Emerson Bettis XTE3000 Manuel utilisateur

Installation, Operation and Maintenance Manual

VCIOM-15070-EN Rev. 1

February 2022

Bettis XTE3000

Sleep Mode

Revision Details

Installation, Operation and Maintenance Manual

VCIOM-15070-EN Rev. 1

Revision Details

February 2022

Revision Details

Revision Date Description Prepared Checked Approved

1 February 2022 Migration to new template

Installation, Operation and Maintenance Manual

VCIOM-15070-EN Rev. 1

Table of Contents

February 2022

Table of Contents

Section 1: Introduction

Introduction ............................................................................................................ 1

Section 2: Conditions to Activate SLEEP Function

Conditions to Activate SLEEP Function ..................................................................... 2

Section 3: Conditions to Switch to SLEEP Mode

Conditions to Switch to SLEEP Function.................................................................... 3

Section 4: Conditions to Exit from SLEEP Mode

Conditions to Exit from SLEEP Function .................................................................... 4

Section 5: SLEEP Mode Status

SLEEP Mode Status................................................................................................... 5

Section 6: Current Consumption

Current Consumption .............................................................................................. 6

Installation, Operation and Maintenance Manual

VCIOM-15070-EN Rev. 1

Notes

February 2022

This page intentionally left blank

Installation, Operation and Maintenance Manual

VCIOM-15070-EN Rev. 1 February 2022

Introduction 1

Section 1: Introduction

SLEEP is a new function available in the XTE3000 electric actuator which reduces power

consumption from the electronics when the actuator is not moving.

This function is useful when the actuator is powered via battery and solar panel, and if few

valve travel events are expected. In these applications, electrical power is absorbed from

the battery when the motor is running and when the motor is off, the solar panels recharge

the battery and power the actuator’s electronics.

Since the run time of the motor is a small percentage of the total time that the actuator

will spend in the eld, the energy necessary to power the electronics during the motor’s

rest phase is a high percentage of the total energy needed. Reducing energy requirements

when the motor is OFF allows a smaller solar panel to be used.

Figure 1 demonstrates the utility of the SLEEP function.

Figure 1

Power

Energy absorbed

when motor runs Energy absorbed

when motor runs

Energy savings with SLEEP function ON and motor OFF

Energy absorbed when motor is OFF and SLEEP function is active

Time

Energy with SLEEP function OFF and motor OFF

February 2022

Installation, Operation and Maintenance Manual

VCIOM-15070-EN Rev. 1

Conditions to Activate

Section 2: Conditions to Activate

SLEEP Function

The SLEEP function is activated by the following conditions:

• Parameter SLEEP in the “Actuator Setup” menu, “Restricted” section: ENABLED

• Firmware releases of microprocessors of BASE card:

— >= 9.00 for H8S

— >= 7.00 for PIC

• Firmware release of microprocessors of TERMINAL BOARD card:

— >= 6.0 for PIC

• Parameter SW TYPE in the “Actuator Setup” menu, “Restricted” section: XTE

• Parameter POSITIONER in the “Actuator Setup” menu, “Restricted” section: DISABLED

• Parameter HW CONFIG in the “Actuator Setup” menu, “Restricted” section: BASE

• Parameter BACKLIGHT in the “Actuator Setup” menu, “Restricted” section: AUTO

• Parameter POWER TYPE in the “Nameplate” menu, “Power Supply” section: DC

Installation, Operation and Maintenance Manual

VCIOM-15070-EN Rev. 1 February 2022

Conditions to Switch 3

Section 3: Conditions to Switch

Section 3: Conditions to Switch to

SLEEP Mode

The XTE3000 electronics switch to SLEEP status when:

• 30 seconds after the end of the last command (OPEN, CLOSE, ESD) via remote control

• 2 minutes after the last operation on the local interface of the actuator

(local selector and push buttons)

• 30 seconds after closure of Bluetooth or RS232 communication channel

(if present)

• 255 seconds after closure of IrDA communication channel (if enabled)

February 2022

Installation, Operation and Maintenance Manual

VCIOM-15070-EN Rev. 1

4Conditions to Exit

Section 4: Conditions to Exit

Section 4: Conditions to Exit from

SLEEP Mode

The XTE3000 electronics exit from SLEEP status when:

• Command via remote control OPEN, CLOSE, ESD (duration of command: > 0.7 second)

• By operating the actuator local interface (local push buttons or selector)

(duration of command: >1 second)

• Change of position > 5% via manual operation (handwheel)

When the XTE3000 exits from SLEEP mode, all functions are restored and the actuator is

available for normal operation.

Installation, Operation and Maintenance Manual

VCIOM-15070-EN Rev. 1 February 2022

5SLEEP Mode Status

Section 5: SLEEP Mode Status

In SLEEP mode:

• The alphanumeric display of actuator shows the message “SLEEP”

• Auxiliary relays AS1, AS7 do not change

• Auxiliary relay AS8 is de-energized

• Monitor Relay:

— de-energized if parameter “MR in SLEEP” in “Actuator Setup” menu,

“Restricted” section is “OFF” (with local selector in REMOTE)

— energized if parameter “MR in SLEEP” in “Actuator Setup” menu,

“Restricted” section is “ON” (with local selector in REMOTE)

• Any internal heater on the electronic cards are OFF

February 2022

Installation, Operation and Maintenance Manual

VCIOM-15070-EN Rev. 1

6Current Consumption

Section 6: Current Consumption

Minimum current consumption is obtained via the following conguration:

• Actuator without 4 - 20 mA position re-transmission card

• Parameter “MR in SLEEP” in “Actuator Setup” menu, “Restricted” section in “OFF”

In the above condition, the current consumption measured by a multimeter (on average on

an XTE3000 supplied at 24 V DC) is 58 mA, corresponding to 1.4 W (at 24 V DC).

If the actuator is equipped with a 4 - 20 mA position transmitter module, the current

consumption is 78 mA.

If the parameter “MR in SLEEP” in “Actuator Setup” menu, “Restricted” section is in “ON”,

the current consumption is 98 mA (2.4 W at 24 V DC).

When actuator exits from SLEEP mode, all XTE3000 functions are restored to normal

operation and the current consumption returns to normal.
