EndurEnergy Systems ESP-5K HL Manuel utilisateur



ESP-5K HL

Residential & Commercial

ESS Manual

About this manual

This manual is intended for the ESP-5K HL Lithium Iron Phosphate (LiFePo4) Battery.

These batteries can be installed in parallel and series configurations. Please pay close

attention to the DIP switch setting, address selection and cable connections.

Statement

This product is compliant with the Best Practice Guide for Battery Storage Equipment—

Electrical Safety, version 1. It meets the mandatory requirements of Method 1 for pre-

assembled integrated battery energy storage system equipment, as well as the optional

requirements listed under points a), c), e), f), g), h), i), j), k), l), m), n), o), p), and q).

Declaration

EndurEnergy declares that the ESP-5K HL is compliant with the essential requirements

and other relevant standards of UL/CE.

Disclaimer

EndurEnergy cannot be responsible for system failure, damage, or injury resulting from

improper installation of their products. The information included in this manual is subject to

change without notice.




CONTENT
1Safety Introduction ......................................................................................................................................... 1
1 Important Safety Instructions....................................................................................................... 1
2 Warnings in this Document............................................................................................................ 1
3 Battery Handing Guide ....................................................................................................................2
4 Response to Emergency Situations ............................................................................................2
4.1 Leaking Batteries ....................................................................................................................2
4.2 Fire ...............................................................................................................................................3
4.3 Wet battery.................................................................................................................................3
4.4 Damaged Battery.....................................................................................................................3
5 Installers ............................................................................................................................................ 4
6 Disposing Batteries......................................................................................................................... 4
7 Contact Information ........................................................................................................................ 4
2Guidance for Disconnection of Batteries During Shipment.............................................................. 5
3Product Introduction ......................................................................................................................................6
1 Technical Specifications .................................................................................................................6
2 Indicators and Ports.........................................................................................................................7
2.1 Indicators ...................................................................................................................................7
2.2 Ports ............................................................................................................................................7
2.3 Communication Interface..................................................................................................... 8
3 Typical Battery application.............................................................................................................9
4 Feature................................................................................................................................................11
4Installation Prerequisites............................................................................................................................11
1 Installation Process ........................................................................................................................11
2 Installation Location ...................................................................................................................... 12
3 Tools.................................................................................................................................................... 12
4 Personal protective equipment (PPE)...................................................................................... 13
5 Storage............................................................................................................................................... 13
5Battery Installation.......................................................................................................................................14
1 Package Items .................................................................................................................................14
2 Before Installation..........................................................................................................................14
3 Battery Mounting............................................................................................................................. 15
3.1 Rack Mounting (R6 / R12) ....................................................................................................15
3.2 Enclosure Mounting - (BU10/15/20/30)...........................................................................18
4 Cable Connections of the Battery.............................................................................................. 21
4.1 Battery Grounding ................................................................................................................ 22
4.2 Series Connection (High Voltage application)............................................................. 23
4.3 Parallel Connection (Low Voltage application) ........................................................... 25
4.4 Communication Cables....................................................................................................... 27
5 Battery DIP Switch Setting ......................................................................................................... 30
6Battery Internet connectivity....................................................................................................................40

6.1 APP Connection..............................................................................................................................40

6.1.1 Configure Battery WIFI.........................................................................................................41

6.1.2 Visualize Battery Data from the App ..............................................................................43

7Commissioning .............................................................................................................................................43

7.1 Commissioning Battery................................................................................................................43

7.2 Shutting Down Battery.................................................................................................................44

8Firmware Update & Troubleshooting.....................................................................................................44



1Safety Introduction

1.1 Important Safety Instructions

This manual contains crucial instructions for the ESP-5K HL Residential and Commercial ESS

product. It is imperative to follow this manual during installation and use of the product.

While this product is designed and tested to meet international safety requirements such as UL1973,

CE, IEC 62040, and IEC 62619, it is essential to take certain precautions when installing and/or

operating any electrical and electronic equipment. Tominimize the risk of personal injury and ensure

the safe installation and operation of the product, it is crucial to thoroughly read and adhere to all

instructions, cautions, and warnings provided in this manual.

WARNING

Failure to follow the instructions or warnings in this document can result in electrical

shock, serious injury, or death. Damage to the Battery is also possible, potentially

rendering it inoperable.

High Life Risk Due to Fire or Electrocution – ONLY qualified personnel should install the

ESP-5K-HL.

1.2 Warnings in this Document

A warning indicates a potential hazard to equipment or personnel. It highlights procedures or

practices that, if not performed correctly, may result in damage to or destruction of the equipment,

other connected equipment, or personal injury.

Symbol

Description

Caution, risk of electric shock

Heavy enough may cause severe injure

Keep the battery away from open flame or ignition sources

Keep the battery away from children

Dispose of waste batteries according to local laws and regulations

Recycling

Read this manual before installation and operation

For safety reasons, it is the responsibility of installers to thoroughly review the contentsof this manual

and familiarize themselves with all warnings prior to performing the installation.



1.3 Battery Handing Guide

Please follow the guidelines below to ensure safe handling and usage of the battery pack:

⚫Use the battery pack only as directed.

⚫If the battery appears cracked, broken, damaged, or fails to operate, immediately contact

EndurEnergy hot line at 1-888-E2-ENDUR (1-888-323-6387).

⚫Do not attempt to open, disassemble, repair, tamper with, or modify the battery in any way.

⚫The battery is not suitable for users to handle independently.

⚫When transporting the battery, handle itwith care to protect the battery and its components from

damage.

⚫Avoid subjecting the battery to any strong force or impact.

⚫Do not insert foreign objects into any part of the battery pack.

⚫Refrain from using cleaning solvents to clean the battery.

⚫Never connect the battery directly to a SELV (Separated Extra-Low Voltage) circuit.

1.4 Response to Emergency Situations

While the ESP-5K HL Residential and Commercial ESS is equipped with multiple safety features to

prevent hazards caused by failures, it is important to note that EndurEnergy cannot guarantee

absolute safety in uncertain situations.

1.4.1 Leaking Batteries

In the event of electrolyte leakage from the battery pack, it is crucial to avoid contact with the

leaking liquid or gas. Electrolyte is corrosive and can cause skin irritation and chemical burns. If

you are exposed to the leaked substance, please follow these actions:

•Inhalation:

oEvacuate the contaminated area immediately.

oSeek medical attention without delay.

•Eye contact:

oRinse your eyes with flowing water for at least 15 minutes.

oSeek medical attention promptly.

•Skin contact:

oWash the affected area thoroughly with soap and water.

oSeek medical attention as soon as possible.

•Ingestion:

oIf the electrolyte is ingested, promptly induce vomiting.

oSeek immediate medical attention.



The previous instructions are provided to address potential risks associated with electrolyte

leakage. It is important to prioritize your safety and seek professional medical assistance without

delay in case of exposure to the leaked substance.

1.4.2 Fire

In the event of a fire, it is important to have an ABC or carbon dioxide extinguisher readily available.

Do not use water to extinguish the fire.

WARNING

The battery pack may catch fire when heated above 150°

If a fire breaks out where the battery is installed, please follow these actions:

•Prioritize extinguishing the fire before the battery catches fire if it is safe to do so. Use

appropriate fire extinguishing methods and equipment according to the type of fire (e.g., ABC

or carbon dioxide extinguisher). Ensure your safety and consider seeking professional

assistance if necessary.

•If the battery has already caught fire or if it is not safe to attempt extinguishing the fire,

prioritize the immediate evacuation of all individuals from the area. Follow established

emergency evacuation procedures and ensure everyone moves to a safe location. Contact

the appropriate emergency services to report the fire.

Note: The above actions are intended to address fire situations where the battery is involved.Always

prioritize personal safety and adhere to established emergency procedures.

WARNING

If the battery catches fire, it will produce poisonous gases. Do not approach.

1.4.3 Wet battery

Ifthebatterybecomes wet orsubmergedinwater,donot attempttoaccess it. Instead,pleasecontact

EndurEnergy Customer Service or reach out to your distributor for immediate technical assistance.

1.4.4 Damaged Battery

If you notice any damage to the battery, please contact EndurEnergy customer service or your

distributor for assistance as soon as possible. It is crucial to handle a damaged battery with extreme

caution, as it can be dangerous. A damaged battery is not suitable for use and may pose a risk to



people and property. If you suspect the battery is damaged, promptly return it to EndurEnergy or

your distributor.

CAUTION

A damaged battery may potentially release electrolyte or flammable gas.

1.5 Installers

It is highly recommended that the installation of the ESP-5K HL Residential and Commercial ESS is

carried out by a skilled worker or electrician. A skilled worker is defined as an individual who has

received proper training and possesses the necessary qualifications as an electrician, or has

acquired the following skills and experience:

⚫Comprehensive knowledge of the functional principles and operation of on-grid Energy Storage

systems.

⚫Understanding of the potential dangers and risks associated with the installation and use of

electrical devices, as well as familiarity with acceptable mitigation methods.

⚫Proficiency in the installation of electrical devices.

⚫Familiarity with and adherence to the instructions provided in this manual, including all safety

precautions and best practices.

1.6 Disposing Batteries

When dealing with scrap battery(-ies), it is important to comply with local laws and regulations

regarding the recycling or disposal of batteries. Please ensure that you follow the appropriate

procedures as outlined by your local authorities for recycling or disposing of Lithium Iron Phosphate

batteries.

1.7 Contact Information

For technical assistance, please use the contacts provided. Please note that the phone numbers

are available for assistance during business hours on weekdays.

Customer careline

1-888-E2-ENDUR (1-888-323-6387)

support@endurenergy.com



2Guidance for Disconnection of Batteries During Shipment

⚫The ESP-5K HL is not suitable for air transport.

⚫Cartons that have been crushed, punctured, or torn in such a way that the contents are

revealed shall be set aside in an isolated area and inspected by a skilled person. If the

package is deemed to be non-shippable, the contents shall be promptly collected,

segregated, and either the consignor or consignee should be contacted.

⚫The DC circuit of the ESP-5K HL battery has been disconnected and turned off prior to

shipping.

⚫We have conducted comprehensive tests to ensure that the equipmentdistributed worldwide

is safe for shipping. These products should be handled with care and immediately inspected

if visibly damaged. If the carton is visibly damaged, please contact EndurEnergy customer

service to confirm whether the battery can be used safely or not.



3Product Introduction

3.1 Technical Specifications

Product Type

ESP-5K HL

Total Energy*

5.00 kWh

Usable Energy (DC)*

5.00 kWh

Nominal Discharge/Charge Power

3.0 kW

Peak Power (Only Discharge)

6 kW for 3s

Voltage

48~56 VDC

Constant Current

(Only Discharge)

70A

Battery Capacity

100 Ah

Maximum Charge Current

60A

Maximum Charge Voltage

57.6 VDC

Weight

45 kg

99.21 lb

Dimensions

442 x 500 x 133 mm

17.4 x 19.7 x 5.2 inch

Max. Recommended Depth of

Discharge (DOD)

90%

Operating Condition

Indoor use

Charge Temperature Range

0-50 ⁰C

32-122 ⁰F

Discharge Temperature Range

-10-50 ⁰C

14-131 ⁰F

WIFI Frequency Range

2400 MHz-2483 MHz

Humidity Limit

＜60% (no condensed water)

Over Voltage Category

Cooling Type

Natural cooling

Case Material

Steel

Color

White

Installation

Wall Mounting/Ground Installation

IP Rating

IP 20

Protective Class

Max. Number of Parallel

Connections

16S/16P

Warranty

10-Year

Lifespan

> 15 years

Communication Protocols

CAN/ RS485

Protection Mode

Dual hardware protection

Battery Protection

Over-current/Over-voltage/Short circuit/ Under-

voltage/Over temperature

Safety Certificate

UL1973, UL9540a, UL9540

Hazardous Material

Classification

Transportation

UN 38.3

*Testing conditions based on temperature 25 ⁰C at the beginning of life.

*Total Energy/Usable Energy measured under specific conditions from ESP 0.2C CC-CV.

Table des matières

Manuels Bloc de piles populaires d'autres marques

Acumentrics

Acumentrics PACK-POWER SYSTEM Manuel utilisateur

ACDC Dynamics

ACDC Dynamics SPF12-50 Manuel utilisateur

Aegis

Aegis ABL-72020P Manuel utilisateur

Dyness

Dyness TowerESS Manuel utilisateur

Growatt

Growatt APX 5.0P-S0-US Manuel utilisateur

EGO

EGO BAX1300 Manuel utilisateur

CyberPower

CyberPower BCA Series Manuel utilisateur

Intermec

Intermec 700 Series Manuel utilisateur

Dometic

Dometic PLB40 Manuel utilisateur

V-TAC

V-TAC VT-48280-W2 Manuel utilisateur

Valence

Valence RT Manuel utilisateur

Nikon

Nikon MB-D14 Manuel utilisateur

IOGear

IOGear GBP24V Series Manuel utilisateur

Inventus Power

Inventus Power PROTRXion S-12V100-TRX-HD Manuel utilisateur

Clas Ohlson

Clas Ohlson PW-290A Manuel utilisateur

EINHELL

EINHELL MULTI-Ah Power X-Change Plus Manuel utilisateur

Samsung

Samsung EB-U3300 Manuel utilisateur

ECTIVE

ECTIVE LC Series Manuel utilisateur
