SLIM WRITER
DVD±R/RW
USB 2.0 External Drive
User’s Manual
CAUTION
CLASS 3B VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID DIRECT EXPOSURE TO BEAM.
VORSICHT
KLASSE 3B SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG WENN
GEOFFNET. NICHT IN DEN STRAHL SEHEN.
ATTENTION
RADIATION DU FAISCEAU LASER VISIBLES ET INVISIBLES DE CLASSE 3B
EN CAS D'OUVERTURE. EVITER TOUTE EXPOSITION AUX RAYONS.
Copyright Statement
It is a criminal offence, under applicable copyright laws, to make
unauthorised copies of copyright-protected material, including
computer programs, films, broadcasts and sound recordings. This
equipment should not be used for such purposes.
CLASS 1 LASER PRODUCT
APPAREIL A LASER DE CLASSE 1
LASER KLASSE 1
LUOKAN 1 LASERLAITE
PRODUIT LASER
CATEGORIE 1
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may
cause undesired operation.
FCC Warning Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
FOR EUROPE
“The drive is in conformity with the EMC directive and low-voltage directive.”
Table of Contents
INTRODUCTION 1
FEATURES 1
ABOUT USB 2
SYSTEM REQUIREMENTS 3
PACKAGE CONTENTS 3
INSTALLATION 4
HARDWARE INSTALLATION 4
DRIVER INSTALLATION 5
APPLICATION 9
SOFTWARE 9
DVD REGION CODING 10
OPERATION & CONNECTION 12
FRONT PANEL 12
REAR VIEW 13
TECHNICAL DATA 14
APPENDIX 16
1
INTRODUCTION
Features
Accompanying the new DVD storage technology, we are honored to
present you a compact and multiformat external drive of USB 2.0 interface:
8X Slim Writer DVD±R/RW.
This Slim Writer frees up precious bay space and offers more backup
choices other than acting as a CD-R/RW drive and as a DVD-ROM reader.
It supports dual formats of DVD+R/RW and DVD-R/RW enabling excellent
compatibility, simple, quick recording of both CD/DVD formats, huge
capacity storage, and theater-quality playback.
The bundled package of mastering software offers the creation fun of video,
photos, and music editing. You can either record up to 4.7GB, 3 hours of
TV shows or movies into high-quality DVD video, or author your own DVD
movies – from capture to editing and burning, which both are playable in
most DVD players and DVD-ROM drives.
Handy and easy to use, this Slim Writer is an ideal model to enjoy the
fascinating DVD entertainment on your desktop and here are some more
important features:
Here are some important features of this drive:
♦ Slim type for moving office use
♦ USB 2.0 interface, easy to connect USB 2.0 port in Notebook or PC
♦ 8X DVD+R, 4X DVD-R Write, 4X DVD+RW, 2X DVD-RW Rewrite
speed, 8X DVD-ROM Read speed
♦ 24X CD-R, 24X CD-RW Write/Rewrite speed, 24X CD-ROM Read
speed
2
♦ Supports writing modes of TAO, DAO, SAO and packet writing
♦ Supports MultiRead function
♦ Serves as RPC-2 DVD-ROM Drive
♦ Smooth DVD playback
♦ Compatible with most existing DVD-ROM drives and DVD video
players
♦ Bundled with an extensive software package
About USB
USB (Universal Serial Bus), a means of attaching devices to your
computer, is basically a standardized intelligent serial connection which
provides an expandable, hot-pluggable*1interface. Devices suitable for
USB range from simple items like mice and keyboards to more
complicated devices like printers, MP3 players, and storage devices.
One other benefit of USB is plug and play. That is, when you plug the
USB device in, it is automatically detected, drivers installed and then
ready for operation.
USB 2.0 supports data transfer at up to 480Mbps for high-speed
devices. It is backward compatible with USB 1.1*2software and
peripherals. If your computer doesn’t have a built-in USB 2.0 port, you
need to install a USB 2.0 PCI host card in your pc for the CD-RW drive
to run at USB 2.O speed. Otherwise, this CD-RW drive will run at
standard USB speed.
*1You can connect and disconnect devices while the computer is
running.
*2 USB 1.1 can transfer data at rates up to 12Mb/s.
3
System Requirements
For IBM compatible PCs, the system requirements recommended are
as follows:
♦ Pentium III, 850MHz or above with at least 256MB of memory
♦ Minimum 1GB free Hard Disk space
♦ Operating system: Microsoft Windows 98SE/ME/2000/XP
♦ USB 2.0 PCI host card (If there’s no USB 2.0 built-in port on
board.)
We recommend that you use motherboards with built-in USB 2.0
connectors. If USB 2.0 host card is used, the reading speed of DVD might
be influenced.
Package Contents
♦ USB 2.0 external Slim Writer DVD±R/RW
♦ Power adapter
♦ USB 2.0 cable
♦ Application software discs
♦ Quick Installation Guide
4
INSTALLATION
Hardware Installation
1. Connect the power adapter to the drive.
External Power
AC IN 100-240V to DC OUT + 5V
2. Attach the USB 2.0 cable to the mini USB 2.0 connector on the
rear of the drive.
USB Connector
3. Attach the other end of the USB 2.0 cable to the USB port in your
computer. The drive is now ready to use.
If you are installing a USB 2.0 drive, your computer must have a
USB 2.0 port to reach top speed. You may experience slower USB
2.0 drive performance if it is connected to USB 1.1.
Note:
♦ Be sure to use the USB 2.0 cable & the power adapter (DC IN +
5V) packed with the drive.
♦ Never plug or unplug in any other USB device while the drive is
transferring data. It’s likely to loss data.
♦ It’s advisable not to disconnect the drive or unplug the power to
the drive while a CD is inserted.
5
♦ Don’t connect more than two CD-RW drives of USB connections
to a single computer.
Driver Installation
Windows Environment
This Slim Writer is a PnP (Plug and Play) device, and Windows
ME/2000/XP can automatically detect the drive and load the
appropriate driver.
For the users who run Windows 98SE, it is required to install the
provided driver included in the burning software disc.
How to install on Windows 98SE
Please follow the steps below for first time installation of the USB 2.0
device. After the successful installation, you can re-connect the
device and the system should automatically recognize the attached
USB 2.0 Device:
1. Turn on the computer.
2. When the hardware is fully installed, the system will
automatically detect the new hardware. A window shown below
pops up. Click [Next.]
6
3. Once the [Add New Hardware Wizard] window appears, select
[Search for the best driver for your device] and then click
[Next.]
4. Insert the burning software disc.
Check “Specify a location”, and browse the disc for the driver:
D:\Win98 USB driver.
Click [Next.]
