Epcom EPMONTVI4K Manuel utilisateur
EPMONTVI4K
User Manual
（V01.00）
Thank you for purchasing the IP camera tester. Please read the manual efore using the IP camera
tester and use properly.
For using the IP camera tester safely, please first read the「Safety Information」carefully in the
manual.
The manual should e kept well in case of reference.
Keep the S/N la el for after-sale service within warranty period. Product without S/N la el will
e charged for repair service.
If there is any question or pro lem while using the IP camera tester, or damages occurred on the
product, please contact our technical Department.
Content
1 .Safety information--------------------------------------------------------------------------------------------------1
2. IP Camera Tester Introduction------------------------------------------------------------------------------------2
2.1 General-------------------------------------------------------------------------------------------------------2
2.2 Packing list---------------------------------------------------------------------------------------------------3
2.3 Function interface-------------------------------------------------------------------------------------------4
3. Operation------------------------------------------------------------------------------------------------------------8
3.1 Installing the Battery---------------------------------------------------------------------------------------8
3.2 Instrument connection--------------------------------------------------------------------------------------9
3.2.1 IP camera connection------------------------------------------------------------------------------9
3.2.2 Analog camera connection-----------------------------------------------------------------------10
3.2.3 HD Coaxial camera connection-----------------------------------------------------------------11
3.2.4 HDMI IN ( *Optional )---------------------------------------------------------------------------12
3.3 OSD menu--------------------------------------------------------------------------------------------------12
3.3.1 Lite mode & Normal mode----------------------------------------------------------------------12
3.3.2 Drop-down Menu---------------------------------------------------------------------------------16
3.3.3 Short cut-menu------------------------------------------------------------------------------------17
3.3.4 Screen capture-------------------------------------------------------------------------------------18
3.3.5 TesterPlay------------------------------------------------------------------------------------------18
3.3.6 Rapid video----------------------------------------------------------------------------------------20
3.3.7 IP discovery----------------------------------------------------------------------------------------21
3.3.8 Rapid ONVIF test---------------------------------------------------------------------------------22
3.3.9 IP camera test--------------------------------------------------------------------------------------35
3.3.10 HDMI IN ( *Optional )------------------------------------------------------------------------38
3.3.11 Video monitor test-------------------------------------------------------------------------------42
3.3.12 Color- ar generator (TV OUT)----------------------------------------------------------------50
3.3.13 SDI Camera Test ( *Optional )----------------------------------------------------------------51
3.3.14 CVI camera test ( *Optional )-----------------------------------------------------------------52
3.3.15 TVI camera test ( *Optional )-----------------------------------------------------------------58
3.3.16 AHD camera test ( *Optional )----------------------------------------------------------------60
3.3.17 Network tool-------------------------------------------------------------------------------------62
（1）IP address scan------------------------------------------------------------------------------------62
（2）PING Test-----------------------------------------------------------------------------------------62
（3）Network test (Ethernet andwidth test)-------------------------------------------------------63
（4）Port Flashing--------------------------------------------------------------------------------------66
（5）DHCP server--------------------------------------------------------------------------------------67
（6）Trace route----------------------------------------------------------------------------------------67
（7）Link monitor--------------------------------------------------------------------------------------68
3.3.18 Rapid IP Discovery------------------------------------------------------------------------------69
3.3.19 PoE power / DC12V 2A and DC 5V 2A USB power output------------------------------69
3.3.20 Ca le Test----------------------------------------------------------------------------------------71
3.3.21 RJ45 ca le TDR test----------------------------------------------------------------------------72
3.3.22 Ca le Search ( *Optional )--------------------------------------------------------------------75
3.3.23 TDR ca le test ( *Optional )------------------------------------------------------------------76
3.3.24 PoE voltage and power measurement---------------------------------------------------------79
3.3.25 12V power input test----------------------------------------------------------------------------80
3.3.26 Digital Multi-meter ( *Optional )-------------------------------------------------------------81
3.3.27 Optical power meter ( *Optional )------------------------------------------------------------86
3.3.28 Visual Fault Locator ( *Optional )------------------------------------------------------------88
3.3.29 Audio Record------------------------------------------------------------------------------------89
3.3.30 Data monitor-------------------------------------------------------------------------------------90
3.3.31 Audio player--------------------------------------------------------------------------------------91
3.3.32 Media Player-------------------------------------------------------------------------------------91
3.3.33 RTSP Player--------------------------------------------------------------------------------------92
3.3.34 Hik test tool---------------------------------------------------------------------------------------93
3.3.35 Dahua test tool-----------------------------------------------------------------------------------96
3.3.36 Update---------------------------------------------------------------------------------------------99
3.3.37 Office--------------------------------------------------------------------------------------------100
3.3.38 LED Flashlight---------------------------------------------------------------------------------100
3.3.39 Browser------------------------------------------------------------------------------------------101
3.3.40 Notepad:-----------------------------------------------------------------------------------------102
3.3.41 System Setting----------------------------------------------------------------------------------103
3.3.42 File explorer------------------------------------------------------------------------------------107
3.3.43 Theme--------------------------------------------------------------------------------------------109
3. 4 Audio test------------------------------------------------------------------------------------------------111
3.5 PoE power output----------------------------------------------------------------------------------------112
3.7 DC12V 2A power output-------------------------------------------------------------------------------113
4. Specifications----------------------------------------------------------------------------------------------------115
4.1 General Specifications----------------------------------------------------------------------------------115
4.2 Multi-meter specifications------------------------------------------------------------------------------118
4.3 Optical power meter specifications--------------------------------------------------------------------120
4.4 Visual fault locator specifications---------------------------------------------------------------------121
1 .Safety information
◆ The tester is intended to use in compliance with the local rules of the electrical usage and avoid to
apply at the places which are inapplica le for the use of electrics such as hospital, gas station etc.
◆ To prevent the functional decline or failure, the product should not e sprinkled or damped.
◆ The exposed part of the tester should not e touched y the dust and liquid.
◆ During transportation and use, it is highly recommended to avoid the violent collision and vi ration
of the tester, lest damaging components and causing failure.
Don’t leave the tester alone while charging and recharging. If the attery is found severely hot, the ◆
tester should e powered off from the electric source at once. The tester should not e charged over 8
hours.
◆ Don’t use the tester where the humidity is high. Once the tester is damp, power off immediately and
move away other connected ca les.
◆ The tester should not e used in the environment with the flamma le gas.
◆ Do not disassem le the instrument since no component inside can e repaired y the user. If the
disassem ly is necessary indeed, please contact with the technician of our company.
◆ The instrument should not e used under the environment with strong electromagnetic interference.
◆ Don’t touch the tester with wet hands or waterish things.
◆ Don’t use the detergent to clean and the dry cloth is suggested to use. If the dirt is not easy to remove,
the soft cloth with water or neutral detergent can e used. But the cloth should e tweaked
sufficiently.
About Digital Multi-meter
◆ Before using, you must select the right input jack, function and range.
◆ Never exceed the protection limit values indicated in specifications for each range of measurement.
When the tester is linked to a measurement circuit, do not touch unused terminals.◆
Do not measure voltage if the voltage on the terminals exceeds 660V a ove earth ground.◆
At the manual range, when the value scale to e measured is unknown eforehand, set the range ◆
selector at the highest position.
Always e careful when working with voltages a ove 60V DC or 40V AC, keep fingers ehind the ◆
Page.1.
pro e arriers while measuring.
Never connect the meter with any voltage source while the function switch is in the current, resistance,◆
capacitance, diode, continuity, otherwise it will damage the meter.
Never perform capacitance measurements unless the capacitor to e measured has een discharged ◆
fully.
Never measure any of resistance, capacitance, diode or continuity measurements on live circuits.◆
Visual laser sources
When you turn on visual laser sources, please don’t stare at it, or will damage to eyes
When not using it, please turn it off and cover the protective cap .
2. IP Camera ester Introduction
2.1 General
The 4.3 inch IPS touch screen IP camera monitor is designed for maintenance and installation of IP
cameras, analog cameras, TVI, CVI AHD, SDI cameras, as well as testing 4K H.264 /4k H.265 camera
y mainstream, The 960x540 resolution ena les it to display network HD cameras and analog cameras
in high resolution. The unit supports many ONVIF PTZ and analog PTZ control. The com ination of
touch screen and key uttons make the IP camera tester very user- friendly.
The tester is also a great tool for Ethernet network testing. It can test PoE power voltage, PING, and IP
address searching. You can use the lue ca le tracer to locate individual connected ca les from a undle
of ca les. Test LAN ca le for proper connection termination. Other functions include providing 24W
PoE power to your camera, HDMI IN and out, CVBS loop test , testing IP and analog at the same time,
LED Flashlight, DC 12V 2A power output and much more. Its porta ility, user-friendly design and
many other functions make the IP tester an essential tool for all installers or technicians.
Page.2.
2.2 Packing list
1). Tester
2). Adaptor DC12V 2A
3) Network ca le tester
4) Polymer lithium ion attery (7.4V DC 5000mAh)
5). BNC ca le
6). RS485 ca le
7). SC,ST connector（Only for optical power meter）
8). Multi-meter test leads one pair of red and lack (only for the Multi-meter models)
9). Output Power ca le
10). Audio ca le
11). TDR alligator clamp (only for TDR models)
12). Safety cord
13). Tool ag
14). Manual
15).8GB SD card
Page.3.
2.3 Function interface
Page.4.
1
Press more than 2 seconds, turn on or off the device ,short press to turn on or off the
menu display
2Set key
3Menu key, press it to call shortcut- menu
4Near focus: Focus the image near y
5Far focus: Focus the image faraway
6TELE: zoom in the image
7WIDE: zoom out the image
8Open/set ,Confirm the setting of parameters, open or enlarge the aperture
9
Return/Close : Return or cancel while setting parameters of the menu, close or
decrease the aperture
10 Upward, set function or add parameter. Tilt the PTZ upward
11
Rightward, select the parameter whose value will e changed. Add the value of the
parameter. Pan the PTZ right
12 Confirm key (Long press it to capture screen interface)
13 Leftward, select the parameter whose value will e changed
14
Downward, set function or reduce the value of the parameter. Tilt the PTZ
downward
15 Snapshot
16 Video record
17 Open/set ,Confirm the setting of parameters, open or enlarge the aperture
18
Return/Close : Return or cancel while setting parameters of the menu, close or
decrease the aperture
19 Multimeter interface (Optional)
Page.5.
