Eliminator Lighting LED CLOUD Manuel utilisateur
LED CloudLED Cloud
User Manual
SKU#: LED CLOUD
UPC#: 817175010198
©2021 Eliminator Lighting all rights reserved. Information, specications, diagrams, images, and
instructions herein are subject to change without notice. Eliminator logo and identifying product
names and numbers herein are trademarks of Eliminator Lighting. Copyright protection claimed in-
cludes all forms and matters of copyrightable materials and information now allowed by statutory or
judicial law or hereinafter granted. Product names used in this document may be trademarks or reg-
istered trademarks of their respective companies and are hereby acknowledged. All non-Eliminator
brands and product names are trademarks or registered trademarks of their respective companies.
Eliminator Lighting and all aliated companies hereby disclaim any and all liabilities for property,
equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic
loss associated with the use or reliance of any information contained within this document, and/
or as a result of the improper, unsafe, insucient and negligent assembly, installation, rigging, and
operation of this product.
Eliminator Lighting USA
6122 S. Eastern Ave. | Los Angeles, CA 90040 USA
2
3
GENERAL INFORMATION
INTRODUCTION
Please read and understand all instructions in this manual carefully and thoroughly before attempting
to operate this product. These instructions contain important safety and use information.
UNPACKING: This product has been thoroughly tested and has been shipped in perfect condition.
Carefully check the shipping carton for damage that may have occurred during shipping. If the car-
ton appears to have been damaged, carefully inspect your product for damage and be sure all ac-
cessories necessary to assemble the product have arrived intact. In the event that damage has been
found or parts are missing, please contact our customer support team for further instructions. Please
do not return this product to your dealer without rst contacting customer support at the number
listed below. Please do not discard the shipping carton in the trash. Please recycle whenever pos-
sible.
CUSTOMER SUPPORT
Tel: (323) 213-4592 | Fax: (323) 582-2941
WARRANTY RETURNS
All returned service items, whether under warranty or not, must be freight pre-paid and accompa-
nied by a return authorization (R.A.) number. The R.A. number must be clearly written on the outside
of the return package. A brief description of the problem as well as the R.A. number must also be
written down on a piece of paper and included in the shipping container. If the unit is under warranty,
you must provide a copy of your proof of purchase invoice. Items returned without an R.A. number
clearly marked on the outside of the package will be refused and returned at customer’s expense.
You may obtain an R.A. number by contacting customer support.
Eliminator Lighting warranty is valid from the date of purchase. Our 1 year limited warranty cov-
ers manufacturing defects only. Serial number and place of purchase with dated valid receipt must
be submitted at time of service. Eliminator Lighting warranty does not cover items or parts prone
to wear and tear: lamps, LEDs, fuses, brushes, and belts. Eliminator Lighting warranty is only valid
within the United States of America.
Warning! To prevent or reduce the risk of electrical shock or re, do not expose this unit to rain or
moisture.
Caution! There are no user serviceable parts inside this unit. Do not attempt to perform any repairs
yourself, as doing so will void your manufacturer’s warranty. In the unlikely event that your unit may
require service, please contact Eliminator Lighting. Eliminator Lighting will not accept any liability for
any resulting damages caused by the non-observance of information in this manual or any unauthor-
ized modications to this unit.
During operation, the housing may become extremely hot. Avoid touching the unit with bare hands
while in use.
4
LIMITED WARRANTY (USA ONLY)
A. Eliminator Lighting, an ADJ Products, LLC brand, hereby warrants, to the original purchaser, ADJ Products, LLC
products to be free of manufacturing defects in material and workmanship for a prescribed period from the date of
purchase (see specic warranty period listed below). This warranty shall be valid only if the product is purchased
within the United States of America, including possessions and territories. It is the owner’s responsibility to estab-
lish the date and place of purchase by acceptable evidence, at the time service is sought.
B. For warranty service you must obtain a Return Authorization number (RA#) before sending back the product,
please contact ADJ Products, LLC Service Department at 800-322-6337. Send the product only to the ADJ Prod-
ucts, LLC factory. All shipping charges must be pre-paid. If the requested repairs or service (including parts re-
placement) are within the terms of this warranty, ADJ Products, LLC will pay return shipping charges only to a des-
ignated point within the United States. If the entire instrument is sent, it must be shipped in its original package. No
accessories should be shipped with the product. If any accessories are shipped with the product, ADJ Products,
LLC shall have no liability whatsoever for loss of or damage to any such accessories, or for the safe return thereof.
C. This warranty is void if the serial number has been altered or removed; if the product is modied in any manner
which ADJ Products, LLC concludes, after inspection, aects the reliability of the product; if the product has been
repaired or serviced by anyone other than the ADJ Products, LLC factory unless prior written authorization was
issued to purchaser by ADJ Products, LLC; if the product is damaged because not properly maintained as set forth
in the instruction manual.
D. This is not a service contract, and this warranty does not include maintenance, cleaning or periodic check-up.
During the period specied above, ADJ Products, LLC will replace defective parts at its expense with new or refur-
bished parts, and will absorb all expenses for warranty service and repair labor by reason of defects in material or
workmanship. The sole responsibility of ADJ Products, LLC under this warranty shall be limited to the repair of the
product, or replacement thereof, including parts, at the sole discretion of ADJ Products, LLC. All products covered
by this warranty were manufactured after August 15, 2012, and bear identifying marks to that eect.
E. ADJ Products, LLC reserves the right to make changes in design and/or improvements upon its products with-
out any obligation to include these changes in any products theretofore manufactured. No warranty, whether
expressed or implied, is given or made with respect to any accessory supplied with products described above.
Except to the extent prohibited by applicable law, all implied warranties made by ADJ Products, LLC in connection
with this product, including warranties of merchantability or tness, are limited in duration to the warranty period
set forth above. And no warranties, whether expressed or implied, including warranties of merchantability or t-
ness, shall apply to this product after said period has expired. The consumer’s and/or Dealer’s sole remedy shall be
such repair or replacement as is expressly provided above; and under no circumstances shall ADJ Products, LLC
be liable for any loss or damage, direct or consequential, arising out of the use of, or inability to use, this product.
This warranty is the only written warranty applicable to Eliminator Lighting, an ADJ Products, LLC brand, and su-
persedes all prior warranties and written descriptions of warranty terms and conditions heretofore published.
MANUFACTURER’S LIMITED WARRANTY PERIODS:
All Eliminator Lighting products (except laser diodes) = 1-year (365 days) Limited Warranty (Such as: Special
Eect Lighting, Intelligent Lighting, UV lighting, Strobes, Fog Machines, Bubble Machines, Mirror Balls, Par Cans,
Trussing, Lighting Stands etc., excluding lamps)
Laser Products = 1 Year (365 Days) Limited Warranty (excluding laser diodes which have a 6 month limited war-
ranty)
Batteries = 180 Day Limited Warranty
To register your Eliminator Lighting product online, please click here to the ADJ Warranty Registration Page:
https://www.adj.com/portal/user/register/
5
SAFETY GUIDELINES
THERE ARE NO USER SERVICEABLE PARTS INSIDE THESE DEVICES. DO NOT
ATTEMPT ANY REPAIRS YOURSELF; DOING SO WILL VOID YOUR MANUFAC-
TURER’S WARRANTY. DAMAGES RESULTING FROM MODIFICATIONS TO THESE
DEVICES AND/OR THE DISREGARD OF SAFETY INSTRUCTIONS AND GUIDE-
LINES IN THIS MANUAL VOID THE MANUFACTURER’S WARRANTY AND ARE
NOT SUBJECT TO ANY WARRANTY CLAIMS AND/OR REPAIRS.
NEVER TOUCH FIXTURE DURING OPERATION, AS IT MAY BE HOT!
ALWAYS REPLACE FUSES WITH REPLACEMENTS OF THE SAME TYPE!
KEEP FLAMMABLE MATERIALS AWAY FROM THESE DEVICES!
INDOOR / DRY LOCATIONS USE ONLY!
DO NOT EXPOSE DEVICES TO RAIN AND/OR MOISTURE!
NEVER LOOK DIRECTLY INTO THE LIGHT SOURCE!
RETINA INJURY RISK - MAY INDUCE BLINDNESS!
SENSITIVE PERSONS MAY SUFFER AN EPILEPTIC SHOCK!
6
MAINTENANCE GUIDELINES
DISCONNECT POWER BEFORE PERFORMING ANY CLEANING OR
MAINTENANCE!
CLEANING
Frequent cleaning is recommended to ensure proper function, optimized light output, and an extend-
ed life. The frequency of cleaning depends on the environment in which the device operates: damp,
smoky, or particularly dirty environments can cause greater accumulation of dirt on the xture hous-
ing and/or light xture optics. Clean the external surface and the front lens of the device periodically
with a soft cloth to avoid dirt/debris accumulation
NEVER use alcohol, solvents, or ammonia-based cleaners.
MAINTENANCE
Regular inspections are recommended to ensure proper function and extended life. There are no
user serviceable parts inside these devices; please refer all other service issues to Eliminator Light-
ing. Should you need any spare parts, please order genuine parts from Eliminator Lighting.
FUSE REPLACEMENT
Locate and remove the unit’s power cord. Once the cord has been removed located the fuse holder
located inside the power socket. Insert a at-head screw driver into the power socket and gently pry
out the fuse holder. Remove the bad fuse and replace with a new one. The fuse holder has a built-in
socket for a spare fuse; be sure not to confuse the spare fuse with active fuse.
7
INSTALLATION INSTRUCTIONS
FLAMMABLE MATERIAL WARNING
Keep devices at least 5.0 feet (1.5m) away from ammable materials and/or pyrotech-
nics.
ELECTRICAL CONNECTIONS
A qualied electrician should be used for all electrical connections and/or installations.
DO NOT INSTALL THE DEVICE IF YOU ARE NOT QUALIFIED TO DO SO!
OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, INCLUDING CALCULATING
WORKING LOAD LIMITS, KNOWLEDGE OF INSTALLATION MATERIAL BEING USED, AND
PERIODIC SAFETY INSPECTION OF ALL INSTALLATION MATERIALS. IF YOU LACK THESE
QUALIFICATIONS, DO NOT ATTEMPT THE INSTALLATION YOURSELF. IMPROPER INSTALLA-
TION CAN RESULT IN BODILY INJURY.
BEFORE RIGGING/MOUNTING DEVICES TO ANY METAL TRUSS/STRUCTURE OR CEILING, A
PROFESSIONAL EQUIPMENT INSTALLER MUST BE CONSULTED TO DETERMINE WHETHER
THE METAL TRUSS/STRUCTURE OR CEILING IS PROPERLY CERTIFIED TO SAFELY HOLD
THE COMBINED WEIGHT OF THE LIGHT FIXTURE, CLAMPS, CABLES, AND ACCESSORIES.
BEFORE MOUNTING DEVICES TO ANY SURFACE OR STRUCTURE, MAKE SURE THE SUR-
FACE OR STRUCTURE CAN HOLD A MINIMUM POINT LOAD OF 10 TIMES THE WEIGHT OF
THE DEVICES.
MAKE SURE SCREWS AND/OR ANCHOR BOLTS (NOT INCLUDED) FIT INTO MOUNTING
HOLES!
FOR ADDED PROTECTION, MOUNT DEVICES OUTSIDE WALKING PATHS, SEATING AREAS,
OR AREAS WHERE UNAUTHORIZED PERSONNEL CAN REACH THE DEVICES.
SECURE FIXTURE WITH A SECONDARY SAFETY ATTACHMENT, SUCH AS AN APPROPRIATE-
LY RATED SAFETY CABLE. (NOT INCLUDED)
NEVER STAND DIRECTLY BELOW THE DEVICES WHEN MOUNTING, REMOVING OR SERVIC-
ING.
DEVICES MUST ALL BE INSTALLED FOLLOWING ALL LOCAL, NATIONAL, AND COUNTRY
COMMERICAL ELECTRICAL AND CONSTRUCTION CODES AND REGULATIONS.
8
OPERATING INSTRUCTIONS:
This unit is a 4 channel DMX intelligent LED unit. It can be run as a stand-alone or in a primary-sec-
ondary conguration. The unit has 3 operating modes: sound active mode, auto mode, and DMX
controlled. This unit has been inspected at the factory for problems and defects. No assembly is
required, and the unit is ready to be plugged in to a power outlet. A fog machine can be used in con-
junction with this device to enhance the display. The instructions below explain the operation of each
mode in detail.
Auto Run Mode:
1. Plug the xture in and press the MODE button until “AU.XX” is displayed. “XX” represents the cur-
rently selected running speed.
2. Press ENTER, then use the UP and DOWN buttons to adjust the running speed. The running
speed can be adjusted from “AU.00” (slowest speed) to “AU.99” (fastest speed).
Sound Active Mode: In this mode the LED Cloud will react to sound.
1. Plug the xture in and press the MODE button until “SU.XX” is displayed. “XX” represents the cur-
rently selected sound senstivity level.
2. Press ENTER, then use the UP and DOWN buttons to adjust the sound sensitivity. The sensitivity
can be adjusted from “SU.01” (least sensitive) to “SU.99” (most sensitive).
DMX Mode: Operating through a DMX controller gives the user the freedom to create their own pro-
grams tailored to their own individual needs. The LED Cloud has 4 DMX channels. See the chart in
the DMX Traits section of this manual for the DMX traits and values.
1. This function will allow you to control each individual xture’s traits with a standard DMX 512 con-
troller.
2. To run your xture in DMX mode, press the MODE button until “AXXX” is displayed. “XXX” repre-
sents the currently selected DMX address. Press ENTER and use the UP or DOWN buttons to nd
your desired DMX address.
3. After you have chosen your desired DMX address, plug in the xture via the XLR connections to
any standard DMX controller.
Primary-Secondary Conguration:
1. Daisy chain your units together via the XLR connectors on the rear of the units. Use standard XLR
data cables to link your units together. Remember that the Male XLR connector is the input and
the Female XLR connector is the output. The rst unit in the chain (primary) will use the female
XLR connector only, and the last unit in the chain will use the male XLR connector only.
2. Connect the rst “Secondary” unit to the “Primary.”
3. Set the “Primary” unit to your desired mode of operation. On the “Secondary” unit, set the DMX
address to “001”. The “Secondary” unit will now follow the “Primary”.
SYSTEM MENU
9
DMX TRAITS
Eliminator LED Cloud - DMX Traits
CHANNEL DMX VALUE DESCRIPTION
1
Color Macros
000 - 007 Blackout
008 - 015 Red
016 - 023 Green
024 - 031 Blue
032 - 039 White
040 - 047 Amber
048 - 055 Red + Green
056 - 063 Green + Blue
064 - 071 Blue + White
072 - 079 White + Amber
080 - 087 Red + Amber
088 - 095 Green + Amber
096 - 103 Blue + Amber
104 - 111 Red + Blue
112 - 119 Red + White
120 - 127 Green + White
128 - 135 Red + Green + Blue
136 - 143 Green + Blue + White
144 - 151 Blue + White + Amber
152 - 159 Red + White + Amber
160 - 167 Green + White + Amber
168 - 175 Red + Green + Amber
176 - 183 Red + Green + White
184 - 191 Red + Blue + Amber
192 - 199 Red + Blue + White
200 - 207 Green + Amber + Blue
208 - 215 Red + Green + Blue + White
216 - 223 Green + Blue + White + Amber
224 - 231 Red + Green + Blue + Amber
CONTINUED ON NEXT PAGE
10
DMX TRAITS
Eliminator LED Cloud - DMX Traits
CHANNEL DMX VALUE DESCRIPTION
1
Color Macros (continued)
232 - 239 Red + Green + White + Amber
240 - 247 Red + Green + Blue + White + Amber
248 - 255 Sound Active
2
Rotation
000 - 009 Stop Rotation
010 - 120 Clockwise Rotation, fast to slow
121 - 134 Stop Rotation
135 - 245 Counter-Clockwise Rotation, fast to slow
246 - 255 Stop Rotation
3
Strobe
000 Strobe O
001 - 255 Strobe Speed, slow to fast
4000 - 255 Dimmer, 0% to 100%
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Eliminator Lighting Matériel de DJ
Eliminator Lighting
Eliminator Lighting Moon Beam Manuel utilisateur
Eliminator Lighting
Eliminator Lighting EZ8 System Manuel utilisateur
Eliminator Lighting
Eliminator Lighting FROST FX BAR RGBW Manuel utilisateur
Eliminator Lighting
Eliminator Lighting Mini Par UV LED Manuel utilisateur
Eliminator Lighting
Eliminator Lighting E 138 Manuel utilisateur
Eliminator Lighting
Eliminator Lighting LED Moon Beam Manuel utilisateur
Eliminator Lighting
Eliminator Lighting COSMIC BURST Manuel utilisateur
Eliminator Lighting
Eliminator Lighting Electro 64 BLED Manuel utilisateur
Eliminator Lighting
Eliminator Lighting Katana LED Manuel utilisateur
Eliminator Lighting
Eliminator Lighting UV Disc Manuel utilisateur
Eliminator Lighting
Eliminator Lighting Follow Spot 100 LED Manuel utilisateur
Eliminator Lighting
Eliminator Lighting Stealth Wash Zoom Manuel utilisateur
Eliminator Lighting
Eliminator Lighting E 143 ASTEROID Manuel utilisateur
Eliminator Lighting
Eliminator Lighting EM12 Manuel utilisateur
Eliminator Lighting
Eliminator Lighting MEGA PAR PROFILE EP Manuel utilisateur
Eliminator Lighting
Eliminator Lighting EM30 Manuel utilisateur
Eliminator Lighting
Eliminator Lighting Electro Swarm Manuel utilisateur
Eliminator Lighting
Eliminator Lighting Mini Par RGBW LED Manuel utilisateur
Eliminator Lighting
Eliminator Lighting Furious Five RG Manuel utilisateur
Eliminator Lighting
Eliminator Lighting TriDisc9 LED Manuel utilisateur
Manuels Matériel de DJ populaires d'autres marques
thomann
thomann Stairville DJ Lase 40-G MK-III Manuel utilisateur
Eagletone
Eagletone 6 Eyes Flower Manuel utilisateur
EuroLite
EuroLite FLD-1508 Manuel utilisateur
Technical Pro
Technical Pro LG8xSEA Manuel utilisateur
JB Systems
JB Systems Lounge Laser DMX Manuel utilisateur
Lightmaxx
Lightmaxx Vega Halo 90 Manuel utilisateur
Elation
Elation FUZE WASH Z350 Manuel utilisateur
Maverick
Maverick MK3 WASH Manuel utilisateur
Infinity
Infinity TF-260C7 Fresnel Manuel utilisateur
Chauvet
Chauvet EVE E-50Z Manuel utilisateur
EuroLite
EuroLite Mini Multicolor LED Flashing Light SC Manuel utilisateur
KAM
KAM DMX Laser80 FScan Manuel utilisateur
