Installation and Maintenance Manual
EP-2000 DIN
2
EP Technical Support: techsupport@ep2000.com • 800.500.7436
Mailing Address: 1802 N. Carson Street, Suite 108-2132, Carson City, NV 89701
FIVE YEAR WARRANTY
• Environmental Potentials will replace or repair EP-2000 DIN as long as it was not
damaged during installation or damaged from faulty installation.
• EP warranty registration card must be filled out and received by Environmental
Potentials within 15 days of installation.
• is warranty is for the repair or replacement of damaged EP products only.
Environmental Potentials accepts no liability, written or expressed, for the damage
that may have occurred to any other equipment; nor does Environmental Potentials
warranty cover any labor cost associated with replacement of such product.
Contact Us: warranty@ep2000.com •800.500.7436
Table of Contents
3 – Safety First
3 – Pre-Installation Preparations
4 – Wiring for loads 15 Amps or less
5 – Wiring for loads greater than 15 amps
6 – Wiring for DC Applications
EP-2000 DIN
Installation and Maintenance Manual
EP-2000 DIN INSTALLATION GUIDE
4EP-2000 DIN INSTALLATION GUIDE
Wiring for loads 15 Amps or less:
1. Screw in the input neutral from the incoming neutral source to screw terminal number 1.
2. Screw in the input phase from the incoming power source to screw terminal number 4.
3. Screw in the output neutral to screw terminal number 2 and connect to the input neutral terminal of the load.
4. Screw in the output phase to screw terminal number 5 and connect it to the input phase terminal of the load.
PLC Power Supply
DIN RAIL
Input Voltage
N
1 2 3 4 5
L
HOT
HOT
NEUTRAL
NEUTRAL
NEUTRAL
L 3
L 2
L 1
®
CAUTION – Ungrounded power systems are inherently unstable and can produce excessively high line-
to-ground voltages during certain fault conditions. During these fault conditions any electrical equipment,
including an SPD, may be subjected to voltages which exceed their designed ratings. is information is being
provided to the user so that an informed decision can be made before installing any electrical equipment on
an ungrounded power system.
EP-2000 DIN INSTALLATION GUIDE5
Wiring for loads greater than 15 amps:
1. Screw in the input neutral from the incoming neutral source to screw terminal number 1.
2. Screw in the input phase from the incoming power source to screw terminal number 4.
3. Screw in the input neutral from the incoming neutral source to the incoming neutral terminal of the load.
4. Screw in the input phase from the incoming power source to the incoming phase terminal of the load.
PLC Power Supply
Load at Greater than 15A
DIN RAIL
Input Voltage
N
1 2 3 4 5
L
HOT
HOT
NEUTRAL
NEUTRAL
NEUTRAL
L 3
L 2
L 1
*Do not install on loads greater than 25 amps
®
*also use this install method if the output wire size is larger than AWG#12
CAUTION – Ungrounded power systems are inherently unstable and can produce excessively high line-
to-ground voltages during certain fault conditions. During these fault conditions any electrical equipment,
including an SPD, may be subjected to voltages which exceed their designed ratings. is information is being
provided to the user so that an informed decision can be made before installing any electrical equipment on
an ungrounded power system.
EP-2000 DIN INSTALLATION GUIDE 6
PLC POWER SUPPLY
DIN RAIL
Output Voltage 1 2 3 4 5
NEGATIVE (-)
POSITIVE (+)
-
+
Wiring for DC Application:
1. Screw in the input (+) DC from the incoming (+) DC source to screw terminal number 1.
2. Screw in the input (-) DC from the incoming power source to screw terminal number 4.
3. Screw in the output (+) DC to screw terminal number 2 and connect to the input (+) DC terminal of the load.
4. Screw in the output (-) DC to screw terminal number 5 and connect it to the input (-) DC terminal of the load.
CAUTION – Ungrounded power systems are inherently unstable and can produce excessively high line-
to-ground voltages during certain fault conditions. During these fault conditions any electrical equipment,
including an SPD, may be subjected to voltages which exceed their designed ratings. is information is being
provided to the user so that an informed decision can be made before installing any electrical equipment on
an ungrounded power system.
®
