Elnur powered by Gabarrón | ADL | Installation Guide 2
• Please read these instructions before installing or
using this appliance for the first time. The warranty
of the storage heater will not cover any damage
caused by non-observance of any of these
instructions.
• This Guide must be kept and given to any new owner
for future references.
• Nothing may be placed within 30cms of the front of
the heater at any time. This is to avoid items coming
into contact with the grille and the head air which
leaves, it. Blocking some or all of this area could
represent a fire hazard. Never use this heater to
dry clothes.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning the use of the appliance in
a safe way and understand the hazards involved.
Children must not play with the appliance. Cleaning
and user maintenance must not be undertaken by
children without supervision.
• Children aged from 3 years and less than 8 years
shall only switch on/off the appliance provided that
it has been placed or installed in its intended normal
operating position and they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children aged from 3 years and less than
8 years shall not plug in, regulate and clean the
appliance or perform user maintenance.
• Children of less than 3 years should be kept away
unless continuously supervised. Please check that
the voltage in the rating label fits the power supply.
• Should the heater be moved and reinstalled it is
essential that the work is carried out by a fully
qualified engineer. Before carrying out any work
inside the appliance, the heater must be
disconnected from the electricity supply.
• If during any installation the thermal insulation shows
any sign of damage, it is necessary for the faulty
part to be removed and replaced by an identical part.
• The use of storage heaters is forbidden in any area
where there is a presence of gases, explosives
or inflammable objects.
• The air inlet and outlet grills are provided to ensure
the most efficient operation of the appliance.
They also protect the heater from overheating; therefore,
it is essential that at no time are they covered.
• Surfaces of this appliance could be hot. Children
should be supervised to ensure they do not play
with the heater.
• This heater should be switched off at the isolating
switch before any repair work is carried out.
This action should also be taken during the times
of the year when heat is not required.
• The installation of the heaters must be carried out
in such a way that each pole can be disconnected
from the supply having a contact separation of
at least 3 mm.
• The storage heater should not be installed just below
an electrical socket.
• Ensure that both wall supply switches next to the
heater are turned on. During the summer when no
heat is required, both wall switches can be turned off.
Remember to turn both back when the heat is
required again.
• The appliance must be installed in such a way that
it is impossible for anyone using a bath or shower,
to touch the controls. Never touch the heater with
wet hands.
• The nominal charging time of this storage heater is
indicated on its rating plate and must be controlled
by means of a programmer. Never open a charged
heater.
• The installation must be carried out in accordance
with the current electrical regulations. Check the
voltage on the rating label is the same as the supply.
• This appliance must be earthed.
• After installation a survey of the first charging cycle
should be carried out to ensure that the main input
thermostat switches off. Ventilate the room during
this first cycle.
• The fan may run at any time. This will happen
automatically to maintain the temperature that you
have programmed into the control system.
• To maintain stability, it is essential that the heater is
placed on a level surface and care should be taken
to avoid irregular surfaces, such as carpets or tiled
surrounds partially protruding under the heater.
• The presence in the air of particles of smoke, dust
and other pollutants could, in time, discolour the
walls and surfaces around the heater.
1. WARNING
CAUTION: Some parts of this product can become very hot and cause burns. Particular
attention must be given when children and vulnerable people are present.
!
WARNING: In order to avoid overheating do not cover the heater.
