ENERMAX PRO80PLUS Manuel utilisateur

PRO80+ Power Supply Series

FEATURES

80PLUS ready!

80-86% efficiency @ 20-100% load. Compliant with 80PLUS®efficiency requirements.

AirGuard

Patented air-inlet with optimal aero-dynamical design reducing noisy air turbulences.

SpeedGuard

Advanced fuzzy logic 12cm fan speed control for optimal cooling and minimum noise. (Patented)

SafeGuard

Industry-leading octuple protection circuitry of OCP, OVP, AC UVP, DC UVP, OPP, OTP, SCP & SIP.

ATX12V v2.3 ready!

Compliant with the newest standard for desktop power supplies.

DXXI ready!

100% 6+2P (8P) PCI-E connector to support new generation DXXI graphic cards.

ErP Lot 6 2010 ready!

Help system to meet ErP Lot 6 2010 (<1W at standby mode) with high efficiency 5Vsb circuitry.*

GAMING ready!

ATX12V v2.3 support for latest Intel®Core™ 2 Duo/Quad/i7/i5/i3, and AMD®Athlon™ 64X2 & Phenom™ II X3/X4/X6

and SLI®or CrossFireX™.

24/7 @ 40°C ready!

Non-Stop industrial class performance at 40°C/104°F ambient.

WORLD ready!

100-240VAC in with automatic adjustment and active PFC for global usage.

Japanese Main Capacitor

Highest components standards for maximum durability and stability.

400W / 500W

620W / 720W

www.enermax.com forum.enermax.com

*Required for ErP Lot 6 2010 compliant systems.

ErP Lot

2010 ready

3 Years Warranty

www.enermax.com forum.enermax.com

ErP Lot 6 2010 ready!

Advanced +5Vsb circuitry with up to 20% improved efficiency

in comparison to generic designs helps your system meet

ErP Lot 6 2010 (AC < 1W at standby) requirement.

*With ErP Lot 6 enabled motherboard.

SpeedGuard

Advanced fuzzy logic 12cm fan speed control for optimal

cooling and minimum noise.

1500

1200

800

600

450450450

500

1000

1500

2000

2500

7 5

100

450

FAN RPM (±10%)

PSU Loading (@ 25°C ambient)

720W

400/500/620W

24/7 @ 40ºC ready!

Non-Stop industrial class performance at 40°C/104°F ambient.

2Symmetric Double Forward topology

For high efficiency performance.

115% output transformer

Ensure maximum output quality @ 40oC/104oF extreme environment.

Enhanced EMI filtering

Protect nearby appliance against EMI interference.

Surge & inrush protection

To protect PSU and system against lightning and inrush current strokes.

Japanese heavy-duty main capacitor

For reliable power output.

SafeGuard + PWM combo control IC

For best safety.

105oC secondary capacitors

For best durability.

Dual anodized aluminum heatsink with array splitting

For rapid heat dissipation.

80PLUS ready! (Max. 86% @ 230VAC)

Gaming system @300W load

Efficiency*1 AC Draw(W)

Annual Money

wasted*3

Annual CO2

wasted*4

Annual

KWh*2

Annual

KWh

wasted

PRO80+ 620W

86% 1273 - - -

other ~77% 600W

77%

348.8

389.6 1422 149 $22 / €32.7 92.3kg

*1 Based on 230VAC input power.

*2 Annual KWh is estimated based on 10 hours a day, 365 days a year runtime. Formula: AC Draw(w) x 10(hr) x 365(days)/1000

*3 1KWh = $0.1501(California) /

€

0.22(Germany).Fare might vary by countries and regional providers.

*4 Calculation based on 1 KWh=0.62kg CO2. Figures might vary by countries.

20% 50% 100%

PSU Loading

230VAC

115VAC

PSU Efficiency

High efficiency standard & ECO design, certified.

PSU +5Vsb efficiency @ 0.09A load, 230VAC

36%

57%

Non ErP Lot 6 2010

Compliant PSU

ENERMAX ErP Lot 6

2010 Compliant PSU

*400/500W model illustrated

www.enermax.com forum.enermax.com

Specifications

Cables & Connectors

Safety & Certifications

+3.3V

+5V

+12V1

+12V2

6.7-3A 7.5-3.5A 9.5-4A

EES400AWT-GP EES500AWT-GP EES620AWT-GP

0.1-20A

0.1-22A

0.5-22A

120W 130W

384W (32A)

0.1-24A

0.1-30A

0.5-30A

140W

576W (48A)

-12V 0.6A 7.2W 0.6A 7.2W

+5Vsb 3A 15W

0.1-24A

0.5-24A 456W (38A)

0.6A 7.2W

3A 15W 3A 15W

440W 550W 680W

Input Voltage

Input Current

400W 500W / 620W / 720W

45cm 75cm

50cm 55cm 60cm 65cm 70cm

24P Mainboard

4+4P CPU 12V

6+2P PCI Express

SATA

4P Molex 4P Molex

FDD

45cm 75cm 85cm

50cm 55cm 60cm 65cm 70cm 80cm

24P Mainboard

4+4P CPU 12V

8P CPU 12V

6+2P PCI Express

SATA SATA SATA SATA

SATA SATA

4P Molex 4P Molex

4P Molex 4P Molex 4P Molex

0.1-24A

0.1-25A

0.5-25A

+12V3 - - - 0-25A

140W

660W (55A)

0.6A 7.2W

3A 15W

Model Name

AC Input Rating

100-240VAC, 50-60Hz, Active PFC

Max. range : 90-265VAC

DC Output Rating

Peak Power

Total Power 400W 500W 620W

10-4A

EES720AWT-GP

790W

720W

Safety

EMC

differ from illustrations. Omissions and printing errors excepted. Content of delivery might differ in different countries or areas.Some trademarks may be claimed

as the property of others.

*2 500W / 620W only

6+2P PCI Express

*4 720W only

720W only

*1 500W / 620W

*2 720W

4P Molex

*1 500W only

4P Molex

*1 620W / 720W

only
