Elmo QNW4000 Manuel utilisateur

QNW4000

INSTRUCTION MANUAL

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and maintenance

(servicing) instructions in the literature

accompanying the appliance.

CAUTION

CAUTI N : T REDUCE THE RISK F ELECTRIC SH CK.

D N T REM VE C VER ( R BACK).

N USER SERVICEABLE PARTS INSIDE.

REFER SERVICING T QUALIFIED SERVICE PERS NNEL.

RISK F ELECTRIC SH CK

D N T PEN

The lightning flash with arrowhead symbol, within

an equilateral triangle, is intended to alert the user

to the presence of uninsulated "dangerous

voltage" within the product's enclosure that may

be of sufficient magnitude to constitute a risk of

electric shock to persons.

CAUTI N

.Do not use any power supply other than

specified.

WARNING

T REDUCE THE RISK F FIRE R

ELECTRIC SH CK, D N T EXP SE

THIS APPLIANCE T RAIN R M ISTURE.

* The CAUTI N label is attached on the

bottom of camera.

INF RMATI N

This equipment has been tested and found

to comply with the limits for Class A digital

device, pursuant to Part 15 of the FCC

Rules. These limits are designed to

provide reasonable protection against

harmful interference when the equipment

is operated in a commercial environment.

This equipment generates, use, and can

radiate radio frequency energy and, if not

installed and used in accordance with the

instruction manual, may cause harmful

interference to radio communications.

peration of this equipment in a

residential area is likely to cause harmful

interference in which case the user will be

required to correct the interference at his

own expense.

USER-INSTALLER CAUTI N: Your

authority to operate this FCC verified

equipment could be voided if you make

changes or modifications not expressly

approved by the party responsible for

compliance to Part of the FCC Rules.

- 1 -

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

. Do not block any ventilation openings, install in accordance with the manufacture's

instructions.

8. Do not install near heat sources such a radiators, heat registers, stoves or other

apparatus (including amplifiers) that produce heat.

9. Only use attachment/accessories specified by the manufacturer.

10.Unplug this apparatus during lighting storms or when unused for long periods of

time.

11.Refer all servicing to qualified personnel. Servicing is required when the apparatus

has been damaged in any way, such as power-supply cord or plug is damaged,

liquid has been spilled or objects have been fallen onto the apparatus, the apparatus

has been exposed to rain or moisture, does not operate normally, or has been

dropped.

IMPORTANT SAFETY INSTRUCTIONS

- 2 -

Caution:

- Do not install this camera at sea, at coast or in coastal area or at any corrosive

gas generating place.

- Since it is not of totally weatherproof specifications, do not install this camera at

any weather-beaten place.

When it is used ounted with the shade for outdoor use (SS-20), the weatherproof

specifications eet the require ents of IP54 (Confor able to IEC/EN 60529).

This ca era ay be installed outdoors but with restrictions; do not install this

ca era at any place open to gusty wind and rain as seen in typhoon (e.g., high steel

tower), to snow (e.g., cold district), to water spray (e.g., coast or coastal area), or to

water (e.g., under the water).

For further infor ation of installation place, consult our dealer.

Indoor utdoor but under

roof or eaves utdoor not under

roof or eaves Height or blowing

place like steel tower

(Shading cover required)

Housing Protection

- 3 -

PART NAMES AND FUNCTIONS

Front glass

Tripod fixing tapped holes (1/4-20UNC)

These tapped holes are used to fix the camera on the tripod and mount the shade (optional) on

the camera.

The tapped holes for fixing the tripod are provided at 2 locations in the top and bottom surface

of the camera. Each tapped hole is 5mm deep.

Weatherproof cap

84 (3.3) 45 (1.8)

14 (0.6)

230 (9.1)

84 (3.3 )

75 (3.0)

84 (3.3) 45 (1.8)

14 (0.6)

All dimensions in mm (inch)

- 4 -

INT/LL switch

INT (internal) control switch

When the internal synchronization is used, set the switch to the INT side.

LL (Line-Lock) control switch

Matching the vertical synchronization with the power frequency is called the line-lock.

When two or more cameras are switched by the video switcher to a monitor TV, the vertical

sync. phase can be locked with the power frequency, and a stable vertical sync. is obtained

without being disturbed at the time of switching.

Line-lock is operative only when the AC 24V power supply is connected.

Caution:

1.The camera is synchronized to the power frequency of 60Hz 0.5Hz covering a

normal fluctuation of the power frequency. The camera may not compensate for

large fluctuation caused by power generated by an engine generator. etc.

2.It takes about 10 seconds or more to obtain a stable synchronization after the

power is turned on. This is necessary to stabilize the camera against the power

noise.

BLC (Back Light Control) switch

In case the back lighting is too bright to shoot the main object clearly, set this switch to ON

position.

- 5 -

SENS-UP switch

To increase the sensitivity, set this switch to ON position.

DAY/NIGHT switch

When the DAY/NIGHT function is used, this switch is turned ON. (See P. 9.)

Camera output terminal

This is an image output terminal. When the camera direction, the field angle or the focal point is

adjusted, a monitor TV or other type display is connected to this terminal.

When a monitor TV is connected to this terminal, remove the 2P connector beforehand.

Level adjusting volume

This volume is used to adjust the brightness of the image. If the lens iris is not appropriate,

adjust the iris with this level adjusting volume.

Vertical sync. phase adjustment potentiometer

Vertical sync. phase adjusting potentiometer is set at the position fully that the delay time of

vertical sync. phase against the phase of power frequency is shortest, when shipped from the

factory.

Select this up ( ) and down ( ) button will make the delay time of vertical sync. phase

against the phase of power frequency longer.

Use the function control potentiometer if the picture image on a monitor TV may flow

when using the camera in combination with other camera(s) controlled by the Line-Lock

synchronization.

In this case, get a proper image by shifting the phase of vertical sync. signal of the camera

against that of the other. If a proper image cannot be obtained even after this adjustment, reset

the potentiometer to its original position, and use the function control potentiometer of the

other camera to shift the phase of vertical sync. signal of other camera.

Caution:

Before making adjustment, make sure that cameras have their power supplies

connected with the same polarity. (not 180 apart)

- 6 -

Coaxial core clamp

This clamp fixes the cores of the coaxial cable.

Coaxial cable clamp

This clamp fixes the sheath of the coaxial cable.

Ground terminal

This is a supplementary ground terminal.

AC power terminal

Connect this to the AC24V 60Hz power supply.

Earth terminal

Connect this to the ground wire of the power supply cord.

- 7 -

1. Remove the rear cover, the GND cable, and the two 2P connectors.

2. Connect the coaxial cable and the power cable.

After connecting the power cable on the terminal block, be sure to mount the protective cover.

Caution:

Fasten the weatherproof cap firmly, and make sure that the cable is fixed

completely. If the cap is not fastened firmly, water leak may be caused.

(The appropriate tightening torque: 4.0~4.5N.m)

When connecting the coaxial cable, be sure to remove the 2P connectors.

3. Connect the two 2P connectors and the GND cable.

After connecting the connectors and the cable, mount the rear cover.

Caution:

The rear cover has a weatherproof seal. Before mounting the rear cover, make

sure that the seal is set in the groove in the rear cover. If the setting of the seal is

not sufficient, water leak may be caused.

When mounting the rear cover, be careful not to pinch the two 2P connectors or

the GND cable.

Be sure to connect the ground wire of the power cable to the earth terminal .

Do not use the power cable of flat type, which does not fit

the weatherproof cap.

For the power cable, use one attached with a force-fit

terminal.

If the force-fit portion of the force-fit terminal is protruded

from the terminal block, insulate the force-fit portion.

Coaxial cable clamp

Weatherproof cap

Coaxial cable

Rear cover

Seal

GND cable

Terminal block

(with protective cover)

2P connector 2P connector

Applicable cable diameter:

5.0~10.0mm

Power cable

Coaxial core clamp

HOW TO CONNECT

5.7

force-fit terminal

force-fit portion

Power cable (GND)

- 8 -

1. Built-in Lens

This camera is built in with a dedicated varifocal lens.

F: 1.4 f: 2.8mm~5.8mm

2. Lens adjustment

Adjust the field angle of the lens with the zoom ring, and set the focus with the focus ring.

After setting, lock the lens firmly with the focus ring locking knob and the zoom ring locking

knob. (Factory setting: WIDE end / Infinite)

Adjust the iris volume, if necessary, to obtain the appropriate exposure. (See P.5 .)

Caution:

When adjusting the iris of the auto iris lens, open the iris fully in the circumstance

with sufficient light amount of the object beforehand. If the light amount of the

object is not sufficient, a malfunction may occur.

Zoom ring

Focus ring

Camera main unit

Front cover

Zoom ring locking knob

Focus ring locking knob

LENS

- 9 -

This camera is provided with Day/Night function that can detect the brightness of the objects and

automatically switch the color mode / black-and-white mode according to the detected brightness.

This function allows the output of ordinary colored images for the outdoor monitoring during

daylight and the output of black-and-white images for the night monitoring with a lack of sufficient

light volume. Therefore, even at night, this camera can provide monitoring through images with

little noise.

Furthermore, since this function raises the sensitivity in the infrared area, even a dark object can be

imaged more clearly at night when a commercially available infrared lamp is used together. To

make this function enabled, set the Day/Night switch on the rear panel to "ON."

When the Day/Night switch is set to "OFF," the camera operates as an ordinary color camera even

at night.

When the Day/Night switch is set to "ON" and the object becomes gradually brighter as the time

passes like dawn, it may take time to switch from the black-and-white mode to the color mode. As a

result, the image taken in the early morning may be in black and white. However, note that this is

not a malfunction.

The Day/Night function controls the mode switching between the color mode and the black-and-

white mode according to the signal level.

Since the signal level varies depending on the camera settings to shoot the object, the timing of

Day/Night switching varies accordingly.

When more than one screen is displayed by the controller or the like, the Day/Night mode may vary

depending on the camera shooting conditions even if the brightness is the same.

Day/Night FUNCTION

Autres manuels pour QNW4000

Autres manuels Elmo Caméra de sécurité

Elmo

Elmo PTC-201CIP Manuel utilisateur

Elmo

Elmo TD4114 IP II Manuel utilisateur

Elmo

Elmo TSN420D Manuel utilisateur

Elmo

Elmo PTC-400C Manuel utilisateur

Elmo

Elmo TD4114IP II Manuel utilisateur

Elmo

Elmo SE420 Manuel utilisateur

Elmo

Elmo CCD Color Video Camera TNC4604 Manuel utilisateur

Elmo

Elmo ESD-300DR Manuel utilisateur

Elmo

Elmo Dome Camera TND4004 Manuel utilisateur

Elmo

Elmo QSN301D Manuel du propriétaire

Elmo

Elmo PTC-200C Manuel utilisateur

Elmo

Elmo Vandal Resistant Dome Camera TND4204VX Manuel utilisateur

Elmo

Elmo CCD Color Video Camera TSN410H Manuel utilisateur

Elmo

Elmo PTC-200C Manuel utilisateur

Elmo

Elmo TSE400 Manuel utilisateur

Elmo

Elmo X Line TND4003X Manuel utilisateur

Elmo

Elmo BUTP200 Manuel utilisateur

Elmo

Elmo PTC-201CIP Manuel utilisateur

Elmo

Elmo TSN280D Manuel utilisateur

Elmo

Elmo Vandal Resistant Dome Camera TND4204VX Manuel utilisateur

Elmo

Elmo ESD-370 Manuel utilisateur

Elmo

Elmo HC7501 Manuel utilisateur

Elmo

Elmo TSE270X Manuel utilisateur

Elmo

Elmo PTC-100S Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
