1. BRIEF DESCRIPTION OF DEVICE

The display module provides the function of calling via the contacts list of the panel on which it is installed.

If the panel has a keypad art. 41019, calls to the indoor units can also be made by entering the desired number via

the keypad.

The device also provides visual feedback on the operating phases of the panel, such as the indications for "call in

progress" and "talking", in addition to that associated with the entry control modules.

The display module is equipped with an installation menu with which the basic panel conguration parameters can be

managed.

3.5 in display for audio or audio-video modules, 3 buttons for calls from

contacts list backlit with white LEDs, 1 input congurable as external but-

ton for CA door opener or PA door open, to be completed with front cover

Description of wiring terminal block

Terminal function

CA- Lock control additional button (Default). Alternatively (if congured via SaveProg), sensor input to signal “Door

Open”.

CA+

5V- External additional power supply.

Caution: You must observe the polarity in the connection.

5V+

a) Display, 3.5”

b) button (UP)

c) button (DOWN)

d) button (OK)

e) Mini USB connector for connecting to a PC.

f) Removable wiring terminal block

g) Connector for the connection to the previous electronic module

h) Connector for the connection to the next electronic module

Front and rear view

5V- 5V+CA+CA-

bcd

2. FEATURES

2.1. Features

• The 3.5" display has the following features: 320 x 480 pixels, 65K colours, 500 lux.

• The device must always be accompanied by an audio/video or audio module.

• Power supply: 5V DC from audio video or audio module via harness. Maximum current draw: 220 mA. When connect-

ing the modules, observe the limit of the maximum current that can be supplied by the specic Audio/Video module

being used; if it is necessary to provide an independent power supply to the display module, the device is equipped

with an additional power supply unit on the 5V+ and 5V- terminals with a voltage of 5V DC ± 5% and a minimum

current of 220 mA.

Connecting an additional power supply unit disables the power supply input from the connected Audio/Video module,

which must in its turn be powered for the display module to work properly.

•

Operating temperature: -25 °C / +55°C.

•

Protection class: IP54

•

IK08-rated for protection against impact (Pixel)

3. CONFIGURATION VIA PC

3.1. Programming the Contacts List and entry control codes

The contacts list (up to 8192 entries) and the entry control codes (up to 2000 codes) can be programmed via the PC

programming SW (SaveProg), connecting to the audio/video module.

Follow the instructions given on SaveProg.

3.1.1. Standby views

When rst switching on, without having programmed any contacts list, the device looks like this:

Without a keypad

With a keypad installed

Press

After programming the contacts list, the standby view looks like this.

Without a keypad

With a switchboard

and keypad

Contacts

Press

Porter

Contacts

Extension

Contacts

Porter

3.2. Setting contacts list lters

SaveProg lets you enable a set of lters for targeted access to the subsets of the contacts list.

The available lters are described below.

3.2.1. Initials pre-lter

This lter lets you access a section of the contacts list identied by the names that start with the chosen letter.

Extension

Contacts

Porter

Users

3.2.2. Building lter

This lter lets you access the subset of users paired with a specic building.

Extension

Contacts

Porter

Buildings

Users

The Building lter can be combined with the names pre-lter.

Extension

Contacts

Porter

Buildings

Users

3.2.3. Stair lter

The Stair lter lets you access the subset of users paired with a specic stair or all users.

It can be combined with the two previous lters.

In particular, with the buildings lter you obtain:

Extension

Contacts

Porter

Buildings

Stairs

Stair A

Stair B

Stair E

Stair D

Stair C

Users

Stair A

With the buildings and names lter

Extension

Contacts

Porter

Buildings

Stairs

Stair A

Stair B

Stair E

Stair D

Stair C

Users

Stair A

Users

Stair A

3.3. Additional information

Additional information comprises additional descriptions that appear on a contacts list entry when the user hovers

over it for more than 3 s.

One of these items can be set as additional information:

• Service Information, such as the business hours of an ofce;

• List of extensions, created automatically from the names in the contacts list paired with the same extension

number;

• A second name.

Extension

Contacts

Porter

Users

Back

3.4. Updating

The device can be updated via its USB port.

Follow the WinBoot user instructions.

To update the module you need to disconnect the bus wiring harness, disconnect any auxiliary power supply, connect

the USB port to the PC and start the update within 10 s of this connection.

The situation of remaining in bootloader lasts 10 s from entry. It exits automatically if the update is not started.

4. CONFIGURATION VIA MENU

The display provides the ability to congure the basic parameters of the panel.

There are two menus:

1. administrator: the administrator side lets you modify the display module interface;

2. installer: lets you change some of the functional parameters of the panel.

You access the menu by simultaneously pressing (UP) + (DOWN) for 5 s and entering the respective pass-

words.

The passwords have a xed length and are composed of a sequence of the “ (UP)” “ (DOWN)” “ (OK)”

buttons.

The default passwords are:

Administrator: (UP) + (UP) + (UP) + (UP) + (UP)

Installer: (DOWN) + (DOWN) + (DOWN) + (DOWN) + (DOWN)

The passwords can be changed via SaveProg.

4.1. Administrator menu

The structure is summarized below:

Label Settings

Level 0 Level 1 Level 2

Display

Language Italian, English, French, German, Spanish, Greek and

Portuguese (Default: Italian)

Menu Navigation Navigable/Direct (Default: Navigable)

Font Normal/Large (Default: Normal)

LCD

Brightness 1-5 (Default:5)

Colours B/W, BLUE, GREEN (Default: B/W)

Standby ON/OFF (Default: ON)

The items are accompanied by the current value of the set parameter.

4.1.1. Language

This lets you choose the language of the messages of the user and installer menus.

• Language: Italian, English, French, German, Spanish, Greek and Portuguese

4.1.2. Menu

This lets you choose the variant of the menu structure according to need.

• Navigation: Navigable/Direct

Navigable: lets you scroll through the menu selecting the items with the arrows and entering the selected

sections with (OK);

Direct: lets you enter the items directly by pressing the (UP)/(DOWN) control buttons of the display

module

Select

Contacts

Porter

Contacts

Porter

Navigation Direct

• Font: Normal/Large

Changes the font size, to improve readability.

Extension

Contacts

Porter

SELEZIONA

SELECT

PORTER

EXTENSION

CONTACTS

Normal Large

4.1.3. LCD

This lets you dene the operating parameters of the display

• Brightness: 0-5

Brightness level

• Colours: B/W, BLUE, GREEN

Lets you select one of the predened colour schemes for viewing the menu, according to readability.

Extension

Delete

Confirm

Extension

Delete

Confirm

Extension

Delete

Confirm

B/W BLUE GREEN

• Standby: ON, OFF

Lets you disable display standby mode, i.e. not decreasing the brightness level of the LCD when it is not being

used.

4.2. Installer menu

The structure is shown below:

Label Settings

Level 0 Level 1 Level 2

Display

Language Italian, English, French, German, Spanish, Greek

and Portuguese (Default: Italian)

Menu Navigation Navigable/Direct (Default: Navigable)

Font Normal/Large (Default: Normal)

LCD

Brightness 1-5 (Default:5)

Colours B/W, BLUE, GREEN (Default: B/W)

Standby ON/OFF (Default: ON)

Panel

Audio Speaker 0=auto, +4 levels

Microphone 0=auto, +4 levels

Push-buttons

Setting ID - Status screen (in progress)

- Status screen (OK/fail)

Module order - Status screen (in progress)

- Status screen (OK/fail)

Grouping Single, Double, Quadruple

Addressing

Interphones - Status screen (in progress)

- Status screen (OK/fail)

Panels - Status screen (in progress)

- Status screen (OK/fail)

Timing Lock 10 values

Talk 10 values

Info

AV FW Ver xxxxx

LCD FW Ver xxxxx

KP FW Ver xxxx

System

Reset Settings OK/C (Conrm/Delete)

Reset Panel OK/C (Conrm/Delete)

Reboot Panel OK/C (Conrm/Delete)

Reboot Installation OK/C (Conrm/Delete)

The Display section is described in the previous chapter "4.1 Administrator menu".

4.3. Panel

This section lets you set the basic parameters of the audio/video module of the panel. Refer to the specic instruc-

tions of the specic audio/video module for details of the settings.

4.3.1. Audio

This lets you set the operating levels of the loudspeaker and microphone.

• Speaker: 0=auto, +4 levels

• Microphone: 0=auto, +4 levels

4.3.2. Push-buttons

This lets you manage push-button conguration.

• Setting ID

Starts the "call button remapping" procedure.

• Module order

Starts the procedure of assigning the order of the button modules.

• Grouping: Single rocker, single axial, double axial button

Lets you choose the type of grouping of the panel.

4.3.3. Addressing

This lets you start the panel and indoor unit addressing procedures.

• Interphones

Starts the indoor unit address assignment procedure.

• Panels

Starts the panel address assignment procedure.

4.3.4. Times

This lets you choose the times for:

• Lock

Lock command duration

• Talk

Maximum talk duration

4.4. Info

This section gives the release information for the devices installed on the panel.

4.5. System

This section lets you restore the factory settings of the various devices or restart the panel.

• Reset Settings: Yes/No

Restores the factory default settings of the display module, after conrmation.

• Reset Panel: Yes/No

Restores the factory default settings of the panel, after conrmation.

• Reboot Panel: Yes/No

Restarts the panel.

• Reboot Installation: Yes/No

Restarts the entire Due Fili installation.

After the reboot, the display shows the screen described in paragraph 5.6.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Elvox Système d'interphone

Elvox

Elvox PETRARCA 6029 Manuel utilisateur

Elvox

Elvox TAB 7529 Manuel utilisateur

Elvox

Elvox DIGIBUS 7200 Series Manuel utilisateur

Elvox

Elvox 6604 Manuel utilisateur

Elvox

Elvox 8100 Series Manuel utilisateur

Elvox

Elvox Vimar 40610.S Guide de l'utilisateur

Elvox

Elvox Giotto 6341 Manuel utilisateur

Elvox

Elvox 885A Manuel utilisateur

Elvox

Elvox 69PH Instructions de montage

Elvox

Elvox K40515.E Manuel utilisateur

Elvox

Elvox GIOTTO Series Manuel utilisateur

Elvox

Elvox 85CE/240 Manuel utilisateur

Elvox

Elvox 8870 Manuel utilisateur

Elvox

Elvox Giotto 6329 Instructions de montage

Elvox

Elvox Giotto 6341 Manuel utilisateur

Elvox

Elvox Giotto 6329/C Instructions de montage

Elvox

Elvox PETRARCA 6029 Manuel utilisateur

Elvox

Elvox 6601/AU Manuel utilisateur

Elvox

Elvox 637G/S1 Manuel utilisateur

Elvox

Elvox Vimar K40912 Manuel utilisateur

Elvox

Elvox 68TU/K93 Manuel utilisateur

Elvox

Elvox 12B2 Mode d’emploi

Elvox

Elvox 62KF Manuel utilisateur

Elvox

Elvox PETRARCA 6002 Manuel utilisateur

Manuels Système d'interphone populaires d'autres marques

Bticino

Bticino LINEA 3000 Manuel utilisateur

MSI

MSI MSI-140 Manuel utilisateur

golmar

golmar Stadio Plus Manuel utilisateur

CyberData

CyberData 011211 series Manuel

Vidos

Vidos duo M1021 Manuel utilisateur

Vimar

Vimar ELVOX 7539/E Manuel utilisateur

SSS Siedle

SSS Siedle BTSV 850-03 Manuel utilisateur

Dahua

Dahua VTO Series Manuel utilisateur

Videx

Videx VIDEOKIT Series Manuel utilisateur

Rocom

Rocom Doortello Business FW T2.05W2.04 Manuel utilisateur

Viking

Viking E-35-EWP Manuel utilisateur

Safeguard Supply

Safeguard Supply LRA-EX1000 Manuel utilisateur

SSS Siedle

SSS Siedle BFCV 850 Series Manuel utilisateur

GRD

GRD MAX V2 Manuel utilisateur

Alecto

Alecto ADI-250 Manuel utilisateur

Aiphone

Aiphone IE-8MD Manuel utilisateur

Perel

Perel EDB4 Manuel utilisateur

Bticino

Bticino Classe 300 Manuel utilisateur
