1 Overview
Based on a full-digital intelligent technology, the NPower series is a pure sine wave inverter, converting
12/24/48V DC power to 220/230V AC power. With advanced SPWM technology, voltage-current double
closed-loop control, and completely isolated inverter technology, the NPower has high-quality electrical
parameters and a stronger ability to resist impact load. The input terminal's surge prevention helps meet
the lithium battery's special requirements and ensures the inverter's safety and reliability.
The cage is designed with a galvanized board of high strength and corrosion resistance.
With high reliability, high efficiency, complete protection function, easy installation and operation, the
inverter is suitable for AC loads of household appliances, power tools, industrial equipment, electronic
audio and video, and solar PV power generation system(such as vehicle inverter application, solar RV,
solar household, solar yacht, and solar power station, etc.)
Features：
Advanced SPWM technology and pure sine wave output
Full digital double closed-loop control to enhance the load capacity
Completely isolated inverter technology for the input and output
Anti-surge design to support the lithium battery system perfectly
Lower output harmonic distortion(THD≤3%)
Excellent EMC design for the AC output to prevent interference of connected equipment
Selectable output voltage(220/230VAC) and frequency(50/60Hz) by the DIP switch
Extensive protection: input reverse polarity, input over voltage, input low voltage, output overload,
output short circuit, and overheating
Remote control and monitor the inverter by APP or PC software
Configurable input under voltage and input under voltage reconnect voltage via the APP or PC
software
Set the inverter's ID via theAPP or PC software to monitor several inverters.
Adopt a Galvanized board of high strength and strong corrosion resistance for the cage
Selectable output terminal: Chinese dual-socket, Australia/New Zealand, European, Universal, and
Terminal
Display running status by the local device(only NP4000-22(T) and NP5000-42(T)), optional external
remote meter
Easy maintenance and repair
