EQUITY I+
Computer Specifications
CPU
MATH
CO.PROCESSOR
RAM
ROM
FLOPPY DISK
CONTROLLER
110
EXPANSION
SLOTS
SPEAKER
CLOCK/CALENDAR
RAM
KEYBOARD
POWER SUPPLY
MASS STORAGE
Standard
Optronal
Optional
Optional
INTERFACES
Standard
Standard
608610 mfcroprocessor 4 77MHz
or
1OMHz
swatch
selectable clock
speeds
8087 support (optron). 477MHz
or
1OMHz
64OKB.
parrty
brt
optronal
16K6
one socket
Supports four
droves
maximum.
5 25” double-densfty (360KB)
3 5”
(72OKEt)
Switch 1 Function
Frve
full length PC/XT conipatrble
slots
Internal. programmable
1
2 3 4567 8
Real-trme
clock/calendar
wrth
battery backup
Detachable. 3
posrtron.
enhanced
AT-style
Worldwrde
115/23OV
AC 80 watts
Two half
herghl
devrces
maxrmum
5 25” half
hetght
floppy
drsk
drove.
360K storage capacity
5 25’ half height floppy
drsk
drove
360K storage capacity
3 5” half height floppy
desk
drove.
720K storage capacity
3 5” half height hard
drsk
drive
20MB storage capacity
Centronrcs
compatible parallel
port
RS232C compatrble
serral
port
3f*
Enhanced Keyboard
In
Unenhanced Keyboard
off NPX Installed
On*
NPX Not installed
off*
oif’
RAM size = 640K
On Off RAM size = 576K
Off On RAM size = 512K
On On RAM size = 256K
off* off* Display = Monochrome
On Off Display = Dolor 80
Off On Display = Color 40
On On Display = Reserved
off off Number of
FDDs
= 4
On Off Number of
FDDs
= 3
Off On Number of
FDDs
= 2
On On Number of
FDDs
=
1
PHYSICAL CHARACTERISTICS
CPU
Keyboard
Wrdth
.
144rn
193Irl
Depth
148rn
7 7rn
Hefght
5 7rn
18rn
Werght
19
8lbs
3 9
Ibs
POWER
REGUIREMENTS
115V
AC. 60Hz 17A
230V AC.
50Hz.
0 9A
OPTIONS
Display Adapters Monochrome Display Adapter
Color Graphics Adapter
MGA (Multr Mode Graphics
Adapter)
EGA (Enhanced Graphics
Adapter)
Monrtors Monochrome Display
(720
x
350 dots)
Color Display (640
x
200 dots)
Enhanced Color Display
(640
x
200 or 640
x
350 dots
automatrcally selectable)
I
I
1
Switch Settings
1
The CPU SPEED switch selects between 4.77 MHz and 10
MHz. When the computer is running at 4.77 MHz, the power
light is orange, and at 10 MHz, the light is green.
System Configuration Switches
I/O Configuration
Switch 2
1 2 3 4
Function
off* off* Parallel port secondary
Off On Parallel port primary
On Gff Parallel port tertiary
On On Parallel port disabled
off* off* Serial port primary
On Off Serial port secondary
On
Serial port disabled
Equity Series Computers
* Factory Settings
12/12/88 EQI+ - 1
EQUITY I+
Connector Pin Assignments
Parallel Port Connector
PIN NO. SIGNAL NAME
DIRECTION DESCRIPTION
1
-STROBE 0
Strobe
2
DATA
0
0
Data
Bit 0
3
DATA 1 0
Data
Bit 1
4
DATA 2 0 Data Bit 2
5
DATA 3 0
Data Bit 3
6
DATA 4 0
Data Bit 4
7
DATA 5 0
Data Bit 5
a
DATA 6 0
Data Bit 6
9
DATA
7
0
Data Bit 7
ia
-ACK
-Acknowledge
11
BUSY
I
BUSY
12
PE
I
Paper Empty
13
SLCT
I
Printer Selected
14
-AUTO
FD 0
-Auto
Paper
Feed
15
-ERROR
I
-Error
16 -1NI'T
0
-Initialize
17
-SELECTIK
0
-Select In
18
^
25 GND Ground
Serial Port Connector
PIN NO.
SIGNAL NAME DIRECTION DESCRIPTION
1
NC No
connection
2
TRAKSMITTED
DATA 0
Transmitted
Data
3
RECEIVED DATA
I
Received Data
4
REQUEST TO SEND
0
Request to send
5
CLEAR TO SEND
I
clear
to send
6
DATA SET READY
I
Data Set Ready
7
SIGNAL
CROWD
Signal Ground
8
CARRIER DETECT
I
Carrier Detect
9-19 NC
No
cnnnection
20
DATA
TRAKSMIT
READY
0
Data Transmit Ready
21
NC No connection
22
RING INDICATOR
I
Ring Indicator
23-25 NC No connection
Keyboard Connector
PIN NO.
SIGNAL NAME DIRECTION DESCRIPTION
1
KBD CLK
I/O
Keyboard Clock
2
KBD DATA
I/O
Keyboard Data
3
-KBD RESET
0
-Keyboard Reset
4
GND
Ground
5
+5v Power
6
-a
NC
tie
connection
Note. The CURRENT LOOP functions are not supported. Standard
RSm232C
Interfacehas its function described
beloi;,
Pin 9 : TRANSllIT
CURRENT LOOP RETURN
Pin
11:
TRWSMIT
CURRENT LOOP DATA
Pin
ia:
RECEIVE CURRENT LOOP DATA
EQI+ -2
12/12/88 Equity Series Computers
I/O Port Addresses
Address Function
000-OlF
DMA Controller
020
-
03F
Interrupt Controller
040
-
05F
Timer
060
-
07F
Programmable Peripheral Interface
080
-
09F
DMA Page Register
OAX
NMI Mask Register
200
-
20F
Game Control
210-217 Expansion Unit
21F Reserved
278
-
27F
Parallel Printer Port 2
260
-
2DF
Alternate Enhanced Graphics Adapter
2El
GPIB
(Adapter 0)
2E2
-2E3 Data Acquisition (Adapter 0)
2F8
-2FF Serial Port 2
300-31F
Prototype Card
320
-
32F
Hard Disk
348
-
357
DCA 3278
360
-
367
PC Network (low address)
368
-
36F
PC Network (high address)
378
-
37F
Parallel Printer Port 1
380 -38F
SDLC,
Bisynchronous (BSC) 2
390
-
393
Cluster
3A0
-
3AF
Bisynchronous (BSC) 1
380
-3BF Monochrome Display and Printer Adapter
3C0 -3CF Enhanced Graphics Adapter
3DO-3DF Color Graphics Monitor Adapter
3F0
-
3F7
Floppy Disk Controller
3F8-3FF
Serial Port 1
1184
RTC Address Register (write only)
1185
RTC Data Register
EQUITY I+
Jumper Locations DMA Channels
Channel Function
0
Refresh
1
Spare
2
FDD Adapter
3
HDD Adapter
Jumper Settings for FDC, RAM, and EPROM
Configuration
I:““:’
3
,Function
A
B
A
l-l
B
A
B
FDC enabled
FDC disabled
Parity RAM disabled
Parity
RAM
enabled
64KB/128KB EPROM selected
256KB EPROM selected
Parity RAM lnstallation
The Equity I+ supports parity RAM checking to insure that
the data stored in memory is valid. To install this option,
insert two 50256 or 51256 chips in sockets 6M and 7M; and
4164 chips in sockets 6N and 7N. Then set jumper J2 as
shown in the table above.
Hardware Interrupts
Number
Function
IRQO
IRQl
IRQ2
IRQ3
IRQ4
IRQ5
Timer
Keyboard
EGA, PC Net,
3278179
Serial 2
Serial 1
Hard Disk
IRQ6
IRQ7
Floppy Disk
Printer
1
Equity Series Computers
12/12/88 EQI+ -3
EQUITY I+
lnstallation/Support Tips
Power
The Equity
If
has a power supply that is switchable
between 115 V, for US and Canadian use, and 230 V, for
use in other countries. The voltage switch is located at the
rear of the CPU between the AC inlet and the AC outlet.
(See figure below.)
Power
Inlet
/
RS232C
Serial
port
WARNING! The voltage is not changed between the AC
inlet and the AC outlet. If the CPU is switched for 230 V in
order to function in Europe, only peripherals certified for use
at 230 V should be plugged into the outlet.
Video Adapters
--- When using the Epson MGA video adapter in
conjunction with a monochrome monitor with the
Equity I+, set DIP switches 2- 1 and 2-2 both
OFF. This will define the parallel port as secondary
and avoid conflict with the address for a parallel
port on the video adapter. The port itself is not
installed on the adapter, but the address is in use.
--- When using an EGA or VGA video adapter in the
Equity I+, set DIP switches 1 -5 and 1 -6 both
ON.
Installing Floppy Disk Drives
-
When installing a floppy disk drive as drive B,
remember to set the drive select jumper to the
second position and attach the pass -through
connector on the floppy drive controller cable to the
drive, not the end connector.
EQI+ -4
12/12/88
Installing Hard Disk Drives
-
If you are having difficulty in formatting the hard
disk drive, try starting over with the Unconditional
Format option in diagnostics.
Third Party Option Boards
--- If you find that some third party option boards do
not function properly in the Equity I+ at the higher
speed, try setting the CPU speed back to 4.77 MHz.
Software Problems
--- When installing a copy - protected software package
on the Equity I +, set the the CPU speed to
4.77MHz. This has been found to have fewer
conflicts with copy -protection. After the installation,
the CPU can be switched back to the higher speed.
-
If a software package does not appear to be
compatible with the Equity I+, try switching the
CPU speed to 4.77MHz before giving up. Some
software packages (e.g., Disk Optimizer from
Softlogic Solutions) have been found to function
only at 4.77MHz.
Equity Series Computers
EQUITY I +
Product Support Bulletins
so010
so011
S-0016
S-0018
soo196
50023
s-0026
S-W31
VI87
Equity It
/Ill
t Worldwide Power Selection
618187 MS-DOS 3.2 Select Command Manual Error
a/25/87
ARNET
-
IDEA
-
3COM
-
ARCNET Certifications
g/16/87 SC0
-
Fox Research
-
Manzana Carfificatlons
12/2/87
Equity/Apex Coprocessor Selection Guide
1
O/29/87 Equity It
With
MGA Card
-
Parallel
Port
Setup
11/19/87
Equity t Series Compatibility Certification
12114187 Equity Series with Word and Serial Printers
3/3/88
Equity Series Power Available and Consumption
3/28/88
Equity It
-
Common Questions and Answers
6/7/89
Equity It File Creation Error Update
S-OCI47A
so0540
S-0061
S-0097
S-0092
6112189
5/18/88
W/@
lO/l2/88
6/WQ
l/6/89
v/89
4119189
6/13/89
S/IO/89
8/l
l/89
Using Expanded Memory
with
Equity and Apex
Equity Series
with
PLUS HARDCARD 20
Using
Math
Cnprocassors
with Equity and Apex
Equity t Series Novell Netware Certifications
Equity Series Computers
-
ROM History
Equity
Compatibility
with
the
SOTA296i
and the 286 Express
Equity It
/
EGA and VGA Video Adapters
Apex/Apex Plus/Equity Series Keyboards
Tapa Backup Systems Test
Results
Equity It with Manzana 3.5” External Floppy Drives
Novell Nefware Cnmpatibiity Results for
Equity
I+
EQI+-6
9/22/89
Equity Series Computers
EQUITY I+
Related Documentation
Q3QokA.4
laOsO
M-TMEQI
+
MPMEQI
+
PRM
MPL-EQI +
Y144QQ102101
Y144991022w
5/9/88
Equity I+ Software Package. MS-DOS 3.2 and
GW-Basic
Equity I+
software
Package. MS-DOS 3.3 Upgrade
Equity I+ Technical Manual
Equity I+ Programmer’s
Reference
hbnual
Equity
I+ Parts List
Equity I+ User’s Guide
Equity I+ Diagnostics Manual
Equity Series Computers
9/22/89
EQI + -7
Autres manuels pour Apex 110
2
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Epson Ordinateur de bureau
Epson
Epson Apex Manuel d'installation et d'exploitation
Epson
Epson EL 486UC+ Manuel utilisateur
Epson
Epson Equity 4 Dimensions
Epson
Epson ActionTower 8000 Manuel utilisateur
Epson
Epson ActionPC 8600 Manuel d'installation et d'exploitation
Epson
Epson Endeavor VL Manuel utilisateur
Epson
Epson EQUITY II+ Dimensions
Epson
Epson Apex 200 Dimensions
Epson
Epson EISA Tower Manuel utilisateur
Epson
Epson EQUITY Y14499113001 Manuel utilisateur
Epson
Epson Progression Manuel utilisateur
Epson
Epson Equity III Manuel utilisateur
Epson
Epson ExpressStation Manuel d'installation et d'exploitation
Epson
Epson Equity 486DX2/50 PLUS Manuel d'installation et d'exploitation
Epson
Epson ActionDesk 4000 Manuel utilisateur
Epson
Epson Endeavor Manuel utilisateur
Epson
Epson Endeavor Pro Manuel utilisateur
Epson
Epson Printer Manuel utilisateur
Epson
Epson EQUITY 3865X/20 PLUS Manuel utilisateur
Epson
Epson Stylus Pro 5000 - Print Engine Manuel d'installation et d'exploitation
