------------------------------------------------------------------7
MeterView Pro --------------------------------------------------7
Compliance Information--------------------------------8
Electromagnetic Compatibility----------------------------8
Safety Information----------------------------------------9
Installation --------------------------------------------------9
Unpacking--------------------------------------------------------9
Panel Mounting Instructions-------------------------------9
Mounting Dimensions ------------------------------------10
Transmitter Supply Voltage Selection (P+, P-) ----10
Connections---------------------------------------------------11
Connectors Labeling--------------------------------------11
Power Connections ---------------------------------------11
Pulse Signal Connections -------------------------------12
Modbus RTU Serial Communications----------------12
Relay Connections ----------------------------------------12
Switching Inductive Loads-------------------------------13
F4 Digital Input Connections----------------------------13
External Relay & Digital I/O Connections -----------14
Interlock Relay Feature ----------------------------------14
Basic Operation and Programming--------------- 15
Front Panel Buttons and Status LED Indicators--15
Controller Operation----------------------------------------16
Batch Control Operation Example---------------------17
MeterView®Pro Software ---------------------------------19
MeterView Pro Installation ------------------------------19
Display Functions and Messages----------------------20
Setting Numeric Values -----------------------------------22
Setting Up the Batch Controller (setup) -------------23
Scaling and Calibration ----------------------------------24
Setting the Input Signal (Input) -----------------------24
Setting the Totalizer and Batching Features (total)
 -----------------------------------------------------------------24
Setting the Input Units or Custom Tags (units)---24
Setting the Decimal Point (dEc pt)-------------------25
Programming the Batch Controller (prog)-----------25
Input Calibration Method (InCAL)------------------26
K-Factor Calibration (Factor) ----------------------26
Scaling the Controller (SCALE)----------------------27
Time Base, Total Conversion Factor & Total
Reset------------------------------------------------27
Batch Start Mode (mode)------------------------------28
Calibrating the Controller with External Source
(Cal)-------------------------------------------------28
Setting the Display Parameter & Intensity (dsplay)
----------------------------------------------------------------- 29
Setting the Relay Operation (relay) ------------------ 30
Relay Assignment (Assign) ---------------------------- 31
Setting the Relay Action--------------------------------- 31
Setting Batch Control Relays--------------------------- 31
Programming Alarm Set and Reset Points --------- 32
Setting Fail-Safe Operation----------------------------- 32
Programming Time Delay------------------------------- 32
Relay Operation Details----------------------------------- 33
Overview----------------------------------------------------- 33
Relays Initialization --------------------------------------- 33
Fail-Safe Operation--------------------------------------- 33
Front Panel LEDs ----------------------------------------- 33
Automatic Reset (Auto)---------------------------------- 34
Pump Alternation Control-------------------------------- 34
Setting Up the Interlock Relay (Force On) Feature34
Sample Relay Operation -------------------------------- 35
Relay and Alarm Operation Diagrams---------------- 35
High Alarm Operation (Set > Reset)------------------ 35
Low Alarm Operation (Set < Reset) ------------------ 35
High Alarm with Fail-Safe Operation (Set > Reset)
----------------------------------------------------------------- 35
Low Alarm with Fail-Safe Operation (Set < Reset)35
Rate Relay Sampling Operation----------------------- 36
Total Relay Sampling Operation----------------------- 36
Time Delay Operation------------------------------------ 37
Reset Menu (reset)----------------------------------------- 38
Control Menu (Contrl)------------------------------------- 38
Setting Up the Password (pass)------------------------ 38
Protecting or Locking the Controller------------------ 38
Grand Total Reset Password & Non-Resettable
Total ---------------------------------------------------------- 39
Making Changes to a Password Protected
Controller---------------------------------------------------- 39
Disabling Password Protection ------------------------ 39
Advanced Operation and Programming---------40
Advanced Features Menu & Display Messages--- 41
Function Keys Operation-------------------------------- 42
F4 Operation------------------------------------------------ 42
Multi-Point Calibration & Scaling ---------------------- 42
Maximum/Minimum Readings-------------------------- 43
Noise Filter (filter) ------------------------------------- 43
Noise Filter Bypass (bypass)--------------------------- 43
Rounding Feature (round)------------------------------ 43
Modbus RTU Serial Communications (serial)--- 44
Select Menu (SElEct)------------------------------------ 44
Signal Conditioning Selection (Functn)---------- 45
Low-Flow Cutoff (CutofF) --------------------------- 45
Total and Grand Total Count Direction (Count) 45
Programmable Function Keys User Menu (user)- 45
Troubleshooting-----------------------------------------47
Diagnostics Menu (diag)-------------------------------- 47
Determining Software Version ------------------------- 47
Reset Controller to Factory Defaults ----------------- 47
Factory Defaults & User Settings---------------------- 48
Troubleshooting Tips-------------------------------------- 49

Equflow 6010BCPM Pulse Input Batch Controller Instruction Manual

Table of Figures

Figure 1: 1/8 DIN Panel Mounting................................ 9

Figure 2: Controller Dimensions - Side View............ 10

Figure 3: Controller Dimensions - Top View............. 10

Figure 4: Transmitter Supply Voltage Selection....... 10

Figure 5: Connector Labeling for 6010BCPM........... 11

Figure 6: Power Connections..................................... 11

Figure 7: Flowmeter Powered by Internal Power

Supply.................................................................. 12

Figure 8: Flowmeter Powered by External Supply... 12

Figure 9: Self-Powered Magnetic Pickup Coil

Flowmeter............................................................ 12

Figure 10: NPN open Collector Input .........................12

Figure 11: PNP Sensor Powered by Internal Supply 12

Figure 12: Switch Input Connections.........................12

Figure 13: Relay Connections ....................................12

Figure 14: AC and DC Loads Protection....................13

Figure 15: Low Voltage DC Loads Protection ...........13

Figure 16: F4 Digital Input Connections....................13

Figure 17: Expansion Modules & DIN Rail Mounting

Kit..........................................................................14

Figure 18: Digital I/O Module Connections................14

Figure 19: Interlock Connection.................................14

Introduction

The Equflow 6010BCPM is an easy-to-use batch controller ideal for simplifying independent batch

control operations where local control is preferred to expensive and expansive plant operation

systems.

The controller comes programmed for easy front panel start, pause, stop, and batch size (preset)

changes. The bottom display can be programmed to display rate, grand total, batch count, or

preset by cycling the Stop (F3) button. A digital input is standard.

Manual start batching is default, but automatic batching with a restart after a programmed time

delay from the completion of the last batch, is also possible.

Overrun correction adjusts the closing of the batch control relays to adjust for inaccuracies from

batch to batch. This increases accuracy over time as systems wear out. The overrun correction

feature is capable of compensating for inaccuracies of up to 10% of the programmed preset value.

Ordering Information

Model

Description

6010BCPM001XX

1/8 DIN Pulse Input Batch Controller with 2 Relays powered by 85-265 VAC

Accessories

Model

Description

60101002

DIN rail mounting kit for two expansion modules

60101044

4 digital inputs & 4 digital outputs (2 may be connected)

60101232

RS-232 serial adapter

60101485

RS-485 serial adapter

60107485-I

RS-232 to RS-422/485 isolated converter

60108232-N

USB to RS-232 non-isolated converter

60108485-I

USB to RS-422/485 isolated converter

Equflow 6010BCPM Pulse Input Batch Controller Instruction Manual

Specifications

Except where noted all specifications apply to operation at +25°C.

General

Display

Line 1: 0.6" (15 mm) high, red LEDs

Line 2: 0.46" (12 mm) high, red LEDs

6 digits: each (-99999 to 999999), with lead

zero blanking.

Default

Display

Assignment

The Upper display shows batch total. The

Lower display shows rate with alternating

units, and can be switched to show grand

total, batch count, or preset with the STOP

key.

Custom

Display

Assignment

The Upper and Lower displays may be

assigned to rate, total, grand total, batch

count, preset, set points, units (lower display

only), alternating R & T, R & GT, preset &

rate, max & min, or a Modbus display

may be programmed to alternate with a

custom unit or tag.

Alternating

Display

Displays alternate every 10 seconds when

display is selected or the batch is paused.

Display

Intensity

Eight user selectable intensity levels

Display

Update Rate

5/second (200 ms)

Overrange

Display flashes 999999

Underrange

Display flashes -99999

Front Panel

NEMA 4X, IP65

Programming

Methods

Four front panel buttons, digital inputs, or

PC and MeterView Pro software.

Recalibration

All ranges are calibrated at the factory.

Recalibration is recommended at least every

12 months.

Max/Min

Display

Max/min readings reached by the process

are stored until reset by the user or until

power to the controller is cycled.

Password

Three programmable passwords restrict

modification of programmed settings and

two prevent resetting the totals.

Pass 1: Allows use of function keys and

digital inputs

Pass 2: Allows use of function keys, digital

inputs and editing set/reset points

Pass 3: Restricts all programming, function

keys, and digital inputs.

Total Password: Prevents resetting the total

manually

Gtotal Password: Prevents resetting the

grand total manually

Non-Volatile

Memory

All programmed settings are stored in non-

volatile memory for a minimum of ten years

if power is lost.

Power

Options

85-265 VAC 50/60 Hz, 90-265 VDC, 20 W

max or 12-24 VDC 10%, 15 W max

Powered over USB for configuration only

Fuse

Required external fuse: UL Recognized, 5 A

max, slow blow; up to 6 controllers may

share one 5 A fuse

Isolated

Transmitter

Power Supply

TerminalsP+& P-:24VDC10%.12-24 VDC

poweredmodelsselectablefor24, 10,or5VDC

supply(internaljumperJ4).

85-265 VAC models rated @200 mA max, 12-

24 VDC poweredmodelsrated @100mAmax,

@50mAmax for5 or 10 VDCsupply.

Normal Mode

Rejection

Greater than 60 dB at 50/60 Hz

Isolation

4 kV input/output-to-power line

500 V input-to-output or output-to-P+ supply

Overvoltage

Category

Installation Overvoltage Category II:

Local level with smaller transient

overvoltages than Installation Overvoltage

Category III.

Environmental

Operating temperature range: -40 to 65°C

Storage temperature range: -40 to 85°C

Relative humidity: 0 to 90% non-condensing

Connections

Removable screw terminal blocks accept 12

to 22 AWG wire, RJ45 for external relays,

digital I/O, and serial communication

adapters.

Enclosure

1/8 DIN, high impact plastic, UL 94V-0,

color: black

Mounting

1/8 DIN panel cutout required:

3.622" x 1.772" (92 mm x 45 mm)

Two panel mounting bracket assemblies are

provided.

Tightening

Torque

Screw terminal connectors: 5 lb-in (0.56 Nm)

Overall

Dimensions

4.68" x 2.45" x 5.64" (119 mm x 62 mm x

143 mm)

(W x H x D)

Weight

9.5 oz (269 g)

Warranty

3 years parts & labor

Pulse Input

Inputs

Field selectable: Pulse or square wave 0-5

V, 0-12 V, or 0-24 V @ 30 kHz; TTL; open

collector 4.7 kpull-up to 5 V @ 30 kHz;

NPN or PNP transistor, switch contact 4.7

kpull-up to 5 V @ 40 Hz; Modbus PV

(Slave)

Low Voltage

Mag Pickup

(Isolated)

Sensitivity: 40 mVp-p to 8Vp-p

Minimum

Input

Frequency

0.001 Hz

Minimum frequency is dependent on high

gate setting.

Maximum

Input

Frequency

30,000 Hz (10,000 for low voltage mag

pickup)

Input

Impedance

Pulse input: Greater than 300 k@ 1 kHz.

Open collector/switch input: 4.7 kpull-up

to 5 V.

Accuracy

±0.03% of calibrated span ±1 count

Temperature

Drift

Rate display is not affected by changes in

temperature.

Equflow 6010BCPM Pulse Input Batch Controller Instruction Manual

Multi-Point

Linearization

2 to 32 points

Low-Flow

Cutoff

0-999999 (0 disables cutoff function)

Decimal Point

Up to five decimal places or none:

d.ddddd, d.dddd, d.ddd, d.dd, d.d,or

dddddd

Calibration

May be calibrated using K-factor, internal

calibration, or by applying an external

calibration signal.

K-Factor

Field programmable K-factor converts input

pulses to rate in engineering units. May be

programmed from 0.00001 to 999,999

pulses/unit.

Calibration

Range

Input 1 signal may be set anywhere in the

range of the controller; input 2 signal may be

set anywhere above or below input 1 setting.

Minimum input span between any two inputs

is 10 Hz.

An error message will appear if the input 1

and input 2 signals are too close together.

Filter

Programmable contact de-bounce filter: 40

to 999 Hz maximum input frequency allowed

with low speed filter.

Time Base

Second, minute, hour, or day

Gate

Low gate: 0.1-99.9 seconds

High gate: 2.0-999.9 seconds

F4 Digital

Input

Contacts

3.3 VDC on contact. Connect normally open

contacts across F4 to COM.

F4 Digital

Input

Logic Levels

Logic High: 3 to 5 VDC

Logic Low: 0 to 1.25 VDC

Batch Controller Rate/Totalizer Display

Rate Display

Indication

-99999 to 999999, lead zero blanking. “R”

LED illuminates while displaying rate.

Batch Total &

Grand Total

Display

0 to 999,999; automatic lead zero blanking.

“T” LED is illuminated while displaying batch

total. “GT” LEDs are illuminated while

displaying grand total. Up to 999,999 for

batch total/preset. Up to 999,999,999 with

grand total-overflow feature. “oF” is displayed

to the left of grand total overflow and ▲ LED

is illuminated.

Batch Total

Decimal Point

Up to five decimal places or none:

d.ddddd, d.dddd, d.ddd, d.dd, d.d,or

dddddd

Total decimal point is independent of rate

decimal point.

Totalizer

Calculates total based on rate and field

programmable multiplier to display total in

engineering units. Time base must be

selected according to the time units in which

the rate is displayed.

Grand

Totalizer

Rollover

Grand totalizer rolls over when display

exceeds 999,999,999. Relay status reflects

display.

Grand Total

Alarms

Up to seven, user selectable under setup

menu. Any set point can be assigned to

grand total and may be programmed

anywhere in the range of the controller for

grand total alarm indication. Relay 1 should

always be assigned to batch.

Programmabl

e Delay on

Release

0.1 and 999.9 seconds; applied to the first

relay assigned

to total or grand total.

If the controller is programmed to reset total

to zero automatically when the preset is

reached, then a delay will occur before the

total is reset.

Grand Total

Reset

Via front panel button, external contact

closure on digital inputs, automatically via

user selectable preset value and time delay,

or through serial communications.

Grand Total

Reset

Password

Grand total passwords may be entered to

prevent resetting the grand total from the

front panel.

Non-

Resettable

Grand Total

The grand total can be programmed as a

non-resettable total by entering the

password “050873”.

Caution!

Once the Grand Total has been

programmed as “non-resettable”

the feature cannot be disabled.

Relays

Rating

2 SPDT (Form C) internal; rated 3 A @ 30

VDC and 125/250 VAC resistive load; 1/14

HP (≈50 W) @ 125/250 VAC for inductive

loads

Noise

Suppression

Noise suppression is recommended for each

relay contact switching inductive loads; see

page 13 for details.

Relay

Assignment

Relays may be assigned to batch control

total, sampling, rate, or grand total alarms.

Preclose

0-100% of batch size, individually user

programmable for each additional batch

control relay beyond the first.

Alarm

Deadband

0-100% of span, user programmable

High or Low

Alarm

User may program any alarm for high or low

trip point.

Unused alarm LEDs and relays may be

disabled (turn off).

Relay

Operation

Batch control

Automatic (non-latching)1

Sampling

Off (disable unused relays and enable

Interlock feature)

Manual on/off control mode

Secondary Functions2

Latching (requires manual acknowledge)

Equflow 6010BCPM Pulse Input Batch Controller Instruction Manual

Relay Reset

User selectable via front panel buttons,

digital inputs, or PC

1. Automatic reset only (non-latching),

when the input passes the reset point

or total is reset to zero.

2. Automatic + manual reset at any time

(non-latching)

3. Manual reset only, at any time

(latching)

4. Manual reset only after alarm condition

has cleared (L)

Note: Digital inputs may be assigned to

acknowledge relays programmed for manual

reset. It is not recommended to change the

functions of front panel buttons to manual

reset.

Alarm Time

Delay

0 to 999.9 seconds, on & off relay time

delays

Programmable and independent for each

relay.

Fail-Safe

Operation

Programmable and independent for each

relay.

Note: Relay coil is energized in non-alarm

condition.

In case of power failure, relay will go

to alarm state.

Alarm Auto

Initialization

When power is applied to the controller,

relays will reflect the state of the input to the

controller.1

1. Alarms are active only when the batch is running.

2. These functions are not functional when the unit is being

used as a batch controller with total set to yes.

Modbus®RTU Serial Communications

Slave Id

1 –247 (Controller address)

Baud Rate

300 - 19,200 bps

Transmit

Time Delay

Programmable between 0 and 199 ms

Data

8 bit (1 start bit, 1 or 2 stop bits)

Parity

Even, Odd, or None with 1 or 2 stop bits

Byte-To-Byte

Timeout

0.01 –2.54 second

Turn Around

Delay

Less than 2 ms (fixed)

Note: Refer to the Modbus Register Tables located at

www.equflow.com for details.

60101044 Digital Input & Output Expansion

Module

Channels

4 digital inputs & 4 digital outputs per

module

System

Up to 2 modules for a total of 8 inputs & 8

outputs

Digital Input

Logic High

3 to 5 VDC

Digital Input

Logic Low

0 to 1.25 VDC

Digital Output

Logic High

3.1 to 3.3 VDC

Digital Output

Logic Low

0 to 0.4 VDC

Source

Current

10 mA maximum output current

Sink Current

1.5 mA minimum input current

+5 V Terminal

To be used as pull-up for digital inputs only

Connect normally open pushbuttons across

+5 V & DI 1-4.

MeterView Pro

System Re-

quirements

Microsoft®Windows®XP/Vista/7/8/10

Communica-

tions

USB 2.0 (Standard USB A to Micro USB

Configuration

Configure meters one at a time

Equflow 6010BCPM Pulse Input Batch Controller Instruction Manual

Compliance Information

Electromagnetic Compatibility

Emissions

EN 55022:2010

Class A ITE emissions requirements

Radiated

Emissions

Class A

AC Mains

Conducted

Emissions

Class A

Immunity

EN 61326-1:2013

Measurement, control, and laboratory equipment

EN 61000-6-2:2005

EMC heavy industrial generic immunity standard

RFI - Amplitude

Modulated

80 -1000 MHz 10 V/m 80% AM (1 kHz)

1.4 - 2.0 GHz 3 V/m 80% AM (1 kHz)

2.0 - 2.7 GHz 1 V/m 80% AM (1 kHz)

Electrical Fast

Transients

±2kV AC mains, ±1kV other

Electrostatic

Discharge

±4kV contact, ±8kV air

RFI - Conducted

10V, 0.15-80 MHz, 1kHz 80% AM

AC Surge

±2kV Common, ±1kV Differential

Surge

1KV (CM)

Power-Frequency

Magnetic Field

30 A/m 70%V for 0.5 period

Voltage Dips

40%V for 5 & 50 periods

70%V for 25 periods

Voltage

Interruptions

<5%V for 250 periods

Note:

Testing was conducted on 6010FCPM series meters installed through the covers of grounded metal

enclosures with cable shields grounded at the point of entry representing installations designed to

optimize EMC performance. All hardware is identical to the 6010BCPM controllers.

Declaration of Conformity available at www.equflow.com

Equflow 6010BCPM Pulse Input Batch Controller Instruction Manual

Safety Information

CAUTION: Read complete

instructions prior to installation and

operation of the controller.

WARNING: Risk of electric shock

or personal injury.

Warning!

Hazardous voltages exist within enclosure.

Installation and service should be performed

only by trained service personnel.

Installation

There is no need to remove the controller from its case to complete the installation, wiring, and

setup of the controller for most applications. Instructions are provided for changing the transmitter

power supply to output 5 or 10 VDC instead of 24 VDC, see page 10.

Unpacking

Remove the controller from box. Inspect the packaging and contents for damage. Report

damages, if any, to the carrier.

If any part is missing or the controller malfunctions, please contact your supplier or the factory for

assistance.

Panel Mounting Instructions

•Prepare a standard 1/8 DIN panel cutout –3.622" x 1.772" (92 mm x 45 mm). Refer to Figure 1 for

more details.

•Clearance: allow at least 6.0" (152 mm) behind the panel for wiring.

•Panel thickness: 0.04" - 0.25" (1.0 mm - 6.4 mm).

Recommended minimum panel thickness to maintain Type 4X

rating: 0.06" (1.5 mm) steel panel, 0.16" (4.1 mm) plastic panel.

•Remove the two mounting brackets provided with the controller (back-off the two screws so that there is

¼" (6.4 mm) or less through the bracket. Slide the bracket toward the front of the case and remove).

•Insert controller into the panel cutout.

•Install mounting brackets and tighten the screws against the panel. To achieve a proper seal, tighten

the mounting bracket screws evenly until

controller is snug to the panel along its short side. DO NOT OVER

TIGHTEN, as the rear of the panel may be damaged.

Figure 1: 1/8 DIN Panel Mounting

3.622" (92 mm)

1.772"

(45mm)

Panel Cutout

to DIN 43700

Square Corners to 0.060"

(1.5mm) Max Radius

Tolerances:

A: +0.032 (+0.8mm)

-0.000 (-0.0mm)

B: +0.024 (+0.6mm)

-0.000 (-0.0mm)

Equflow 6010BCPM Pulse Input Batch Controller Instruction Manual

Mounting Dimensions

Figure 2: Controller Dimensions - Side

View

Figure 3: Controller Dimensions - Top

View

Transmitter Supply Voltage Selection (P+, P-)

All controllers, including models equipped with the 12-24 VDC power option, are shipped from the

factory configured to provide 24 VDC power for the transmitter or sensor.

If the transmitter requires 5 or 10 VDC excitation, the internal jumper J4 must be configured

accordingly.

To access the voltage selection jumper:

1. Remove all the connectors.

2. Unscrew the back cover.

3. Slide the back cover about 1 inch.

4. Configure the J4 jumper, located behind the

input signal connector, for the desired

excitation voltage as shown. Figure 4: Transmitter Supply Voltage Selection

NC NC C

NO C

NC NC C

NO C+

-R

Table des matières

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
