Declaration of conformity 10 ..........................................................................................................................................

2/10 energysistem.com

3/10 energysistem.com

Introduction

Thank you for trusting our company and buying the new Tower EU True Wireless. We hope you enjoy it. Before you start

using the device, we strongly recommend reading this manual to get used to it.

Care and maintenance

Do not expose your Tower EU True Wireless to impacts, dust, humidity or high temperatures.

Use neither corrosive nor abrasive cleaning products.

Do not press the speaker membranes since they could be damaged.

Do not disassemble the device. All repair works should be carried out exclusively by qualiﬁed staﬀ of Energy

Sistem Technology, S.A.

4/10 energysistem.com

Features

General features

Amazing 2.1 sound tower with 65 W real output power.

True Wireless system to pair two sound towers and enjoy powerful sound at home.

Wireless sound. Transfer your music wirelessly within 20 m distance with Bluetooth 5.0 technology.

Don't let the music stop. Play the MP3 ﬁles from your microSD cards or USB memory sticks (up to 128 GB

capacity).

Several EQ modes to adjust sound according to your preferences.

Touch panel on the tower upper part for easy operation.

You can easily control all tower functions with the remote control.

You will never run out of battery again. This sound tower features a USB port to connect your tablet or

smartphone and charge your devices while enjoying the best music.

Don?t worry about your smartphone or tablet when charging the battery. You can place them safely on the top

holder.

High-quality wood ﬁnish for better sound quality.

Technical speciﬁcations

Audio

AUDIO

Sound system: stereo (2.1).

Power: 65 W

Frequency response: 40 Hz - 18 kHz.

1 subwoofer: 5", 30 W.

2 full range speakers: 4", 15 W.

1 tweeter: 1", 5 W.

Bass reﬂex.

Signal/Noise ratio: > 90 dB

Bluetooth

Bluetooth 5.0. True Wireless Stereo. Class II.

Up to 20 m range.

Compatible Bluetooth proﬁles: A2DP, AVRCP.

Frequency band: 2.4 GHz.

Maximum output power: < 20.00 dBm.

TWS technology compatible with

Tower EU True Wireless

Tower 5 g2

USB and microSD player

128 GB USB and microSD MP3 player.

Supported formats: WAV and MP3.

Change folder feature.

Shuﬄe and repeat modes.

Analogue inputs

3.5 mm jack input (analogue input).

Power requirements

AC/DC power adapter: 100 ~ 240 V / 50 ~ 60 Hz

Plug for electric socket: EU plug

Power cable length: 150 cm

Power consumption at medium volume: 6 Wh

Power consumption at maximum volume: 30 Wh

5/10 energysistem.com

Other features

2-band analogue equaliser

Digital equaliser with 5 EQ modes.

Wood cabinet.

Remote control with up to 10 metres range.

USB charging port: 5 V, 2 A.

LED segment display.

Product content

Tower EU True Wireless

Remote control + batteries

Quick guide

General overview

6/10 energysistem.com

Power switch1.

On/Oﬀ2.

LED display3.

Playback mode4.

Volume -5.

Back6.

Play/Pause7.

Next8.

Volume +9.

Equaliser10.

USB charging port11.

USB playback port12.

MicroSD card slot13.

3.5 mm audio-in (AUX)14.

Treble equaliser15.

Bass equaliser16.

Change folder17.

Mute18.

Repeat mode19.

Main Functions

Switching on and oﬀ the device

Plug the power cable into the back of your Tower EU TWS, connect the plug to the socket and move the Power switch

(1) to the ON position.

To switch on your Tower EU TWS, press On/Oﬀ (2) on the top panel or the provided remote control. At this point, the

LED display (3) lights up showing the selected playback mode.

Press and hold On/Oﬀ (2) on the top panel or remote control for 2 seconds to switch oﬀ the device. The LED display (3)

will switch oﬀ.

Note 1: When switching on the device, it will always enable the last playback mode selected.

Note 2: If you are not going to use your Tower EU TWS for a long period of time, we recommend moving the Power

switch (1) to the "OFF" position.

Playback modes

Once the Tower EU TWS is on, you can choose the playback mode you prefer. To do so, press Playback mode (4)

repeatedly until ﬁnding the preferred playback mode. Playback modes will appear in the following order:

Bluetooth --> SD --> USB --> AUX

If you plug a removable storage unit (USB stick or microSD card) or use the AUX input, your Tower EU TWS will enable

the corresponding playpack mode and will play the content automatically.

Playback control

Once selected the preferred playback mode, you can control music playback directly from the Tower EU TWS or using

the remote control.

Press Play/Pause (7) to play or pause a song.

Press Volume - (5) or Volume + (9) to adjust the volume level according to your preferences.

7/10 energysistem.com

Press Back (6) or Next (8) to skip to the previous or next song.

If you plug a USB stick or a microSD card, press and hold Play/Pause (7) for 2 seconds or press repeatedly Repeat mode

(19) on the remote control to select the preferred playback mode. The information below will appear on the LED display

(3):

1) ALL: all USB or card contents will be repeated. The folders and ﬁles stored on your removable storage units will be

read in chronological order.

2) ONE: the song you are listening to will be repeated.

3) RANDOM: random playback of all the contents of your removable storage unit.

4) FOLDER: the folder with the songs you are listening to will be repeated.

Press Mute (18) on the remote control to mute playback.

If you prefer to switch to another folder, press Change folder (17) on the remote control.

Important: If you are using the AUX input, you will have to control playback from the connected music player.

Bluetooth (BT)

To pair your speaker with a Bluetooth device, press Playback mode (4) until Bluetooth mode is enabled. The Bluetooth

symbol (bt) will ﬂash on the LED display (3).

At this point, access the Bluetooth settings on the device and search for Tower EU TWS among the detected devices.

Select it to establish the connection. The devices will be connected immediately. You will hear a sound conﬁrming both

devices are correctly paired. At this point, the Bluetooth symbol (bt) is displayed permanently on the display.

Your Tower EU TWS pairs with the source device automatically when turning on the sound tower once again, provided

that Bluetooth is enabled on the source device.

Press and hold Playback mode (4) for 2 seconds to disconnect the current device and pair the sound tower with a new

one. You will hear a sound when both devices disconnect and the Bluetooth symbol (bt) will ﬂash on the LED display (3).

True Wireless Stereo (TWS)

This technology allows you to wirelessly connect another True Wireless Stereo device within a maximum distance range

of 20 metres to increase power and create a stereo system with separate left and right channels.

To do so, connect your smartphone or Bluetooth source device to the tower on the left side of the room. This tower will

be fed with the left channel. Once you?ve done this, switch on the second tower and press and hold Play/Pause (7) for 2

seconds on both tower speakers. Two letters, ?L? and ?R?, will ﬂash on the LED display (3). This means both sound

towers are in search mode. Wait a few seconds until both towers connect to eath other. You will hear a conﬁrmation

sound. The letters ?L? and ?R? will light up permanently.

To disable the True Wirelesss Stereo function, press and hold Play/Pause (7) for two seconds on any tower. You will hear

a conﬁrmation sound when both units disconnect.

Removable storage units (USB sticks/MicroSD cards)

Play .mp3 and .wav ﬁles from your USB sticks or microSD cards (up to 128 GB). Plug the USB stick into the USB

playback port (12) or the microSD card into the microSD card slot (13). The device plays the contents automatically a

few seconds after plugging the storage unit.

If you turn oﬀ your Tower EU TWS or select another playback mode, the internal memory will save the moment where

8/10 energysistem.com

you paused playback.This way, music playback will always resume from the last track you listened to.

Press Play/Pause (7) to play or pause a song.

Press Volume - (5) or Volume + (9) to adjust the volume level according to your preferences.

Press Back (6) or Next (8) to skip to the previous or next song.

If you plug a USB stick or a microSD card, press and hold Play/Pause (7) for 2 seconds or press repeatedly Repeat mode

(19) on the remote control to select the preferred playback mode. The information below will appear on the LED display

(3):

1) ALL: all USB or card contents will be repeated. The folders and ﬁles stored on your removable storage units will be

read in chronological order.

2) ONE: the song you are listening to will be repeated.

3) RANDOM: random playback of all the contents of your removable storage unit.

4) FOLDER: the folder with the songs you are listening to will be repeated.

Press Mute (18) on the remote control to mute playback.

If you prefer to switch to another folder, press Change folder (17) on the remote control.

The root folders and ﬁles of your removable microSD cards will be read in chronological order and the songs included in

your folders in alphabetical order.

Here you have a diagram of the reading order:

Auxiliary audio input

Your Tower EU TWS features a 3.5 mm audio-in (AUX) (14) to plug your music player using a 3.5 mm jack cable.

When using the audio-in (AUX), your Tower EU TWS enters AUX mode automatically, thus showing it is ready to start

playing content from an external device.

Important: If you are using the AUX input, you will have to control playback from the connected music player.

9/10 energysistem.com

Charging devices through the USB port

Your Tower EU TWS features a USB charging port (11) to connect a USB cable and charge other devices such as

smartphones, tablets or MP3 players, even if the tower is playing music.

Output technical speciﬁcations:

Voltage = 5 V

Current = 2 A

Equaliser

The device features a Treble (15) and bass equaliser (16) on the back to adjust the sound to your liking.

Lower treble as you turn up the tower speaker volume to get a balanced sound. We recommend to set treble below 50%

when the volume is above 20 points.

The device also features digital EQ modes. Press repeatedly Equaliser (10) to select the preferred EQ mode while the

device is playing music. There are 5 EQ modes available:

EQ1: Flat or ﬂat EQ.

EQ2: Bass, EQ for an extra bass boost.

EQ3: Treble, EQ for an extra treble boost.

EQ4: Mid high, EQ for a mid boost.

EQ5: Mid low, EQ for a mid cut.

Software upgrades

You can ﬁnd the latest software version upgrade at https://www.energysistem.com/en/drivers.

Warranty

Energy Sistem Technology, S.A. is liable for any lack of conformity for 36 months from the date the goods are

purchased. Batteries are excluded from the 36-month warranty, having a warranty period of 24 months.

This warranty covers defects in workmanship or materials and does not cover product failures due to accidents, misuse

or alteration made by an unauthorised person.

The extended 36-month warranty is valid for the European Union. For other countries please refer to your speciﬁc

legislation or your local distributor.

Warranty procedure

Please visit http://www.energysistem.com/en/support and select your product to view the FAQ (Frequently Asked

Questions), user manual, quick guide, drivers and updates available as well as to submit a query to our Technical

Support or manage the warranty.

You may also contact the distributor that sold the product by presenting the purchase receipt or invoice.

Important: This warranty does not cover any damage or loss of data stored on warranty products. Energy Sistem?s

Technical Support will not assume any loss of the above-mentioned information. In this respect we recommend making

a backup of your data and removing any personal data from the product internal memory before you send it or send it

only with the original data. Speciﬁcations are subject to change without notice.

Trademarks. All company, brand and product names are trademarks or registered trademarks of their respective

10/10 energysistem.com

companies. Speciﬁcations are subject to change without notice.

Declaration of conformity

Issuer's name: Energy Sistem Technology, S.A. - CIF: A53107488

Address: C/ Calpe, 1 - 03509 Finestrat, Alicante (Spain)

Tel: +34 966 830 324

We declare under our sole and exclusive responsibility that the product:

Description: home speaker

Brand: Energy Sistem

Model: Tower EU True Wireless

Manufacturer: Energy Sistem Technology, S.A.

Manufacturing country: China

referred to in this declaration is in compliance with the following European Union directives:

EN 62479:2010

EN 62368-1:2014+A11:2017

EN 301 489-17 V3.2.2

EN 301 489-1 V2.2.3

EN 300 328 V2.2.2

in conformity with the provisions of the Directive 2014/53/EU of the European Parliament and of the Council of 16th

April 2014.

Finestrat, 01st August 2020

Miguel Ángel Aragüez García

Innovation and Technology Director

Table des matières

Autres manuels ENERGY SISTEM Intervenants

ENERGY SISTEM

ENERGY SISTEM Frame Speaker Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM Home Speaker7 Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM Multiroom Portable Wi-Fi Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM S250 Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM Xsound 5000 Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM Music Box 7 Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM Tower 3 g2 Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM Smart Speaker 7 Tower Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM LOL&ROLL Pop Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM Party 3 Go Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM Tower 5 g2 Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM eco beech wood Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM ENERGY TOWER 3 Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM home speaker4 Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM Urban Box Supernova Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM boombox3 Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM Linnker 7000 Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM Energy Soundbar 200 Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM Party 6 Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM tower7 Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM Tower 1 Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM music box 9+ Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM XSOUNND 5000 Manuel utilisateur

ENERGY SISTEM

ENERGY SISTEM Music Box Z3 Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
