ELPRO SD104 Manuel utilisateur

ELPRO Video Labs s.r.l.

Via della Praia 4/a FERRIERA di BUTTIGLIERA ALTA (TO) – ITALY

Tel.+ 9 0119 48778 - FAX + 9 0119 48779

SD104 HIGH PERFORMANCE DIGITAL DISTRIBUTOR AMPLIFIER

SDI presence indication

High accuracy in the input and outputs ret. loss

Autosensing circuit for fault monitoring

Able to compensate 220m of R 59DS cable

Regenerated and reclocked outputs

On board SDI to Pal converter (DOP107, optional)

To be fitted in dvr-mv/rk rack

SD104-M 09/06/08

1.0 OVERVIEW

The SD104 is a high performance digital video signal distributor. It features 1

input and 6 outputs adapted at 75Ω.

arious features of this distributor make it a unique product, as yet unequalled on

the market:

-Automatic PLL for 143, 177, 270 and 360Mbit/sec

-High accuracy in the input and outputs ret. loss

-Autosensing circuit for fault monitoring

-Able to compensate 220m of RG59DS cable

-Regenerated and reclocked outputs

-On board SDI to Pal converter (DOP107, optional)

The distributor consists of a plug-in and of a separate rear part denominated

DRB104 on which the connectors for link-up to the external world are fitted. The

DRB104 is an integral part of the supply.

A conversion board that provides a PAL signal in output can be fitted on the plug-

in. The conversion board, known as DOP107, must be ordered separately.

The plug-in and the rear part must be inserted in the ELPRO 19" 3RU standard

rack with code DVR-MV/RK.

ELPRO ideo Labs s.r.l.

ia della Praia 4/a FERRIERA di BUTTIGLIERA ALTA (TO) – ITALY

Tel.+39 0119348778 - FAX +39 0119348779 2

SD104 HIGH PERFORMANCE DIGITAL DISTRIBUTOR AMPLIFIER

Input type

Input ret. loss

Outputs ret loss

Jitter

Outputs amplitude

PLL locking:

bps

143 Mb/s

1 Mb/s

2 0 Mb/s

360 Mb/s

Main input

Power consumption

Weight

Safety

EMC

CE Mark

2.0 PRESETTINGS

The unit has no internal presettings.

At the center of the plug-in, there is a 12-pin connector in which to insert an

optional board, the DOP107.

This board converts the SDI signal at 2 0Mbit/sec, entering the SD104, providing

a Pal signal output.

The Pal signal is available on the BNC connector identified as MON fitted on the

DRB104 rear part.

ELPRO Video Labs s.r.l.

Via della Praia 4/a FERRIERA di BUTTIGLIERA ALTA (TO) – ITALY

Tel.+39 0119348 8 - FAX +39 0119348 9

SD104 HIGH PERFORMANCE DIGITAL DISTRIBUTOR AMPLIFIERSD104

DOP 107

3.0 INDICATIONS

The SD104 features four indicator lights on the front panel:

3.1 ON :The ON light switches on when the plug-in is powered

correctly and the internal oltages are correct. A sensing

circuit on the internal power supplies switches off the ON

light if one of these is not at rated alue.

3.2 SDI :Lights up if there is a 270Mbit/sec digital signal in input

3.3 FAULT (Alarm) :The FAULT light switches to indicate a fault in the circuit

that affects correct functioning.

The SD104 is fitted with an autosensing circuit for permanent monitoring of the

correct le el of the work points of the circuitry. If one of these le els is not within

tolerance, the light switches on.

This function is ery useful when many SD104 are fitted in an array as it permits

immediate identification of the faulty unit.

3.4 OUT PAL :The OUT PAL light switches on to indicate that the

DOP107

option board is fitted on the plug-in.

hole

ELPRO Video Labs s.r.l.

Via della Praia 4/a FERRIERA di BUTTIGLIERA ALTA (TO) – ITALY

Tel.+39 0119348778 - FAX +39 0119348779 4

SD104 HIGH PERFORMANCE DIGITAL DISTRIBUTOR AMPLIFIER

4.0 INSTALLATION

The unit must be installed in a DVR-MV/RK rack

WARNING

The presence of the SD104 is compati le

with other plug-ins of the 100 family

1) Fasten the DRB104 rear part to the rear of the rack and connect the input and

output signals.

WARNING

If the DOP107 option oard is fitted,

the Pal output will e present on the MON BNC connector

2) If it has been purchased separately, insert the DOP107 option on the

SD104

plug-in. Make sure that the notch on the DOP107 fits into the specific

hole

pro ided on the SD104 plug-in. Fasten with the 3X6 screw pro ided.

3) From the front panel of the rack, insert the SD104 plug-in so that the

connector

fitted is inserted in the edge connector present on the rear part of the DRB104.

WARNING

Remem er that SD104 can manage signals with a rate of

etween 143M /s and 360M /s. Phase looking of the internal PLL

is automatic and without external presettings

The SD104 is fitted with a circuit that automatically compensates losses of the

cable that carries the signal to its input. The six outputs are reclocked.

WARNING

Compensation of a section of 220 m

is assured using RG59DS ca le

4) Power on The DVR-MV/RK.

Automatically either the plug-in SD104 is supplied.

Check that the led ON is switched on

ELPRO Video Labs s.r.l.

Via della Praia 4/a FERRIERA di BUTTIGLIERA ALTA (TO) – ITALY

Tel.+39 0119348778 - FAX +39 0119348779

SD104 HIGH PERFORMANCE DIGITAL DISTRIBUTOR AMPLIFIER

5.0 TECHNICAL DATA

Input type :AC coupled

Input ret. loss :44dB at 10MHz, 41dB at 100MHz,

34dB at 200MHz, 29,5dB at 2 0MHz

Outputs ret loss :33dB at 10MHz, 24dB at 100MHz,

22dB at 200MHz, 21dB at 2 0MHz

Jitter :better than 150ps

Outputs amplitude :800mVpp

Outputs rise/fall time : 80ps at 2 0Mb/s (measured from 20% to 80%)

Automatic compensation :220mt RG59DS cable with SDI check field

(Test with SPG422 and VFM 601i Tektronix)

DOP10 Pal out ret. loss :21dB at 5MHz

PLL locking:

bps center freq. f. min. f.max

143 Mb/s 1,5 MHz 64,6 MHz 6,5 MHz

1 Mb/s 88,5 MHz 9,8 MHz 93,1 MHz

2 0 Mb/s 135,0 MHz 124,0 MHz 144,6 MHz

360 Mb/s 180,0 MHz 166,9 MHz 194,6 MHz

Main input :230Vac 50Hz

Power consumption :5VA

Weight :0.3Kg

Operating temp. range :0 ÷ 45°C

Safety :according to EN 60065

EMC :according to EN 55013 and EN 55020

CE Mark

a Pal

ELPRO Video Labs s.r.l.

Via della Praia 4/a FERRIERA di BUTTIGLIERA ALTA (TO) – ITALY

Tel.+39 0119348 8 - FAX +39 0119348 9 6

SD104 HIGH PERFORMANCE DIGITAL DISTRIBUTOR AMPLIFIER

the market:

6.0 NOTES

This product is warranted for 2 years from the date of purchase.

If the fault in the p oduct is due to imp ope use o ope ations

ca ied out by thi d pa ties, the wa anty is fo feited.

During the warranty period, Elpro will repair the faulty units free of charge.

The faulty units must be sent CARRIAGE FREE to the Elp o offices in Tu in

with a egula accompanying note.

The units repaired will be returned CARRIAGE FORWARD to the addressee.

Outside the warranty period, Elpro will repair the faulty units EX its Turin offices,

charging the cost of the repair to the customer.

Fo any p oblems du ing installation of its p oducts

use the Elp o hot-line +39 011 9348778

o E-mail: info@elp ovideolabs.com

ELPRO ideo Labs s.r.l.

ia della Praia 4/a FERRIERA di BUTTIGLIERA ALTA (TO) – ITALY

Tel.+39 0119348778 - FAX +39 0119348779

SD104 HIGH PERFORMANCE DIGITAL DISTRIBUTOR AMPLIFIER

ELPRO Video Labs s.r.l.

Via della Praia 4/a FERRIERA di BUTTIGLIERA ALTA (TO) – ITALY

Tel.+ 9 0119 48778 - FAX + 9 0119 48779 8

SD104 HIGH PERFORMANCE DIGITAL DISTRIBUTOR AMPLIFIER

If the input is already connected to an SDI signal either the SDI led must be

switched on.

SDI outputs are a ailable on the BNC connectors OUT 1÷6
