Entrematic Ditec E2H Manuel utilisateur

IP2019

rev. 2012-09-26

LUXO - E2H QUICK REFERENCE

XEL5

XEL2

TX XEL2 RX

4x0,5 mm²

3x1,5 mm²

TRANSFORMER

4x0,5 mm²

3x1,5 mm² (max 10 m)

0 1

Power supply

RG58 (max 10 m)

2x1,5 mm²

E2H

LN 15 14 015 9 13 1520 01 60

343635 33 32 31

GOL4-GOL4C

AMPH

ANT

LUXO3BH/4BH

E2H

LUXO3BH/4BH

1. ELECTRICAL CONNECTIONS FOR STANDARD INSTALLATION

Before installing the product, carefully read the instructions.

IP2019 • 2012-09-26

Regolazione finecorsa

di apertura

Opening limit switch

adjustment

C Regolazione finecorsa di chiusura

Closing limit switch adjustment

C C

NO NO

NC NC

33/36 32/35 31/34

A C

Motor

24V=

MOTOR 2MOTOR 1

3133 32

MOTOR 1

24V=

33/36

31/34

3436 35

MOTOR 2

24V=

33/36

31/34

3436 35

MOTOR 2

24V=

33/36

31/34

MOTOR 2 MOTO

R 1

3133 32

MOTOR 1

24V=

33/36

31/34

2. LIMIT SWITCHES CONNECTION (OPTIONAL)

3. LUXO MOTORS CONNECTION

3IP2019 • 2012-09-26

Slow down

speed

MOTOR 2 MOTOR 1

OPENING CYCLE

CLOSING CYCLE

MOTOR 2

MOTOR 1

OPENING CYCLE

CLOSING CYCLE

CLOSING

MECHANICAL STOP

CLOSING

MECHANICAL STOP

OPENING

MECHANICAL STOP

OPENING

MECHANICAL STOP

OPENING

MECHANICAL STOP

OPENING

MECHANICAL ST

4.1 USAGE WITHOUT LIMIT SWITCHES

4.2. USAGE WITH STOP LIMIT SWITCHES (OPTIONAL) - DEFAULT SETTING

4.3. USAGE WITH SLOW DOWN LIMIT SWITCHES (OPTIONAL)

Opening limit

switch setting

Closing limit

switch setting

Slow down

speed

Opening limit

switch setting

Closing limit

switch setting

Slow down

speed after

limit switch

activation

OPENING CYCLE

CLOSING CYCLE

MOTOR 1MOTOR 2

CLOSING

MECHANICAL STOP

CLOSING

MECHANICAL STOP

OPENING

MECHANICAL STOP

OPENING

MECHANICAL STOP

OPENING

MECHANICAL STOP

OPENING

MECHANICAL STOP

IP2019 • 2012-09-26

5. LUXO SETTING

JR5

DOWN



ENTERESC

E2H

15913

36 35 34

JR1

33 32 31 15 14 0 1520 016 018

LUXO MEMORY CARD

M1LX

FIRST TIME ONLY WHEN POWER ON

7.3 OPENING MODE WITH AUTOMATIC CLOSING SETTING (DEFAULT: 1 minute)

7.2 STEP BY STEP MODE WITH AUTOMATIC CLOSING SETTING (DEFAULT: 1 minute)

7.1 STEP BY STEP MODE WITHOUT AUTOMATIC CLOSING SETTING

6. RADIO ENABLING

2 s

DITEC S.p.A.

Via Mons. Ban, 3

21042 Caronno Pertusella (VA) - ITALY

Tel. +39 02 963911 - Fax +39 02 9650314

www.ditec.it - [email protected]

For different setting and further information consult the automation instruction manual, the control panel

instruction manual and radio instruction manual.
