Operating Instructions
CUA261
Adapter for installing process photometers in
VARIVENT process connections
BA01652C/07/EN/01.16
71348639
2016-12-31
Table of contents CUA261
2 Endress+Hauser
Table of contents
1 Document information ......... 3
1.1 Warnings ........................... 3
1.2 Symbols used ........................ 3
1.3 Symbols on the device ................ 4
2 Basic safety instructions ....... 4
2.1 Requirements for the personnel ........ 4
2.2 Designated use ...................... 4
2.3 Occupational safety .................. 4
2.4 Operational safety ................... 4
2.5 Product safety ....................... 5
3 Incoming acceptance and
product identification .......... 5
3.1 Incoming acceptance ................. 5
3.2 Product identification ................. 5
3.3 Scope of delivery ..................... 6
4 Installation ...................... 6
4.1 Installation conditions ................ 6
4.2 Dimensions ......................... 9
4.3 Installation ........................ 12
4.4 Post-installation check ............... 14
5 Maintenance .................. 14
5.1 Maintenance schedule ............... 14
5.2 Replacing the sensor window and
seals .............................. 14
6 Repairs ......................... 17
6.1 Spare parts ........................ 17
6.2 Return ............................ 17
7 Technical data ................. 18
7.1 Process ............................ 18
7.2 Mechanical construction ............. 18
Index ................................. 19
CUA261 Document information
Endress+Hauser 3
1 Document information
1.1 Warnings
Structure of information Meaning
LDANGER
Causes (/consequences)
If necessary, Consequences of non-
compliance (if applicable)
‣Corrective action
This symbol alerts you to a dangerous situation.
Failure to avoid the dangerous situation will result in a fatal or serious injury.
LWARNING
Causes (/consequences)
If necessary, Consequences of non-
compliance (if applicable)
‣Corrective action
This symbol alerts you to a dangerous situation.
Failure to avoid the dangerous situation can result in a fatal or serious injury.
LCAUTION
Causes (/consequences)
If necessary, Consequences of non-
compliance (if applicable)
‣Corrective action
This symbol alerts you to a dangerous situation.
Failure to avoid this situation can result in minor or more serious injuries.
NOTICE
Cause/situation
If necessary, Consequences of non-
compliance (if applicable)
‣Action/note
This symbol alerts you to situations which may result in damage to property.
1.2 Symbols used
Symbol Meaning
Additional information, tips
Permitted or recommended
Not permitted or not recommended
Reference to device documentation
Reference to page
Reference to graphic
Result of a step
Basic safety instructions CUA261
4 Endress+Hauser
1.3 Symbols on the device
Symbol Meaning
Reference to device documentation
2 Basic safety instructions
2.1 Requirements for the personnel
• Installation, commissioning, operation and maintenance of the measuring system may be
carried out only by specially trained technical personnel.
• The technical personnel must be authorized by the plant operator to carry out the specified
activities.
• The electrical connection may be performed only by an electrical technician.
• The technical personnel must have read and understood these Operating Instructions and
must follow the instructions contained therein.
• Faults at the measuring point may only be rectified by authorized and specially trained
personnel.
Repairs not described in the Operating Instructions provided must be carried out only
directly at the manufacturer's site or by the service organization.
2.2 Designated use
The CUA261 adapters are designed for the installation of optical sensors (OUSAF44,
OUSAF12, OUSAF22, OUSAF46 and OUSTF10) in pipes with VARIVENT process connections
(N 68 mm).
Their mechanical construction means that they can be operated in pressurized systems (see
technical data).
Use of the device for any purpose other than that described, poses a threat to the safety of
people and of the entire measuring system and is therefore not permitted.
The manufacturer is not liable for damage caused by improper or non-designated use.
2.3 Occupational safety
As the user, you are responsible for complying with the following safety conditions:
• Installation guidelines
• Local standards and regulations
2.4 Operational safety
1. Before commissioning the entire measuring point, verify that all connections are
correct. Ensure that electrical cables and hose connections are undamaged.
CUA261 Incoming acceptance and product identification
Endress+Hauser 5
2. Do not operate damaged products, and safeguard them to ensure that they are not
operated inadvertently. Label the damaged product as defective.
3. If faults cannot be rectified:
Take the products out of operation and safeguard them to ensure that they are not
operated inadvertently.
2.5 Product safety
The product is designed to meet state-of-the-art safety requirements, has been tested, and
left the factory in a condition in which it is safe to operate. The relevant regulations and
European standards have been observed.
3 Incoming acceptance and product identification
3.1 Incoming acceptance
1. Verify that the packaging is undamaged.
Notify your supplier of any damage to the packaging.
Keep the damaged packaging until the matter has been settled.
2. Verify that the contents are undamaged.
Notify your supplier of any damage to the delivery contents.
Keep the damaged products until the matter has been settled.
3. Check the delivery for completeness.
Check it against the delivery papers and your order.
4. Pack the product for storage and transportation in such a way that it is protected
against impact and moisture.
The original packaging offers the best protection.
The permitted ambient conditions must be observed (see "Technical data").
If you have any questions, please contact your supplier or your local sales center.
3.2 Product identification
3.2.1 Nameplate
The nameplate provides you with the following information on your device:
• Manufacturer identification
• Order code
• Extended order code
• Serial number
• Ambient and process conditions
• Safety information and warnings
Compare the data on the nameplate with your order.
Installation CUA261
6 Endress+Hauser
3.2.2 Product identification
Product page
www.endress.com/cua261
Interpreting the order code
The order code and serial number of your product can be found in the following locations:
• On the nameplate
• In the delivery papers
Obtaining information on the product
1. Go to the product page for your product on the Internet.
2. At the bottom of the page, click the link Online Tools and then select Access device
specific information.
An additional window opens.
3. Enter the order code from the nameplate into the search field and then select Show
details.
You will receive information on each feature (selected option) of the order code.
Manufacturer's address
Endress+Hauser Conducta GmbH+Co. KG
Dieselstraße 24
D-70839 Gerlingen
3.3 Scope of delivery
The delivery comprises:
• Adapter in the version ordered,
with or without VARIVENT flow assembly N 68 mm
• Clamp connector (only for version with VARIVENT flow assembly)
• Operating Instructions
4 Installation
4.1 Installation conditions
4.1.1 Installation instructions
• Make sure that the optical windows of the flow assembly are vertically aligned. This
prevents buildup on the window surfaces. The optical windows are vertical when the sensor
and the detector housing are in a horizontal position.
• Install the flow assembly and sensor upstream from the pressure regulators.
CUA261 Installation
Endress+Hauser 7
C
A
BE
D
A0032627
1 Sensor installation
A Optimum mounting angle, best installation position
B Suitable mounting angle, better than D
C Mounting angle to be avoided
D Acceptable mounting angle
E Forbidden mounting angle
Installation CUA261
8 Endress+Hauser
4.1.2 Air purge
The optical windows can be purged with dry air or nitrogen through pneumatic ports,
preventing the formation of condensate on the optical windows.
1 2 3 45
A0032628
2 Purge gas supply via modified window rings of the VARIVENT adapter
1 Compressed air or nitrogen supply
2 Air drier (not required for nitrogen)
3 Pressure regulator
4 Flow controller
5 Sensor in VARIVENT flow assembly (version with air purge function)
The purge gas must be clean and dry (ultra zero air).
Optimum purge gas pressure at: 1)
Modified window ring CUA261 with elbow connector 0.21 bar (2.5 psi) at room temperature
1) Indicated as overpressure
The CUA261 version with the air purge function is supplied with hoses ready-connected
on the window side (length 1 m (3.3 ft)). All you have to do is connect the hoses to the
purge gas supply.
CUA261 Installation
Endress+Hauser 9
4.2 Dimensions
45°
4x 3.4 (0.13)!
40 (1.58)
84 (3.31)
75 (2.96)
65 (2.56)
28 (1.11)
32 (1.25)
24 (0.95)
68 (2.68)
1.7 (0.07)
8.3 (0.33)
10.8 (0.43)
a
b
c
A0032654
3 Adapters for a wide variety of pipe diameters and path lengths, dimensions in mm (inch)
a-c See table
Pipe diameter, path length [mm] a [mm (inch)] b [mm (inch)] c [mm (inch)]
DN50, 5/10/20 27.2 (1.07) 3.6 (0.14) 3.4 (0.13)
DN65, 5/10/20 35.2 (1.39) 11.6 (0.46) 3.4 (0.13)
DN65, 30/40 25.2 (0.99) 2.8 (0.11) 2.2 (0.09)
DN80, 5/10/20 42.7 (1.68) 19.1 (0.75) 3.4 (0.13)
DN80, 30/40 32.7 (1.29) 9.1 (0.36) 3.4 (0.13)
DN100, 5/10/20 52.2 (2.05) 28.6 (1.13) 3.4 (0.13)
DN100, 30/40 42.2 (1.66) 18.6 (0.73) 3.4 (0.13)
2", 5/10/20 26.0 (1.02) 2.4 (0.09) 3.4 (0.13)
2½", 5/10/20 26.0 (1.02) 2.4 (0.09) 3.4 (0.13)
2½", 30/40 22.2 (0.87) 2.5 (0.10) 2.0 (0.08)
3", 5/10/20 38.7 (1.52) 15.1 (0.59) 3.4 (0.13)
3", 30/40 28.7 (1.13) 5.1 (0.20) 3.4 (0.13)
4", 5/10/20 51.0 (2.00) 27.4 (1.08) 3.4 (0.13)
4", 30/40 41.2 (1.62) 17.7 (0.70) 3.4 (0.13)
Installation CUA261
10 Endress+Hauser
45°
4x 3.4 (0.13)!
40 (1.58)
84 (3.31)
75 (2.96)
65 (2.56)
28 (1.11)
32 (1.25)
24 (0.95)
68 (2.68)
3.0 (0.12)
8.3 (0.33)
d
10.3 (0.43)
A0032655
4 Adapter for DN50/2" with 30 or 40mm path lengths, dimensions in mm (inch)
d See table
Pipe diameter, path length [mm] d [mm (inch)]
DN50, 30/40 18.3 (0.72)
2", 30/40 17.1 (0.67)
