FULL HD NETWORK CAMERA
7
CHAP1.INTRODUCTION
1‐4.Specification
Description Remark
Image Device /Scanning System 1/3 inch CMOS/ Progressive Scan
Effective Pixels arraysize 1,944(H) X1,092(V) : 2.1M
Min.Illumination 0.1Lux (ICR ON) with 50IRE
Quantityof IR LED 42 EA
Visual range 30M
Focal Length 2.8mm ~12.0mm (Vari Focal Lens) ±5%
Aperture Ratio F# 1.0
Angular Field ofView D: 128°±5%~36°±5% ; H : 100°±5%~29°±5% ; V : 73.2°±5%~21.7°±5%
Min. ObjectDistance 0.5M
Audio Input/ Output 1 * Line Input / 1 * Line Output
Audio Compression Method G.711 PCMU, G.711 PCMA, G.726
Day& Night Color, Optical ICR Filter
BacklightCompensation ON / OFF
Motion Detection ON (5 programmable zones) /OFF
White Balance Auto / Indoor / Outdoor
Electronic Shutter Speed Auto /Flickerless(ON/50Hz,60Hz) / Manual (1/6~ 1/1000sec)
PrivacyMasking 8 regions
Flip Mode Horizontal,Vertical
Video Out CVBS: Composite NTSC/PAL, BNC connector
Ethernet RJ-45 (10/100BASE-T)
Video Compression Format H.264 /MJPEG
Max.Resolution @FPS H.264 /MJPEG:1920 x1080 / 1280 x720 /704 x480 / 352 x240 @ 30 fps
Video QualityAdjustment H.264 :Compression Level,TargetBitrate Level Control
MJPEG:QualityLevel Control (5 step)
Bitrates Control Method H.264:VBR,CBR /MJPEG:VBR
Streaming Capability Primary,Secondary
IP DHCP/IPv4
Protocol ONVIF, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS,
DHCP,FTP,SMTP ,ARP,DNS,DDNS
Security HTTPS Login Authentication,IPAddress Filtering,User access Log
Streaming Method Unicast,Multicast
Max.User Access 4 users
Recording Mode Always/Motion Detection/ Event/ Schedule
Webpage Language English
Supported OS :Windows XP Higher
Supported Web Browser :Internet Explorer 7.0 or Higher
Central ManagementSW EVMS (9CH Bundle Software)
Mobile Viewer M-EYES
MemorySlot SD/SDHC MemorySlot
Operating Temperature /Humidity -10°C ~+50°C (+14°F~ +122°F) /20% ~ 80% RH
Dustproofand Water Proof IP68 Grade(Weatherproof)
PowerConsumption PoE, DC12V/700mA, AC24V(Option)
Dimension /Weight 98.7(W) x90.22(H) x309.3(D)mm / Material : Aluminium / 1.43 kgs
Network
Web Viewer
Others
Fetures
Function
Camera
Lens
Audio
