Entone Hydra HD Manuel utilisateur
Version 1.0
Date: 2/23/2009
Hydra HD Setup Guide
for
3
rd
Party Remote Control
Hydra HD Setup Guide for 3
rd
Party Remote Control – 1 –
Copyright © 2008 Entone Technologies (HK) Ltd.
V1.2
Entone Technologies (HK) Ltd.
On the web at http://www.entone.com
Copyright © 2008 Entone Technologies (HK) Ltd. All rights reserved. No part of this document
may be copied or reproduced in any form, or by any means, electronic or mechanical, for any
purpose, without the express written permission of Entone Technologies (HK) Ltd.
Notice
Every effort was made to ensure that the information in this document was complete and accurate
at the time of printing. However, information is subject to change without notice.
Limited Warranty
Entone Technologies (HK) Ltd. assumes no responsibility for any errors that may appear in this
manual. Companies, names, and data used in examples herein are fictitious unless otherwise
noted. Entone makes no warranties with respect to this documentation and disclaims any implied
warranties of merchantability or fitness for a particular purpose. From time to time changes may
occur in the file names and in the files actually included on the distribution disks. Entone makes
no warranties that such files or facilities, as mentioned in this documentation, exist on the
distribution disks or as part of the materials distributed.
Hydra HD Setup Guide for 3
rd
Party Remote Control – 2 –
Copyright © 2008 Entone Technologies (HK) Ltd.
V1.2
Revision History:
Revision Date Updated by Changed/Remarks
v1.0 16 July 2008
Kenrick Fu Initial version
V1.1 14 Aug 2008
Kenrick Fu Updated setup instructions for Sling Player 2.0
V1.2 17 Sep 2008
Kenrick Fu Updated code 1 support for Sling Player 2.0
Hydra HD Setup Guide for 3
rd
Party Remote Control – 3 –
Copyright © 2008 Entone Technologies (HK) Ltd.
V1.2
1
Introduction ................................................................................................................................................................4
2
Programming TiVO IR remote to control Hydra HD ...................................................................................................5
3
Programming Slingbox remote to control Hydra HD................................................................................................10
3.1
For Sling Player 1.x ..........................................................................................................................................10
3.2
For Sling Player 2.0 ..........................................................................................................................................14
4
Programming 3rd Party Universal Remote Control..................................................................................................16
4.1
Learning Mode..................................................................................................................................................16
4.2
Preprogrammed Device....................................................................................................................................16
Hydra HD Setup Guide for 3
rd
Party Remote Control – 4 –
Copyright © 2008 Entone Technologies (HK) Ltd.
V1.2
1 Introduction
This document describes the programming of 3
rd
party remote control for the use with Hydra HD Set Top Box. It covers
the use of TiVO IR control, Slingbox IR, programming 3
rd
party universal remote control with IR learning mode or
preprogrammed devices.
Hydra HD supports the following preprogrammed devices. Please refer to later sessions for details of programming
your remote control.
•MAGNAVOX 10024-B (TV)
•CENTURION 00092-B (TV)
•TOSHIBA TSR-202 (Satellite Box)
•HITACHI HDS-100R (Satellite Box)
The table below summarizes the supported keys in TiVO, Slingbox and 3
rd
party universal remote controls:
Remote Control Supported Keys
TIVO (including MAGNAVOX 10024-B,
CENTURION 00092-B, TOSHIBA TSR-202,
HITACHI HDS-100R)
Num Key 0 – 9, Channel Up/Channel Down, POWER
3
rd
Party Remote Controls Num Key 0 – 9, Channel Up/Channel Down, POWER
Slingbox (SlingPlayer 2.0) UP, DOWN, LEFT, RIGHT, Num Key 0 –9, MENU, POWER, FF,
REW, PAUSE, PLAY, STOP, GUIDE, INFO, SELECT, EXIT
Hydra HD Setup Guide for 3
rd
Party Remote Control – 5 –
Copyright © 2008 Entone Technologies (HK) Ltd.
V1.2
2 Programming TiVO IR remote to control Hydra HD
Hydra HD supports 4 IR keycodes and they are configured in TiVo as follows :
IR Key Code Supported by
Entone
Brand in TiVo
Central
TiVO IR Code
MAGNAVOX 10024-B Cable Box 10024-B
CENTURION 00092-B Cable Box 00092-B
TOSHIBA TSR-202 Satellite Box 00126-B
HITACHI HDS-100R Satellite Box 10008-B
The example belows illustrates the use of TiVO IR key code with MAGNAVOX 10024-B or CENTURION 00092-B.
1. Press “INPUT” and then “MENU” in sequence within 1 second on the Entone Universal Remote Control to
enter the User Menu. Under URC IR KeyCode, select MAGNAVOX 10024-B or CENTURION 00092-B, and
then select SUBMIT to save the changes.
Hydra HD Setup Guide for 3
rd
Party Remote Control – 6 –
Copyright © 2008 Entone Technologies (HK) Ltd.
V1.2
2. Go to TiVo Channel Changing screen. From TiVo Central; select Messages & Setting > Setting >
Channels > Channel Changing
3. Select No, I’ve switched to a different cable box.
4. Select MAGNAVOX or CENTURION (the brand that selected in Step 1 from Entone User Menu need to match
with TiVo selection below).
Hydra HD Setup Guide for 3
rd
Party Remote Control – 7 –
Copyright © 2008 Entone Technologies (HK) Ltd.
V1.2
5. Make sure the IR cable is connected to the Hydra properly (please refer to the Tivo documentation for proper
connection) and select OK, I’m sure the IR cable is hooked up correctly.
6. Select “005” (typical for digital cable)
7. Select NO (typical).
Hydra HD Setup Guide for 3
rd
Party Remote Control – 8 –
Copyright © 2008 Entone Technologies (HK) Ltd.
V1.2
8. On the TiVo remote, press the following keys in order: THUMBS UP > THUMBS DOWN > PAUSE > PLAY
•You should hear 5 rings when you enter the key sequence above. If you do not hear the rings, enter
the code again.
9. On the Channel Changing Tests screen, you should now see the phrase “Press ENTER for advanced setup”
at the bottom of the screen. Press the ENTER key on your remote.
10. You will now see the Cable Channel Changing Advanced Setup screen. Highlight IR Code and press
SELECT.
11. Enter 10024 for MAGNAVOX IR Code, then press SELECT. Or enter 00092 for CENTURION IR Code, then
press SELECT.
Hydra HD Setup Guide for 3
rd
Party Remote Control – 9 –
Copyright © 2008 Entone Technologies (HK) Ltd.
V1.2
12. On the next screen, select 10024-B for MAGNAVOX or 00092-B for CENTURION.
13. Once you have selected a code, select Use these settings. You should now be able to change channels
using IR control.
