4 Description of Flatpack Power Tower
10(48) Operation Guide, Flatpack Power Tower
351401.013v2 July 2003
4.1.1 Basic or extended functionality for monitoring and control
The Flatpack Power Tower is available with either basic- or extended functionality for monitoring and control of
the system. The type of interface PCB mounted inside determines whether the distribution unit has basic or
extended functionality. The pictures below show that the interface PCB used distribution units with basic
functionality has less wire connectors than the PCB used in distribution units with extended functionality.
A distribution with extended functionality includes five more alarm relay outputs (totally 11) in addition to the
standard monitoring and control features.
4.1.1.1 Basic functionality
4.1.1.2 Extended functionality
4.1.1.3 Front access interface PCB
Interface PCB for distribution units with basic
functionality (part no. 100350). Includes all
standard monitoring and control features.
See chapter 5.6.2.2Basic version (PCB part no.
100350) for more details.
Interface PCB for distribution units with extended
functionality (part no. 100145). Includes all
standard monitoring and control features and five
additional alarm relay outputs.
See chapter 5.6.2.3 Extended version (PCB part
no 100145)for more details.
Interface PCB for distribution units with basic
functionality (part no. 1001714). Includes all
standard monitoring and control features.
See chapter 5.6.2.4 Front Access PCB (PCB Part
number 101714) for more details.
