GB | Digital Multimeter

Read this instruction manual thoroughly before you begin using

the M0430. It contains particularly important passages concerning

occupational safety principles when using the device. Such passages

are highlighted. Reading the manual will prevent potential injury by

electric current or damage to the device.

The multimeter was designed in accordance with standard EN

61010-1, applying to electronic measuring instruments belonging

to category CAT III 600 V/CAT II 1000 V, pollution degree 2. CAT III is

intended for measuring circuits powered by xed wiring installations,

such as relays, sockets, distribution boxes, feeder lines and short

branching circuits and lighting systems in large buildings.

Category CAT II is intended for measurements made on circuits

directly connected to low-voltage installations (e.g. household

appliances, portable tools and similar equipment).

Do not use the multimeter to measure ranges that fall into the

category IV!

Warning:

Use the M0430 multimeter only in the manner specied below. Other

uses may cause damage to the device or endanger your health.

Comply with the following instructions:

• Before measuring resistance, diodes or current, disconnect the

circuits from the power supply and discharge any high-voltage

capacitors. Use a function appropriate for the given measure-

ment. Before changing the range (or switching functions) dis-

connect the conductors from the circuit that is being measured.

• Make sure the device is undamaged before you begin using the

multimeter. If you nd obvious signs of damage on the body of

the device, do not make any measurements! Check that the

surface of the multimeter does not have scratches and that the

side joints are not coming apart.

• Also check the insulation on the measuring probes. Damaged

insulation may result in injury by electric current. Do not use

damaged measuring probes!

• Do not measure voltages above 1000 V! If you intend to measure

current, check the multimeter‘s fuse and turn o the power

supply to the circuit before you connect the multimeter. Before

measuring, make sure the circular switch for setting measuring

range is in the correct position. Under no circumstances should

you make any changes to the measuring range (by moving the

circular switch for changing measuring programmes) while

measuring! Doing so could damage the device. When you are

measuring, rst connect the black conductor (probe) and then

the red conductor (probe). When disconnecting the testing

conductors, disconnect the red one rst.

• If you nd that the multimeter is making abnormal measure-

ments, stop using it. The fuse may be damaged. If you are unsure

of the cause of the defect, contact a service centre.

• Do not measure voltages higher than listed on the front panel

of the multimeter. Risk of injury by electric current or damage

to the multimeter!

• Check that the multimeter is working properly before use. Test

on a circuit with known electrical values.

• Before you connect the multimeter to a circuit you intend to

measure, turn o the power to the circuit.

• Do not use or store the multimeter in environments with high

temperature, dust or humidity. It is also not recommended to

use the device in environments with potentially strong magnetic

elds or risk of explosion or re.

• When changing parts of the multimeter (e.g. the battery or fuse)

use spare parts of the same type and specications. Change

parts only when the multimeter is disconnected and turned o.

• Disconnect the testing conductors from the tested circuit before

opening the rear casing of the device.

• Do not alter or otherwise interfere with the internal circuitry

of the multimeter!

• Be extra careful when measuring voltages higher than 30 V AC

rms, 42 V peak or 60 V DC. Risk of injury by electric current!

• When using measuring tips, make sure you are holding them

behind the nger barriers.

• Do not perform measurements if the multimeter‘s casing is

removed or loose.

• Once the screen shows the low battery icon , replace the

batteries. Otherwise, subsequent measurements may be in-

accurate. Incorrect measurements may then result in injuries

by electric current! Use alkaline batteries only; do not use

re-chargeable batteries.

Maintenance Instructions

Attention

Do not attempt to repair or modify the multimeter in any way if you

are not qualied to do so or do not have access to the necessary

calibration equipment. Make sure that water does not get into the

multimeter – prevents injury by electric current!

• Disconnect the measuring tips from the tested circuit before

opening the casing of the multimeter.

• Regularly clean the body of the multimeter with a moist cloth and

a mild detergent. Perform cleaning only when the multimeter is

disconnected and turned o.

• Do not use solvents or abrasive agents for cleaning!

• If you will not be using the multimeter for an extended period

of time, turn it o and remove the battery.

• Do not store the multimeter in places with high humidity and

temperature or in environments with strong magnetic elds!

Changing Batteries

When the symbol appears on the screen, it indicates the batteries

are close to depletion and must be immediately replaced. To replace

the batteries, unfasten the screw at the rear of the casing and remove

the casing. Replace the at batteries with new ones of the same

type (9 V, type 1604 or 6F22) and make sure to observe the correct

polarity. Replace the rear casing.

Electrical Symbols

Alternating current (AC)

Direct current (DC)

Alternating and direct current (AC/DC)

Warning symbol, hazard. Pay particular attention to sections of

the manual marked with this symbol.

Risk of injury by electric current

Fuse

Earthing

Double insulation

The product complies with applicable EU standards

Battery low

Continuity test

°C Celsius temperature unit

°F Fahrenheit temperature unit

Automatic switch-o

Automatic range

Data hold

Description of the Device (see Fig. 1)

The M0430 is a 5 ¾ digit, digital multimeter with automatic range

adjustment for measuring DC and AC voltage, DC and AC current, re-

sistance, capacity and temperature, and testing continuity and diodes.

1 – magnetic loop for hanging

2 – screen

3 – Select, , max/min, Range, Relative, Hz/Duty

4 – Circular switch for changing measuring range/choosing a function

5 – 10 A socket – for the plug at the end of the red (positive)

tipped measuring conductor for measuring current in a

current range of 10 A AC/DC

6 – µA/mA socket – for the plug at the end of the red (positive)

tipped measuring conductor for measuring current in a

current range to up to 600 mA AC/DC

7 – COM socket – for the plug at the end of the black (negative)

tipped measuring conductor

8 – INPUT socket – for the plug at the end of the red (positive)

tipped measuring conductor for measuring voltage, resist-

ance, diodes, transistors, continuity, capacity, frequency and

duty cycle, temperature

9 – protective casing

10 – removing the probe cover

Technical Information

Screen: 5 ¾ digit LCD with a maximum displayable value of 5,999

Negative polarity indication: the screen automatically displays „-“

Overload indication: the screen displays „OL“

Reading frequency: approx. 2× a second

Temperature measurement range: -20°C to 1,000°C

(-20°C to 300°C with the enclosed thermocouple)

Power supply: 1× 9 V battery, type 6F22 or equivalent

Operating temperature: 0°C to 40°C, relative humidity < 80%

Storage temperature: -10°C to 50°C, relative humidity < 85%

Dimensions: 35 × 90 × 190 mm

Weight: 336 g including battery

Measurement Accuracy

Accuracy is specied for the duration of one year after calibration

and at a temperature of 23°C (±5°C) and air humidity up to 80%.

Accuracy specications are:

±[(% of reading) + (lowest valid digits)]

DC Voltage

Range Resolution Accuracy

600 mV 0.1 mV ±(0.8% + 5)

6 V 1 mV ±(0.8% + 3)

60 V 10 mV

1000 V 1 V ±(1% + 5)

Overload protection: 600 V DC/AC rms

Maximum input current: 600 V DC

Input impedance: 10 MΩ

Measure 1,000 V DC range in CAT II

AC Voltage

Range Resolution Accuracy

600 mV 0.1 mV ±(1.2% + 8)

6 V 1 mV

±(1.2% + 6)60 V 10 mV

600 V 100 mV

750 V 1 V ±(1.2% + 8)

Overload protection: 600 V DC/AC rms

Input impedance: 10 MΩ

Frequency range: 40 Hz to 400 Hz

Maximum input voltage: 600 V AC rms CAT III

Measure 750 V AC range in CAT II, CAT III

Response: True RMS, corresponding to a calibrated eective value

of a sine wave.

Direct Current (DC)

Range Resolution Accuracy

600 µA 0.1 µA

±(0.8% + 5)

6000 µA 1 µA

60 mA 10 µA

600 mA 100 µA

10 A 10 mA ±(1.5% + 3)

Overload protection:

µA/mA range: 500 mA/600 V fuse, type F, Ø 6.3 × 32 mm.

10 A range: 10 A/600 V fuse, type F, Ø 6.3 × 32 mm.

Maximum input current: µA/mA socket max. 600 mA; 10 A socket

max. 10 A (when measuring current above 5 A; the measurement

duration must be max. 10 seconds and further measurement may

only be made after 15 minutes)

Voltage drop: 60 mV for 600 µA/60 mA range, 600 mV for

6000 µA/600 mA/10 A range

Alternating Current (AC)

Range Resolution Accuracy

600 µA 0.1 µA

±(1.5% + 8)

6000 µA 1 µA

60 mA 10 µA

600 mA 100 µA

10 A 10 mA ±(2% + 10)

Overload protection:

µA/mA range: 500 mA/600 V fuse, type F, Ø 6.3 × 32 mm.

10 A range: 10 A/600 V fuse, type F, Ø 6.3 × 32 mm.

Maximum input current: µA/mA socket max. 600 mA; 10 A socket

max. 10 A (when measuring current above 5 A; the measurement

duration must be max. 10 seconds and further measurement may

only be made after 15 minutes)

Voltage drop: 60 mV for 600 µA/60 mA range, 600 mV for

6000 µA/600 mA/10 A range

Frequency range: 40 Hz to 400 Hz

Alternating Current (AC) (measurement using clamps – optional

accessory)

Range Resolution Accuracy

200 A 1 mV/1 A ±(2.5% + 10)

600 A 1 mV/10 A

Resistance

Range Resolution Accuracy

600 Ω 0.1 Ω

±(1.5% + 3)

6 kΩ 1 Ω

60 kΩ 10 Ω

600 kΩ 100 Ω

6 MΩ 1 kΩ

60 MΩ 10 kΩ ±(1.5% + 5)

Overload protection: 250 V DC/AC rms

Voltage of an open circuit: approximately 0.25 V

Continuity Test

Symbol Description Note

If resistance is lower than 30 Ω, the

built-in buzzer will sound constantly.

If resistance is between 30 Ω and

70 Ω; the built-in buzzer may or may

not sound.

If resistance is higher than 70 Ω, the

built-in buzzer will not sound.

Voltage of an

open circuit:

approximately

0.5 V

Overload protection: 250 V DC/AC rms

Diode Test

Symbol Description Note

The approximate voltage of

the diode in the direction of

the current ow will appear

on the screen.

Voltage of an open

circuit: approximately

1.5 V

Overload protection: 250 V DC/AC rms

hFE Transistor Test

Range hFE Testing

current

Testing

voltage

PNP and NPN 0 ~ 1000 Ib ≈ 2 µA Vce ≈ 1 V

Capacity

Range Resolution Accuracy

10 nF 10 pF

±(8% + 5)

100 nF 100 pF

1 µF 1 nF

10 µF 10 nF

100 µF 100 nF

20 mF 10 µF

Voltage of an open circuit: approximately 0.5 V

Overload protection: 500 mA/600 V fuse, type F, Ø 6.3 × 32 mm

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Manuels Multimètre populaires d'autres marques

Agilent Technologies

Agilent Technologies 34420A Manuel utilisateur

Fluke

Fluke 83 Manuel utilisateur

Hameg

Hameg HM 8012 Manuel utilisateur

Mastech

Mastech MY70 Manuel utilisateur

Steren

Steren MUL-300 Manuel utilisateur

Somogyi Elektronic

Somogyi Elektronic home SMA 92 Manuel utilisateur

Gossen MetraWatt

Gossen MetraWatt METRAmax 6 Manuel utilisateur

PeakTech

PeakTech 4000 Manuel d'utilisation et d'entretien

YOKOGAWA

YOKOGAWA 90050B Manuel utilisateur

Gossen MetraWatt

Gossen MetraWatt METRALINE DMM16 Manuel utilisateur

Fluke

Fluke 8846A Manuel d'utilisation et d'entretien

Tempo Communications

Tempo Communications MM200 Manuel utilisateur

Elenco Electronics

Elenco Electronics CM-1555 Manuel utilisateur

Mastech

Mastech MS8238C Manuel utilisateur

SDAR

SDAR 830A, 830B, 830D, 830C Manuel utilisateur

RS PRO

RS PRO RS-9519BT Manuel utilisateur

BGS technic

BGS technic 8890 Manuel utilisateur

Amprobe

Amprobe Hexagon 60 Manuel utilisateur
