Emerson Turbo HD8003 Manuel utilisateur

WATER RESISTANT

PERSONAL CD-R/RW PLAYER

with DIGITAL TUNER

and 45 SECOND ANTI-SKIP PROTECTION

HD8003

OWNER’S MANUAL

Visit our web site at www.emersonradio.com

HD8003_ib040403.p65 4/4/2003, 11:3223

Thankyou forpurchasing thisEmerson Water-ResistantPersonalCD-R/

RWPlayerwithDigitalTuner.The CD-R/RWplayerhasa24 track

programmablememorysoyou can listen tothe songson yourfavorite

CD'sinanyorderyouchoose.OryoucanusetheRandomplayback feature

and letthe playerselectthe playback orderforyou.Usethe 3-wayRepeat

featuretorepeatasingletrack,the entiredisc,oraprogrammed sequence

oftracks,indefinitely.We'vealsoincluded 45 second ElectronicAnti-Skip

Protection whichmakesthisplayervirtuallyskip-free during mostactive

uses.

Pleaseread thisinstruction manualcompletelyand carefullytomakesure

you understand the properoperation ofthisproduct, and getthe maximum

enjoymentoutofall the featuresofthisstate-of-the-artCD-R/RWplayer.

Onceagain,thanks forpurchasing thisEmerson product.

The serialnumberofyourCD playercan be found on the bottomcabinet.

Wesuggestthatyou recordthe serialnumberofyourunitinthe space

belowforfuturereference.

ModelNumber:HD8003

SerialNumber:

HD8003_ib040403.p65 4/4/2003, 14:171

WARNING: TOPREVENTFIREORSHOCKHAZARD,

DONOTEXPOSETHISUNITTORAINORMOISTURE.

Thisdevicecomplieswithpart15 ofthe FCC rules.Operation issubjecttothe

condition thatthisdevicedoesnotcauseharmfulinterference.

CLASS 1LASERPRODUCT

APPAREILÁLASERDECLASSE 1

PRODUCTOLASERDECLASE 1

CAUTION

INVISIBLELASERRADIATION

WHENOPENAND INTERLOCKS

DEFEATED.

AVOIDEXPOSURETOBEAM

ThisproductcontainsalowpowerLaserDevice.

•Placesexposed todirectsunlightor

closetoheatradiatingappliancessuch

aselectricheaters.

Avoidinstalling theunitinlocationsdescribedbelow:

•Dustyplaces.

•Placessubjecttoconstant

vibration.

•Humidormoistplaces.

CAUTION!!

THISLASERCOMPACTDISCPLAYERFUNCTIONSBY HELPOFINVISIBLE

LASERLIGHTAND ISEQUIPPEDWITHSAFETYSWITCHES TOAVOID

EXPOSUREWHENDOORISOPENAND SAFETYINTERLOCKS ARE

DEFEATED.ITISDANGEROUSTODEFEATORBYPASS SAFETYSWITCHES.

IMPORTANTNOTES

DANGEROUSVOLTAGE

Uninsulated DangerousVoltage,thatmaybe ofsufficient

magnitude toconstitutearisk ofelectricshock topersonsis

presentwithinthisproduct'senclosure.

ATTENTION

The Owner'sManualcontainsimportantoperating and

maintenanceinstructions.

Foryoursafety,itisnecessarytorefertothe manual.

HD8003_ib040403.p65 4/4/2003, 14:172

PREPARATIONFORUSE

POWER SOURCES

This personal CD player with digital tuner is designed to operate on two alkaline

“AA” batteries, or on an optional AC adapter, not included.Attempting to operate

this unit on any other power source may cause damage to the unit and such damage

is not covered by your warranty.

INSTALLING THE BATTERIES

The battery compartment is located inside the CD player.

1.) Open the CD door locking hinge as shown and then open the CD door.

Remove the “dummy CD” transit protection card from the CD spindle and

discard it.

2.) Press the battery cover locking tab

in the direction of the arrow and

open the battery cover as shown.

Note: To prevent loss the battery cover cannot be completely removed

from the player.

HD8003_ib040403.p65 4/4/2003, 14:173

3.) Insert two fresh “AA” alkaline batteries in the battery compartment. Be sure to

follow the polarity makings in the battery compartment. If the batteries are

inserted incorrectly the unit will not work.

4.) Close the battery compartment cover and make sure that it is locked in place

so that it does not come in contact with a CD.

WHEN TO CHANGE THE BATTERIES

When the Battery Indicator appears in the display the batteries are getting

weak and should be changed as soon as possible. Do not leave weak or exhausted

batteries in the player as they will eventually leak and cause corrosion inside the

battery compartment.

USING AN OPTIONAL AC/DC ADAPTER

If you decide to purchase an optional AC adapter the specification should be as

follows:

Input Voltage: 120V/60Hz AC.

Output Voltage: 4.5V DC 500mA.

Plug Type: Center-pin 1.3mm Female Plug with Positive (+) Center

Positive(+)Negative(–)

HD8003_ib040403.p65 4/4/2003, 14:174

You may also purchase a “Universal” typeAC adapter that allows you to select the

desired output voltage, and normally includes several of the most popular plug

sizes. Make sure that the adapter you purchase is “UL Listed”. Look for the “UL”

mark on the packaging and on the adapter itself.

Connect the adapter housing directly to a 120V AC outlet. Connect the appropriate

adapter plug to the “DC Input 4.5V” jack on the side of the CD player. Remove the

rubber cap from the Input jack before connecting the adapter plug. Replace the

rubber cap when the adapter plug is removed from the player.

Notes:

• The housing of the adapter may become warm during operation. This

is normal.

• Never insert or remove the adapter housing from the AC outlet while

your hands are wet.

• The adapter plug must be completely disconnected from the CD player

in order to operate the player on batteries.

BATTERYPRECAUTIONS

Followtheseprecautionswhen using batteriesinthisdevice:

1.Useonlythe sizeand type ofbatteriesspecified.

2.Besuretofollowthe correctpolaritywhen installing the batteriesasindicated inthe battery

compartment. Reversed batteriesmaycausedamage tothe device.

3.Donotmixdifferenttypesofbatteriestogether(e.g.Alkaline and Carbon-Zinc)oroldbatteries

withfreshones.

4. If the deviceisnottobe used foralong period oftime,removethe batteriestoprevent

damage orinjuryfrompossiblebatteryleakage.

5.Donottrytorecharge batteriesnotintended tobe recharged;theycan overheatand rupture

(Followbatterymanufacturer’s directions.)

4.5VDC

AC/DCADAPTER

(OPTIONAL)

120V/60HzACOUTLET

HD8003_ib040403.p65 4/4/2003, 14:175

HAND STRAP INSTALLATION

This player is supplied with an accessory hand-strap to secure the player in your

hand while you are jogging or performing other strenuous activities.

To install the hand-strap, thread the strap through the two slots in the hand strap

bracket as shown, and then through the buckle. Adjust the Velcro®strap to fit

comfortably but securely around your hand.

HD8003_ib040403.p65 4/4/2003, 14:176

LOCATIONOFCONTROLSAND INDICATORS

TOP CABINET

1.) CD Door Locking Hinge.

2.) PROG/MEMORY Button.

3.) MODE Button.

4) PRESET DOWN Button.

5.) PRESET UP Button.

6.) CD/Radio Display.

7.) POWER ON

CD PLAY/PAUSE Button.

8.) CD F.SKIP/TUN.UP Button.

9.) CD R.SKIP/TUN.DOWN Button.

10.) CD STOP /POWER OFF Button.

11.) ASP (Anti Skip)/Radio BAND Button.

12.) HOLD On/Off Switch.

13.) Direct Access Radio Preset

Buttons (1 – 5).

14.) “M5+” Button.

LEFT SIDE CABINET

15.) DC IN 4.5V Jack.

16.) CD/RADIO Selector Switch.

17.) VOLUME Control.

RIGHT SIDE CABINET

18.) PHONES Jack.

BOTTOM CABINET

19.) Hand-strap Bracket.

15 16 17

HD8003_ib040403.p65 4/4/2003, 14:177

1.)PROG –CD ProgramIndicator.

2.)INTRO–IntroPlayback Indicator.

3.)RAND –RandomPlayback Indicator.

4.)PRESET–TunerPresetIndicator.

5.)RepeatIndicator..

6.)“ALL”Tracks RepeatIndicator.

7.)CD-RWIndicator.

8.)BatteryLevelIndicator.

9.)AntiSkipProtection (ASP)LevelIndicator.

11.)FMStereo Indicator.

10.)RadioFrequency/CDTimeDisplay.

12.)FM/AMBand Indicators.

13.)RadioPreset/CDTrack NumberDisplay.

MULTIFUNCTIONLCD DISPLAY

RAND

INTRO FM

ALL

CD-RW

MHz

KHz

PROG

PRESET

5 7 8

10111213

HD8003_ib040403.p65 4/4/2003, 14:178

OPERATINGINSTRUCTIONS

• Make sure the batteries are installed correctly, or that the optional

AC adapter (not included) is installed properly.

• If you have not already done so remove the “dummy CD” transit

protection from the CD spindle and discard it.

• Set the VOLUME control to a low level.

• Fully unwind the headphone cord and connect the headphone plug

to the headphone jack. The plug must be fully inserted into the jack,

otherwise the sound may be intermittent.

• Make sure that the HOLD switch is in the ‘Off’ position.

IMPORTANT INFORMATION

This personal CD player is designed to be "water-resistant". Jogging

with this product in the rain will not cause any problems. However

this product is not "water-proof" and should never be immersed in

water. Extra care should taken to prevent water from getting inside

the cabinet while loading or unloading CD's, or while changing the

batteries. In addition, the rubber plugs which cover the headphone

jack and the DC Input jack should remain sealed when those jacks

are not in use. After jogging with this model in the rain please wipe

excess moisture off the cabinet with a soft, dry towel before putting

the model away for storage.

SPORTS STYLE LIGHTWEIGHT STEREO HEADPHONES

The lightweight stereo headphones supplied with this CD player have ear-pieces

designed to fit directly into your ear. Be sure to observe the “L” (Left) and “R”

(Right) markings on the ear-pieces to make sure that you put the headphones on

correctly. Always set the VOLUME control to a low level before putting on the

earphones, and then gradually increase the volume to a comfortable listening level.

HD8003_ib040403.p65 4/4/2003, 14:179
