QUICK MANUAL

TFT LCD MONITOR

Installation and Operating Instructions

VMC-27LEDM

VMC-32LEDM

VMC-42LED

SHORT KEY FUNCTION

KEY BUTTON

OSD Key Function

Activates and exit the OSD

Select input source, and select the OSD menu

Move the OSD menu and auto adjustment of RGB source

Decrease the level of volume and move the previous menu

Increase the level of volume and select rhe OSD menu

Turns the power ON or OFF. There will be a few seconds

delay before the display appears.The power LED (next to the

power switch) lights with green when the power is turned ON.

The power is turned off by pressing the power switch again

and the power LED goes red.

1 2 3 4 5 6 7 8 9 10 11

HDMI

1AUDIO (VIDEO-1 / S-VIDEO)

HDMI signal 1 / 2 input Stereo audio input for VIDEO-1 or S-VIDEO

DVI

2S-VIDEO IN / OUT

DVI signal input S-VIDEO signal input / looping out

VGA

3VIDEO-2 IN / OUT

VGA (PC RGB) signal input VIDEO-2 signal input / looping out

AUDIO (PC)

4VIDEO-1 IN / OUT

Stereo audio input for VGA VIDEO-1 signal input / looping out

COMPONENT

5TRIGGER

COMPONENT (Y/Pb/Pr) signal & stereo audio input TRIGGER signal input

AUDIO (VIDEO-2)

6AC POWER

Stereo audio input for VIDEO-2 AC100~240V input

CONNECTION

MODE SETTING

PICTURE MENU

VIDEO1

Select VIDEO1 mode

VIDEO2

Select VIDEO2 mode

S-VIDEO

Select S-VIDEO mode

RGB PC

Select VGA mode

DVI

Select DVI mode

HDMI1

Select HDMI1 mode

COMPONENT

Select COMPONENT mode

HDMI2

Select HDMI2 mode

VIDEO1

VIDEO2

S-VIDEO

√RGB PC

DVI

HDMI 1

HDMI 2

COMPONENT

▼/▲:MOVE ▶:ENTER

INPUT

Inputs can be set to VIDEO1, VIDEO2, S-VIDEO, RGB PC, DVI, HDMI1, HDMI2 & COMPONENT mode

CONTRAST : Adjust visual color contrast

BRIGHTNESS : Adjust color brightness

COLOR : Adjust visual color of screen

TINT : Adjust tint of color

SHARPNESS : Adjust sharpness of screen

COLOR TEMP : Switch color temperature of

screen

MODE SELECT : Adjust mode of screen

(DVI, HDMI mode only)


CONTRAST

60%

BRIGHTNESS

50%

COLOR

50%

TINT

50%

SHARPNESS

50%

PEAKING CONTROL

50%

COLOR TEMP ◀MEDIUM

RED

50%

GREEN

50%

BLUE

▼/▲: MOVE ◀/▶: ADJUST ▶: ENTER MENU : EXIT VER : *.*

50%


SCREEN

SETUP

RGB

SETUP

CYCLE

TRIGGER

▶

MODE SELECT ◀1080P ▶

SCREEN MENU

SCAN MODE : Select the scan mode of screen

PIP : Activates PIP/PBP mode

SCREEN

SCAN MODE

PIP

PIP INPUT

PIP SWAP

PIP SIZE

PIP R/T


SCREEN

SETUP

RGB

SETUP

CYCLE

TRIGGER

◀R/B ▶

◀SMALL ▶

▶

◀VIDEO2 ▶

◀OFF ▶

◀FULL ▶

▼/▲: MOVE ◀/▶: ADJUST ▶: ENTER MENU : EXIT VER : *.*

VIDEO-1 VIDEO-2 S-VIDEO COMPONENT VGA DVI HDMI

VIDEO-1

MAIN SUB

X O O X X X X

VIDEO-2

O X O X X X X

S-VIDEO

O O X X X X X

COMPONENT

O O O X X X X

VGA

O O O X X X X

DVI

O O O X X X X

HDMI

O O O X X X X

PIP, PBP - COMBINATION OF SIGNAL INPUT

SETUP MENU

RGB SETUP MENU

INPUT : Select an input source for main screen

LANGUAGE : Set to different language mode

SOUND MUTE : Turn on/off the sound

BUTTON LOCK : Locking the button

NOISE REDUCTION : Set a noise reduction mode

OSD TIME : Set a time duration of OSD menu

DEFAULT : Factory default setting

NO OPERATION : Set a no operation mode

LINE SHIFT : Move a little to protect the screen

SETUP

INPUT

LANGUAGE

SOUND MUTE

BUTTON LOCK

NOISE REDUCTION

OSD TIME


SCREEN

SETUP

RGB

SETUP

CYCLE

TRIGGER

DEFAULT ▶

LINE SHIFT ◀ON ▶

NO OPERATION ◀OFF ▶

◀ON ▶

◀OFF ▶

◀ENGLISH ▶

◀VIDEO1 ▶

▼/▲: MOVE ◀/▶: ADJUST ▶: ENTER MENU : EXIT VER : *.*

15s

RGB SETUP

H-POSITION

V-POSITION

CLOCK

PHASE

AUTO ADJUST

POWER SAVING


SCREEN

SETUP

RGB

SETUP

CYCLE

TRIGGER

AUTO REPEAT ◀OFF ▶

▶

◀OFF ▶

▼/▲: MOVE ◀/▶: ADJUST ▶: ENTER MENU : EXIT VER : *.*

100%

H-POSITION : Adjust horizontal position of monitor

V-POSITION : Adjust vertical position of monitor

CLOCK : Adjust clock of monitor

PHASE : Adjust phase of monitor

AUTO ADJUST : Auto adjust position of screen

POWER SAVING : Power saving mode

AUTO REPEAT : Adjust auto repeat of monitor

TRIGGER MENU

CYCLE SETUP MENU

CYCLE TIME : Adjust cycle time to displayed on

the screen

CYCLE : Selected mode keep change continuously

CYCLE SETUP

CYCLE TIME

CYCLE

VIDEO1

VIDEO2

S-VIDEO

RGB PC


SCREEN

SETUP

RGB

SETUP

CYCLE

TRIGGER

DVI

HDMI 1 ◀OFF ▶

HDMI 2 ◀OFF ▶

COMPONENT ◀OFF ▶

◀OFF ▶

▼/▲: MOVE ◀/▶: ADJUST ▶: ENTER MENU : EXIT VER : *.*

10s

TRIGGER MODE : Set the trigger mode

trigger mode

TRIGGER DWELL : Set the display time of

trigger mode

TRIGGER INPUT : Select the input source of

TRIGGER

TRIGGER MODE

TRIGGER INPUT

TRIGGER DWELL


SCREEN

SETUP

RGB

SETUP

CYCLE

TRIGGER

◀OFF ▶

◀VIDEO1 ▶

▼/▲: MOVE ◀/▶: ADJUST ▶: ENTER MENU : EXIT VER : *.*

10s

Technical changes reserved.

eneo

is a registered trademark of VIDEOR E. Hartig GmbH

Exclusive distribution through specialised trade channels only.

VIDEOR E. Hartig GmbH

Carl-Zeiss-Straße 8 • 63322 Rödermark, Germany

Tel. +49 (0) 6074 / 888-0 • Fax +49 (0) 6074 / 888-100

www.videor.com

www.eneo-security.com
