DAG 4.3GE Card User Manual

Endace Measurement Systems Ltd EDM01.05-01r1 DAG 4.3GE Card User Manual

www.endace.com

Leading Network Intelligence

Published by:

Endace Measurement Systems®Ltd

Building 7

17 Lambie Drive

PO Box 76802

Manukau City 1702

New Zealand

Phone: +64 9 262 7260

Fax: +64 9 262 7261

[email protected]

www.endace.com

International Locations

New Zealand Americas Europe, Middle East & Africa

Endace Technology®Ltd

Level 9

85 Alexandra Street

PO Box 19246

Hamilton 2001

New Zealand

Phone: +64 7 839 0540

Fax: +64 7 839 0543

[email protected]

www.endace.com

Endace USA®Ltd

Suite 220

11495 Sunset Hill Road

Reston

Virginia 20190

United States of America

Phone: ++1 703 382 0155

Fax: ++1 703 382 0155

[email protected]

www.endace.com

Endace Europe®Ltd

Sheraton House

Castle Park

Cambridge CB3 0AX

United Kingdom

Phone: ++44 1223 370 176

Fax: ++44 1223 370 040

[email protected]

www.endace.com

any form or by any means electronic, mechanical, photocopying, recording, or otherwise, without the prior

written permission of the publisher. Prepared in Hamilton, New Zealand.

Endace Measurement Systems Ltd EDM01.05-01r1 DAG 4.3GE Card User Manual

www.endace.com

Typographical Conventions Used in this Document

•Command-line examples suitable for entering at command prompts are displayed in

mono-space courier font. The font is also used to describe config file data

used as examples within a sentence. An example can be in more than one sentence.

Results generated by example command-lines are also displayed in mono-space

courier font.

•The software version references such as 2.3.x, 2.4.x, 2.5.x are specific to Endace

Measurement Systems and relate to Company software products only.

Protection Against Harmful Interference

When present on product this manual pertains to and indicated by product labelling, the statement "This device complies

with part 15 of the FCC rules" specifies the equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the Federal Communications Commission [FCC] Rules.

These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a

commercial environment.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

Extra Components and Materials

The product that this manual pertains to may include extra components and materials that are not essential to its basic

operation, but are necessary to ensure compliance to the product standards required by the United States Federal

Communications Commission, and the European EMC Directive. Modification or removal of these components and/or

materials, is liable to cause non compliance to these standards, and in doing so invalidate the user’s right to operate this

equipment in a Class A industrial environment.

Endace Measurement Systems Ltd EDM01.05-01r1 DAG 4.3GE Card User Manual

www.endace.com

Table of Contents

1.0 PREFACE...........................................................................................................................1

1.1 User Manual Purpose......................................................................................................1

1.2 DAG 4.3GE Card Product Description...........................................................................2

1.3 DAG 4.3GE Card Architecture.......................................................................................2

1.4 DAG 4.3GE Card Extended Functions...........................................................................3

1.5 DAG 4.3GE Card System Requirements........................................................................4

2.0 INSTALLING DAG 4.3GE CARD..................................................................................5

2.1 Installation of Operating System and Endace Software..................................................5

2.2 Insert DAG 4.3GE Card into PC.....................................................................................5

2.3 DAG 4.3GE Card Port Connectors.................................................................................6

2.4 Pluggable Optical Transceivers.......................................................................................6

3.0 SETTING OPTICAL POWER ........................................................................................9

3.1 Optical Power Input ........................................................................................................9

3.2 Splitter Losses...............................................................................................................10

4.0 CONFIDENCE TESTING..............................................................................................11

4.1 Interpreting DAG 4.3GE Card LED Status...................................................................11

4.2 DAG 4.3GE Card LED Display Functions...................................................................12

4.3 Configuration in WYSYCC Style.................................................................................13

4.4 DAG 4.3GE Card Capture Session...............................................................................14

4.5 Inspect Interface Statistics.............................................................................................15

4.6 Reporting Problems.......................................................................................................17

5.0 RUNNING DATA CAPTURE SOFTWARE................................................................19

5.1 Starting Capture Session...............................................................................................19

5.2 High Load Performance................................................................................................22

5.3 DAG 4.3GE Card Packet Transmission Capabilities....................................................23

5.3.1 DAG Packet Transmission......................................................................................23

5.3.2 Inline Forwarding....................................................................................................26

6.0 SYNCHRONIZING CLOCK TIME..............................................................................27

6.1 Configurations Tool Usage...........................................................................................28

6.2 Time Synchronization Configurations..........................................................................29

6.2.1 Single Card no Reference Time Synchronization...................................................29

6.2.2 Two Cards no Reference Time Synchronization....................................................30

6.2.3 Card with Reference Time Synchronization...........................................................31

6.3 Synchronization Connector Pin-outs.............................................................................33

7.0 DATA FORMATS OVERVIEW....................................................................................35

7.1 Data Formats.................................................................................................................35

7.2 Timestamps...................................................................................................................37

Endace Measurement Systems Ltd EDM01.05-01r1 DAG 4.3GE Card User Manual

www.endace.com

USE THIS SPACE FOR NOTES

Endace Measurement Systems Ltd EDM01.05-01r1 DAG 4.3GE Card User Manual

www.endace.com

1.0 PREFACE

Introduction The installation of the Endace DAG 4.3GE card on a PC begins with

installing the operating system and the Endace software. This is followed

by fitting the card and connecting the ports.

Viewing this

document This document, DAG 4.3GE Card User Manual is available on the

installation CD.

In this chapter This chapter covers the following sections of information.

•User Manual Purpose

•DAG 4.3GE Card Product Description

•DAG 4.3GE Card Architecture

•DAG 4.3GE Card Extended Functions

•DAG 4.3GE Card System Requirements

1.1 User Manual Purpose

Description The purpose of this DAG 4.3GE Card User Manual is to describe:

•Installing DAG 4.3GE Card

•Setting Optical Power

•Confidence Testing

•Running Data Capture Software

•Synchronizing Clock Time

•Data Formats Overview

Pre-requisite This document presumes the DAG card is being installed in a PC already

configured with an operating system.

A copy of the Debian Linux 3.1 (Sarge) is available as a bootable ISO

image on one of the CD's shipped with the DAG card.

To install on the Linux/FreeBSD operating system, follow the instructions

in the document EDM04.05-01r1 Linux FreeBSD Installation Manual,

packaged in the CD shipped with the DAG card.

To install on a Windows operating system, follow the instructions in the

document EDM04.05-02r1 Windows Installation Manual, packaged in the

CD shipped with the DAG card

Endace Measurement Systems Ltd EDM01.05-01r1 DAG 4.3GE Card User Manual

www.endace.com

1.2 DAG 4.3GE Card Product Description

Description The DAG 4.3GE card is a PCI-X bus card designed for cell and packet

capture and generation on Ethernet networks.

Figure Figure 1-1 shows the DAG 4.3GE PCI-X card.

Figure 1-1. DAG 4.3GE PCI-X Card.

The DAG 4.3GE card collects packet header and payload from Ethernet

networks and is protocol independent. Full packet capture at line rate

allows recording of all header information and/or payload with a high

precision timestamp.

The DAG 4.3GE is capable of transmitting packets at 100% line rate on

both ports while simultaneously receiving packets at 100% line rate on

both ports.

1.3 DAG 4.3GE Card Architecture

Description Serial Ethernet optical network data received by two 1000baseSX optical

interfaces flow into an Ethernet Framer ASIC then immediately into the

Field-Programmable Gate Array [FPGA].

The FPGA contains an Endace DAG Universal Clock Kit [DUCK]

timestamp engine, packet record processor, and PCI-X interface logic.

Because of component close association, packets or cells are time-stamped

accurately. Time stamped packet records are stored in an external FIFO

memory before transmission to the host.

Continued on next page

Endace Measurement Systems Ltd EDM01.05-01r1 DAG 4.3GE Card User Manual

www.endace.com

1.3 DAG 4.3GE Card Architecture, continued

Figure Figure 1-2 shows the DAG 4.3GE Card major components and process

flow.

Tx Optics Module

Rx Optics Module

Framer

Coprocessor

Connector

DAG 4.3

FPGA CPLD

Time Stamping

Clock Flash

ROM

LED’s

FIFO

Sync

In/Out

PCI-X 64-bit 66-133MHz

Figure 1-2. DAG 4.3GE Card Major Components and Data Flow.

1.4 DAG 4.3GE Card Extended Functions

Description The DAG 4.3GE card is equipped with a coprocessor connector which can

be used with the optional Endace DAG Coprocessor as a data processing

tool.

The IP packet classification specifications are:

•Packets are classified by TCP/IP header fields and/or payload

content.

•Up to 16,384 TCP/IP header classification rules. Up to ~2,000

arbitrary payload search strings.

•Classification rules are assigned a user-defined 16-bit identifier

•Packets matching classification rules are assigned the matching

rule's identifier.

•Programmable actions may be associated with each rule identifier.

For example, The packet should either be dropped, retransmitted to

the network, or presented to the host.

•Packets presented to the host include the rule-match identifier in the

record header.

Contact the Endace customer support team at [email protected] to

enable effective use of extended functions.

Endace Measurement Systems Ltd EDM01.05-01r1 DAG 4.3GE Card User Manual

www.endace.com

1.5 DAG 4.3GE Card System Requirements

Description The DAG 4.3GE card and associated data capture system minimum

operating requirements are:

•PC, at least Intel Xeon 1.8GHz or faster

•Intel E7500, ServerWorks Grand Champion LE/HE, or newer chip

set

•256 MB RAM

•At least one free PCI-X 1.0 slot supporting 66-133MHz operation

•Software distribution free space of 30MB

Operating

system For convenience, the Debian 3.1 [Sarge] Linux system is included on the

Endace Software Install CD. Endace currently supports Windows XP,

Windows Server 2000, Windows Server 2003, FreeBSD, RHEL 3.0, and

Debian Linux operating systems.

Different

system For advice on using a system substantially different from that specified

above, contact Endace support at [email protected]

Endace Measurement Systems Ltd EDM01.05-01r1 DAG 4.3GE Card User Manual

www.endace.com

2.0 INSTALLING DAG 4.3GE CARD

Introduction The DAG 4.3GE card can be installed in any free PCI-X 1.0 slot. It will

operate at 66, 100, or 133MHz PCI-X mode, however it will not operate

correctly in 32 or 64-bit PCI slots.

Higher speed slots are recommended for best performance.

The DAG 4.3GE should be the only device on the PCI-X bus if possible

as the cards make very heavy use of PCI-X bus data transfer resources.

Although the driver supports up to four DAG cards by default in one

system, due to bandwidth limitations there should not be more than one

card on a single PCI-X bus.

In this section This section covers the following topics of information.

•Installation of Operating System and Endace Software

•Insert DAG 4.3GE Card into PC

•DAG 4.3GE Card Port Connectors

•Pluggable Optical Transceivers

2.1 Installation of Operating System and Endace Software

Description If the DAG device driver is not installed, before proceeding with the next

chapter, install the software by following the instructions in EDM04-01

Linux/FreeBSD Installation Guide.

To install the software on a Windows operating system, follow the

instructions in EDM04-02 Windows Installation Guide.

Go to the next chapter of information when the DAG device driver is

installed.

2.2 Insert DAG 4.3GE Card into PC

Description Inserting the DAG 4.3GE card into a PC involves accessing the PCI-X bus

slot, fitting the card, and secure the bus slot screw.

Procedure Follow these steps to insert the DAG 4.3GE card.

Step 1. Access bus Slot

Power computer down.

Remove PCI-X bus slot cover.

Continued on next page

Table des matières

Autres manuels Endace Carte PCI

Endace

Endace DAG 3.7T Manuel utilisateur

Endace

Endace DAG 3.7T Manuel utilisateur

Endace

Endace DAG 3.8S Manuel utilisateur

Endace

Endace DAG 3.6D Manuel utilisateur

Endace

Endace DAG 3.7GF Manuel utilisateur

Endace

Endace DAG 4.3S Manuel utilisateur

Endace

Endace DAG 3.7G Series Manuel utilisateur

Manuels Carte PCI populaires d'autres marques

ERMA

ERMA SSI 1417 Manuel utilisateur

SIIG

SIIG CyberSerial Dual PCI Instructions de montage

Moxa Technologies

Moxa Technologies CP-102E Manuel utilisateur

I-Bus

I-Bus IBC2602 Manuel utilisateur

Exsys

Exsys EX-60102 Manuel utilisateur

Chelsio Communications

Chelsio Communications T5 Series Manuel utilisateur

Conrad Electronic

Conrad Electronic 97 46 71 Manuel utilisateur

Micro Innovations

Micro Innovations USB650A Manuel utilisateur

KTI Networks

KTI Networks KF-310 Manuel utilisateur

Asus

Asus SpaceLink WL230 Manuel utilisateur

SIIG

SIIG SC2475 Manuel utilisateur

TRENDnet

TRENDnet TEW-703PI Manuel utilisateur

Belkin

Belkin F5D7000F Manuel utilisateur

Pericom

Pericom PI7C7100 Manuel utilisateur

ADLINK Technology

ADLINK Technology cPCI-3548 Manuel utilisateur

Digium

Digium TE200 Series Manuel utilisateur

Allo.com

Allo.com 2nd Gen E1/T1/J1 Manuel utilisateur

Western Digital

Western Digital FireWire PCI Adapter Manuel utilisateur
