Embest SBC8140 Manuel utilisateur

SBC8140

Single Board Computer

Quick Guide

Version 1.0 –Mar. 20th, 2013

SBC8140 and its related intellectual property are owned by Shenzhen Embest

Technology Co., Ltd.

Shenzhen Embest Technology has the copyright of this document and reserves

all rights. Any part of the document should not be modified, distributed or

duplicated in any approach and form with the written permission issued by

Embest Technology Co., Ltd.

M The use of Microsoft, MS-DOS, Windows, Windows95, Windows98,

Windows2000 and Windows embedded CE 6.0 are authorized by Microsoft.

Revision History:

Version

Date

Note

1.0

2013-3-20

Original Version

Embest Technology

Table of Contents

Chapter 1 Product Overview ............................................................................................1

1.1 Packing List............................................................................................................1

1.2 Default Specifications.............................................................................................1

Chapter 2 Preparations .....................................................................................................2

2.1 Hardware Connections and Buttons ......................................................................2

2.2 Setting Up HyperTerminal ......................................................................................3

Chapter 3 Linux Operating System..................................................................................7

3.1 Updating SD Card and Booting from It...................................................................7

3.2 Updating NAND Flash and Booting from It............................................................8

Chapter 4 WinCE Operating System..............................................................................10

4.1 Updating SD Card and Booting from It.................................................................10

4.2 Updating NAND Flash and Booting from It..........................................................12

Technical Support and Warranty....................................................................................13

Embest Technology

Chapter 1 Product Overview

1.1 Packing List

SBC8140 x 1

Cross-over serial cable（DB9 to DB9）x 1

10-pin JTAG cable x 1

JTAG8000 module x 1

5V/2A power adapter x 1

DVD-ROM x 1

LCD screen x 1 (optional item, available in 4.3-inch 480*272 or 7-inch 800*480)

1.2 Default Specifications

SBC8140 does not have RTC battery on board by default

SBC8140 has a Linux2.6.32 system in NAND Flash by default

SBC8140 boots from NAND Flash by default; pressing and holding BOOT

button (button CN11) before connecting power can make it boot from SD card;

Embest Technology

Chapter 2 Preparations

2.1 Hardware Connections and Buttons

Please connect hardware components and find locations of button according to the

figure shown below;

Figure 2-1 Hardware connections

Table 2-1 Hardware Connections

No.

Descriptions

No.

Descriptions

Insert a SD card

BOOT button

Connect serial cable

Connect power adapter

Embest Technology

2.2 Setting Up HyperTerminal

1）Click Start > Programs > Accessories > Communications >

HyperTerminal on your PC’s desktop;

Figure 2-2 Start HyperTerminal

2）Enter a name in the Name field and select an icon below, and then click OK;

Figure 2-3 Create a new HyperTerminal

Embest Technology

3）Select the port to be used and click OK;

Figure 2-4 Select port

Embest Technology

4）Please configure the port you selected as shown in the following window,

and then click OK;

Figure 2-5 Configure port

Embest Technology

5）HyperTerminal has been set up successfully.

Figure 2-6 HyperTerminal window

Embest Technology

Chapter 3 Linux Operating

System

This chapter will introduce how to update SD card and NAND Flash and boot Linux

system from them respectively.

3.1 Updating SD Card and Booting from It

1）You can download HP USB Disk Storage Format Tool 2.0.6 from

http://www.embedinfo.com/english/download/SP27213.exe, and use it to

format SD card; the figure shown below is the tool’s interface;

Figure 3-1 Format SD card
