EnGenius M36 Manuel utilisateur

M36

Wireless High power AP

2.4GHz Super G 108Mbps Access Point/ WDS/Universa Repeater

Package Contents

- 1* High power mu ti-function

AP (M36)

- 1* 12V/1A Power Adapter

- 1* CAT5 UTP Cab e

- 1*QIG

- 1*CD (User’s Manua )

- 1* Wa mount screw set

The M36 is a smoke detector ooking Wire ess Access Point / Universa

Repeater / WDS that operates seam ess y in the 2.4 GHz frequency

spectrum supporting the 802.11b (2.4GHz, 11Mbps) and Super high

speed of 802.11g (2.4GHz, 108Mbps) wire ess standards. It's the best

way to add wire ess capabi ity to your existing wired network, or to add

bandwidth to your wire ess insta ation.

M36 features high transmitted output power and high receivab e

sensitivity a ong with antenna diversity. High output power and high

sensitivity can extend range and coverage to reduce the roaming

between Access Points to get a more stab e wire ess connection. It a so

reduces the expense of equipment in the same environment.

To protect your wire ess connectivity, it can encrypt a wire ess

transmissions through 64/128-bit WEP data encryption and a so

supports WPA/WPA2. The MAC address fi ter ets you se ect exact y

which stations shou d have access to your network. In addition, the User

Iso ation function can protect the private network between c ient users.

The attractive design, high performance, and array of features make

M36 a suitab e wire ess so ution for your residence or office.

Features

Features Benefits

Mesh Networking Convenient Wire ess Connection bui d up. In this mode for better

performance, recommended 1 Gateway with 4 Re ay in inear and

radiative dep oyment scenario.

Super G so ution up to 108Mbps

Capab e of hand ing heavy data pay oads such as MPEG, video

streaming, arge fi e transfer and VoIP

High Output Power up to 28 dBm

Extended exce ent Range and Coverage (fewer APs)

IEEE 802.11b/g Comp iant Fu y Interoperab e with IEEE 802.11b/IEEE802.11g comp iant devices

Embedded Antenna Users won’t see antenna in your bui ding environment

Point-to-point,

Point-to-mu tipoint Wire ess

Connectivity

Let users transfer data between two bui dings or mu tip e bui dings

M36

Wireless High power AP

2.4GHz Super G 108Mbps Access Point/ WDS/Universa Repeater

WDS

(Wire ess Distributed System)

Make wire ess AP and Bridge mode simu taneous y as a wire ess

repeater

Repeater The easiest way to expand your wire ess network's coverage

Support Mu ti-SSID function

(4 SSID) in AP mode

A ow c ients to access different networks through a sing e access point

and assign different po icies and functions for each SSID by manager

Antenna diversity support Enhance the traffic signa

WPA2/WPA/ IEEE 802.1x

support

Powerfu data security

MAC address fi tering in AP

mode(up to 50)

Ensures secure network connection

User iso ation support

(AP mode)

Protect the private network between c ient users.

Power-over-Ethernet

(IEEE802.3af)

F exib e Access Point ocations and cost savings

Keep persona setting Keep the atest setting when firmware upgrade

SNMP Remote Configuration

Management

He p administrators to remote y configure or manage the Access Point

easi y.

QoS (WMM) support Enhance user performance and density

Technical Specifications

Hardware Specification

Memory 32MB SDRAM

F ash 8MB

Expansion S ots N/A

Physica Interface LAN: One 10/100 Fast Ethernet RJ-45

Reset Button

Power Jack

LEDs Status Power/ Status

LAN (10/100Mbps)

WLAN (Wire ess Connection)

Power Requirements Power Supp y: 100 to 240 VDC ± 10％, 50/60 Hz (depends on different countries)

Active Ethernet (Power over Ethernet, IEEE802.3af)- 48 VDC/0.375A

M36

Wireless High power AP

2.4GHz Super G 108Mbps Access Point/ WDS/Universa Repeater

Device: 12V/1A

Regu ation

Certifications

FCC Part 15, ETSI 300/328/CE

RF Specification

Frequency Band 2.400～2.484 GHz

Media Access Protoco

Carrier sense mu tip e access with co ision avoidance (CSMA/CA)

OFDM: BPSK, QPSK, 16-QAM, 64-QAM Modu ation

Techno ogy DBPSK, DQPSK, CCK

Operating Channe s 11 for North America, 14 for Japan, 13 for Europe

IEEE802.11g EEE802.11b Receive Sensitivity

(Typica ) I6Mbps@ -92dBm

54Mbps@ -74dBm

1Mbps@ -97dBm

11Mbps@ -89dBm

IEEE802.11g IEEE802.11b

Avai ab e transmit

power

(The Max. Power wi

be different depending

on oca regu ations)

26dBm@6~24 Mbps

25dBm@36 Mbps

23dBm@48 Mbps

22dBm@54Mbps

27dBm@1 ~ 11Mbps

Antenna Directiona Embedded antenna (Diversity support)

Antenna Gain = 4 dBi

Standard IEEE 802.11n and 802.11b/g

Frequency Range 2.4 to 2.49 GHz

Peak Gain 4 dBi

VSWR 2:1

Feed Impedance 50 Ohms

Power Hand ing 30 dBm

Interface Two sets of so dering pads for 50 ohm,1.13mm diameter,

micro coax cab e

100 x 50 (mm)

Antenna Specification

Antenna Dimensions

M36

Wireless High power AP

2.4GHz Super G 108Mbps Access Point/ WDS/Universa Repeater

Weight 0.3oz (9 grams)

Antenna Radiation

Patterns

Software Features

Setting

Topo ogy Infrastructure

Operation Mode Access Point/ Repeater/WDS

LAN DHCP C ient

VPN VPN pass-through (PPTP, L2TP, IPSEC)

Wire ess - Wire ess Mode – 11b / 11g / Super G / Disab e

- Channe Se ection (Setting varies by Country)

- Transmission Rate

11 b/g: 108, 54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 in Mbps

- Transmit power contro (by dBm)

- Antenna Diversity

M36

Wireless High power AP

2.4GHz Super G 108Mbps Access Point/ WDS/Universa Repeater

Security - WEP Encryption-64/128/152 bit

- WPA Persona (WPA-PSK using TKIP or AES)

- WPA Enterprise (WPA-EAP using TKIP)

- 802.1x Authenticator

- Hide SSID in beacons

- Mu tip e SSID with 802.1q VLAN tagging (up to 4 SSIDs)

- MAC Fi ter

- L2 iso ation

- Wire ess STA (C ient) connected ist

QoS WMM

Management

Configuration Web-based configuration (HTTP)/Te net

Firmware Upgrade - Upgrade firmware via web-browser

- Keep atest setting when f/w update

Administrator Setting - Administrator password change

Reset Setting - Reboot (press 1 second)

- Reset to Factory Defau t (press more than 5 seconds)

System monitoring Status, Statistics and Event Log

SNMP V1, V2c

MIB MIB I, MIB II (RFC1213)

Backup & Restore Settings through Web

LED on/off Remote contro LED on/off

En ironment & Mechanical

Temperature Range Operating: 0°C to 45°C (32°F to 113°F)

Storage: -20°C to 70°C (-4°F to 158°F)

Humidity

(non-condensing)

5%～95% typica

Dimensions Diameter:120mm

Height: 50mm

M36

Wireless High power AP

2.4GHz Super G 108Mbps Access Point/ WDS/Universa Repeater

Weight 280g
