ENDEAVOUR ET6005-01 Manuel utilisateur
1. FEATURES
2. SPECIFICATION
3. APPLICATION
4. INSTRUCTION
5. RELATED ITEMS
P.1
WHEEL HANGERS
2-PC WHEEL HANGER SLEEVES - M12 × P1.5
ET6005-01
2-2-PC WHEEL HANGEPC WHEEL HANGERS - M12 × P1.5RS - M12 × P1.5
ET6005-02
2-PC WHEEL HANGERS - M14 × P1.5
ET6005-03
111--PPCC WHEELWHEEL HANGERHANGERPC WHEEL HANGER - M16 × P1.5-
ET6005-05
2-PC WHEEL HANGERS - M14 × P1.25
ET6005-04
P.2
1. FEATURES
2. SPECIFICATION
ŹSave energy and time when changing tires and wheels
ŹAlso provides easier work for disc brake services, preventing brake disc
from wobbling
CAUTION
◆Always read the instruction manual carefully before working
◆Wheel hanger is for wheel installation/removal and disc brake service ONLY
◆Sleeve type as shown in 4.1 instruction can work for disc brake service ONLY
◆Always wear eye protection that meets OSHA and ANSI Z87.1 standards
◆Always wear gloves when work with this tool
◆Ensure the work area has adequate lighting
◆Keep children and unauthorised people away from the work area
◆Keep work area clean and tidy, dry and free from unrelated materials
◆DO NOT allow untrained people to use the kit
M14 x P1.5
M12 x P1.5
M14 x P1.25
M16 x P1.5
150mm
tMaterial: Steel S45C
tSurface finish: Chrome
tHardness: 38 - 43 degrees
tM14 × P1.25 Wheel hanger surface finish: Painting (blue)
ø7
R78mm
For easily holding Can insert screwdriver or any bar
to install / remove wheel hanger
Connect with
wheel hub thread
M12 x P1.5
150mm
R105mm
Hex 10mm
For easily holding
Connect with wheel
hub stub
Can install this tool
with a spanner
P.3
3. APPLICATION
3.
APPLI
C
ATI
ON
2-PC WHEEL HANGER SLEEVES - M12 × P1.5
For Lexus, Toyota and Volvo
2-PC WHEEL HANGERS - M12 × P1.5
For Audi, Alfa Romeo, BMW, Mercedes-Benz,
Mini, Porsche, Vauxhall, Volvo and VW
2-PC WHEEL HANGERS - M14 × P1.5
For Audi, BMW, Citroën, Chrysler, Ferrari, Fiat,
Ford, GM, Hyundai, Land Rover,
Lamborghini, Mercedes-Benz, Opel,
Peugeot, Porsche, Renault, Rover, Saab, Seat,
Škoda, Vauxhall, Volvo and VW
2-PC WHEEL HANGERS - M14 × P1.25
Mini Cooper
2007-2014
BMW
2007-
X5
2008-
X5 X6
2009-
750 X5 X6
2010-
750 760 X5 X6
2011-
528 535 550 740 750 B7 X5 X6
2012-2013
328 335 528 535 550 740 750
B7 M5 X5 X6
1-PC WHEEL HANGER - M16 × P1.5
1
For Fiat, Land Rover and Peugeot
P.4
4. INSTRUCTION
4.1. SLEEVE TYPE (FEMALE) - FOR DISC BRAKE SERVICE
4.2. SLEEVE TYPE (FEMALE) - FOR TIRE SERVICE
No more brake disc wobbling
+DQGVIUHHZKHHOEDODQFLQJ
6LPSO\VFUHZWKHZKHHO
KDQJHURQDZKHHOKXE
DQGWKHQZKHHOLQVWDOODWLRQ
FDQEHGRQHHDVLO\DQGIDVW
+DQGVIUHHZKHHOEDODQFLQJ
6LPSO\VFUHZWKHZKHHO
KDQJHURQDZKHHOKXE
DQGWKHQZKHHOLQVWDOODWLRQ
FDQEHGRQHHDVLO\DQGIDVW
1RQHHGWRVFUHZDOXJQXWWR
VWDEOL]HEUDNHGLVFIRUEUDNHFDOLSHU
PRXQWLQJDQGWKHQXQVFUHZWKHOXJ
QXWDJDLQIRULQVWDOOLQJZKHHO
6LPSO\VFUHZWKHZKHHOKDQJHURQD
ZKHHOKXEVWXEDQGWKHQEUDNH
FDOLSHU
PRXQWLQJDQGZKHHO
LQVWDOODWLRQFDQEHGRQHHDVLO\DQG
IDVW
4.3. BAR TYPE (MALE) - FOR TIRE SERVICE
2003AA
