Wall mounted Patio heater – Infra-red Radiator!
2
1.- IMPORTANT INFORMATION
•Read these instructions carefully before installing or using this heater for the first time. The guarantee will not cover
damage caused by not following these instructions.
•The instructions should be retained for future reference. This guide must be kept and given to any new owner.
•The use of this heater is forbidden in areas where gases, explosive or inflammable substances are present.
•DO NOT USE THIS HEATER TO DRY CLOTHES.
•Ensure the power supply to the socket into which the heater is plugged is in accordance with the rating label on the
heater and that the socket is earthed.
•Keep the power cable away from the hot body of the heater.
•Do not let the cable hang over the edge of a table or counter or let it come into contact with any hot surfaces.
•Do not use the heater while sleeping. Never leave the heater unattended while it is operated.
•The improper handling can cause injuries.
•Always unplug the heater when moving it from one location to another.
•Do not use extension cable. This could overheat and cause fires.
•Never touch the heater with wet or humid hands or barefoot.
•Do not leave any object above the heater, covering the grill, or restricting the air flow.
•The heater must be disconnected during installation and cleaning.
•The heater should not be located in front of, or under an electrical socket.
•The heater should be positioned so the controls cannot be used when using the shower or bath.
•The location of the heater should not be close to curtains or other inflammable articles, and the heater must not be
located immediately below dripping clothes.
•It is important to maintain a minimum distance of 80 cm between the heater and curtains, or any other combustible
materials that will be affected by the radiated heat.
•Installation should be carried out by a qualified electrical installer.
•The heater must be positioned at least 1.8 m from the floor, and a minimum distance of 30 cm from the ceiling.
•Do not touch the fireguard or reflecting cover when the heater is in use; do not insert any objects into the fireguard to
prevent high temperature scalding.
•Never rotate the heating part of the appliance during operation. To change the tit angle of the heating part, we advise
you to wait for 15 minutes after the appliance has been switched off.
•Although the heating element has stopped glowing, it may still be live and potentially dangerous. Check that the
selection indicator (5) is in position off before taking any action.
•Avoid using the heater where there are children or disabled persons without being adequately supervised by a
responsible person.
•Never dismantle the components of the heater or replace the components with the ones that do not meet the safety
requirements. If the supply cord is damaged, it must be replaced by the manufacturer or its service agents or a
similarly qualified person in order to avoid a hazard.
•The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
•Children should be supervised to ensure that they do not play with the appliance
•The heater should be switched off and be disconnected from electric supply to avoid accidents when it is not being
watched or not in use for a long time.
•This appliance must be earthed.
•Ensure the voltage is suitable for the heater. Refer to technical label.
•The presence in the atmosphere of tobacco smoke or atmospheric pollution can with time discolour the heater
surface.
•The infrared heater is designed to only work in a horizontal position.
•Do not fix to the ceiling.
•This movable appliance is designed for use indoor and outdoor. Although the heater may be used outdoors, the main
plug must only be connected to the supply indoors.
2.- INSTALLATION
Open the box to take out the heater and all the accessories.
Make the four holes on the wall in accordance with the four holes at the back of the
heater.
Insert wall plugs and tighten the screws.
The heater must be positioned at least 1.8 m from the floor, and a minimum distance
of 30 cm from the ceiling.
Between the plan and the head of the screw you must leave enough space in a way
to hook the heater.
Attach the heater to the four screws and slide down.
According to the request of use angle, Heating Element Assembly can adjust Angle
at 0º~45º.
